262

5-1. MOBILITY

Supra Owner's Manual

245/45 R 18 96 Y
245: nominal width in mm
45: aspect ratio in %

Tire inflation pressure values over 100 mph/160 km/h

SZ-R models

Tire size

Pressure specifications in bar/PSI

Specifications in bar/PSI with cold
tires

225/50 R 17 98 H M+S XL Std/RSC

2.2 / 32

255/40 R 18 99 V M+S XL Std

2.2 / 32

Front: 255/40 ZR 18 95 Y Std
Rear: 275/40 ZR 18 99 Y Std

2.2 / 32
2.2 / 32

Front: 255/35 ZR 19 96 Y XL Std
Rear: 275/35 ZR 19 100 Y XL Std

2.2 / 32
2.2 / 32

RZ models

Tire size

Pressure specifications in bar/PSI

Specifications in bar/PSI with cold
tires

225/50 R 17 98 H M+S XL Std/RSC

2.2 / 32

255/40 R 18 99 V M+S XL Std

2.6 / 38

Front: 255/40 ZR 18 95 Y Std
Rear: 275/40 ZR 18 99 Y Std

2.6 / 38
2.6 / 38

Front: 255/35 ZR 19 96 Y XL Std
Rear: 275/35 ZR 19 100 Y XL Std

2.6 / 38
2.6 / 38

Tire identification marks

Tire size

263

5-1. MOBILITY

Supra Owner's Manual

5

MOBILITY

R: radial tire code
18: rim diameter in inches
96: load rating, not for ZR tires
Y: speed rating, before the R on
ZR tires

Maximum tire load is the maxi-
mum permissible weight for
which the tire is approved.
Locate the maximum tire load
on the tire sidewall and the
Gross Axle Weight Rating –
GAWR – on the certification
label on the driver door B-pillar.
Divide the tire load by 1.1. It
must be greater than one-half of
the vehicle’s Gross Axle Weight
Rating – GAWR. Note, front vs.
rear GAWR and tire loads,
respectively.

Q = up to 100 mph/160 km/h
R = up to 106 mph/170 km/h
S = up to 112 mph/180 km/h
T = up to 118 mph/190 km/h
H = up to 131 mph/210 km/h
V = up to 150 mph/240 km/h
W = up to 167 mph/270 km/h
Y = up to 186 mph/300 km/h

DOT code: DOT xxxx xxx 3818

xxxx: manufacturer code for the
tire brand
xxx: tire size and tire design
3818: tire age
Tires with DOT codes meet the
guidelines of the U.S. Depart-
ment of Transportation.

Regardless of the tire tread,
replace tires at least every 6
years.

You can find the manufacture
date of the tire on the tire's side-
wall.

Quality grades can be found
where applicable on the tire
sidewall between tread shoulder
and maximum section width.
E.g.: Treadwear 200; Traction
AA; Temperature A

Treadwear

Maximum tire load

Speed letter

Tire Identification Number

Tire age

Recommendation

Manufacture date

Designation

Manufacture

date

DOT … 3818

38th week, 2018

Uniform Tire Quality Grad-
ing

DOT Quality Grades

264

5-1. MOBILITY

Supra Owner's Manual

Traction AA A B C
Temperature A B C
All passenger vehicle tires must
conform to Federal Safety
Requirements in addition to
these grades

The treadwear grade is a com-
parative rating based on the
wear rate of the tire when tested
under controlled conditions on a
specified government test
course. E.g., a tire graded 150
would wear one and one-half, 1
g, times as well on the govern-
ment course as a tire graded
100. The relative performance
of tires depends upon the actual
conditions of their use, however,
and may depart significantly
from the norm due to variations
in driving habits, service prac-
tices and differences in road
characteristics and climate.

The traction grades, from high-
est to lowest, are AA, A, B, and
C.
Those grades represent the
tire's ability to stop on wet pave-
ment as measured under con-
trolled conditions on specified
government test surfaces of
asphalt and concrete. A tire
marked C may have poor trac-

tion performance.
The traction grade assigned to
this tire is based on
straight-ahead braking traction
tests, and does not include
acceleration, cornering, hydro-
planing, or peak traction charac-
teristics.

The temperature grades are A,
the highest, B, and C, represent-
ing the tire's resistance to the
generation of heat and its ability
to dissipate heat when tested
under controlled conditions on a
specified indoor laboratory test
wheel. Sustained high tempera-
ture can cause the material of
the tire to degenerate and
reduce tire life, and excessive
temperature can lead to sudden
tire failure.
The grade C corresponds to a
level of performance which all
passenger vehicle tires must
meet under the Federal Motor
Vehicle Safety Standard No.
109. Grades Band A represent
higher levels of performance on
the laboratory test wheel than
the minimum required by law.

Treadwear

Traction

Temperature

265

5-1. MOBILITY

Supra Owner's Manual

5

MOBILITY

Winter and all-season tires with
better cold weather performance
than summer tires.

Do not drive with a tire tread of
less than 0.12 in/3 mm, other-
wise there is an increased risk
of hydroplaning.

Do not drive with a tire tread of
less than 0.16 in/4 mm, as such
tires are less suitable for winter
operation.

Wear indicators are distributed
around the tire's circumference
and have the legally required
minimum height of 0.063
inches/1.6 mm.
The positions of the wear indica-
tors are marked on the tire side-
wall with TWI, Tread Wear
Indicator.

Inspect your tires regularly for
damage, foreign objects lodged
in the tread, and tread wear.
Driving over rough or damaged
road surfaces, as well as debris,
curbs and other obstacles can
cause serious damage to
wheels, tires and suspension
parts. This is more likely to
occur with low-profile tires,
which provide less cushioning
between the wheel and the
road. Be careful to avoid road
hazards and reduce your speed,
especially if your vehicle is

WARNING

The temperature grade for this tire

is established for a tire that is

properly inflated and not over-

loaded. Excessive speed, under-

inflation, or excessive loading,

either separately or in combina-

tion, can cause heat buildup and

possible tire failure.

M+S

Tire tread

Summer tires

Winter tires

Minimum tread depth

Tire damage

General information

266

5-1. MOBILITY

Supra Owner's Manual

equipped with low-profile tires.
Indications of tire damage or
other vehicle malfunctions:
• Unusual vibrations.
• Unusual tire or running

noises.

• Unusual handling such as a

strong tendency to pull to the
left or right.

Damage can be caused by the
following situations, for instance:
• Driving over curbs.
• Road damage.
• Tire inflation pressure too low.
• Vehicle overloading.
• Incorrect tire storage.

Have mounting and wheel bal-
ancing carried out by your Toy-
ota dealer.

You can ask your Toyota dealer
about the correct wheel/tire
combination and wheel rim ver-
sions for the vehicle.

Safety information

WARNING

Damaged tires can lose tire infla-

tion pressure, which can lead to

loss of vehicle control. There is a

risk of an accident. If tire damage

is suspected while driving, imme-

diately reduce speed and stop.

Have wheels and tires checked.

For this purpose, drive carefully to

the nearest your Toyota dealer.

Have vehicle towed or trans-

ported as needed. Do not repair

damaged tires, but have them

replaced.

WARNING

Tires can become damaged by

driving over obstacles, e.g., curbs

or road damage, at high speed.

Larger wheels have a smaller tire

cross-section. The smaller the tire

cross-section, the higher the risk

of tire damage. There is a danger

of accidents and property dam-

age. If possible, drive around

obstacles, or drive over them

slowly and carefully.

Changing wheels and
tires

Mounting and wheel bal-
ancing

Wheel and tire combina-
tion

General information

267

5-1. MOBILITY

Supra Owner's Manual

5

MOBILITY

For each tire size, the manufac-
turer of the vehicle recommends
certain tire brands. The tire
brands can be identified by a
star on the tire sidewall.

Tire traction is not optimal due to
manufacturing circumstances
when tires are brand-new; they
achieve their full traction poten-
tial after a break-in time.
Drive conservatively for the first
200 miles/300 km.

The manufacturer of your vehi-
cle does not recommend the
use of retreaded tires.

Safety information

WARNING

Wheels and tires which are not

suitable for your vehicle can dam-

age parts of the vehicle, for

instance due to contact with the

body due to tolerances despite

the same official size rating.

There is a risk of an accident. The

manufacturer of your vehicle

strongly suggests that you use

wheels and tires that have been

recommended by the vehicle

manufacturer for your vehicle

type.

WARNING

Mounted steel wheels can cause

technical problems, for instance

independent loosening of the lug

bolts, damage to the brake discs.

There is a risk of an accident. Do

not mount steel wheels.

WARNING

Incorrect wheel/tire combinations

will have a negative impact on the

vehicle's handling and on the

function of a variety of systems,

such as the Anti-lock Brake Sys-

tem or Vehicle Stability Control

System. There is a risk of an acci-

dent. To maintain good handling

and vehicle response, use only

tires with a single tread configura-

tion from a single manufacturer.

The manufacturer of the vehicle

recommends that you use wheels

and tires that have been recom-

mended by the vehicle manufac-

turer for your vehicle type.

Following tire damage, have the

original wheel/tire combination

remounted on the vehicle as soon

as possible.

Recommended tire brands

New tires

Retreaded tires

WARNING

Retreaded tires can have different

tire casing structures. With

advanced age the service life can

be limited. There is a risk of an

accident. The manufacturer of

your vehicle does not recommend

the use of retreaded tires.

268

5-1. MOBILITY

Supra Owner's Manual

Winter tires are recommended
for operating on winter roads.
Although so-called all-season
M+S tires provide better winter
traction than summer tires, they
usually do not provide the same
level of performance as winter
tires.

If the maximum speed of the
vehicle is higher than the per-
missible speed for the winter
tires, then attach a label show-
ing the permissible maximum
speed in the field of view. The
label is available from your Toy-
ota dealer.
With winter tires mounted,
observe and do not exceed the
permissible maximum speed.

Swapping the front wheels with
the rear wheels or vice versa is
not permitted on vehicles with
different tire or rim dimensions
on the front and rear axles.

Do not exceed the maximum tire
inflation pressure indicated on
the side wall of the tire.

Store wheels and tires in a cool,
dry and dark place.
Always protect tires against all
contact with oil, grease, and sol-
vents.
Do not leave tires in plastic
bags.
Remove dirt from wheels or
tires.

• Park the vehicle as far away

as possible from passing traf-
fic and on solid ground.

• Switch on the hazard warning

system.

• Secure the vehicle against

rolling away by setting the
parking brake.

• Turn the steering wheel until

the front wheels are in the
straight-ahead position and
engage the steering wheel
lock.

• Have all vehicle occupants

get out of the vehicle and

Winter tires

General information

Maximum speed of winter
tires

Rotating wheels between
axles

Storing tires

Tire inflation pressure

Storage

Repairing a flat tire

Safety measures

269

5-1. MOBILITY

Supra Owner's Manual

5

MOBILITY

ensure that they remain out-
side the immediate area in a
safe place, such as behind a
guardrail.

• If necessary, set up a warning

triangle at an appropriate dis-
tance.

With the Mobility System, minor
tire damage can be sealed tem-
porarily to enable continued
travel. To accomplish this, seal-
ant is pumped into the tires,
which seals the damage from
the inside.

• Follow the instructions on

using the Mobility System
found on the compressor and
sealant container.

• Use of the Mobility System

may be ineffective if the tire
puncture measures approx.
1/8 inches/4 mm or more.

• Contact your Toyota dealer if

the tire cannot be made driv-
able.

• If possible, do not remove for-

eign bodies that have pene-
trated the tire. Only remove
foreign objects if they are visi-
bly protruding from the tire.

• Pull the speed limit sticker off

the sealant container and

apply it to the steering wheel.

• The use of a sealant can

damage the TPM wheel elec-
tronics. In this case, have the
electronics checked and
replaced at the next opportu-
nity.

The compressor can be used to
check the tire inflation pressure.

The Mobility System is located in
the right storage compartment of the
cargo area.

• Sealant container, arrow

1

.

• Filling hose, arrow

2

.

Observe use-by date on the

Mobility System

Concept

General information

Overview

Storage

Sealant container

270

5-1. MOBILITY

Supra Owner's Manual

sealant container.

1

Sealant container unlocking

2

Sealant container holder

3

Tire pressure gauge

4

Reduce tire inflation pressure
button

5

On/off switch

6

Compressor

7

Connector/cable for socket

8

Connection hose

• Park the vehicle as far away

as possible from passing traf-
fic and on solid ground.

• Switch on the hazard warning

system.

• Secure the vehicle against

rolling away by setting the
parking brake.

• Turn the steering wheel until

the front wheels are in the
straight-ahead position and
engage the steering wheel
lock.

• Have all vehicle occupants

get out of the vehicle and

ensure that they remain out-
side the immediate area in a
safe place, such as behind a
guardrail.

• If necessary, set up a warning

triangle at an appropriate dis-
tance.

Compressor

Safety measures

Filling the tire with sealant

Safety information

WARNING

If the exhaust pipe is blocked or

ventilation is insufficient, harmful

exhaust gases can enter into the

vehicle. The exhaust gases con-

tain pollutants which are colorless

and odorless. In enclosed areas,

exhaust gases can also accumu-

late outside of the vehicle. There

is danger to life. Keep the exhaust

pipe free and ensure sufficient

ventilation.

NOTICE

The compressor can overheat

during extended operation. There

is a risk of damage to property. Do

not run the compressor for more

than 10 minutes.

271

5-1. MOBILITY

Supra Owner's Manual

5

MOBILITY

1

Shake the sealant container.

2

Pull filling hose completely
out of the cover of the sealant
container. Do not kink the
hose.

3

Slide the sealant container
into the holder on the com-
pressor housing, ensuring
that it engages audibly.

4

Screw the filling hose of the
sealant container onto the

tire valve of the nonworking
wheel.

5

With the compressor
switched off, insert the plug
into the power socket inside
the vehicle.

6

With standby state switched
on or the engine running,
switch on the compressor.

Let the compressor run for max.
10 minutes to fill the tire with
sealant and achieve a tire infla-
tion pressure of approx. 2.0 bar.

Filling

272

5-1. MOBILITY

Supra Owner's Manual

While the tire is being filled with
sealant, the tire inflation pres-
sure may sporadically reach
approx. 5 bar. Do not switch off
the compressor at this point.

1

Switch off the compressor.

2

Read the tire inflation pres-
sure on the tire pressure
gauge.

To continue the trip, a tire infla-
tion pressure of at least 2 bar
must be reached.

1

Unscrew the filling hose of
the sealant container from
the tire valve.

2

Press the red unlocking
device.

3

Remove the sealant con-
tainer from the compressor.

4

Wrap and store the sealant
container in suitable material
to avoid dirtying the cargo
area.

1

Pull the connector out of the
power socket inside the vehi-
cle.

2

Drive 33 ft/10 m forward and
back to distribute the sealant
in the tire.

3

Screw the connection hose of
the compressor directly onto
the tire valve stem.

4

Insert the connector into the
power socket inside the vehi-
cle.

5

With standby state switched
on or the engine running,
switch on the compressor.

If a tire inflation pressure of at least

2 bar cannot be reached, contact

your Toyota dealer.
If a tire inflation pressure of at least

Checking and adjusting
the tire inflation pressure

Checking

Removing and stowing the
sealant container

Minimum tire inflation pres-
sure is not reached

273

5-1. MOBILITY

Supra Owner's Manual

5

MOBILITY

2 bar is reached, see Minimum tire

inflation pressure is reached.

6

Unscrew the connection
hose of the compressor from
the tire valve.

7

Pull the connector out of the
power socket inside the vehi-
cle.

8

Stow the Mobility System in
the vehicle.

1

Unscrew the connection
hose of the compressor from
the tire valve.

2

Pull the connector out of the
power socket inside the vehi-
cle.

3

Stow the Mobility System in
the vehicle.

4

Immediately drive approx. 5
miles/10 km to ensure that
the sealant is evenly distrib-
uted in the tire.

Do not exceed a speed of 50

mph/80 km/h.
If possible, do not drive at speeds

less than 12 mph/20 km/h.

1

Stop at a suitable location.

2

Screw the connection hose of
the compressor directly onto
the tire valve stem.

3

Insert the connector into the
power socket inside the vehi-
cle.

4

Correct the tire inflation pres-
sure to at least 2.0 bar.

• Increase tire inflation pres-

sure: with standby state
switched on or the engine
running, switch on the com-
pressor.

• Reduce tire inflation pressure:

press the button on the com-
pressor.

5

Unscrew the connection
hose of the compressor from
the tire valve.

6

Pull the connector out of the
power socket inside the vehi-
cle.

Minimum tire inflation pres-
sure is reached

Adjustment

274

5-1. MOBILITY

Supra Owner's Manual

7

Stow the Mobility System in
the vehicle.

Do not exceed the maximum
permissible speed of 50 mph/80
km/h
Reset the Tire Pressure Monitor
TPM, refer to page 274.
Replace the nonworking tire and
the sealant container of the
Mobility System promptly.

Tire chains cannot be mounted.
Snow tires should be used
instead.

The system monitors tire infla-
tion pressure in the four
mounted tires. The system
warns you if there is a loss of
pressure in one or more tires.

Sensors in the tire valves mea-
sure the tire inflation pressure
and tire temperature.
The system detects the
mounted tires automatically. The
system displays the specified
nominal pressure values on the
Control Display and compares
these values to the actual tire
pressure values.
If tires are being used that are
not specified on the tire inflation
pressure details on the vehicle,
refer to page 248, such as tires
with special approval, the sys-
tem needs to be actively reset.
The system will then take over
the actual tire inflation pressures
as the target pressures.
When operating the system,
also note the additional informa-
tion found in the Tire inflation
pressure, refer to page 248,
chapter.

Continuing the trip

Snow chains

NOTICE

■

Driving with tire chains

Do not fit tire chains. Tire chains

may damage the vehicle body

and suspension, and adversely

affect driving performance.

Selecting tire chains

Tire Pressure Monitor
TPM

Concept

General information

275

5-1. MOBILITY

Supra Owner's Manual

5

MOBILITY

The following conditions must
be met for the system; other-
wise, reliable flagging of a loss
of tire inflation pressure is not
assured:
• After each tire or wheel

change, the system detects
and updates the mounted
tires and displays them after a
short trip on the Control Dis-
play.

Enter the information about the
mounted tires in the tire settings
when the system does not automat-
ically detect the tires.

• For tires with special

approval:

• After a tire or wheel replacement,

a reset was performed with the
correct tire inflation pressure.

• After the tire inflation pressure

was adjusted to a new value, a
reset was performed.

• Wheels with TPM wheel elec-

tronics.

The information about the
mounted tires can be entered in
the tire settings if the system
does not automatically detect
the tires.
The tire sizes of the mounted
tires can be gathered from the
tire inflation pressure details on
the vehicle, refer to page 258, or
directly on the tires.
The tire details do not need to
be re-entered when the tire infla-
tion pressure is corrected.
For summer and winter tires, the
tire details entered last are
stored. After a tire or wheel
replacement, the settings of the
tire sets used last can be
selected.

Via Toyota Supra Command:

1

"My vehicle"

2

"Vehicle status"

3

 "Tire Pressure Monitor"

Via Toyota Supra Command:

1

"Tire settings"

Safety information

WARNING

The display of the target pres-

sures is not a substitute for the

tire inflation pressure details on

the vehicle. Incorrect entries in

the tire settings can lead to incor-

rect target tire inflation pressure

values. In this case, it cannot be

guaranteed that the notification of

a loss of tire inflation pressure will

be reliable. There is a risk of injury

and risk of damage to property.

Ensure that the tire sizes of the

mounted tires are displayed cor-

rectly and match the details on the

tires and on the vehicle.

Functional requirements

Tire settings

General information

Opening the menu

Changing settings

276

5-1. MOBILITY

Supra Owner's Manual

2

Selecting tires:

• "Summer tires"
• "Winter tires/all-season tires"

3

"Current:"

4

Select the tire type that is
mounted on the rear axle:

• Tire size, e.g., 245/45 R18 96

Y.

• For tires with special

approval: "Other tire"

5

Select the maximum road
speed that will be used with
the tires.

6

"Confirm settings"

The measurement of the current
tire inflation pressure is started.
The measurement progress is
displayed.

The system status can be dis-
played on the Control Display,
e.g., whether or not the system
is active.
Via Toyota Supra Command:

1

"My vehicle"

2

"Vehicle status"

3

 "Tire Pressure Monitor"

The current status is displayed.

The current tire inflation pres-

sure is displayed for each tire.
The current tire inflation pres-
sures may change during driv-
ing operation or depending on
the external temperature.

Depending on the model, the
current tire temperatures are
displayed.
The current tire temperatures
may change while driving or due
to the external temperature.

Tire and system status are indi-
cated by the color of the wheels
and a SMS text message on the
Control Display.
Any existing messages are not
deleted if the displayed target
pressure is not reached after the
tire inflation pressure is cor-
rected.

• The system is active and

bases warnings on the dis-
played target pressures.

• For tires with special

approval: the system is active
and bases warnings on the
tire inflation pressures stored
during the last reset.

Status display

Current status

Current tire inflation pres-
sure

Current tire temperature

Tire conditions

General information

All wheels green

277

5-1. MOBILITY

Supra Owner's Manual

5

MOBILITY

A flat tire or major drop in the
tire inflation pressure has
occurred in the indicated tires.

It may not be possible to identify
tire inflation pressure losses.
Possible causes:
• Malfunction.
• During tire inflation pressure

measurement, after confirma-
tion of the tire settings.

• For tires with special

approval: the system is being
reset.

Via Toyota Supra Command:

1

"My vehicle"

2

"Vehicle status"

3

"Tire Pressure Monitor"

4

"Tire settings"

• When not selecting "Other

tire":

5

"Confirm settings"

6

Drive the vehicle.

• When selecting "Other tire":

7

"Tire settings"

8

Switch on drive-ready state
and do not drive off.

9

Reset tire inflation pressure:
"Perform reset".

10

Drive away.

The wheels are displayed in red
and the following is displayed
"Resetting Tire Pressure Moni-
tor…".
After driving faster than 19
mph/30 km/h for a short period,
the set tire inflation pressures
are accepted as the target tire
inflation pressures. The reset is
completed automatically while
driving.
After a successfully completed
reset, the wheels on the Control
Display are shown in green and
the following is displayed: "Tire
Pressure Monitor active. See
label for recommended pres-
sure.".
You may interrupt this trip at any
time. When you continue the
reset resumes automatically.

A low tire inflation pressure may
cause the VSC Vehicle Stability
Control System to be switched
on.

One to four yellow wheels

Gray wheels

Reset the tire inflation
pressure

Messages: for tires with-
out special approval

General information

278

5-1. MOBILITY

Supra Owner's Manual

■

Message

A symbol with a vehicle mes-
sage appears on the Control
Display.

■

Measure

Check the tire pressure and cor-
rect as needed.

■

Message

In addition, a symbol with a
vehicle message appears on the
Control Display.

■

Measure

1

Reduce the vehicle speed.
Do not exceed a speed of 80
mph/130 km/h.

2

At the next opportunity, for
instance at a gas station,
check the tire inflation pres-
sure in all four tires and cor-
rect if necessary.

■

Message

In addition, a symbol with the
affected tire appears in a vehicle
message on the Control Display.

■

Measure

Reduce your speed and stop
cautiously. Avoid sudden brak-
ing and steering maneuvers.

Safety information

WARNING

A damaged regular tire with low or

missing tire inflation pressure

impacts handling, such as steer-

ing and braking response. Do not

continue driving if the vehicle is

equipped with normal tires.

If a tire inflation pressure
check is required

Symbol

Possible cause

Inflation was not carried
out according to specifi-
cations, e.g., when the
tire has not been suffi-
ciently inflated or in the
case of a natural steady
tire pressure loss.

If the tire inflation pressure
is too low

A yellow warning light is
illuminated in the instru-
ment cluster.

Symbol

Possible cause

There is a tire inflation

pressure loss.

If there is a significant loss
of tire inflation pressure

A yellow warning light is
illuminated in the instru-
ment cluster.

Symbol

Possible cause

There is a flat tire or a
major loss in tire infla-
tion pressure.

279

5-1. MOBILITY

Supra Owner's Manual

5

MOBILITY

A low tire inflation pressure may
cause the VSC Vehicle Stability
Control System to be switched
on.

■

Message

A symbol with a vehicle mes-
sage appears on the Control
Display.

■

Measure

1

Check the tire pressure and
correct as needed.

2

Perform a system reset.

■

Message

In addition, a symbol with a
vehicle message appears on the
Control Display.

Messages: for tires with
special approval

General information

Safety information

WARNING

A damaged regular tire with low or

missing tire inflation pressure

impacts handling, such as steer-

ing and braking response. Do not

continue driving if the vehicle is

equipped with normal tires.

If a tire inflation pressure
check is required

Symbol

Possible cause

Inflation was not carried
out according to specifi-
cations, e.g., the tire
has not been suffi-
ciently inflated.
The system has
detected a wheel
change, but no reset
was done.
The tire inflation pres-
sure has fallen below
the level of the last
reset.
No reset was per-
formed for the system.
The system issues a
warning based on the
tire inflation pressures
stored during the last
reset.

If the tire inflation pressure
is too low

A yellow warning light is
illuminated in the instru-
ment cluster.

280

5-1. MOBILITY

Supra Owner's Manual

■

Measure

1

Reduce the vehicle speed.
Do not exceed a speed of 80
mph/130 km/h.

2

At the next opportunity, for
instance at a gas station,
check the tire inflation pres-
sure in all four tires and cor-
rect if necessary.

3

Reset the system.

■

Message

In addition, a symbol with the
affected tire appears in a vehicle
message on the Control Display.

■

Measure

Reduce your speed and stop
cautiously. Avoid sudden brak-
ing and steering maneuvers.

1

Identify the damaged tire.

Check the tire inflation pressure in

all four tires, for instance using the

tire pressure gauge of a flat tire kit.
For tires with special approval: if

the tire inflation pressure in all four

tires is correct, the TPM may not

have been reset. In this case, per-

form the reset.
If tire damage cannot be found,

contact your Toyota dealer.

2

Repair the flat tire, e.g., with
a flat tire kit or by changing
the wheel.

Use of sealant, for instance from
the flat tire kit, may damage the
TPM wheel electronics. Have
the electronics replaced at the
next opportunity.

Symbol

Possible cause

There is a tire inflation
pressure loss.
No reset was per-
formed for the system.
The system issues a
warning based on the
tire inflation pressures
stored during the last
reset.

If there is a significant loss
of tire inflation pressure

A yellow warning light is
illuminated in the instru-

ment cluster.

Symbol

Possible cause

There is a flat tire or a
major loss in tire infla-
tion pressure.
No reset was per-
formed for the system.
The system issues a
warning based on the
tire inflation pressures
stored during the last
reset.

Actions in the event of a
flat tire

281

5-1. MOBILITY

Supra Owner's Manual

5

MOBILITY

The tire inflation pressure
depends on the tire's tempera-
ture.
Driving or exposure to the sun
will increase the tire's tempera-
ture, thus increasing the tire
inflation pressure.
The tire inflation pressure is
reduced when the tire tempera-
ture falls again.
These circumstances may
cause a warning when tempera-
tures fall very sharply.
Following a temperature-related
warning, the target pressures
are displayed on the Control
Display again after a short dis-
tance.

The system cannot indicate sud-
den serious tire damage caused
by external circumstances.

Tires with special approval: the
system will not function correctly
if a reset was not performed, for
example a flat tire may be indi-
cated although the tire inflation
pressures are correct.

• A wheel without TPM wheel

electronics, such as an emer-
gency wheel, is mounted:
have the wheels checked, if
needed.

• Malfunction: have the system

checked.

• Interference caused by sys-

tems or devices with the
same radio frequency: after
leaving the area of the inter-
ference, the system automati-
cally becomes active again.

• For tires with special

approval: the system was
unable to complete the reset.
Perform a system reset again.

• Each tire, including the spare

(if provided) should be
checked monthly when cold
and inflated to the inflation

System limits

Temperature

Sudden tire pressure loss

Failure to perform a reset

Malfunction

Message

The yellow warning
light flashes and is then
illuminated continu-
ously. A vehicle mes-
sage is displayed. It
may not be possible to
identify tire pressure
losses.

Measure

Declaration according to
NHTSA/FMVSS 138 Tire
Pressure Monitoring System

282

5-1. MOBILITY

Supra Owner's Manual

pressure recommended by
the vehicle manufacturer on
the vehicle placard or tire
inflation pressure label. (If
your vehicle has tires of a dif-
ferent size than the size indi-
cated on the vehicle placard
or tire inflation pressure label,
you should determine the
proper tire inflation pressure
for those tires.) As an added
safety feature, your vehicle
has been equipped with a tire
pressure monitoring system
(TPMS) that illuminates a low
tire pressure telltale when one
or more of your tires is signifi-
cantly under-inflated. Accord-
ingly, when the low tire
pressure telltale illuminates,
you should stop and check
your tires as soon as possi-
ble, and inflate them to the
proper pressure. Driving on a
significantly under-inflated tire
causes the tire to overheat
and can lead to tire failure.
Under-inflation also reduces
fuel efficiency and tire tread
life, and may affect the vehi-
cle's handling and stopping
ability. Please note that the
TPMS is not a substitute for
proper tire maintenance, and
it is the driver's responsibility
to maintain correct tire pres-
sure, even if under-inflation
has not reached the level to
trigger illumination of the
TPMS low tire pressure tell-

tale. Your vehicle has also
been equipped with a TPMS
malfunction indicator to indi-
cate when the system is not
operating properly. The TPMS
malfunction indicator is com-
bined with the low tire pres-
sure telltale. When the system
detects a malfunction, the tell-
tale will flash for approxi-
mately one minute and then
remain continuously illumi-
nated. This sequence will
continue upon subsequent
vehicle start-ups as long as
the malfunction exists. When
the malfunction indicator is
illuminated, the system may
not be able to detect or signal
low tire pressure as intended.
TPMS malfunctions may
occur for a variety of reasons,
including the installation of
replacement or alternate tires
or wheels on the vehicle that
prevent the TPMS from func-
tioning properly. Always
check the TPMS malfunction
telltale after replacing one or
more tires or wheels on your
vehicle to ensure that the
replacement or alternate tires
and wheels allow the TPMS
to continue to function prop-
erly.

283

5-1. MOBILITY

Supra Owner's Manual

5

MOBILITY

If a tire is punctured and loses
pressure, it is not necessary to
replace the tire immediately if a
tire repair kit (Mobility System) is
used.
If needed, the tools for changing
wheels are available as acces-
sories from your Toyota dealer.

The wheel lug bolts have a spe-
cial coding. The lug bolts can
only be released with the
adapter which matches the cod-
ing.

The adapter of the lug bolt lock
is in the onboard vehicle tool kit
or in a storage compartment
close to the onboard vehicle tool
kit.

• Lug bolt, arrow

1

.

• Adapter, arrow

2

.

1

Attach the adapter to the lug
bolt.

2

Unscrew the lug bolt.

3

Remove the adapter after
unscrewing the lug bolt.

1

Attach the adapter to the lug
bolt. If necessary, turn the
adapter until it fits on the lug
bolt.

2

Screw on the wheel stud.
The tightening torque is 140
Nm.

3

Remove the adapter and
stow it after screwing on the
lug bolt.

Changing wheels/tires

General information

Lug bolt lock

Concept

Overview

Unscrewing

Screwing on

284

5-1. MOBILITY

Supra Owner's Manual

This chapter describes all stan-
dard, country-specific and
optional features offered with
the series. It also describes fea-
tures and functions that are not
necessarily available in your
vehicle, e.g., due to the selected
options or country versions. This
also applies to safety-related
functions and systems. When
using these functions and sys-
tems, the applicable laws and
regulations must be observed.

Engine compartment

Vehicle features and
options

285

5-1. MOBILITY

Supra Owner's Manual

5

MOBILITY

1

Filler neck for washer fluid

2

Jump-starting, negative battery terminal

3

Jump-starting, positive battery terminal

4

Oil filler neck

5

Coolant reservoir, auxiliary cooling

6

Coolant reservoir, engine

7

Vehicle identification number

Overview

Hood

Safety information

WARNING

Improperly executed work in the

engine compartment can damage

vehicle components and impair

vehicle functions. There is a risk

of personal and property damage.

The manufacturer of your vehicle

recommends that, in the effort to

avoid such risks, work in the

engine compartment be per-

formed by your Toyota dealer.

286

5-1. MOBILITY

Supra Owner's Manual

1

Pull lever, arrow

1

.

Hood is unlocked.

2

After the lever is released,
pull the lever again, arrow

2

.

Hood can be opened.

3

Be careful of protruding parts
on the hood.

Energetically close the hood
from approx. 20 in/50 cm.

WARNING

The engine compartment accom-

modates moving components.

Certain components in the engine

compartment can also move with

the vehicle switched off, for

instance the radiator fan. There is

a risk of injury. Do not reach into

the area of moving parts. Keep

articles of clothing and hair away

from moving parts.

WARNING

There are protruding parts, for

instance locking hook, on the

inside of the hood. There is a risk

of injury. If the hood is open, pay

attention to protruding parts and

keep clear of these areas.

WARNING

An incorrectly locked hood can

open while driving and restrict vis-

ibility. There is a risk of an acci-

dent. Stop immediately and

correctly close the hood.

WARNING

Body parts can be jammed when

opening and closing the hood.

There is a risk of injury. Make sure

that the area of movement of the

hood is clear during opening and

closing.

NOTICE

Folded-away wipers can be

jammed when the hood is

opened. There is a risk of damage

to property. Make sure that the

wipers with the wiper blades

mounted are folded down onto the

windshield before opening the

hood.

NOTICE

When the hood is closed, it must

engage on both sides. Pressing

again can damage the hood.

There is a risk of damage to prop-

erty. Open the hood again and

then close it energetically. Avoid

pressing again.

Opening

Closing

287

5-1. MOBILITY

Supra Owner's Manual

5

MOBILITY

The hood must engage on both
sides.

This chapter describes all stan-
dard, country-specific and
optional features offered with
the series. It also describes fea-
tures and functions that are not
necessarily available in your
vehicle, e.g., due to the selected
options or country versions. This
also applies to safety-related
functions and systems. When
using these functions and sys-
tems, the applicable laws and
regulations must be observed.

Depending on the region, many
gas stations sell fuel that has
been customized to winter or
summer conditions. Fuel that is
available in winter,for instance
helps make a cold start easier.

For the best fuel efficiency, the
gasoline should be sulfur-free or
very low in sulfur content.
Fuels that are marked on the
gas pump as containing metal

Operating materials

Vehicle features and
options

Fuel recommendation

General information

Gasoline

General information

288

5-1. MOBILITY

Supra Owner's Manual

must not be used.
Fuels with a maximum ethanol
content of 25 %, i. e. E10 or
E25, may be used for refueling.
Ethanol should meet the follow-
ing quality standards:
US: ASTM 4806–xx
CAN: CGSB-3.511–xx
xx: comply with the current stan-
dard in each case.

Toyota recommends AKI 91.

Toyota recommends AKI 89.
If you use gasoline with this min-

Safety information

WARNING

The use of poor-quality fuels may

result in harmful engine deposits

or damage. Additionally, problems

relating to drivability, starting and

stalling, especially under certain

environmental conditions such as

high ambient temperature and

high altitude, may occur.
If drivability problems are encoun-

tered, we recommend switching

to a high quality gasoline brand

and a higher octane grade - AKI

number - for a few tank fills. To

avoid harmful engine deposits, it

is highly recommended to pur-

chase gasoline from Top Tier

retailers.
Failure to comply with these rec-

ommendations may result in the

need for unscheduled mainte-

nance.

NOTICE

Even small quantities of the

wrong fuel or wrong fuel additives

can damage the fuel system and

engine. Furthermore, the catalytic

converter is permanently dam-

aged. There is a risk of damage to

property. Do not refuel or add the

following in the case of gasoline

engines:
• Leaded gasoline.
Do not press the Start/Stop button

after refueling with the wrong fuel.

Contact your Toyota dealer.

• Metallic additives, for instance

manganese or iron.

NOTICE

Incorrect fuels can damage the

fuel system and the engine. There

is a risk of damage to property. Do

not use fuels with a higher per-

centage of ethanol than recom-

mended. Do not refuel with fuels

containing methanol, e.g. M5 to

M100.

NOTICE

Fuel that does not comply with the

minimum quality can compromise

engine function or cause engine

damage. There is a risk of dam-

age to property. Do not fill with

fuel that does not comply with the

minimum quality.

Recommended fuel grade

Minimum fuel grade

289

5-1. MOBILITY

Supra Owner's Manual

5

MOBILITY

imum AKI Rating, the engine
may produce knocking sounds
when starting at high external
temperatures. This has no effect
on the engine life.

The engine oil consumption is
dependent on your driving style
and driving conditions.
Therefore, regularly check the
engine oil level after refueling by
taking a detailed measurement.
The engine oil consumption can
increase in the following situa-
tions, for example:
• Sporty driving style.
• Break-in of the engine.
• Idling of the engine.
• With use of engine oil types

that are classified as not suit-
able.

Different vehicle messages
appear on the Control Display
depending on the engine oil
level.

The electronic oil measurement
has two measuring principles:
• Monitoring.
• Detailed measurement.
When making frequent
short-distance trips or using a
dynamic driving style, for
instance when taking curves
aggressively, regularly perform
a detailed measurement.

■

Concept

The engine oil level is monitored
electronically while driving and
can be shown on the Control
Display.
If the engine oil level is outside
its permissible operating range,
a vehicle message is displayed.

 A red indicator light indi-

cates that the engine oil pres-
sure is too low.

Engine oil

General information

Safety information

NOTICE

An engine oil level that is too low

causes engine damage. There is

a risk of damage to property.

Immediately add engine oil.

NOTICE

Too much engine oil can damage

the engine or the catalytic con-

verter. There is a risk of damage

to property. Do not add too much

engine oil. When too much engine

oil is added, have the engine oil

level corrected by your Toyota

dealer.

Electronic oil measure-
ment

General information

Monitoring

290

5-1. MOBILITY

Supra Owner's Manual

■

Functional requirements

A current measured value is
available after approx. 30 min-
utes of normal driving.

■

Displaying the engine oil
level

Via Toyota Supra Command:

1

"My Vehicle"

2

"Vehicle status"

3

 "Engine oil level"

The engine oil level is displayed.

■

System limits

When making frequent
short-distance trips or using a
dynamic driving style, it may not
be possible to calculate a mea-
sured value. In this case, the
measured value for the last, suf-
ficiently long trip is displayed.

■

Concept

The engine oil level is checked
when the vehicle is stationary
and displayed via a scale.
If the engine oil level is outside
its permissible operating range,
a vehicle message is displayed.

■

General information

During the measurement, the
idle speed is increased some-
what.

■

Functional requirements

• Vehicle is parked in a horizon-

tal position.

• Selector lever in selector lever

position N or P and accelera-
tor pedal not depressed.

• Engine is running and is at

operating temperature.

■

Performing a detailed mea-
surement

Via Toyota Supra Command:

1

"My Vehicle"

2

"Vehicle status"

3

 "Engine oil level"

4

"Measure engine oil level"

5

"Start measurement"

The engine oil level is checked
and displayed via a scale.

Only add engine oil when the
message is displayed in the
instrument cluster. The quantity
to be added is indicated in the
message shown on the Control
Display.
Only add suitable types of
engine oil, refer to page 291.
Safely park the vehicle and
switch off drive-ready state
before adding engine oil.
Take care not to add too much
engine oil.

Detailed measurement

Adding engine oil

General information

291

5-1. MOBILITY

Supra Owner's Manual

5

MOBILITY

The oil filler neck is located in
the engine compartment, refer
to page 285.

1

Open the hood, refer to page
286.

2

Open the lid counterclock-
wise.

3

Add engine oil.

4

Close the cap.

The engine oil quality is critical
for the life of the engine.
Only add the types of engine oil
which are listed.

Safety information

WARNING

Operating materials, for instance

oils, greases, coolants, fuels, can

contain harmful ingredients.

There is a risk of injuries or dan-

ger to life. Follow the instructions

on the containers. Avoid the con-

tact of articles of clothing, skin or

eyes with operating materials. Do

not refill operating materials into

different bottles. Store operating

materials out of reach of children.

NOTICE

An engine oil level that is too low

causes engine damage. There is

a risk of damage to property.

Immediately add engine oil.

NOTICE

Too much engine oil can damage

the engine or the catalytic con-

verter. There is a risk of damage

to property. Do not add too much

engine oil. When too much engine

oil is added, have the engine oil

level corrected by your Toyota

dealer.

Overview

Adding engine oil

Engine oil types to add

General information

Safety information

NOTICE

Oil additives can damage the

engine. There is a risk of damage

to property. Do not use oil addi-

tives.

NOTICE

Incorrect engine oil can cause

malfunctions in the engine or

damage it. There is a risk of dam-

ageto property. When selecting an

engine oil, make sure that the

engine oil has the correct oil rat-

ing.

292

5-1. MOBILITY

Supra Owner's Manual

Add engine oils that meet the
following oil rating standards:

If an engine oil suitable for con-
tinuous use is not available, up
to 1 US quart/liter of an engine
oil with the following oil rating
can be added:

More information about suitable
oil ratings and viscosity grades
of engine oils can be requested
from your Toyota dealer.

The vehicle manufacturer rec-
ommends that you have your
Toyota dealer change the
engine oil.

Coolant consists of water and
additives.
Not all commercially available
additives are suitable for the
vehicle. Information about suit-
able additives is available from
your Toyota dealer.

Suitable engine oil types

Gasoline engine

TOYOTA GENUINE MOTOR OIL

SN 0W-20 C5 for TOYOTA Supra

Alternative engine oil types

Oil rating

API SL.

API SM.

API SN.

Viscosity grades

Viscosity grades

SAE 0W-20.

SAE 0W-30.

Engine oil change

NOTICE

Engine oil that is not changed in

timely fashion can cause

increased engine wear and thus

engine damage. There is a risk of

damage to property. Do not

exceed the service data indicated

in the vehicle.

Coolant

General information

Safety information

WARNING

With the engine hot and the cool-

ing system open, coolant can

escape and lead to scalding.

There is a risk of injury. Only open

the cooling system with the

engine cooled down.

293

5-1. MOBILITY

Supra Owner's Manual

5

MOBILITY

Vehicles with gasoline engine
feature two cooling circuits.
Always check the coolant levels
of both coolant reservoirs and
refill as needed.
The coolant level is indicated
using maximum markings in the
filler neck of the coolant reser-
voir.
Depending on the engine instal-
lation, the coolant reservoir is
located on the right side or the
left side of the engine compart-
ment, refer to page 285.

1

Let the engine cool.

2

Open the hood, refer to page
286.

3

Turn the lid of the coolant
reservoir slightly counter-
clockwise to allow any
excess pressure to dissi-
pate, then open it.

4

Open the coolant reservoir
lid.

5

The coolant level is correct if
it is just below the max. mark
in the filler neck.

6

Close the cap.

1

Let the engine cool.

2

Open the hood, refer to page
286.

3

Turn the lid of the coolant
reservoir slightly counter-
clockwise to allow any
excess pressure to dissi-
pate, then open it.

4

Open the coolant reservoir
lid.

5

If the coolant is low, slowly
add coolant up to the speci-
fied level; do not overfill.

6

Close the cap.

7

Have the cause of the cool-
ant loss eliminated as soon
as possible.

■

Disposal

WARNING

Additives are harmful and incor-

rect additives can damage the

engine. There is a risk of injury

and risk of damage to property.

Do not allow additives to come

into contact with skin, eyes or arti-

cles of clothing. Use suitable addi-

tives only.

Coolant level

General information

Checking the coolant level

Adding

294

5-1. MOBILITY

Supra Owner's Manual

Comply with the relevant envi-
ronmental protection regulations
when disposing of coolant and
coolant additives.

All washer nozzles are supplied
from one reservoir.
Use a mixture of tap water and
windshield washer concentrate.
If desired, a windshield washer
concentrate containing anti-
freeze can be used.
Recommended minimum fill
quantity:0.2 US gal/1 liter.

The washer fluid reservoir is
located in the engine compart-
ment.

Washer fluid

General information

Safety information

WARNING

Some antifreeze agents can con-

tain harmful substances and are

flammable. There is a risk of fire

and a risk of injury. Follow the

instructions on the containers.

Keep antifreeze away from igni-

tion sources. Do not refill operat-

ing materials into different bottles.

Store operating materials out of

reach of children.
United States: the washer fluid

mixture ratio is regulated by the

U.S. EPA and many individual

states; do not exceed the allow-

able washer fluid dilution ratio lim-

its that apply. Follow the usage

instructions on the washer fluid

container.

WARNING

Washer fluid can ignite and catch

fire on contact with hot engine

parts. There is a risk of injury or

risk of damage to property. Only

add washer fluid when the engine

is cooled down. Next, fully close

the lid of the washer fluid reser-

voir.

NOTICE

Silicon-containing additives in the

washer fluid for the water-repel-

ling effect on the windows can

lead to damage to the washing

system. There is a risk of damage

to property. Do not add sili-

con-containing additives to the

washer fluid.

NOTICE

Mixing different windshield

washer concentrates or antifreeze

can damage the washing system.

There is a risk of damage to prop-

erty. Do not mix different wind-

shield washer concentrates or

antifreeze. Follow the information

and mixing ratios provided on the

containers.

Overview

295

5-1. MOBILITY

Supra Owner's Manual

5

MOBILITY

The use of undiluted windshield
washer concentrate or alco-
hol-based antifreeze can lead to
incorrect readings at tempera-
tures below +5°F/-15°C.

This chapter describes all stan-
dard, country-specific and
optional features offered with
the series. It also describes fea-
tures and functions that are not
necessarily available in your
vehicle, e.g., due to the selected
options or country versions. This
also applies to safety-related
functions and systems. When
using these functions and sys-
tems, the applicable laws and
regulations must be observed.

The maintenance system indi-
cates required maintenance
measures, and thereby provides
support in maintaining road
safety and the operational reli-
ability of the vehicle.
In some cases, scopes and
intervals of the maintenance
system may vary according to
the country version. Replace-
ment work, spare parts, fuels
and lubricants, and wear materi-
als are calculated separately.
Further information is available
from a Toyota dealer.

Malfunction

Maintenance

Vehicle features and
options

Maintenance system

296

5-1. MOBILITY

Supra Owner's Manual

Sensors and special algorithms
take into account the driving
conditions of the vehicle. CBS
uses these to calculate the need
for maintenance.
The system makes it possible to
adapt the amount of mainte-
nance corresponding to your
user profile.

Information on service require-
ments, refer to page 139, can be
displayed on the Control Dis-
play.

Storage periods during which
the vehicle battery was discon-
nected are not taken into
account.
If this occurs, have a Toyota
dealer update the time-depen-
dent maintenance procedures,
such as checking brake fluid
and, if necessary, changing the
engine oil and the microfil-
ter/activated-charcoal filter.

Please consult your "Owner's
Warranty Information Booklet"
or "Owner's Manual Supple-
ment" for additional information
on service requirements.
The manufacturer of your vehi-
cle recommends that mainte-
nance and repair be performed
by a Toyota dealer. Records of
regular maintenance and repair
work should be retained.

Scheduled maintenance should
be performed at specified inter-
vals according to the mainte-
nance schedule.
For details about maintenance
items and schedules, refer to
the "Scheduled Maintenance
Guide" or "Owner's Manual Sup-
plement".

Devices connected to the OBD
socket trigger the alarm system
when the vehicle is locked.
Remove any devices con-
nected at the OBD socket

Condition Based Service
CBS

Concept

General information

Storage periods

"Owner's Warranty Infor-
mation Booklet" or
"Owner's Manual Supple-
ment"

Scheduled maintenance

Socket for OBD Onboard
Diagnosis

General information

297

5-1. MOBILITY

Supra Owner's Manual

5

MOBILITY

before locking the vehicle.

There is an OBD socket on the
driver's side for checking the pri-
mary components in the vehi-
cle's emissions.

Safety information

NOTICE

The socket for Onboard Diagno-

sis is an intricate component

intended to be used in conjunction

with specialized equipment to

check the vehicle’s primary emis-

sions system. Improper use of the

socket for Onboard Diagnosis, or

contact with the socket for

Onboard Diagnosis for other than

its intended purpose, can cause

vehicle malfunctions and creates

risks of personal and property

damage. Given the foregoing, the

manufacture of your vehicle

strongly recommends that access

to the socket for Onboard Diagno-

sis be limited to your Toyota

dealer or other persons that have

the specialized training and

equipment for purposes of prop-

erly utilizing the socket for

Onboard Diagnosis.

Position

Emissions

• The warning light

lights up:

Emissions are deterio-
rating. Have the vehi-
cle checked as soon
as possible.
• The warning light

flashes under certain
circumstances:

This indicates that
there is excessive mis-
firing in the engine.
Reduce the vehicle
speed and have the
system checked imme-
diately; otherwise, seri-
ous engine misfiring
within a brief period
can seriously damage
emission control com-
ponents, in particular
the catalytic converter.

298

5-1. MOBILITY

Supra Owner's Manual

This chapter describes all stan-
dard, country-specific and
optional features offered with
the series. It also describes fea-
tures and functions that are not
necessarily available in your
vehicle, e.g., due to the selected
options or country versions. This
also applies to safety-related
functions and systems. When
using these functions and sys-
tems, the applicable laws and
regulations must be observed.

The onboard vehicle tool kit is
located under a cover on the
right side of the cargo area.
Unlock the cover of the right
side panel, arrow

1

, and fold

open, arrow

2

.

1

To change the wiper blades,
fold up the wiper arms, refer
to page 122.

2

Lift the wiper all the way off of
the windshield.

Replacing components

Vehicle features and
options

Onboard vehicle tool kit

Wiper blades

Safety information

NOTICE

The window may sustain damage

if the wiper falls onto it without the

wiper blade installed. There is a

risk of damage to property. Hold

the wiper firmly when changing

the wiper blade. Do not fold or

switch on the wiper without a

wiper blade installed.

NOTICE

Folded-away wipers can be

jammed when the hood is

opened. There is a risk of damage

to property. Make sure that the

wipers with the wiper blades

mounted are folded down onto the

windshield before opening the

hood.

Replacing the front wiper
blades

299

5-1. MOBILITY

Supra Owner's Manual

5

MOBILITY

3

Press the button, arrow

1

,

and pull out the wiper blade,
arrow

2

.

4

Insert the new wiper blade
and press it on until it you
hear it snap into the holder.

5

Fold down the wipers.

Lights and bulbs make an
essential contribution to vehicle
safety.
All headlights and lights are
made using LED or laser tech-
nology.
Some items of equipment use
light-emitting diodes installed
behind a cover as a light source.
These light-emitting diodes are
related to conventional lasers
and are officially designated as
Class 1 light-emitting diodes.
The manufacturer of the vehicle
recommends that you let your
Toyota dealer perform the work
in case of a malfunction.

Condensation can form on the
inside of the headlight glass in
cool or humid weather. When
driving with the lights switched
on, the condensation evapo-
rates after a short time. The
headlight glass does not need to
be changed.
If despite driving with the head-
lights switched on, increasing
humidity forms, for instance
water droplets in the light, have
the headlights checked.

The battery is maintenance-free.

Lights and bulbs

General information

Safety information

WARNING

Focused laser light can irritate or

permanently damage the retina of

the eye. There is a risk of injury.

The manufacturer of your vehicle

recommends that the work on the

lighting system including bulb

replacement be performed by

your Toyota dealer.

WARNING

Intensive brightness can irritate or

damage the retina of the eye.

There is a risk of injury. Do not

look directly into the headlights or

other light sources. Do not

remove the LED covers.

Headlight glass

Vehicle battery

General information

300

5-1. MOBILITY

Supra Owner's Manual

More information regarding the
battery can be requested from
your Toyota dealer.
The manufacturer of your vehi-
cle recommends that you have
your Toyota dealer register the
vehicle battery to the vehicle
after the battery has been
replaced. Once the battery has
been registered again, all com-
fort features will be available
without restriction and any vehi-
cle messages displayed which
relate to comfort features will
disappear.

The installed battery is designed
specifically for this vehicle. If an
inappropriate battery is used,
operation of the Auto Start Stop
function may be restricted in
order to protect the battery.
Also, the battery may deterio-
rate faster than normal and the
engine may not be able to be
restarted. Contact your Toyota
dealer for details.

Make sure that the battery is
always sufficiently charged to
guarantee that the battery
remains usable for its full ser-
vice life.

The battery may need to be
charged in the following cases:



When making frequent
short-distance drives.



If the vehicle is not used for
more than a month.

When replacing the bat-
tery

Safety information

WARNING

Vehicle batteries that are not com-

patible can damage vehicle sys-

tems and impair vehicle functions.

There is a risk of personal and

property damage. Only vehicle

batteries that are compatible with

your vehicle type should be

installed in your vehicle. Informa-

tion on compatible vehicle batter-

ies is available at your Toyota

dealer.

Charging the battery

General information

A discharged battery is
indicated by a red indi-
cator light.

301

5-1. MOBILITY

Supra Owner's Manual

5

MOBILITY

In the vehicle, only charge the
battery via the starting aid termi-
nals, refer to page 310, in the
engine compartment with the
engine off.

After a power loss, some equip-
ment needs to be newly initial-
ized or individual settings
updated, for example:



Memory function: store the
positions again.



Time: update.



Date: update.

Maintain the battery in an
upright position for transport and

storage. Secure the battery so
that it does not tip over during
transport.

The fuses are located in the
cargo area on the right side
behind a cover.

Unlock the cover of the right
side panel, arrow

1

, and fold

open, arrow

2

.

Information on the fuse types
and locations, as well as the
positions of any other fuse
boxes, is found on a separate
sheet in the fuse box.

Safety information

NOTICE

Battery chargers for the vehicle

battery can work with high volt-

ages and currents, which means

that the 12 volt on-board network

can be overloaded or damaged.

There is a risk of damage to prop-

erty. Only connect battery char-

gers for the vehicle battery to the

starting aid terminals in the

engine compartment.

Starting aid terminals

Power failure

Disposing of old batteries

Have old batteries dis-
posed of by your Toyota
dealer or take them to a
collection point.

Fuses

Safety information

WARNING

Incorrect and repaired fuses can

overload electrical lines and com-

ponents. There is a risk of fire.

Never attempt to repair a blown

fuse. Do not replace a nonworking

fuse with a substitute of another

color or amperage rating.

Accessing the fuses

302

5-1. MOBILITY

Supra Owner's Manual

The vehicle manufacturer rec-

ommends that you have your
Toyota dealer replace the fuses.



BDC



Front



Rear

Replacing fuses

Fuse informations

303

5-1. MOBILITY

Supra Owner's Manual

5

MOBILITY

304

5-1. MOBILITY

Supra Owner's Manual

Symbol Meaning

VSC Vehicle Stability
Control System

Parking brake

Air conditioning

Blower motor, Interior
ventilation

Rear window heating

Seat heating

Seat setting

Crash-security module

Switching center column,
Light switch element,
steering Operating panel
Audio

HiFi amplifier, Video mod-
ule TV

Rear-view mirror

Overhead function cen-
ter, Exterior door handle
electronics

Instrument cluster

Additional battery: Dual
Accumulator System
(DSS)

Fuel pump control elec-
tronics, Natural Vacuum
Leak Detection, Gas gen-
erator for battery safety
terminal, Remote control
receiver

Electric window opener

Heating and air-condi-
tioning system

Vehicle's diagnostic port
(interface)

Interior lights in the boot

Vertical Dynamic platform

Vertical Dynamic platform

Vertical Dynamic platform

Mono Camera (Kafas)

Head Unit

Active Sound Design

USB Hub

Body Domain Controller

Controller (Toyota Supra
Command)

Symbol Meaning

305

5-1. MOBILITY

Supra Owner's Manual

5

MOBILITY

This chapter describes all stan-
dard, country-specific and
optional features offered with
the series. It also describes fea-
tures and functions that are not
necessarily available in your
vehicle, e.g., due to the selected
options or country versions. This
also applies to safety-related
functions and systems. When
using these functions and sys-
tems, the applicable laws and
regulations must be observed.

Electric fan (air cooler),
Controlled differential
lock

12 V socket, Cigarette
lighter

Interior lights in the boot

Door lock, Exterior door
handle electronics,
Telematic Communica-
tion Box

Electronic gear box con-
trol

Telematic Communica-
tion Box, Exterior door
handle electronics

Electric fan, Rear Power
distributor

Engine control

Switching center column,
Light switch element,
Body Domain Controller

Control panels centre
console, Interior light in
the glove box, Interior
light, Interior light in the
sunvisor, Exterior mirror,
Selector lever

Telematic Communica-
tion Box, Exterior door
handle electronics pas-
senger side

Switcher block driver's
door, Exterior mirror

Symbol Meaning

Breakdown assistance

Vehicle features and
options

If a malfunction occurs
while driving

WARNING

If a malfunction occurs while driv-

ing, immediately stop the vehicle

in a safe place.

306

5-1. MOBILITY

Supra Owner's Manual

WARNING

If a warning light illuminates or

flashes, or a warning message is

displayed, immediately stop the

vehicle in a safe place. Do not

open the hood to inspect the

engine, as doing so may lead to

serious injury, such as steam

burns. If a warning message is

displayed, perform the necessary

procedures according to the dis-

played message or explanation in

the owner’s manual.

These warning messages indicate

that a malfunction has occurred in

a system or function of the vehi-

cle. If you continue to drive the

vehicle, the engine may stop sud-

denly, possibly leading to an acci-

dent. Also, even if no warning

lights are illuminated or messages

are displayed, if any abnormal

sounds, smells or vibrations are

detected, or of the engine stops

suddenly, refrain from opening the

hood to inspect the engine and

consult an authorized Toyota

retailer or Toyota authorized

repairer, or any reliable repairer.

WARNING

If you hear a loud noise or feel

something impact the underside

of the vehicle while driving, imme-

diately stop the vehicle in a safe

place.

After stopping the vehicle in a

safe place, check the underside of

the vehicle for any leaking brake

fluid, oil or fuel. If any fluid is leak-

ing, stop driving immediately and

have the vehicle inspected by an

authorized Toyota retailer or Toy-

ota authorized repairer, or any

reliable repairer.

Brake and fuel lines run under the

floor of the vehicle. If any of these

lines are damaged, the brakes

may fail or leaking fuel may ignite

and cause a fire.

WARNING

During normal driving, do not turn

off the engine. Turning the engine

off while driving will not cause loss

of steering or braking control, but

the power assist to these systems

will be lost. This will make it more

difficult to steer and brake, so you

should pull over and stop the

vehicle as soon as it is safe to do

so.

WARNING

While driving, if a tire has been

punctured or has ruptured, firmly

grip the steering wheel, gradually

reduce the vehicle speed and

stop the vehicle in a safe place.

Avoid sudden braking and steer-

ing operations as doing so may

cause you to lose control of the

vehicle. Gradually reduce the

vehicle speed and stop the vehi-

cle in a safe place.

307

5-1. MOBILITY

Supra Owner's Manual

5

MOBILITY

If you have been involved in a
collision, perform the following:

1

Immediately leave the vehi-
cle and move to a safe place
in order to avoid secondary
collisions. Make sure to turn
the engine switch off to help
prevent the vehicle from
catching fire. If the airbags
have deployed (inflated), the
airbag related parts will be
extremely hot. Avoid touching
the parts with your hands or
any part of your body.

2

If someone has been injured,
contact emergency services
and request assistance. If
someone has no obvious
external injuries, but they

may have a head injury, keep
their airway open while mov-
ing them as little as possible.
If there is danger of the vehi-
cle being involved in a sec-
ondary collision, move the
injured person to a safe place
while keeping them as hori-
zontal as possible.

The button is located in the cen-
ter console.
The red light in the button
flashes when the hazard warn-
ing flashers are activated.

WARNING

If you have been involved
in a collision

Hazard warning flashers

308

5-1. MOBILITY

Supra Owner's Manual

1

Unlock the cover, arrow

1

,

and fold open, arrow

2

.

2

Remove the warning triangle.

Contact the roadside assis-
tance if assistance is needed in
the event of a breakdown.

In the event of a breakdown,
data on the vehicle's condition is
transmitted to the roadside

assistance.
Roadside assistance can also
be contacted via a vehicle mes-
sage, refer to page 132.



Active Toyota Supra Connect
contract.



Cellular network reception.



Standby state is switched on.

Via Toyota Supra Command:

1

"Toyota Supra Connect"

2

"Toyota Supra Assistance"

3

"Roadside assistance"

A voice connection is established.

In case of an emergency, an
emergency call can be triggered
automatically by the system or
manually.

Only press the SOS button in an
emergency.
The automatic emergency call
establishes a connection with

Warning triangle

Roadside assistance

Concept

General information

Functional requirements

Starting roadside assis-
tance

Emergency call

Automatic emergency call

Concept

General information

309

5-1. MOBILITY

Supra Owner's Manual

5

MOBILITY

the Toyota Emergency Call Cen-
ter.
For technical reasons, the emer-
gency call cannot be guaran-
teed under unfavorable
conditions.



Active Toyota Supra Connect
contract.



Standby state is switched on.



The automatic emergency call
is functional.



The SIM card integrated in
the vehicle has been acti-
vated.

Under certain conditions, for
instance if the airbags trigger, an
emergency call is automatically
initiated immediately after an
accident of corresponding

severity. Automatic emergency
call is not affected by pressing
the SOS button.

1

Touch the cover.

2

Press and hold the SOS but-
ton until the LED in the area
of the button illuminates
green.



The LED is illuminated green
when an emergency call has
been initiated.

If a cancel prompt appears on the
Control Display, the emergency call
can be aborted.
If the situation allows, wait in your
vehicle until the voice connection
has been established.



The LED flashes green when
a connection to the Toyota
Emergency Call Center has
been established.

The Toyota Emergency Call Center
then makes contact with you and
takes further steps to help you.
Even if you are unable to respond,
the Toyota Emergency Call Center
can take further steps to help you
under certain circumstances.
For this, data is transmitted to the
Toyota Emergency Call Center
which serves to determine the nec-
essary rescue measures. E.g., the
current position of the vehicle, if it
can be established.

Overview

SOS button.

Functional requirements

Automatic triggering

Manual triggering

310

5-1. MOBILITY

Supra Owner's Manual

Even if you can no longer hear the
Toyota Emergency Call Center
through the loudspeakers, the Toy-
ota Emergency Call Center may still
be able to hear you.

The Toyota Emergency Call
Center ends the Emergency
call.

If the battery is discharged, the
engine can be started using the
battery of another vehicle and
two jumper cables. Only use
jumper cables with fully insu-
lated clamp handles.

1

Check whether the battery of
the other vehicle has a volt-
age of 12 volts. The voltage
information can be found on
the battery.

2

Switch off the engine of the
assisting vehicle.

3

Switch off any electronic sys-
tems/power consumers in
both vehicles.

Before you begin, switch off all
unnecessary electronic sys-
tems/power consumers, such as
the radio, on the assisting and
receiving vehicle.

1

Open the cover of the starting
aid terminal.

2

Attach one terminal clamp of
the positive jumper cable to
the positive terminal of the
battery, or to the correspond-
ing starting aid terminal of the
vehicle providing assistance.

3

Attach the terminal clamp on
the other end of the cable to
the positive terminal of the
battery, or to the correspond-

Jump-starting

General information

Safety information

WARNING

Contact with live components can

lead to an electric shock. There is

a risk of injuries or danger to life.

Do not touch any components

that are under voltage.

WARNING

If the jumper cables are con-

nected in the incorrect order,

sparking may occur. There is a

risk of injury. Pay attention to the

correct order during connection.

NOTICE

In the case of body contact

between the two vehicles, a short

circuit can occur during

jump-starting.There is a risk of

damage to property. Make sure

that no body contact occurs.

Preparation

Connecting the cables

311

5-1. MOBILITY

Supra Owner's Manual

5

MOBILITY

ing starting aid terminal of the
vehicle to be started.

4

Attach one terminal clamp of
the negative jumper cable to
the negative terminal of the
battery, or to the correspond-
ing engine or body ground of
assisting vehicle.

5

Attach the second terminal
clamp to the negative termi-
nal of the battery, or to the
corresponding engine or
body ground of the vehicle to
be started.

Never use spray fluids to start
the engine.

1

Start the engine of the assist-
ing vehicle and let it run for
several minutes at an
increased idle speed.

2

Start the engine of the vehicle
that is to be started in the
usual way.

If the first starting attempt is not

successful, wait a few minutes

before making another attempt in

order to allow the discharged bat-

tery to recharge.

3

Let both engines run for sev-
eral minutes.

4

Disconnect the jumper
cables in the reverse order.

Check the battery and recharge,
if needed.

The vehicle is not permitted to
be towed.

Starting the engine

Tow-starting and towing

Safety information

WARNING

Due to system limits, individual

functions can malfunction during

tow-starting/towing with the Toy-

ota Supra Safety systems acti-

vated. There is a risk of an

accident. Switch all Toyota Supra

Safety systems off prior to

tow-starting/towing.

Transporting the vehicle

General information

Safety information

NOTICE

The vehicle can be damaged

when towing the vehicle with a

single lifted axle. There is a risk of

damage to property. The vehicle

should only be transported on a

loading platform.

NOTICE

The vehicle can become dam-

aged when lifting and securing it.
There is a risk of damage to prop-

erty.

●

Lift the vehicle using suitable

means.

●

Do not lift or secure the vehicle

by its tow fitting, body parts, or

suspension parts.

312

5-1. MOBILITY

Supra Owner's Manual

To remove a broken-down vehi-
cle from the danger area, it can
be pushed for a short distance.
Roll or push, refer to page 125,
the vehicle.

The vehicle should only be
transported on a loading plat-
form.

Switch on the hazard warning
system, depending on local reg-
ulations.
If the electrical system has
failed, clearly identify the vehicle
being towed by placing a sign or
a warning triangle in the rear
window.

The tow fittings used should be
on the same side on both vehi-
cles.
Should it prove impossible to
avoid mounting the tow bar at
an offset angle, please follow
the following:



Maneuvering capability is lim-
ited going around corners.



The tow bar will generate lat-
eral forces if it is secured with
an offset.

When starting to tow the vehicle,
make sure that the tow rope is
taut.

Pushing the vehicle

Tow truck

Towing other vehicles

General information

Safety information

WARNING

If the approved gross vehicle

weight of the towing vehicle is

lighter than the vehicle to be

towed, the tow fitting can tear off

or it will not be possible to control

the vehicle's response. There is a

risk of an accident. Make sure

that the gross vehicle weight of

the towing vehicle is heavier than

the vehicle to be towed.

NOTICE

If the tow bar or tow rope is

attached incorrectly, damage to

other vehicle parts can occur.

There is a risk of damage to prop-

erty. Correctly attach the tow bar

or tow rope to the tow fitting.

Tow bar

Tow rope

313

5-1. MOBILITY

Supra Owner's Manual

5

MOBILITY

Use nylon ropes or straps,
which will enable the vehicle to
be towed without jerking.

The screw-in tow fitting should
always be carried in the vehicle.
The tow fitting can be screwed
in at the front or rear of the vehi-
cle.
The tow fitting is found in the
onboard vehicle tool kit, refer to
page 298.



Use only the tow fitting pro-
vided with the vehicle and
screw it all the way in.



Use the tow fitting for towing
on paved roads only.



Avoid lateral loading of the
tow fitting, for instance do not
lift the vehicle by the tow fit-
ting.

Press on the mark on the edge
of the cover to push it out.
For covers which have an open-
ing instead of a marking, pull the
cover out by the opening.

Do not tow-start the vehicle.
Start the engine by jump-start-
ing, refer to page 310, if possi-
ble.
Have the reasons for the start-
ing difficulties corrected by your
Toyota dealer.

Tow fitting

General information

Safety information

NOTICE

If the tow fitting is not used as

intended, there may be damage

to the vehicle or to the tow fitting.

There is a risk of damage to prop-

erty. Follow the notes on using the

tow fitting.

Screw thread for tow fit-
ting

Tow-starting

314

5-1. MOBILITY

Supra Owner's Manual

This chapter describes all stan-
dard, country-specific and
optional features offered with
the series. It also describes fea-
tures and functions that are not
necessarily available in your
vehicle, e.g., due to the selected
options or country versions. This
also applies to safety-related
functions and systems. When
using these functions and sys-
tems, the applicable laws and
regulations must be observed.

Regularly remove foreign
objects such as leaves in the
area below the windshield when
the hood is raised.
Wash your vehicle frequently,
particularly in winter. Intense
soiling and road salt can dam-
age the vehicle.



Maximum temperature: 140
°F/60 °C.



Minimum distance from sen-
sors, cameras, seals: 12 in/30
cm.

Care

Vehicle features and
options

Washing the vehicle

General information

Steam blaster and
high-pressure washer

Safety information

NOTICE

When cleaning with high-pressure

washers, components can be

damaged due to the pressure or

temperatures being too high.

There is a risk of damage to prop-

erty. Maintain sufficient distance

and do not spray too long continu-

ously. Follow the operating

instructions for the high-pressure

washer.

Distances and temperature

Automatic vehicle washes

Safety information

NOTICE

Water can penetrate in the wind-

shield area due to high-pressure

washers. There is a risk of dam-

age to property. Avoid high-pres-

sure washers.

315

5-1. MOBILITY

Supra Owner's Manual

5

MOBILITY

■

Safety information

■

General information

In a vehicle wash, the vehicle
must be able to roll freely.

Roll or push the vehicle, see
page 125.
Some vehicle washes do not
permit persons in the vehicle.
The vehicle cannot be locked
from the outside when in selec-
tor lever position N. A signal
sounds when an attempt is
made to lock the vehicle.

Make sure that the remote con-
trol is in the vehicle.
Switch on drive-ready state,
refer to page 44.

Do not rub wet headlights dry
and do not use abrasive or
acidic cleaning agents.
Soak areas that have been dirt-
ied, for instance from insects,
with shampoo and wash off with
water.
Thaw ice with de-icing spray; do
not use an ice scraper.

After washing the vehicle, apply
the brakes briefly to dry them;
otherwise, braking action can be
reduced. The heat generated
during braking dries brake discs
and brake pads and protects
them against corrosion.
Completely remove all residues

NOTICE

Improper use of automatic vehicle

washes can cause damage to the

vehicle. There is a risk of damage

to property. Follow the following

instructions:

●

Give preference to cloth vehicle

washes or those that use soft

brushes in order to avoid paint

damage.

●

Avoid vehicle washes with

guide rails higher than 4 in/10

cm to avoid damage to the

chassis.

●

Observe the tire width of the

guide rail to avoid damage to

tires and rims.

●

Fold in exterior mirrors to avoid

damage to the exterior mirrors.

●

Deactivate the wiper and, if nec-

essary, rain sensor to avoid

damage to the wiper system.

●

Do not treat the convertible top

with wax. Ensure that a cycle

without wax or a special cycle

for convertibles is available to

avoid damage to the convertible

top.

Driving into a vehicle wash

NOTICE

Selector lever position P is auto-

matically engaged when standby

state is switched off. There is a

risk of damage to property. Do not

switch standby state off in vehicle

washes.

Driving out of a vehicle wash

Headlights

After washing the vehicle

316

5-1. MOBILITY

Supra Owner's Manual

on the windows, to minimize
loss of visibility due to smearing
and to reduce wiper noises and
wiper blade wear.

Regular care contributes to driv-
ing safety and value retention.
Environmental influences in
areas with elevated air pollution
or natural contaminants, such as
tree resin or pollen can affect
the vehicle's paintwork. Tailor
the frequency and extent of your
vehicle care to these influences.
Aggressive substances such as
spilled fuel, oil, grease or bird
droppings, must be removed
immediately to prevent the finish
from being altered or discolored.

Vehicle care

Vehicle care products

Safety information

WARNING

Cleansers can contain sub-

stances that are dangerous and

harmful to your health. There is a

risk of injury. When cleaning the

interior, open the doors or win-

dows. Only use products intended

for cleaning vehicles. Follow the

instructions on the container.

Vehicle paint

General information

Safety information

WARNING

Improperly performed work on the

vehicle paint can lead to a failure

or malfunction of the radar sen-

sors and thereby result in a safety

risk. There is a risk of accidents or

risk of damage to property. Have

paintwork or paintwork repairs on

bumpers of vehicles with radar

sensors performed by your Toyota

dealer only.

NOTICE

■

To prevent paint deteriora-

tion and corrosion on the

body and components (alumi-

num wheels etc.)

Observe the following precau-

tions:

●

Wash the vehicle immediately in

the following cases:

• After driving near the sea coast

• After driving on salted roads

• If coal tar or tree sap is present

on the paint surface

• If dead insects, insect droppings

or bird droppings are present on

the paint surface

• After driving in an area contami-

nated with soot, oily smoke,

mine dust, iron powder or chem-

ical substances

• If the vehicle becomes heavily

soiled with dust or mud

• If liquids such as benzene and

gasoline are spilled on the paint

surface

●

If the paint is chipped or

scratched, have it repaired

immediately.

317

5-1. MOBILITY

Supra Owner's Manual

5

MOBILITY

Only use cleaning and care
products suitable for vehicles
with matte finish.



Working from top to bottom,
liberally apply water to the
vehicle body, wheel wells and
underside of the vehicle to
remove any dirt and dust.



Wash the vehicle body using
a sponge or soft cloth, such
as a chamois.



For hard-to-remove marks,
use a neutral detergent and
rinse thoroughly with water.



Wipe away any water.



Never use wax or abrasive
compounds.

Remove dust from the leather
regularly, using a cloth or vac-
uum cleaner.
Otherwise, particles of dust and
road grime chafe in pores and
folds, and lead to increased
wear and premature degrada-
tion of the leather surface.
To guard against discoloration,

NOTICE

●

To prevent the wheels from cor-

roding, remove any dirt and

store in a place with low humid-

ity when storing the wheels.

Matte finish

NOTICE

■

To prevent paint deteriora-

tion and corrosion on the

body and components (alumi-

num wheels etc.)

Observe the following precau-

tions:

●

Wash the vehicle immediately in

the following cases:

• After driving near the sea coast

• After driving on salted roads

• If coal tar or tree sap is present

on the paint surface

• If dead insects, insect droppings

or bird droppings are present on

the paint surface

• After driving in an area contami-

nated with soot, oily smoke,

mine dust, iron powder or chem-

ical substances

• If the vehicle becomes heavily

soiled with dust or mud

• If liquids such as benzene and

gasoline are spilled on the paint

surface

●

If the paint is chipped or

scratched, have it repaired

immediately.

●

To prevent the wheels from cor-

roding, remove any dirt and

store in a place with low humid-

ity when storing the wheels.

●

If anything is spilled on a

painted surface, wipe it off as

soon as possible. If spilled

washer fluid or alkaline fluids

are left as is, the paint in the

affected areamay deteriorate,

causing blemishing.

●

Do not wax or apply coating to

the vehicle. Doing so may

cause a change in the body sur-

face's texture or irregularities in

the paint.

Leather care

318

5-1. MOBILITY

Supra Owner's Manual

such as from clothing, clean
leather and provide leather care
roughly every two months.
Clean light-colored leather more
frequently because soiling on
such surfaces is substantially
more visible.
Use leather care products; oth-
erwise, dirt and grease will grad-
ually break down the protective
layer of the leather surface.

Vacuum the upholstery regularly
with a vacuum cleaner.
If upholstery is very dirty, for
instance with beverage stains,
use a soft sponge or microfiber
cloth with a suitable interior
cleaner.
Clean the upholstery down to
the seams using large sweeping
motions. Avoid rubbing the
material vigorously.

When cleaning the vehicle, use
only neutral wheel cleaners hav-
ing a pH value from 5 to 9. Do
not use abrasive cleaning
agents or steam jets above 140
°F/60 °C. Follow the manufac-
turer's instructions.
Aggressive, acidic or alkaline
cleaning agents can destroy the
protective layer of adjacent
components, such as the brake
disc.
After cleaning, apply the brakes
briefly to dry them. The heat
generated during braking dries
brake discs and brake pads and
protects them against corrosion.

Carefully clean Chrome sur-
faces, especially in case of
exposure to road salt, with
plenty of water and added
cleanser as needed.

Environmental influences can
cause surface soiling of rubber
parts and a loss of gloss. Use
only water and suitable cleaning
agents for cleaning.
Treat especially worn rubber

Upholstery material care

General information

Safety information

NOTICE

Open Velcro® fasteners on arti-

cles of clothing can damage the

seat covers. There is a risk of

damage to property. Ensure that

any Velcro® fasteners are closed.

Caring for special compo-
nents

Light-alloy wheels

Chrome surfaces

Rubber components

319

5-1. MOBILITY

Supra Owner's Manual

5

MOBILITY

parts with rubber care agents at
regular intervals. When cleaning
rubber seals, do not use any sili-
con-containing vehicle care
products in order to avoid dam-
age or noises.

Plastic components are e.g.:



Imitation leather surfaces.



Roofliner.



Light lenses.



Matt black spray-coated com-
ponents.



Painted parts in the car's inte-
rior.

Clean with a microfiber cloth.
Dampen cloth lightly with water.
Do not soak the roofliner.

Dirty belt straps impede the reel-
ing action and thus have a neg-
ative impact on safety.
Use only a mild soapy solution
for cleaning the installed belt
straps.
Safety belts should only be
allowed to retract if they are dry.

The floor mats can be removed
from the car's interior for clean-
ing.
If the floor carpets are very dirty,

Plastic components

NOTICE

Cleansers that contain alcohol or

solvents, such as lacquer thin-

ners, heavy-duty grease remov-

ers, fuel, or such, can damage

plastic parts. There is a risk of

damage to property. Clean with a

microfiber cloth. Dampen cloth

lightly with water.

Safety belts

WARNING

Chemical cleansers can destroy

the safety belt webbing. Missing

protective effect of the safety

belts. There is a risk of injuries or

danger to life. Use only a mild

soapy solution for cleaning the

safety belts.

Carpets and floor mats

WARNING

Objects in the driver's floor area

can limit the pedal distance or

block a depressed pedal. There is

a risk of an accident. Stow objects

in the vehicle such that they are

secured and cannot enter into the

driver's floor area. Use floor mats

that are suitable for the vehicle

and can be safely attached to the

floor. Do not use loose floor mats

and do not layer several floor

mats. Make sure that there is suf-

ficient clearance for the pedals.

Ensure that the floor mats are

securely fastened again after they

were removed, for instance for

cleaning.

320

5-1. MOBILITY

Supra Owner's Manual

clean with a microfiber cloth and
water or a textile cleaner. To
prevent matting of the carpet,
rub back and forth in the direc-
tion of travel only.

To clean sensors and camera
lenses, use a cloth moistened
with a small amount of glass
detergent.

Clean with a clean, antistatic
microfiber cloth.
Clean the protective glass of the
Head-up Display, refer to page
148, using a microfiber cloth and
commercially available
dish-washing soap.

When the vehicle is shut down
for longer than three months,
special measures must be
taken. Further information is
available from your Toyota
dealer.

Sensor/camera lenses

Displays, screens, and pro-
tective glass of the Head-up
Display

NOTICE

Chemical cleansers, moisture or

fluids of any kind can damage the

surface of displays and screens.

There is a risk of damage to prop-

erty. Clean with a clean, antistatic

microfiber cloth.

NOTICE

The surface of displays can be

damaged with improper cleaning.

There is a risk of damage to prop-

erty. Avoid pressure that is too

high and do not use any scratch-

ing materials.

Long-term vehicle storage

321

Supra Owner's Manual

6

6

REFERENCE

REFERENCE

.

6-1. REFERENCE

Technical data .............

322

Certification .................

324

322

6-1. REFERENCE

Supra Owner's Manual

6-1.REFERENCE

This chapter describes all stan-
dard, country-specific and
optional features offered with
the series. It also describes fea-
tures and functions that are not
necessarily available in your
vehicle, e.g., due to the selected
options or country versions. This
also applies to safety-related
functions and systems. When
using these functions and sys-
tems, the applicable laws and

regulations must be observed.

The technical data and specifi-
cations in this Owner's Manual
are used as guidance values.
The vehicle-specific data can
deviate from this, for instance
due to the selected special
equipment, country version or
country-specific measurement
method. Detailed values can be
found in the approval docu-
ments, on labels on the vehicle
or can be obtained from your
Toyota dealer.

The dimensions can vary depending on the model version, equip-
ment or country-specific measurement method.
The specified heights do not take into account attached parts, for
instance a roof antenna, roof racks or spoiler. The heights can devi-
ate, for instance due to the selected special equipment, tires, load
and chassis version.

*1

:SZ-R models

*2

:RZ models

Technical data

Vehicle features and
options

General information

Dimensions

Width with mirrors

in/mm

79.8 / 2026

Width without mirrors

in/mm

73.0 / 1854

Height

in/mm

51.1 / 1299

*1

50.9 / 1294

*2

Length

in/mm

172.5 / 4381

Wheelbase

in/mm

97.2 / 2470

Smallest turning radius diam.

ft/m

36.1 / 11

323

6-1. REFERENCE

Supra Owner's Manual

6

REFERENCE

Observe further information on fuel quality, refer to page 287.

Weights

SZ-R models

Approved gross vehicle weight

lbs/kg

3770 / 1710

Load

lbs/kg

474 / 215

Approved front axle load

lbs/kg

1819 / 825

Approved rear axle load

lbs/kg

2006 / 910

RZ models

Approved gross vehicle weight

lbs/kg

4001 / 1815

Load

lbs/kg

474 / 215

Approved front axle load

lbs/kg

1907 / 865

Approved rear axle load

lbs/kg

2116 / 960

Capacities

Fuel tank, approx.

US gal/liters

13.7 / 52
