104

2-1. Instrument cluster

Audio system screen

■

Trip information



Audio without DCM/Audio
Plus without DCM

1

Press the “MENU” button.

2

Select “Info” on the “Menu”
screen.

If a screen other than “Trip Informa-
tion” is displayed, select “Trip Infor-
mation”.



Audio with DCM/Audio Plus
with DCM/Premium Audio

1

Press the “MENU” button.

2

Select “Info” on the “Menu”
screen.

3

Select “ECO” on the “Infor-
mation” screen.

If a screen other than “Trip Informa-
tion” is displayed, select “Trip Infor-
mation”.

Resetting the consumption
data
Fuel consumption in the past
15 minutes
Current fuel consumption
Average vehicle speed since
the engine was started.
Elapsed time since the
engine was started.
Cruising range

Average fuel consumption for
the past 15 minutes is divided
by color into past averages and
averages attained since the
engine switch was last turned to
ON. Use the displayed average
fuel consumption as a refer-
ence.

The image is an example only, and
may vary slightly from actual condi-
tions.

■

History



Audio without DCM/Audio
Plus without DCM

1

Press the “MENU” button.

Fuel consumption

information

Fuel consumption informa-
tion can be displayed on the
audio system screen.

System components

Consumption

105

2-1. Instrument cluster

2

Vehicle

 statu

s information an

d in
dicator

s

2

Select “Info” on the “Menu”
screen.

If a screen other than “History” is
displayed, select “History”.



Audio with DCM/Audio Plus
with DCM/Premium Audio

1

Press the “MENU” button.

2

Select “Info” on the “Menu”
screen.

3

Select “ECO” on the “Infor-
mation” screen.

If a screen other than “History” is
displayed, select “History”.

Best recorded fuel consump-
tion
Latest fuel consumption
Previous fuel consumption
record
Resetting the history data
Updating the latest fuel con-
sumption data

The average fuel consumption
history is divided by color into
past averages and the average
fuel consumption since the last
updated. Use the displayed
average fuel consumption as a
reference.

The image is an example only, and
may vary slightly from actual condi-
tions.

■

Updating the history data

Update the latest fuel consumption

by selecting “Update” to measure

the current fuel consumption again.

■

Resetting the data

The fuel consumption data can be

deleted by selecting “Clear”.

■

Cruising range

Displays the estimated maximum

distance that can be driven with the

quantity of fuel remaining.
This distance is computed based on

your average fuel consumption.

As a result, the actual distance that

can be driven may differ from that

displayed.

106

2-1. Instrument cluster

107

3

3

Before driv

ing

Before driving

.

3-1. Key information

Keys ............................

108

3-2. Opening, closing and

locking the doors

Doors ..........................

115

Trunk ...........................

120

Smart key system .......

123

3-3. Adjusting the seats

Front seats ..................

129

Rear seats...................

130

Head restraints............

132

3-4. Adjusting the steering

wheel and mirrors

Steering wheel ............

134

Inside rear view mirror

..................................

135

Outside rear view mirrors

..................................

136

3-5. Opening and closing the

windows

Power windows ...........

138

Moon roof....................

141

108

3-1. Key information

3-1.Key information

The following keys are provided
with the vehicle.



Type A

Keys (without a wireless
remote control function)
Key number plate



Type B

Keys (with a wireless remote
control function)

Operating the wireless remote con-
trol function (



P.110)

Key number plate



Type C

Electronic keys

• Operating the smart key system

(



P.123)

• Operating the wireless remote

control function (



P.110)

Mechanical keys
Key number plate

■

When riding in an aircraft (with

a wireless remote control func-

tion)

When bringing a key with wireless

remote control function onto an air-

craft, make sure you do not press

any buttons on the key while inside

the aircraft cabin. If you are carrying

the key in your bag, etc., ensure that

the buttons are not likely to be

pressed accidentally. Pressing a

button may cause the key to emit

radio waves that could interfere with

the operation of the aircraft.

■

Key battery depletion (with a

wireless remote control func-

tion)



Vehicles without a smart key sys-

tem

●

The standard battery life is 1 to 2

years.

●

The battery will become depleted

even if the key is not used. The

following symptoms indicate that

the key battery may be depleted.

Replace the battery when neces-

sary. (



P.482)

Keys

The keys

109

3-1. Key information

3

Before driv

ing

• The wireless remote control does

not operate.

• The detection area becomes

smaller.



Vehicles with a smart key system

●

The standard battery life is 1 to 2

years.

●

If the battery becomes low, an

alarm will sound in the cabin and a

message will be shown on the

multi-information display when the

engine is stopped.

●

To reduce key battery depletion

when the electronic key is to not

be used for long periods of time,

set the electronic key to the bat-

tery-saving mode. (



P.125)

●

As the electronic key always

receives radio waves, the battery

will become depleted even if the

electronic key is not used. The fol-

lowing symptoms indicate that the

electronic key battery may be

depleted. Replace the battery

when necessary. (



P.482)

• The smart key system or the wire-

less remote control does not oper-

ate.

• The detection area becomes

smaller.

• The LED indicator on the key sur-

face does not turn on.

●

To avoid serious deterioration, do

not leave the electronic key within

3 ft. (1 m) of the following electri-

cal appliances that produce a

magnetic field:

• TVs

• Personal computers

• Cellular phones, cordless phones

and battery chargers

• Recharging cellular phones or

cordless phones

• Table lamps

• Induction cookers

●

If the electronic key is near the

vehicle for longer than necessary,

even if the smart key system is not

operated, the key battery may

become depleted faster than nor-

mal.

■

Replacing the battery (with a

wireless remote control func-

tion)



P.482

■

If “A New Key has been Regis-

tered Contact Your Dealer for

Details” is shown on the

multi-information display (vehi-

cles with a smart key system)

This message will be displayed

each time the driver’s door is

opened when the doors are

unlocked from the outside for

approximately 10 days after a new

electronic key has been registered.

If this message is displayed but you

have not had a new electronic key

registered, ask your Toyota dealer to

check if an unknown electronic key

(other than those in your posses-

sion) has been registered.

■

If a wrong key is used (with a

wireless remote control func-

tion)

The key cylinder rotates freely, iso-

lated from the internal mechanism.

NOTICE

■

To prevent key damage

●

Do not drop the keys, subject

them to strong shocks or bend

them.

●

Do not expose the keys to high

temperatures for long periods of

time.

●

Do not get the keys wet or wash

them in an ultrasonic washer

etc.

●

Vehicles with a smart key sys-

tem: Do not attach metallic or

magnetic materials to the keys

or place the keys close to such

materials.

●

Do not disassemble the keys.

110

3-1. Key information

The keys are equipped with the
following wireless remote con-
trol:



Vehicles without a smart key
system

Locks the doors (



P.115)

Unlocks the doors (



P.115)

Opens the windows

*1

 and

moon roof

*1, 2

 (



P.115)

Opens the trunk (



P.122)

Sounds the alarm (



P.111)



Vehicles with a smart key sys-
tem

Locks the doors (



P.115)

Unlocks the doors (



P.115)

Opens the windows

*1

 and

moon roof

*1, 2

 (



P.115)

Opens the trunk (



P.122)

Sounds the alarm (



P.111)

*1

:This setting must be customized

at your Toyota dealer.

*2

:If equipped

NOTICE

●

Do not attach a sticker or any-

thing else to the surface of the

key.

●

Vehicles with a smart key sys-

tem: Do not place the keys near

objects that produce magnetic

fields, such as TVs, audio sys-

tems and induction cookers.

●

Vehicles with a smart key sys-

tem: Do not place the keys near

medical electrical equipment

such as low-frequency therapy

equipment or microwave ther-

apy equipment, and do not

receive medical attention with

the keys on your person.

■

Carrying the electronic key

on your person (vehicles with

a smart key system)

Carry the electronic key 3.9 in.

(10 cm) or more away from elec-

tric appliances that are turned on.

Radio waves emitted from electric

appliances within 3.9 in. (10 cm)

of the electronic key may interfere

with the key, causing the key to

not function properly.

■

In case of a smart key system

malfunction or other

key-related problems (vehi-

cles with a smart key system)



P.539

■

When an electronic key is lost

(vehicles with a smart key

system)



P.539

Wireless remote control
(if equipped)

111

3-1. Key information

3

Before driv

ing

■

Panic mode (with a wireless

remote control function)



Vehicles without a smart key sys-

tem

When

 is pressed for longer

than about one second, an alarm

will sound intermittently and the

vehicle lights will flash to deter any

person from trying to break into or

damage your vehicle.
To stop the alarm, press any button

on the wireless remote control.



Vehicles with a smart key system

When

 is pressed for longer

than about one second, an alarm

will sound intermittently and the

vehicle lights will flash to deter any

person from trying to break into or

damage your vehicle.
To stop the alarm, press any button

on the electronic key.

■

Conditions affecting the opera-

tion of the smart key system or

wireless remote control (with a

wireless remote control func-

tion)



Vehicles without a smart key sys-

tem

The wireless remote control function

may not operate normally in the fol-

lowing situations:

●

When the wireless key battery is

depleted

●

Near a TV tower, electric power

plant, gas station, radio station,

large display, airport or other facil-

ity that generates strong radio

waves or electrical noise

●

When carrying a portable radio,

cellular phone or other wireless

communication devices

●

When the wireless key is in con-

tact with, or is covered by a metal-

lic object

●

When a wireless key (that emits

radio waves) is being used nearby

●

If window tint with a metallic con-

tent or metallic objects are

attached to the rear window



Vehicles with a smart key system



P.125

1

Releasing

To release the key, press the button

2

Folding

To stow the key, press the button
then fold the key.

Using the key (vehicles
without a smart key sys-
tem and with a wireless
remote control function)

112

3-1. Key information

To take out the mechanical key,
slide the release button and take
the key out.
The mechanical key can only be
inserted in one direction, as the
key only has grooves on one
side. If the key cannot be
inserted in a lock cylinder, turn it
over and re-attempt to insert it.
After using the mechanical key,
store it in the electronic key.
Carry the mechanical key
together with the electronic key.
If the electronic key battery is
depleted or the entry function
does not operate properly, you
will need the mechanical key.
(



P.539)

■

If you lose your mechanical

keys



P.539

Using the mechanical key
(vehicles with a smart key
system)

113

3-1. Key information

3

Before driv

ing

■

Certification for the wireless remote control (vehicles without a

smart key system)



Except for vehicles sold in Canada



For vehicles sold in Canada

114

3-1. Key information

■

Certification for the wireless remote control (vehicles with a smart

key system)



P.616

115

3-2. Opening, closing and locking the doors

3

Before driv

ing

3-2.Opening, closing and locking the doors

■

Smart key system (if
equipped)

Carry the electronic key to
enable this function.

1

Grip the driver’s door handle
to unlock the door. Holding
the driver’s door handle for
approximately 2 seconds
unlocks all the doors. Grip
the front passenger’s door
handle to unlock all the
doors.

*

Make sure to touch the sensor on
the back of the handle.
The doors cannot be unlocked for 3
seconds after the doors are locked.

*

: The door unlock settings can be

changed. (



P.116, 574)

2

Touch the lock sensor (the
indentation on the side of the
front door handle) to lock all
the doors.

Check that the door is securely
locked.

■

Wireless remote control (if
equipped)



Vehicles without a smart key
system

1

Locks all the doors

Check that the door is securely
locked.

2

Unlocks all the doors

Pressing the button unlocks the
driver’s door. Pressing the button
again within 3 seconds unlocks the
other doors.
Press and hold to open the win-
dows

*1

and moon roof.

*1, 2



Vehicles with a smart key sys-
tem

1

Locks all the doors

Check that the door is securely
locked.

2

Unlocks all the doors

Pressing the button unlocks the
driver’s door. Pressing the button

Doors

Unlocking and locking the
doors from the outside

116

3-2. Opening, closing and locking the doors

again within 3 seconds unlocks the
other doors.
Press and hold to open the win-
dows

*1

and moon roof.

*1, 2

*1

:This setting must be customized

at your Toyota dealer.

*2

:If equipped

■

Key

Turning the key operates the
doors as follows:



Vehicles without a smart key
system

1

Unlocks all the doors

Turning the key unlocks the driver’s
door. Turning the key again unlocks
the other doors.
Turn and hold to open the win-
dows

*1

 and moon roof.

*1, 2

2

Locks all the doors

Turn and hold to close the win-
dows

*1

 and moon roof.

*1, 2

*1

:This setting must be customized

at your Toyota dealer.

*2

:If equipped



Vehicles with a smart key sys-
tem

The doors can also be locked
and unlocked with the mechani-
cal key. (



P.539)

■

Switching the door unlock func-

tion (vehicles with a smart key

system)

It is possible to set which doors the

entry function unlocks using the

wireless remote control.

1

Turn the engine switch off.

2

When the indicator light on the

key surface is not on, press and
hold

 ,

 or

 for

approximately 5 seconds while
pressing and holding

.

The setting changes each time an

operation is performed, as shown

below. (When changing the setting

continuously, release the buttons,

wait for at least 5 seconds, and

repeat step

2

.)

For vehicles with an alarm: To pre-

vent unintended triggering of the

alarm, unlock the doors using the

wireless remote control and open

and close a door once after the set-

tings have been changed. (If a door

Multi-informa-

tion display/Beep

Unlocking func-

tion

Exterior: Beeps 3

times

Interior: Pings

once

Holding the
driver’s door
handle unlocks
only the driver’s
door.

Holding the front
passenger’s
door handle
unlocks all the
doors.

Exterior: Beeps

twice

Interior: Pings

once

Holding either
front door handle
unlocks all the
doors.

117

3-2. Opening, closing and locking the doors

3

Before driv

ing

is not opened within 60 seconds
after

 is pressed, the doors will

be locked again and the alarm will

automatically be set.)

In case that the alarm is triggered,

immediately stop the alarm. (



P.81)

■

Operation signals (with a wire-

less remote control function)



Vehicles without a smart key sys-

tem

A buzzer sounds and the emer-

gency flashers flash to indicate that

the doors have been

locked/unlocked using the wireless

remote control. (Locked: Once;

Unlocked: Twice)



Vehicles with a smart key system

A buzzer sounds and the emer-

gency flashers flash to indicate that

the doors have been

locked/unlocked using the entry

function or wireless remote control.

(Locked: Once; Unlocked: Twice)
A buzzer sounds to indicate that the
windows and moon roof

*

are operat-

ing.

*

: If equipped

■

Security feature (with a wireless

remote control function)



Vehicles without a smart key sys-

tem

If a door is not opened within

approximately 60 seconds after the

vehicle is unlocked using the wire-

less remote control, the security fea-

ture automatically locks the vehicle

again.



Vehicles with a smart key system

If a door is not opened within

approximately 60 seconds after the

vehicle is unlocked using the entry

function or wireless remote control,

the security feature automatically

locks the vehicle again.

■

When the door cannot be

locked by the lock sensor on

the surface of the front door

handle (vehicles with a smart

key system)

If the doors cannot be locked by

touching the lock sensor with a fin-

ger, touch the lock sensor with the

palm of your hand.
If you are wearing gloves, remove

them.

■

Door lock buzzer (vehicles with

a smart key system)

If an attempt to lock the doors using

the entry function or wireless remote

control is made when a door is not

fully closed, a buzzer will sound

continuously for 5 seconds. Fully

close the door to stop the buzzer,

and lock the doors again.

■

Alarm (if equipped)

Locking the doors will set the alarm

system. (



P.81)

■

Conditions affecting the opera-

tion of the smart key system or

wireless remote control (if

equipped)



Vehicles without a smart key sys-

tem



P.111



Vehicles with a smart key system



P.125

118

3-2. Opening, closing and locking the doors

■

If the smart key system or the

wireless remote control does

not operate properly (if

equipped)



Vehicles without a smart key sys-

tem

Replace the key battery with a new

one if it is depleted. (



P.482)



Vehicles with a smart key system

Use the mechanical key to lock and

unlock the doors. (



P.539)

Replace the key battery with a new

one if it is depleted. (



P.482)

■

If the battery is discharged

(vehicles with a smart key sys-

tem)

The doors cannot be locked and

unlocked using the smart key sys-

tem or wireless remote control. Lock

or unlock the doors using the

mechanical key. (



P.539)

■

Customization

Some functions can be customized.

(



P.574)

■

Door lock switches (to
lock/unlock)

1

Locks all the doors

2

Unlocks all the doors

WARNING

■

To prevent an accident

Observe the following precautions

while driving the vehicle.

Failure to do so may result in a

door opening and an occupant

being thrown out of the vehicle,

resulting in death or serious injury.

●

Ensure that all doors are prop-

erly closed and locked.

●

Do not pull the inside door han-

dle while driving.

Be especially careful of the front

doors, as the doors may be

opened even if the inside lock

buttons are in the locked posi-

tion.

●

Set the rear door child-protector

locks when children are seated

in the rear seats.

■

When opening or closing a

door

Check the surroundings of the

vehicle such as whether the vehi-

cle is on an incline, whether there

is enough space for a door to

open and whether a strong wind

is blowing. When opening or clos-

ing the door, hold the door handle

tightly to prepare for any unpre-

dictable movement.

■

When using the wireless

remote control or the key and

operating the power win-

dows or moon roof (if

equipped)

Operate the power windows or

moon roof after checking to make

sure that there is no possibility of

any passenger having any of their

body parts caught in the windows

or moon roof. Also, do not allow

children to operate the wireless

remote control or the key. It is

possible for children and other

passengers to get caught in the

power windows or moon roof.

Unlocking and locking the
doors from the inside

119

3-2. Opening, closing and locking the doors

3

Before driv

ing

■

Inside lock buttons

1

Locks the door

2

Unlocks the door

The front doors can be opened by
pulling the inside handle even if the
lock buttons are in the lock position.

■

Locking the front doors from

the outside without a key

1

Move the inside lock button to

the lock position.

2

Close the door.



Vehicles without a smart key sys-

tem

The door cannot be locked if the key

is in the engine switch.



Vehicles with a smart key system

The door cannot be locked if the

engine switch is in ACC or ON, or

the electronic key is left inside the

vehicle.
The key may not be detected cor-

rectly and the door may be locked.

■

Open door warning buzzer

If a door or the trunk is not fully

closed, a buzzer will sound when

the vehicle speed reaches 3 mph (5

km/h).
The open door(s) or trunk is indi-

cated on the multi-information dis-

play.

The door cannot be opened
from inside the vehicle when
lock is set.

1

Unlock

2

Lock

These locks can be set to prevent
children from opening the rear
doors. Push down on each rear
door switch to lock both rear doors.

The following functions can be
set or canceled:

For instructions on customizing,
refer to P.574.

Rear door child-protector
lock

Automatic door locking
and unlocking systems
