Toyota Corolla (2022 year). Manual in english

396

5-15. What to do if... (Bluetooth

)

Phonebook data cannot be
edited.

■

When using the Bluetooth

message function

Messages cannot be viewed.

New message notifications are
not displayed.

Likely cause

Solution

The profile ver-
sion of the con-
nected cellular
phone may not
be compatible
with transferring
phonebook data.

For a list of spe-
cific devices
which operation
has been con-
firmed on this
system, check
with your Toyota
dealer or the fol-
lowing website:
https://
www.toyota.com/
audio-
multimedia in the
United States,
https://
www.toyota.ca/
connected in
Canada, and
http://
www.toyotapr.
com/audio-
multimedia in
Puerto Rico

Automatic con-
tact transfer
function on this
system is set to
off.

Set automatic
contact transfer
function on this
system to on.
(



P.387)

Passcode has
not been entered
on the cellular
phone.

Enter the pass-
code on the cel-
lular phone if
requested
(default pass-
code: 1234).

Transfer opera-
tion on the cellu-
lar phone has
not completed.

Complete trans-
fer operation on
the cellular
phone (approve
transfer opera-
tion on the
phone).

Likely cause

Solution

Automatic con-
tact transfer
function on this
system is set to
on.

Set automatic
contact transfer
function on this
system to off.
(



P.387)

Likely cause

Solution

Message trans-
fer is not enabled
on the cellular
phone.

Enable mes-
sage transfer on
the cellular
phone (approve
message trans-
fer on the
phone).

Automatic trans-
fer function on
this system is set
to off.

Set automatic
transfer function
on this system to
on. (



P.387)

Likely cause

Solution

Notification of
SMS/MMS/E-ma
il reception on
this system is set
to off.

Set notification of
SMS/MMS/E-ma
il reception on
this system to
on. (



P.385)

Automatic mes-
sage transfer
function is not
enabled on the
cellular phone.

Enable auto-
matic transfer
function on the
cellular phone.

397

5-15. What to do if... (Bluetooth

)

Audio

■

In other situations

The Bluetooth

connection sta-

tus is displayed at the top of the
screen each time the engine
switch is in ACC or ON.

Even though all conceivable
measures have been taken, the
symptom status does not
change.

For details, refer to the owner’s

manual that came with the cellular

phone.

Likely cause

Solution

Connection con-
firmation display
on this system is
set to on.

To turn off the
display, set con-
nection confir-
mation display
on this system to
off. (



P.304)

Likely cause

Solution

The cellular
phone is not
close enough to
this system.

Bring the cellu-
lar phone closer
to this system.

Radio interfer-
ence has
occurred.

Turn off Wi-Fi

devices or other
devices that may
emit radio
waves.

The cellular
phone is the
most likely cause
of the symptom.

Turn the cellular
phone off,
remove and rein-
stall the battery
pack, and then
restart the cellu-
lar phone.

Enable the cellu-
lar phone’s Blue-
tooth

connection.

Stop the cellular
phone’s security
software and
close all applica-
tions.

Before using an
application
installed on the
cellular phone,
carefully check
its source and
how its opera-
tion might affect
this system.

Likely cause

Solution

398

5-16. Connected Services Overview

5-16.Connected Services Overview



Audio Plus/Premium Audio

Owners of this system should
refer to the “NAVIGATION AND
MULTIMEDIA SYSTEM
OWNER’S MANUAL”.

●

Each function is available in the

following areas:

• Toyota apps is available in the

contiguous United States, Wash-

ington D.C., Alaska, Hawaii,

Puerto Rico and Canada.

• Toyota apps is not available in the

United States Virgin Islands.

• Wi-Fi

Hotspot is available in the

contiguous United States, Wash-

ington D.C.,Alaska and Hawaii.

• Wi-Fi

Hotspot is not available in

Puerto Rico, Canada, and in the

United States Virgin Islands.

• Safety Connect features include:

Automatic Collision Notification,

Emergency Assistance, S.O.S,

Stolen Vehicle Location (available

in the contiguous United States,

Washington D.C., Hawaii, Alaska,

Puerto Rico and Canada) and

Enhanced Roadside Assistance

(available in the contiguous

United States, Washington D.C.,

Alaska, Puerto Rico and Canada).

• Safety Connect is not available in

the United States Virgin Islands.

• Service Connect is available in the

contiguous United States, Wash-

ington D.C., Alaska, Hawaii, the

United States Virgin Islands,

Puerto Rico and Canada.

●

Connected services functionality

is dependent upon network recep-

tion level and signal strength.



The functions included are
classified into the following
four types.

• Type A: Function achieved by

using a smart phone or an
embedded cellular device in the
vehicle (DCM: Data Communica-
tion Module) and the system

• Type B: Function achieved by

using DCM and the system

• Type C: Function achieved by

using DCM

• Type D: Function achieved by

using DCM and a smartphone

Functional overview

Toyota Connected hotspot
includes Toyota apps,
Wi-Fi

Hotspot, Safety Con-

nect and Service Connect.

Functional overview

Function

Type

Toyota apps

Type A

Wi-Fi

Hotspot

Type B

Safety Connect

Type C

Service Connect

Type D

399

5-16. Connected Services Overview

Audio

: If equipped

Content provider

Type A: Function achieved by using a smart
phone or DCM

Of the functions included with Connected Services, the Toyota
apps relies on the use of a smart phone or DCM.



Using a smart phone

• Toyota audio multimedia system enables applicable apps

installed on a smart phone to be displayed on and operated from
the screen via a Bluetooth



Via DCM

• Toyota audio multimedia system enables applicable apps

installed on the system to be displayed on and operated from the
screen.

A few settings must be performed before Toyota apps can be
used. (



P.405)

By using a smart phone or DCM

400

5-16. Connected Services Overview

Provides contents to the application server.
Application server
Provides applications to the system or a smart phone.

Smart phone

Using the Toyota mobile application, communication is relayed
between the system, application server and contents provider.
The smart phone cannot be operated while communicating.
Applications
Display usable content from the content providers on the screen
using the data connection of the connected smart phone or DCM.
System
Content received, via a smart phone or DCM, from content pro-
vider servers is displayed on the screen. The system is equipped
with an application player to run applications.
Via DCM

: For known compatible phones, refer to

https://www.toyota.com/connected-services in the United States,
https://www.toyota.ca/connected in Canada, and
http://www.toyotapr.com/connected-services in Puerto Rico.

The required operations to acti-
vate applications and connect a
smart phone to the system, and
the registration steps for the
connected services are
explained in this section.

■

Subscription



Toyota apps does not require
an activation fee or monthly
recurring fees.



Services requiring a separate
contract can also be used.

: For details, refer to

https://www.toyota.com/
connected-services
or call 1-800-331-4331 in the

United States,
https://www.toyota.ca/connected
or call 1-888-869-6828 in Can-
ada, and
http://www.toyotapr.com/
connected-services
or call 1-877-855-8377 in Puerto
Rico.

■

Availability of function



Toyota apps is available in the
contiguous United States,
Washington D.C., Alaska,
Hawaii, Puerto Rico and Can-
ada.



Toyota apps is not available in
the United States Virgin
Islands.

●

Data usage fees may apply while

Before using the function

401

5-16. Connected Services Overview

Audio

using Toyota apps function. Con-

firm data usage fees before using

this function.

●

For details regarding operation of

the Toyota apps, refer to

https://www.toyota.com/

connected-services

in the United States,

https://www.toyota.ca/connected

in Canada, and

http://www.toyotapr.com/

connected-services

in Puerto Rico.

●

These functions are not made

available in some countries or

areas. Availability of functions of

the Toyota apps is dependent on

network reception level.

■

Initializing personal data

The personal data used in appli-
cations can be reset. (



P.320)

The following personal data can
be deleted and returned to their
default settings:



Downloaded contents



Radio stations that were lis-
tened to

Once initialized, the data and set-

tings will be erased. Pay much

attention when initializing the data.

■

Settings required to use
Toyota mobile application

Perform the settings in the fol-
lowing order.

Download the Toyota mobile
application to your smart
phone or the system.

Open the Toyota mobile
application on your smart
phone and follow instruc-
tions. Bluetooth

Pairing is

required.

In order to use Toyota mobile appli-

cation, the following must first be

performed:



phone

with the hands-free system.
(



P.294)

●

Applications can only be used

when the Toyota mobile applica-

tion has been downloaded to your

smart phone or the system, and

the application is running.

●

Toyota mobile application opera-

tional procedures can also be con-

firmed by visiting

https://www.toyota.com/

connected-services

in the United States,

https://www.toyota.ca/connected

in Canada, and

http://www.toyotapr.com/

connected-services

in Puerto Rico.

●

If a Toyota mobile application is

used while iPod audio/video is

being played back, system opera-

tion may become unstable.

Preparation before using
Toyota mobile application

402

5-16. Connected Services Overview

: If equipped

■

Subscription

After you have signed the
Telematics Subscription Service
Agreement and are enrolled,
you can begin receiving ser-
vices. A variety of subscription
terms are available. Contact
your Toyota dealer, or call
1-800-331-4331 in the United
States, 1-888-869-6828 in Can-
ada, and 1-877-855-8377 in
Puerto Rico, for further sub-
scription details. (



P.400)

■

Availability of functions



Wi-Fi

Hotspot is available in

the contiguous United States,
Washington D.C., Alaska and
Hawaii.



Wi-Fi

Hotspot is not avail-

able in Puerto Rico, Canada,
and in the United States Vir-
gin Islands.

Type B: Function

achieved by using

DCM and the system

The functionality of Wi-Fi

Hotspot is made possible
through the shared work of
the DCM and the system.

This service is available by
subscription and supported
by the Toyota response cen-
ter, which operates 24 hours
a day, 7 days a week.

For details about Wi-Fi

Hotspot:



P.306

Before using the function

403

5-16. Connected Services Overview

Audio

: If equipped

Service Connect uses DCM to
collect and transmit vehicle data
that allows Toyota to provide:



Vehicle Health Report (VHR)
(Safety Recalls, Service Cam-
paigns, Current Vehicle
Alerts, Required Mainte-
nance, and Vehicle Condition
Status)



Maintenance Notifications



Vehicle Alert Notifications

■

Availability of function



Service Connect is available
in the contiguous United
States, Washington D.C.,
Alaska, Hawaii, the United
States Virgin Islands, Puerto
Rico and Canada.

Type C: Function

achieved by using

DCM

The functionality of Safety
Connect is made possible
by the use of a DCM.

For details, (



P.73)

Type D: Function

achieved by using

DCM and a smart-

phone

The functionality of Service
Connect is made possible
by the use of a DCM and a
smartphone.

For details about these ser-
vices, refer to
https://www.toyota.com/
connected-services.

Service Connect

405

5-17. Connected Services Operation

Audio

5-17.Connected Services Operation



From the “MENU” button

Press the “MENU” button.

Select “Apps”.

Follow the steps in “From the
“APPS” button” from step

(



P.405)



From the “APPS” button

Press the “APPS” button.

Select “Apps”.

If a specific application screen is

displayed, select “Apps” again.

Select the desired application
screen button.

: Select to activate an applica-

tion.
“Update”: Select to update the

applications. (



P.405)

“App Catalog”: Select to change the

order of the applications. (



P.406)

: Displays the number of new

notifications for the application

When the Toyota apps is acti-
vated, an application may need
to be updated. To update an
application, it is necessary to
download update data and
install it.

■

Downloading update

If an update is available,
“Update” can be selected.

Toyota apps

Toyota apps is a function
that enables certain apps
installed on a smart phone
or the system to be dis-
played on and operated
from the system screen.
Before the Toyota apps can
be used, some setup needs
to be performed. (



P.401)

For details about the func-
tions and services provided
by each application, refer to
https://www.toyota.com/
connected-services
in the United States,
https://www.toyota.ca/
connected
in Canada, and
http://www.toyotapr.com/
connected-services
in Puerto Rico.

Using Toyota apps

Updating an application

406

5-17. Connected Services Operation

Select “Update” on the appli-
cation screen. (



P.405)

Check that downloading
starts.

“Download in Background”: Select

to operate other functions while

downloading.
“Cancel”: Select to cancel updating.

Check that downloading is
complete.

“Later”: Select to install later. When

this screen button is selected, the

screen will return to the last dis-

played screen. To install the update

data: (



P.406)

“See Detail”: Select to display

detailed information on the update

data.
“Install”: Select to install the update

data. Follow the steps “Installing

the update data” from step

(



P.406)

■

Installing the update data

After the downloading is com-
plete, “Update” will be changed
to “Install”.

Select “Install” on the appli-
cation screen. (



P.405)

Select “Continue”.

“Later”: Select to postpone the

installation of the update data and

go back to the previous screen.

Check that installing is
started.

“Install in Background”: Select to

operate other functions while

installing.

Select “OK” after the install-
ing is complete.

The Toyota apps cannot be oper-

ated while installing.

Order of the applications can be
changed.

Display the application
screen. (



P.405)

Select “App Catalog”.

Select the desired application
to be moved.

Select “<<” or “>>” to move
the application, and then
select the done button.

When problems occur with start-
ing the application player, a
message will appear on the
screen. Referring to the follow-
ing items, identify the problem
and take the suggested correc-
tive action.



“When it is safe and legal to
do so, please ensure your
mobile application is running
and logged in on your phone.”

The Toyota mobile application can-
not be connected to Bluetooth

SPP.
Refer to
https://www.toyota.com/
connected-services
in the United States,
https://www.toyota.ca/connected
in Canada, and
http://www.toyotapr.com/
connected-services
in Puerto Rico, to confirm if the

Reordering the applica-
tions

If a message appears on
the screen

407

5-17. Connected Services Operation

Audio

phone is Bluetooth

SPP compati-

ble or not, and then activate the
Toyota mobile application.



“Installation failed, please try
again”

Installation can be attempted again
by changing to the application
screen and pressing the “Install”
switch.



“Application download error.
Please try again later.”

Downloading can be attempted
again by checking the communica-
tion status, changing to the applica-
tion screen and pressing the
“Download” switch again.



“Download error, some mobile
application functions may not
work as expected. Please
reinitiate the download pro-
cess.”

The Toyota mobile application can-
not be connected to Bluetooth

SPP compati-

ble or not, and then activate the
Toyota mobile application.
Please ensure your Toyota mobile
application is running and logged in
on your phone while vehicle is not
moving.



“To use the services, mobile
application needs to be run-
ning on your phone. For more
information, please visit toy-
ota.com or call
1-800-331-4331 in the United
States, 1-888-869-6828 in
Canada, and 1-877-855-8377
in Puerto Rico.”

The Toyota mobile application can-
not be connected to Bluetooth

SPP compati-

ble or not, and then activate the
Toyota mobile application.



“Communication unsuccess-
ful. Please try again.”

Communication was disconnected.
After a few moments, retry the
operation.

A keyword can be entered to an
application by the software key-
board or voice recognition func-
tion. For details about the
functions and services provided
by each application, refer to
https://www.toyota.com/

Entering keyword opera-
tion

408

5-17. Connected Services Operation

connected-services
in the United States,
https://www.toyota.ca/connected
in Canada, and
http://www.toyotapr.com/
connected-services
in Puerto Rico.
The keyboard layout can be
changed. (



P.317)

Display the application
screen. (



P.405)

Select the desired application
screen button.

Select the character entering
space.

Enter a search term, and
then select “OK”.

Entering characters will be
reflected on the character
entering space.

For details on operating the key-

board:



P.289

Display the application
screen. (



P.405)

Select the desired application
screen button.

Press the talk switch.
(



P.360)

Say the desired keyword.

Completion of the keyword will be

detected automatically.

Search results will be dis-
played on the screen.

Entering a keyword using
the software keyboard

Entering a keyword using
the voice recognition func-
tion

409

5-18. Toyota apps settings

Audio

5-18.Toyota apps settings

Press the “MENU” button.

Select “Setup”.

Select “Toyota apps”.

Select the desired items to
be set.

Select to set the pop up
reminder for smart phone
data usage. (



P.407)

Select to detect iPhone app
automatically on/off.

Select to set the enhanced
mode with connecting USB
device on/off.

When an iPhone is connected while
this setting is set to “On”, communi-
cation with devices connected to
other USB ports may not be possi-
ble. Also, depending on the device,
charging may not be possible.

Select to reset all setup
items.

The data use notification
pop-up, which indicates that the
system will use an internet con-
nection, can be enabled/dis-
abled.

Display the Toyota apps set-
tings screen. (



P.409)

Select “Data Usage Mes-
sage”.

Change the setting as
desired.

Setup

The settings of Toyota apps
can be changed.

Displaying the Toyota
apps settings screen

Toyota apps settings
screen

Data use notification
pop-up settings

411

Interior

featur

Interior features

6-1. Using the air conditioning

system and defogger

Manual air conditioning sys-

tem ............................

412

Automatic air conditioning

system.......................

417

Heated steering wheel/seat

heaters ......................

422

6-2. Using the interior lights

Interior lights list ..........

424

6-3. Using the storage features

List of storage features

..................................

426

6-4. Other interior features

Other interior features .

430

Garage door opener....

437

412

6-1. Using the air conditioning system and defogger

6-1.Using the air conditioning system and defogger

: If equipped

The display and button positions will differ depending on the type of
the system.

Fan speed control switch
Temperature control switch
“MAX A/C” switch
“A/C” switch
Outside air mode switch
Recirculated air mode switch
Airflow mode control switch
Rear window defogger and outside rear view mirror defoggers
switch

Windshield defogger switch
On/off switch

Rear window defogger switch

: If equipped

■

Adjusting the temperature
setting

To adjust the temperature set-
ting, turn the temperature con-
trol switch clockwise (warm) or
counterclockwise (cool).

If “A/C” switch is not pressed, the
system will blow ambient tempera-
ture air or heated air.
For quick cooling, press the “MAX
A/C” switch. The air conditioning
will automatically turn on and, if an

Manual air conditioning system

Air conditioning controls

Toyota Corolla (2022 year). Manual in english - page 25
