Up to 5 Bluetooth

devices

(Phones (HFP) and audio play-
ers (AVP)) can be registered.

If more than 1 Bluetooth

device

has been registered, select
which device to connect to.

Display the Bluetooth

set-

tings screen. (

Select “Registered Device”.

Select the device to be con-
nected.

: Phone

: Audio player

: Phone/Toyota apps services



The profile icon for a currently
connected device will be dis-
played in color.



Selecting a profile icon which
is not currently connected will
switch the connection to the
function.



If the desired Bluetooth

device is not on the list, select
“Add New Device” to register
the device. (

P.301)

Bluetooth

setup screen

Connecting a Bluetooth

device

300

5-3. Connectivity settings

Select the desired connec-
tion.

“Device Info”: Select to confirm and
change the Bluetooth

device infor-

mation. (



P.302)

When another Bluetooth

device is connected

To disconnect the Bluetooth

device, select “Yes”.

Check that a confirmation
screen is displayed when the
connection is complete.

If an error message is displayed,

follow the guidance on the screen

to try again.

●

It may take time if the device con-

nection is carried out during Blue-
tooth

audio playback.

●

Depending on the type of Blue-
tooth

device being connected, it

may be necessary to perform

additional steps on the device.

●

When disconnecting a Bluetooth

device, it is recommended to dis-

connect using the system.

■

Connecting a Bluetooth

device in a different way
(from phone top screen)



P.371

■

Connecting a Bluetooth

device in a different way
(from phone setup screen)

P.384

■

Connecting a Bluetooth

device in a different way
(from Bluetooth

audio

screen)

P.343

■

Auto connection mode

To turn auto connection mode
on, set “Bluetooth Power” to on.
(



P.303) Leave the Bluetooth

device in a location where the
connection can be established.



When the engine switch is in
ACC or ON, the system
searches for a nearby regis-
tered device.



The system will connect with
the registered device that was
last connected, if it is nearby.
When automatic connection
priority is set to on and there
is more than one registered
Bluetooth

phone available,

the system will automatically
connect to the Bluetooth

phone with the highest prior-
ity. (

■

Connecting manually

When the auto connection has
failed or “Bluetooth Power” is
turned off, it is necessary to con-
nect the Bluetooth

device man-

ually.

301

5-3. Connectivity settings

Audio

Display the Bluetooth

set-

tings screen. (



Follow the steps in “Connect-
ing a Bluetooth

device” from

step

. (

P.299)

■

Reconnecting the Blue-
tooth

phone

If a Bluetooth

phone is discon-

nected due to poor reception
from the Bluetooth

network

when the engine switch is in
ACC or ON, the system auto-
matically reconnects the Blue-
tooth

phone.

Up to 5 Bluetooth

devices can

be registered.

Bluetooth

compatible phones

(HFP) and audio players (AVP)
can be registered simultane-
ously.
This operation cannot be per-
formed while driving.

Display the Bluetooth

set-

tings screen. (



Select “Add New Device”.



When another Bluetooth

device is connected

To disconnect the Bluetooth

device, select “Yes”.



When 5 Bluetooth

devices

have already been registered

A registered device needs to be
replaced. Select “Yes”, and select
the device to be replaced.

Follow the steps in “Register-
ing a Bluetooth

phone for

the first time” from step

(



P.294)

This operation cannot be per-
formed while driving.

Display the Bluetooth

set-

tings screen. (

Select “Remove Device”.

Select the desired device.

Select “Yes” when the confir-
mation screen appears.

Check that a confirmation
screen is displayed when the
operation is complete.

When deleting a Bluetooth

phone,

the contact data will be deleted at

the same time.

Registering a Bluetooth

device

Deleting a Bluetooth

device

302

5-3. Connectivity settings

The Bluetooth

device’s infor-

mation can be displayed on the
screen. The displayed informa-
tion can be edited.
This operation cannot be per-
formed while driving.

Display the Bluetooth

set-

tings screen. (



Select “Registered Device”.

Select the desired device to
be edited.

Select “Device Info”.

Confirm and change the
Bluetooth

device informa-

tion.

The name of the Bluetooth

device is displayed. It can be
changed to a desired name.
(



Select to set the Bluetooth

audio player connection
method. (

Device address is unique to
the device and cannot be
changed.
Phone number is unique to
the Bluetooth

phone and

cannot be changed.
Compatibility profile is unique
to the Bluetooth

device and

cannot be changed.
Select to reset all setup
items.

Editing the Bluetooth

device information

303

5-3. Connectivity settings

Audio

●

If 2 Bluetooth

devices have been

registered with the same device

name, the devices can be distin-

guished referring to the device’s

address.

●

Depending on the type of Blue-
tooth

phone, some information

may not be displayed.

Select “Device Name”.

Enter the name and select
“OK”.

Even if the device name is changed,

the name registered in your Blue-
tooth

device does not change.

Select “Connect Audio Player
From”.

Select the desired connec-
tion method.

“Vehicle”: Select to connect the

audio player from the vehicle’s

audio/visual system.
“Device”: Select to connect the

vehicle’s audio/visual system from

the audio player.
Depending on the audio player, the

“Vehicle” or “Device” connection

method may be best. As such, refer

to the manual that comes with the

audio player.

The Bluetooth

settings can be

confirmed and changed.

Display the Bluetooth

set-

tings screen. (

Select “Detailed Settings”.

Select the desired item to be
set.

Select to set Bluetooth

con-

nection on/off. (



Select to change the auto-
matic connection priority of
the registered Bluetooth

devices. (

Select to edit the system
information. (



Select to reset all setup
items.

Select “Bluetooth Power”.

When “Bluetooth Power” is on:
The Bluetooth

device is auto-

Changing a device name

Setting audio player con-
nection method

“Detailed Settings”
screen

Changing “Bluetooth
Power”

304

5-3. Connectivity settings

matically connected when the
engine switch is in ACC or ON.
When “Bluetooth Power” is off:
The Bluetooth

device is dis-

connected, and the system will
not connect to it next time.

While driving, the auto connection

state can be changed from off to on,

but cannot be changed from on to

off.

The automatic connection prior-
ity of the registered Bluetooth

devices can be changed.

Select “Preferred Device Set-
tings”.

Select the desired item to be
set.

Select to set automatic con-
nection priority on/off.
Select to change the auto-
matic connection priority of
the registered Bluetooth

phones. (



Select to change the auto-
matic connection priority of
the registered Bluetooth

audio players. (

Select to reset all setup
items.

■

Changing Bluetooth

device automatic connec-
tion priority

Select “Preferred Phones” or
“Preferred Audio Players”.

Select the desired Bluetooth

device and select “Move Up”
or “Move Down” to change
the preferred order.

A newly registered Bluetooth

device will automatically be given

the highest automatic connection

priority.

Select “System Information”.

Setting automatic connec-
tion priority

Editing the system infor-
mation

305

5-3. Connectivity settings

Audio

Select the desired item to be
set.

Displays system name. Can
be changed to a desired
name. (



P.305)

PIN code used when the
Bluetooth

device was regis-

tered. Can be changed to a
desired code. (

P.305)

Device address is unique to
the device and cannot be
changed.
Select to set the connection
status display of the phone
on/off.
Select to set the connection
status display of the audio
player on/off.
Compatibility profile of the
system
Select to reset all setup
items.

■

Editing the system name

Select “System Name”.

Enter a name and select
“OK”.

■

Editing the PIN code

Select “System PIN Code”.

Enter a PIN code and select
“OK”.

306

5-3. Connectivity settings

: If equipped

Enable the Wi-Fi

Hotspot

function. (

Disable the “Hide Access
Point” function. (

P.306)

Search for the vehicle access
point using the device you
wish to connect.

For details about operating the

device, refer to the documentation

which came with it.

Operate the device to con-
nect it to the vehicle access
point.

To check the vehicle access point

password, check “Password”.

(



Hints for connecting to the vehicle
via Wi-Fi

can be displayed.

(



Enable the Wi-Fi

Hotspot

function. (



Enable the “Hide Access
Point” function. (



P.306)

Enter the access point name
(SSID) into the device you
wish to connect and connect
it.



To check the vehicle access
point password, check “Pass-
word”. (



The security settings on the
device must be the same as
that displayed for “Security”.
(





For details about operating
the device, refer to the docu-
mentation which came with it.

Wi-Fi

Hotspot

By connecting a device to
the vehicle via Wi-Fi

, it can

access the internet through
the DCM.



To use this function, a
Wi-Fi

Hotspot service sub-

scription from Verizon Wire-
less is required. Contact
your Toyota dealer for
details.



This function is not made
available in some countries
or areas.

Connecting a device to
the in-vehicle access
point

Searching for and con-
necting a device to the
vehicle access point

Connecting a device to the
in-vehicle access point
using the access point
name (SSID)

307

5-3. Connectivity settings

Audio

Press the “MENU” button.

Select “Setup”.

Select “Wi-Fi

”.

: Wi-Fi

is a registered trademark

of Wi-Fi Alliance

Select the desired item to be
set.

Select to enable/disable the
Wi-Fi

Hotspot function.

(



Select to check/change the
access point password.
(



Select to display hints for
connecting to the vehicle via
Wi-Fi

Select to make the access
point searchable/unsearch-
able.
Select to check/change the
security protocol of the
access point (for authentica-
tion and encryption).
(



Select to change the access
point name (SSID). (



Select to change the Wi-Fi

connection channel (within
the 2.4GHz frequency band).
(



If any settings have been changed,

it will be necessary to reset the
Wi-Fi

system to complete the

changes. To reset the Wi-Fi

sys-

tem, select “Yes” on the pop-up dis-

played after changing the settings.

When the Wi-Fi

Hotspot func-

tion is enabled, the system
checks for a valid Hotspot ser-
vice subscription.
If a hotspot service subscription
has not been started, connect
your device to the in-vehicle
access point to start your sub-

Changing the Wi-Fi

set-

tings

Enabling/disabling the
Wi-Fi

Hotspot function

308

5-3. Connectivity settings

scription. A trial subscription
may be available.

Select “Password”.

Check that the following
screen is displayed.

Displays the password
Select to display/hide the
entered password.
Select to change the pass-
word.

Select “Change Password”.

Enter the desired password
and select “OK”.

When setting/changing a pass-

word, observe the following guide-

lines to help prevent the password

from being cracked by a third party:



Use an 8-character or longer
password consisting of letters
and numbers. (Non-ASCII
characters will not be recog-
nized by the system.)



Change the password regu-
larly.



If you write the password
down, do not leave it some-
where where it would be visi-
ble.



Do not use the same or a sim-
ilar password to that for other
accounts.



Avoid using easy to identify
words, such as your vehicle’s
model name or license plate
number, simple dictionary
words, or words with simple
obfuscation, such as c@t (for
cat), as your password.

Select “Security”.

Select the desired security
protocol.

Select “Access Point Name”.

Enter the desired access
point name (SSID) and select
“OK”.

Select “Channel”.

Checking/changing the
password

Changing the password

Changing the security pro-
tocol

Changing the access point
name (SSID)

Selecting a Wi-Fi

connec-

tion channel

309

5-3. Connectivity settings

Check that the following
screen is displayed.

Select to change the chan-
nel selection to auto-
matic/manual.
When “Manual” is selected,
select to change the channel.

Set “Select Channel” to
“Manual”.

Select “Channel Number”.

Enter the desired channel
number and select “OK”.

Channels 1 through 11 can be

selected.

■

Wi-Fi

function operating hints

●

If a connected device is taken out
of the Wi-Fi

connection area, the

connection will be severed.

●

If the vehicle is driven out of the

cellular communication coverage

area, connecting to the internet
via the Wi-Fi

Hotspot will not be

possible.

●

If a Bluetooth

device is used

while a device is connected using

the Wi-Fi

Hotspot function, the

communication speed may

decrease.

●

If the vehicle is near a radio

antenna, radio station or other

source of strong radio waves and

electrical noise, communication

may be slow or impossible.

The condition of Wi-Fi

connec-

tion appears on the right upper
side of the screen. (

P.282)

Changing the channel

Wi-Fi

function operating

hints

WARNING

●

Use Wi-Fi

devices only when

safe and legal to do so.

●

Your audio unit is fitted with
Wi-Fi

antennas. People with

implantable cardiac pacemak-

ers, cardiac resynchronization

therapy-pacemakers or implant-

able cardioverter defibrillators

should maintain a reasonable

distance between themselves
and the Wi-Fi

antennas.

The radio waves may affect the

operation of such devices.

●

Before using Wi-Fi

devices,

users of any electrical medical

device other than implantable

cardiac pacemakers, cardiac

resynchronization ther-

apy-pacemakers or implantable

cardioverter defibrillators should

consult the manufacturer of the

device for information about its

operation under the influence of

radio waves.

Radio waves could have unex-

pected effects on the operation

of such medical devices.

Conditions displayed with
Wi-Fi

icon

310

5-3. Connectivity settings



Communication standards
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n (2.4GHz)



Security
WPA™
WPA2™

• WPA™ and WPA2™ are trade-

marks of Wi-Fi Alliance

: This function is not made avail-

able in some countries or areas.

Enable Siri on the device to
be connected.

Specifications

Apple CarPlay/

Android Auto

Apple CarPlay allows some
applications, such as Map,
Phone, and Music, to be
used on the system.

When an Apple CarPlay
connection is established,
Apple CarPlay compatible
applications will be dis-
played on the system dis-
play.



Compatible devices

Apple iPhone (iOS Ver. 9.3 or
later) that supports Apple Car-
Play.

For details, refer to
https://www.apple.com/ios/car
play/.

Android™ devices with Android
OS Ver. 5.0 or higher which sup-
port Android Auto and have the
Android Auto application
installed.
For details, refer to

https://www.android.com/auto/
.

: Some devices may not operate

with this system.

Establishing an Apple
CarPlay connection

311

5-3. Connectivity settings

Audio

Connect the device to the
USB port. (



P.326)

Select “Always Enable” or
“Enable Once”.



If “Do Not Enable” is selected,
an Apple CarPlay connection
will not be established. In this
case, the device can be oper-
ated as a normal Apple
device, such as an iPod.



Depending on the device con-
nected, it may take approxi-
mately 3 to 6 seconds before
an Apple CarPlay connection
is established.

Check that home screen of
Apple CarPlay is displayed.

Select to display the home
screen of Apple CarPlay.
Touch and hold to activate
Siri.
Select to start the application.
User can use any iPhone

application supported by
Apple CarPlay.
Select to display the system
screen.

Check that the Android Auto
application is installed to the
device to be connected.

Connect the device to the
USB port. (
