Toyota Mirai (2021 year). Manual in english - part 3

142

4-4. Adjusting the steering wheel and mirrors

Owners Manual_USA_M62102_en

entered to memory and recalled

automatically by the driving position

memory system. (



P.136)

■

Power easy access system (if

equipped)

The steering wheel and driver’s seat

move in accordance with power

switch mode and the driver’s seat

belt condition. (



P.136)

■

After adjusting the steering

wheel (manual adjustment type)

Make sure that the steering wheel is

securely locked.
The horn may not sound if the steer-

ing wheel is not securely locked.

■

Customization

Some functions can be customized.

(



P.500)

Press on or close to the



mark.

WARNING

■

Caution while driving

Do not adjust the steering wheel

while driving.

Doing so may cause the driver to

mishandle the vehicle and cause

an accident, resulting in death or

serious injury.

■

After adjusting the steering

wheel (manual adjustment

type)

Make sure that the steering wheel

is securely locked. Otherwise, the

steering wheel may move sud-

denly, possibly causing an acci-

dent, resulting in death or serious

injury.

Sounding the horn

143

4-4. Adjusting the steering wheel and mirrors

Owners Manual_USA_M62102_en

4

Before

driving

*

: If equipped

The height of the rear view mir-
ror can be adjusted to suit your
driving posture.
Adjust the height of the rear
view mirror by moving it up and
down.



Manual anti-glare inside rear
view mirror

Reflected light from the head-
lights of vehicles behind can be
reduced by operating the lever.

1

Normal position

2

Anti-glare position



Auto anti-glare inside rear
view mirror

Responding to the level of
brightness of the headlights of
vehicles behind, the reflected
light is automatically reduced.
Turn the automatic anti-glare
function mode on/off

When the automatic anti-glare func-
tion is in ON mode, the indicator



illuminates.
The function will set to ON mode
each time the power switch is
turned to ON.
Pressing the button turns the func-
tion to OFF mode. (The indicator

 also turns off.)

Inside rear view mir-

ror

*

The rear view mirror’s posi-
tion can be adjusted to
enable sufficient confirma-
tion of the rear view.

Adjusting the height of
rear view mirror

WARNING

■

Caution while driving

Do not adjust the position of the

mirror while driving.

Doing so may lead to mishandling

of the vehicle and cause an acci-

dent, resulting in death or serious

injury.

Anti-glare function

144

4-4. Adjusting the steering wheel and mirrors

Owners Manual_USA_M62102_en

■

To prevent sensor error (vehi-

cles with an auto anti-glare

inside rear view mirror)

To ensure that the sensors operate

properly, do not touch or cover

them.

*

: If equipped

Digital Rearview Mir-

ror

*

The Digital Rearview Mirror
is a system that uses the
camera on the rear of the
vehicle and displays its
image on the display of the
Digital Rearview Mirror.

The Digital Rearview Mirror
can be changed between
optical mirror mode and dig-
ital mirror mode by operat-
ing the lever.

The Digital Rearview Mirror
allows the driver to see the
rear view despite obstruc-
tions, such as the head
restraints, luggage or rear
sunshade (if equipped)
ensuring rear visibility.
Also, the rear seats are not
displayed and privacy of the
passengers is enhanced.

WARNING

Observe the following precau-

tions.

Failure to do so may result in

death or serious injury.

■

Before using the Digital Rear-

view Mirror

●

Make sure to adjust the mirror

before driving. (



P.146)

• Change to optical mirror mode

and adjust the position of the

Digital Rearview Mirror so that

the area behind your vehicle

can be viewed properly.

145

4-4. Adjusting the steering wheel and mirrors

Owners Manual_USA_M62102_en

4

Before

driving

Camera indicator

Indicates that the camera is operat-
ing normally.

Icon display area

Displays icons, adjusting gauge,
etc. (



P.146)

Select button

Press to change the setting of the
item you want to adjust.

Menu button

Press to display the icon display
area and select the item you want
to adjust.

Lever

Operate to change between digital
mirror mode and optical mirror
mode.

Operate the lever to change
between digital mirror mode and
optical mirror mode.

1

Digital mirror mode

Displays an image of the area
behind the vehicle.

 will illuminate in this mode.

2

Optical mirror mode

Turns off the display of the Digital
Rearview Mirror allows it to be used
as an optical mirror.

■

Digital mirror mode operating

condition

The power switch is turned to ON.

When the power switch is changed

from ON to OFF or ACC, the image

will disappear after several seconds.

■

When using the Digital Rear-

view Mirror in digital mirror

mode

●

If it is difficult the see the rear view

image being displayed due to

water or dust being attached the

camera, operate the rear camera

washer (



P.149). If it is still diffi-

cult to see, change to optical mir-

ror mode.

●

If it is difficult to see the displayed

image due to light reflected off the

Digital Rearview Mirror, the cam-

era being dirty, or if lights of a

vehicle behind your vehicle or the

WARNING

• Change to digital mirror mode

and adjust the display settings.

●

As the range of the image dis-

played by the Digital Rearview

Mirror is different from that of

the optical mirror, make sure to

check this difference before

driving.

System components

Changing modes

146

4-4. Adjusting the steering wheel and mirrors

Owners Manual_USA_M62102_en

displayed image are bothering

you, change to optical mirror

mode.

●

When the trunk is open, the Digital

Rearview Mirror image may not

display properly. Before driving,

make sure the trunk is closed.

●

If the display is difficult to see due

to reflected light, close the elec-

tronic sunshade for the panoramic

moon roof (if equipped).

●

Any of the following conditions

may occur when driving in the

dark, such as at night. None of

them indicates that a malfunction

has occurred.

• Colors of objects in the displayed

image may differ from their actual

color.

• Depending on the height of the

lights of the vehicle behind, the

area around the vehicle may

appear white and blurry.

• Automatic image adjustment for

brighter surrounding image may

cause flickering.

If it is difficult to see the displayed
image or flickering bothers you,
change to optical mirror mode.

●

The Digital Rearview Mirror may

become hot while it is in digital

mirror mode.

This is not a malfunction.

●

Depending on your physical con-

dition or age, it may take longer

than usual to focus on the dis-

played image. In this case,

change to optical mirror mode.

●

Do not let passengers stare at the

displayed image when the vehicle

is being driven, as doing so may

cause motion sickness.

■

When the system malfunctions

If the symbol shown in the illustra-

tion is displayed when using the

Digital Rearview Mirror in digital mir-

ror mode, the system may be mal-

functioning. The symbol will

disappear in a few seconds. Oper-

ate the lever, change to optical mir-

ror mode and have the vehicle

inspected by your Toyota dealer.

■

Adjusting the mirror height

The height of the rear view mir-
ror can be adjusted to suit your
driving posture.
Change to optical mirror mode,
adjusting the height of the rear
view mirror by moving it up and
down.

■

Display settings (digital mir-
ror mode)

Settings of the display in the dig-
ital mirror mode can be
changed.

1

Press the menu button.

Adjusting the mirror

147

4-4. Adjusting the steering wheel and mirrors

Owners Manual_USA_M62102_en

4

Before

driving

The icons will be displayed.

2

Press the menu button
repeatedly and select the
item you want to adjust.

3

Press

 or

 to

change the setting.

The icons will disappear if a button

is not operated for approximately 5

seconds or more.

*

: This is a function for the optical

mirror mode, however, the setting
can also be changed while using
the digital mirror mode.

■

Enabling/disabling the
automatic anti-glare func-
tion (optical mirror mode)

The automatic anti-glare func-
tion in the optical mirror mode
can be enabled/disabled. The
setting can be changed in both
the digital mirror mode and the
optical mirror mode.



When using the digital mirror
mode



P.146

Icons

Settings

Select to adjust the bright-
ness of the display.

Select to adjust the area
displayed up/down.

Select to adjust the area
displayed to the left/right.

Select to adjust the angle of
the displayed image.

Select to zoom in/out the
displayed image.

Select to enable/disable the
automatic anti-glare func-
tion.

*

Responding to the bright-
ness of the headlights of
vehicles behind, the
reflected light is automati-
cally adjusted.
The automatic anti-glare
function is enabled each
time the power switch is
changed to ON.

Select to display Home-
Link

®

 Training Tutorial to

assist customers to train
their Garage Door Opener
System. (



P.373)

Select to change the lan-
guage of the HomeLink

®



Training Tutorial.

Icons

Settings

148

4-4. Adjusting the steering wheel and mirrors

Owners Manual_USA_M62102_en



When using the optical mirror
mode

1

Press the menu button.

The icons will be displayed.

2

Press the menu button

repeatedly and select

.

The setting display will be dis-

played.

3

Press

 or

 to

enable (“ON”)/disable
(“OFF”) the automatic anti-
glare function.

The icons will disappear if a button

is not operated for approximately 5

seconds or more.

■

Adjusting the display (digital

mirror mode)

●

If the displayed image is adjusted,

it may appear distorted. This is not

a malfunction.

●

If the brightness of the Digital

Rearview Mirror is set too high, it

may cause eye strain. Adjust the

Digital Rearview Mirror to an

appropriate brightness. If your

eyes become tired, change to

optical mirror mode.

●

The brightness of the Digital Rear-

view Mirror will change automati-

cally according to the brightness

of the area in front of your vehicle.

■

To prevent the light sensors

from malfunctioning

To prevent the light sensors from

malfunctioning, do not touch or

cover them.

WARNING

Observe the following precau-

tions.

Failure to do so may result in

death or serious injury.

■

While driving

●

Do not adjust the position of the

Digital Rearview Mirror or adjust

the display settings while driv-

ing.

Stop the vehicle and operate

the Digital Rearview Mirror con-

trol switches.

Failure to do so may cause a

steering wheel operation error,

resulting in an unexpected acci-

dent.

●

Always pay attention to the

vehicle’s surroundings.

The size of the vehicles and other
objects may look different when in
digital mirror mode and optical
mirror mode.
When backing up, make sure to
directly check the safety of the
area around your vehicle, espe-
cially behind the vehicle.
Additionally, if a vehicle
approaches from the rear in the
dark, such as at night, the sur-
rounding area may appear dim.

149

4-4. Adjusting the steering wheel and mirrors

Owners Manual_USA_M62102_en

4

Before

driving

■

Cleaning the mirror surface

If the mirror surface is dirty, the
image on the display may be dif-
ficult to see.
Clean the mirror surface gently
using a soft dry cloth.

■

Cleaning the camera

If the camera lens is dirty or cov-
ered with foreign matter, such as
water droplets, snow, mud, etc.,
the displayed image may not be
clear. In this case, rinse the
camera lens with a large quan-
tity of water and then wipe it
clean with a soft cloth damp-
ened with water.
Dirt on the camera lens can be
cleaned by operating the dedi-
cated camera cleaning washer.
(



P.197)

■

The camera

The camera for the Digital Rearview

Mirror is located as shown.

■

Camera cleaning with washer

fluid

●

It may become difficult to see the

rear view of the vehicle due to the

washer fluid which is sprayed

when washing the camera, so

drive while take heed of the sur-

rounding conditions.

●

If washer fluid remains on the

camera lens surface after washing

the camera, it may be difficult to

see the rear view of the vehicle

due to the height and slope of the

head lamps on the vehicle follow-

ing at night. In that case, change

to optical mirror mode.

●

There are cases where even

when the camera is washed it will

not be completed cleaned due to

the dirt. In such cases, rinse off

the camera with large amounts of

water and wipe off the water drop-

lets with soft cloth dampened with

water.

●

Reflective items, such as water,

snow, etc., which are attached in

the vicinity of the camera cannot

be washed as the camera clean-

ing sprays washer fluid to the

camera lens.

WARNING

■

To prevent causes of fire

If the driver continues using the

Digital Rearview Mirror while

smoke or odor comes from the

mirror, it may result in fire. Stop

using the system immediately and

contact your Toyota dealer.

Cleaning the Digital Rear-
view Mirror

NOTICE

■

To prevent the Digital Rear-

view Mirror from malfunction-

ing

●

Do not use detergents, such as

thinner, benzene, and alcohol to

clean the mirror. They may dis-

color, deteriorate or damage the

mirror surface.

150

4-4. Adjusting the steering wheel and mirrors

Owners Manual_USA_M62102_en

NOTICE

●

Do not smoke, use matches,

use cigarette lighters or allow

open flames near the mirror. It

may damage the mirror or

cause a fire.

●

Do not remove, disassemble or

modify the mirror.

■

To prevent the camera from

malfunctioning

●

Observe the following precau-

tions, otherwise the Digital

Rearview Mirror may not oper-

ate properly.

• Do not strike or hit the camera

or subject it to a strong impact,

as the camera installation posi-

tion and angle may be changed.

• Do not remove, disassemble or

modify the camera.

• When washing the camera,

rinse it with a large quantity of

water and then wipe it clean

with a soft cloth dampened with

water.

Do not strongly rub the camera

lens, as it may be scratched and

will not be able to transmit a

clear image.

• Do not allow organic solvent,

car wax, window cleaner or

glass coat to adhere to the cam-

era cover. If this happens, wipe

it off as soon as possible.

• Do not apply hot water to the

camera in cold weather, as the

sudden change of temperature

may cause the camera to not

operate properly.

• When using a high pressure

washer to wash the vehicle, do

not directly spray the camera

and its surrounding area, as

doing so may cause the camera

to not operate properly.

●

Do not subject the camera to a

strong impact as this could

cause a malfunction.

If this happens, have the vehicle

inspected by your Toyota dealer

as soon as possible.

●

Do not block the vent holes of

the mirror. Otherwise, the mirror

may be hot, leading to a mal-

function or a fire.

151

4-4. Adjusting the steering wheel and mirrors

Owners Manual_USA_M62102_en

4

Before

driving

If you notice any of the following symptoms, refer to the following
table for the likely cause and the solution.
If the symptom is not resolved by the solution, have the vehicle
inspected by your Toyota dealer.

If you notice any symptoms

Symptom

Likely cause

Solution

The image is diffi-
cult to see.

The mirror surface is dirty.

Clean the mirror surface
gently, using a soft dry
cloth.

Sunlight or headlights are
shining directly into the Digi-
tal Rearview Mirror.

Change to optical mirror
mode.
(If the light is coming
through the panoramic
moon roof [if equipped]
close the electronic
sunshade.)



The vehicle is in a dark
area.



The vehicle is near a TV
tower, broadcasting sta-
tion, electric power plant,
or other location where
strong radio waves or
electrical noise may be
present.



The temperature around
the camera is extremely
high/low.



The ambient temperature
is extremely low.



It is raining or humid.



Sunlight or headlights are
shining directly into the
camera lens.



The vehicle is under fluo-
rescent lights, sodium
lights, mercury lights, etc.



Water vapor from the tail-
pipe is obstructing the
camera.

Change to optical mirror
mode.
(Change back to digital
mirror mode when the
conditions have
improved.)

152

4-4. Adjusting the steering wheel and mirrors

Owners Manual_USA_M62102_en

The image is diffi-
cult to see.

Foreign matters (such as
water droplets, snow, mud,
etc.) is on the camera lens.



Operate the dedi-
cated camera clean-
ing washer and clean
the camera lens.
(



P.149)



Change to optical mir-
ror mode.



Rinse the camera
with a large quantity
of water, wipe it clean
with a soft cloth
dampened with water,
and then change back
to digital mirror mode.

The image is out of
alignment.

The trunk is not fully closed. Fully close the trunk.

The camera or its surround-
ing area has received a
strong impact.

Change to optical mirror
mode and have the
vehicle inspected by
your Toyota dealer.

The display is dim
and

 is dis-

played.

The system may be mal-
functioning.

Change to optical mirror
mode and have the
vehicle inspected by
your Toyota dealer.

 goes off.

Symptom

Likely cause

Solution

153

4-4. Adjusting the steering wheel and mirrors

Owners Manual_USA_M62102_en

4

Before

driving

 is displayed.

The Digital Rearview Mirror
is extremely hot.
(The display will gradually
become more dim. If the
temperature continues to
increase, the Digital Rear-
view Mirror will turn off.)

Reducing the cabin
temperature is recom-
mended to reduce the
temperature of the mir-
ror.

(

 will disappear

when the mirror
becomes cool.)

If

 does not disap-

pear even though the
mirror is cool, have the
vehicle inspected by
your Toyota dealer.

The lever cannot be
operated properly.

The lever may be malfunc-
tioning.

Change to optical mirror
mode and have the
vehicle inspected by
your Toyota dealer.
(To change to optical
mirror mode, press and
hold the menu button
for approximately 10
seconds.)

Symptom

Likely cause

Solution

154

4-4. Adjusting the steering wheel and mirrors

Owners Manual_USA_M62102_en

1

To select a mirror to adjust,
turn the switch.

Left

Right

2

To adjust the mirror, operate
the switch.

Up

Right

Down

Left

■

Mirror angle can be adjusted

when

The power switch is in ACC or ON.

■

Defogging the mirrors

The outside rear view mirrors can

be cleared using the mirror defog-

gers. Turn on the rear window

defogger to turn on the outside rear

view mirror defoggers. (



P.329,

336)

■

Automatic adjustment of the

mirror angle (if equipped)

A desired mirror face angle can be

entered to memory and recalled

automatically by the driving position

memory. (



P.136)

Outside rear view mir-

rors

The rear view mirror’s posi-
tion can be adjusted to
enable sufficient confirma-
tion of the rear view.

WARNING

■

Important points while driving

Observe the following precautions

while driving.

Failure to do so may result in loss

of control of the vehicle and cause

an accident, resulting in death or

serious injury.

●

Do not adjust the mirrors while

driving.

●

Do not drive with the mirrors

folded.

●

Both the driver and passenger

side mirrors must be extended

and properly adjusted before

driving.

Adjustment procedure

WARNING

■

When the mirror defoggers

are operating

Do not touch the rear view mirror

surfaces, as they can become

very hot and burn you.

155

4-4. Adjusting the steering wheel and mirrors

Owners Manual_USA_M62102_en

4

Before

driving

1

Folds the mirrors

2

Extends the mirrors

Putting the switch in the neutral
position sets the mirrors to auto-
matic mode. Automatic mode
allows the folding or extending of
the mirrors to be linked to lock-
ing/unlocking of the doors.

■

Using automatic mode in cold

weather

When automatic mode is used in

cold weather, the door mirror could

freeze up and automatic stowing

and return may not be possible. In

this case, remove any ice and snow

from the door mirror, then either

operate the mirror using manual

mode or move the mirror by hand.

■

Customization

Some functions can be customized.

(



P.500)

When either “L” or “R” of the mir-
ror select switch is selected, the
outside rear view mirrors will
automatically angle downwards
when the vehicle is reversing in
order to give a better view of the
ground.
To disable this function, select
neither “L” nor “R”.

■

Adjusting the mirror angle
when the vehicle is revers-
ing

With the shift position in R,
adjust the mirror angle at a
desired position.
The adjusted angle will be mem-
orized and the mirror will auto-
matically tilt to the memorized
angle whenever the shift posi-
tion is shifted to R from next
time.

The memorized downward tilt posi-
tion of the mirror is linked to the
normal position (angle adjusted
with the shift position in other than
R). Therefore, if the normal position
is changed after adjustment, the tilt
position will also change.
When the normal position is
changed, readjust the angle in
reversing.

Folding and extending the
mirrors

WARNING

■

When a mirror is moving

To avoid personal injury and mir-

ror malfunction, be careful not to

get your hand caught by the mov-

ing mirror.

Linked mirror function
when reversing

156

4-5. Opening, closing the windows

Owners Manual_USA_M62102_en

4-5.Opening, closing the windows

The power windows can be
opened and closed using the
switches.
Operating the switch moves the
windows as follows:

1

Closing

2

One-touch closing

*

3

Opening

4

One-touch opening

*

*

: To stop the window partway,

operate the switch in the opposite
direction.

■

The power windows can be

operated when

The power switch is in ON

■

Operating the power windows

after turning the fuel cell sys-

tem off

The power windows can be oper-

ated for approximately 45 seconds

even after the power switch is

turned to ACC or turned off. They

cannot, however, be operated once

either front door is opened.

■

Jam protection function

If an object becomes jammed

between the window and the win-

dow frame while the window is clos-

ing, window movement is stopped

and the window is opened slightly.

■

Catch protection function

If an object becomes caught

between the door and window while

the window is opening, window

movement is stopped.

■

When the side window cannot

be opened or closed

When the jam protection function or

catch protection function operates

unusually and the side window can-

not be opened or closed, perform

the following operations with the

power window switch of that door.

●

Stop the vehicle. With the power

switch in ON, within 4 seconds of

the jam protection function or

catch protection function activat-

ing, continuously operate the

power window switch in the one-

touch closing direction or one-

touch opening direction so that the

side window can be opened and

closed.

●

If the side window cannot be

opened and closed even when

performing the above operations,

perform the following procedure

for function initialization.

1

Turn the power switch to ON.

2

Pull and hold the power window

switch in the one-touch closing

direction and completely close

the side window.

3

Release the power window

switch for a moment, resume

pulling the switch in the one-

touch closing direction, and hold

it there for approximately 6 sec-

onds or more.

4

Press and hold the power win-

dow switch in the one-touch

opening direction. After the side

window is completely opened,

continue holding the switch for

an additional 1 second or more.

Power windows

Opening and closing the
power windows

157

4-5. Opening, closing the windows

Owners Manual_USA_M62102_en

4

Before

driving

5

Release the power window

switch for a moment, resume

pushing the switch in the one-

touch opening direction, and

hold it there for approximately 4

seconds or more.

6

Pull and hold the power window

switch in the one-touch closing

direction again. After the side

window is completely closed,

continue holding the switch for a

further 1 second or more.

If you release the switch while the

window is moving, start again from

the beginning.

If the window reverses and cannot

be fully closed or opened, have the

vehicle inspected by your Toyota

dealer.

■

Door lock linked window opera-

tion

●

The power windows can be

opened and closed using the
mechanical key.

*

 (



P.471)

●

The power windows can be

opened using the wireless remote
control.

*

 (



P.121)

*

: These settings must be custom-

ized at your Toyota dealer.

■

Power windows open warning

buzzer

A buzzer sounds and a message is

shown on the multi-information dis-

play in the instrument cluster when

the power switch is turned off and

the driver’s door is opened with the

power windows open.

■

Customization

Some functions can be customized.

(



P.500)

WARNING

Observe the following precau-

tions.

Failure to do so may result in

death or serious injury.

■

Closing the windows

●

The driver is responsible for all

the power window operations,

including the operation for the

passengers. In order to prevent

accidental operation, especially

by a child, do not let a child

operate the power windows. It is

possible for children and other

passengers to have body parts

caught in the power window.

Also, when riding with a child, it

is recommended to use the win-

dow lock switch. (



P.158)

●

Check to make sure that all pas-

sengers do not have any part of

their body in a position where it

could be caught when a window

is being operated.

●

When using the wireless remote

control or mechanical key and

operating the power windows,

operate the power window after

checking to make sure that

there is no possibility of any

passenger having any of their

body parts caught in the win-

dow. Also do not let a child

operate window by the wireless

remote control or mechanical

key. It is possible for children

and other passengers to get

caught in the power window.

●

When exiting the vehicle, turn

the power switch off, carry the

key and exit the vehicle along

with the child. There may be

accidental operation, due to

mischief, etc., that may possibly

lead to an accident.

158

4-5. Opening, closing the windows

Owners Manual_USA_M62102_en

This function can be used to
prevent children from acciden-
tally opening or closing a pas-
senger window.
Press the switch.

The indicator

 will come on and

the passenger windows will be
locked.
The passenger windows can still be
opened and closed using the
driver’s switch even if the lock
switch is on.

■

The power windows can be

operated when

The power switch is in ON.

■

When the 12-volt battery is dis-

connected

The window lock switch is disabled.

If necessary, press the window lock

switch after reconnecting the 12-volt

battery.

WARNING

■

Jam protection function

●

Never use any part of your body

to intentionally activate the jam

protection function.

●

The jam protection function may

not work if something gets

jammed just before the window

is fully closed. Be careful not to

get any part of your body

jammed in the window.

■

Catch protection function

●

Never use any part of your body

or clothing to intentionally acti-

vate the catch protection func-

tion.

●

The catch protection function

may not work if something gets

caught just before the window is

fully opened. Be careful not to

get any part of your body or

clothing caught in the window.

Preventing accidental
operation (window lock
switch)

159

Owners Manual_USA_M62102_en

5

5

Dr

iv

ing

Driving

5-1. Before driving

Driving the vehicle.......

160

Cargo and luggage .....

167

Vehicle load limits .......

169

Trailer towing...............

170

Dinghy towing .............

171

5-2. Driving procedures

Power switch...............

172

Shift position ...............

177

Turn signal lever..........

183

Parking brake..............

184

Brake Hold ..................

187

ASC (Active Sound Control)

..................................

189

Water release (H

2

O switch)

..................................

190

5-3. Operating the lights and

wipers

Headlight switch..........

191

AHB (Automatic High

Beam)........................

193

Windshield wipers and

washer.......................

197

5-4. Refueling

Opening the fuel door .

203

5-5. Using the driving support

systems

Toyota Safety Sense 2.5 +

..................................

207

PCS (Pre-Collision System)

..................................

212

LTA (Lane Tracing Assist)

..................................

223

RSA (Road Sign Assist)

..................................

234

Dynamic radar cruise con-

trol with full-speed range

..................................

237

BSM (Blind Spot Monitor)

..................................

249

Intuitive parking assist.

254

RCTA (Rear Cross Traffic

Alert)..........................

263

RCD (Rear Camera Detec-

tion) ...........................

269

PKSB (Parking Support

Brake)........................

273

Parking Support Brake func-

tion (static objects) ....

278

Parking Support Brake func-

tion (rear-crossing vehi-
cles)...........................

280

Parking Support Brake func-

tion (rear pedestrians)

282

Toyota Teammate Advanced

Park ...........................

284

Driving mode select switch

..................................

314

Snow mode .................

315

Driving assist systems.

316

5-6. Driving tips

Winter driving tips........

321

160

5-1. Before driving

Owners Manual_USA_M62102_en

5-1.Before driving

■

Starting the fuel cell system



P.172

■

Driving

1

With the brake pedal
depressed, shift the shift
position to D.

Check that the shift position indica-

tor shows D.

2

If the parking brake is set,
release the parking brake.
(



P.184)

If the parking brake is in automatic

mode, the parking brake is release

automatically when shifting the shift

lever to any position other than P.

(



P.184)

3

Gradually release the brake
pedal and gently depress the
accelerator pedal to acceler-
ate the vehicle.

■

Stopping

1

Depress the brake pedal.

2

If necessary, set the parking
brake.

If the vehicle is to be stopped for an

extended period of time, shift the

shift position to P. (



P.180)

■

Parking the vehicle

1

Depress the brake pedal to
stop the vehicle completely.

2

If the parking brake is
released, set the parking
brake. (



P.184)

3

Shift the shift position to P.
(



P.180)

Check that the shift position indica-

tor shows P and the parking brake

indicator is illuminated.

4

Press the power switch to
stop the fuel cell system.

5

Slowly release the brake
pedal.

6

Lock the door, making sure
that you have the electronic
key on your person.

If parking on a hill, block the wheels

as needed.

■

Starting off on a steep
uphill

1

Firmly depress the brake
pedal and shift the shift posi-
tion to D.

The hill-start assist control will be

activated.

2

Set the parking brake.
(



P.184)

3

Release the brake pedal and
gently depress the accelera-
tor pedal to accelerate the
vehicle.

4

Release the parking brake.
(



P.184)

When the following unusual

Driving the vehicle

The following procedures
should be observed to
ensure safe driving:

Driving procedure

Sudden start restraint
control (Drive-Start Con-
trol [DSC])

161

5-1. Before driving

Owners Manual_USA_M62102_en

5

Dr

iv

ing

operation is performed with the
accelerator pedal depressed,
the fuel cell system output may
be restrained.
• When the shift lever is shifted

to R

*

.

• When the shift lever is shifted

from P or R to forward drive
shift position such as D

*

.

When the system operates, a mes-
sage appears on the multi-informa-
tion display and head-up display (if
equipped). Read the message and
follow the instruction.

*

: Depending on the situation, the

shift position may not be
changed.

■

For fuel-efficient driving

Keep in mind that fuel cell vehicles

are similar to conventional vehicles,

and it is necessary to refrain from

activities such as sudden accelera-

tion. (



P.88)

■

Driving in the rain

●

Drive carefully when it is raining,

because visibility will be reduced,

the windows may become fogged-

up, and the road will be slippery.

●

Drive carefully when it starts to

rain, because the road surface will

be especially slippery.

●

Refrain from high speeds when

driving on an expressway in the

rain, because there may be a

layer of water between the tires

and the road surface, preventing

the steering and brakes from

operating properly.

■

ECO Accelerator Guidance

(



P.102)

Eco-friendly driving may be

achieved more easily by staying

within the zone of Eco acceleration.

Also, by staying within the zone of

Eco acceleration, it will be easier to

obtain a good Eco score.

●

When starting off:

Gradually depress the accelerator
pedal to stay within the zone of Eco
acceleration and accelerate to the
desired speed. By refraining from
excessive acceleration, a good eco
start score will be obtained.

●

When driving:

After accelerating to the desired
speed, release the accelerator
pedal and drive at a stable speed
while staying within the zone of Eco
acceleration. By staying within the
zone of Eco acceleration, a good
eco cruise score will be obtained.

●

When stopping:

By starting to release the accelera-
tor pedal early before decelerating,
a good eco stop score will be
obtained.

■

Restraining the fuel cell system

output (Brake Override System)

●

When the accelerator and brake

pedals are depressed at the same

time, the fuel cell system output

may be restrained.

●

A warning message is displayed

on the multi-information display

and head-up display (if equipped)

while the system is operating.

(



P.448)

■

Drive-Start Control (DSC)

When the TRAC is turned off

(



P.317), sudden start restraint

control also does not operate. If

your vehicle have trouble escaping

from the mud or fresh snow by oper-

ating sudden start restraint control,

deactivate TRAC (



P.317) so that

the vehicle may become able to

escape from the mud or fresh snow.

162

5-1. Before driving

Owners Manual_USA_M62102_en

■

Breaking in your new Toyota

To extend the life of the vehicle,

observing the following precautions

is recommended:

●

For the first 186 miles (300 km):

Avoid sudden stops.

●

For the first 621 miles (1000 km):

• Do not drive at extremely high

speeds.

• Avoid sudden acceleration.

• Do not drive continuously in low

gears.

• Do not drive at a constant speed

for extended periods.

■

Drum-in-disc type parking

brake system

Your vehicle has a drum-in-disc type

parking brake system. This type of

brake system needs bedding-down

of the brake shoes periodically or

whenever the parking brake shoes

and/or drum are replaced. Have

your Toyota dealer perform the bed-

ding down operation.

■

Operating your vehicle in a for-

eign country

Comply with the relevant vehicle

registration laws and confirm the

availability of the correct fuel.

(



P.485)

WARNING

Observe the following precau-

tions.

Failure to do so may result in

death or serious injury.

■

When starting the vehicle

Always keep your foot on the

brake pedal while stopped with

the “READY” indicator is illumi-

nated. This prevents the vehicle

from creeping.

■

When driving the vehicle

●

Do not drive if you are unfamil-

iar with the location of the brake

and accelerator pedals to avoid

depressing the wrong pedal.

• Accidentally depressing the

accelerator pedal instead of the

brake pedal will result in sudden

acceleration that may lead to an

accident.

• When backing up, you may twist

your body around, leading to dif-

ficulty in operating the pedals.

Make sure to operate the pedals

properly.

• Make sure to keep a correct

driving posture even when mov-

ing the vehicle only slightly. This

allows you to depress the brake

and accelerator pedals properly.

• Depress the brake pedal using

your right foot. Depressing the

brake pedal using your left foot

may delay response in an emer-

gency, resulting in an accident.

●

The driver should pay extra

attention to pedestrians as this

vehicle is powered only by an

electric motor (traction motor).

As there is no engine noise, the

pedestrians may misjudge the

vehicle’s movement. Even with

the acoustic vehicle alerting

system activate, drive with care

as pedestrians in the vicinity

may still not notice the vehicle if

the surrounding area is noisy.

163

5-1. Before driving

Owners Manual_USA_M62102_en

5

Dr

iv

ing

WARNING

●

During normal driving, do not

turn off the fuel cell system.

Turning the fuel cell system off

while driving will not cause loss

of steering or braking control,

however, power assist to the

steering will be lost. This will

make it more difficult to steer

smoothly, so you should pull

over and stop the vehicle as

soon as it is safe to do so.

In the event of an emergency,

such as if it becomes impossible

to stop the vehicle in the normal

way:



P.434

●

Using the brakes continuously

may cause the brakes to over-

heat and lose effectiveness

when driving down a steep hill.

●

Do not adjust the positions of

the steering wheel, the seat, or

the inside or outside rear view

mirrors while driving.

Doing so may result in a loss of

vehicle control.

●

Always check that all passen-

gers’ arms, heads or other parts

of their body are not outside the

vehicle.

●

Do not drive in excess of the

speed limit. Even if the legal

speed limit permits it, do not

drive over 85 mph (140 km/h)

unless your vehicle has high-

speed capability tires. Driving

over 85 mph (140 km/h) may

result in tire failure, loss of con-

trol and possible injury. Be sure

to consult a tire dealer to deter-

mine whether the tires on your

vehicle are high-speed capabil-

ity tires or not before driving at

such speeds.

■

When driving on slippery

road surfaces

●

Sudden braking, acceleration

and steering may cause tire

slippage and reduce your ability

to control the vehicle.

●

Sudden acceleration or regen-

erative braking due to shifting

could cause the vehicle to skid.

●

After driving through a puddle,

lightly depress the brake pedal

to make sure that the brakes

are functioning properly. Wet

brake pads may prevent the

brakes from functioning prop-

erly. If the brakes on only one

side are wet and not functioning

properly, steering control may

be affected.

■

When shifting the shift posi-

tion

●

Do not let the vehicle roll back-

ward while a forward driving

position is selected, or roll for-

ward while the shift position is in

R.

Doing so may result in an acci-

dent or damage to the vehicle.

●

Do not shift the shift position to

P while the vehicle is moving.

Doing so can damage the trans-

mission and may result in a loss

of vehicle control.

●

Do not shift the shift position to

R while the vehicle is moving

forward.

Doing so can damage the trans-

mission and may result in a loss

of vehicle control.

●

Do not shift the shift position to

a driving position while the vehi-

cle is moving backward.

Doing so can damage the trans-

mission and may result in a loss

of vehicle control.

164

5-1. Before driving

Owners Manual_USA_M62102_en

WARNING

●

Changing the shift position to N

while the vehicle is moving will

disengage the fuel cell system.

Regenerative braking is not

available with the fuel cell sys-

tem disengaged.

●

Be careful not to change the

shift position with the accelera-

tor pedal depressed. Changing

the shift position to any posi-

tions other than P or N may lead

to unexpected rapid accelera-

tion of the vehicle that may

cause an accident and result in

death or serious injury.

After changing the shift position,

make sure to confirm the cur-

rent shift position displayed on

the shift position indicator inside

the meter.

■

If you hear a squealing or

scraping noise (brake pad

wear limit indicators)

Have the brake pads checked and

replaced by your Toyota dealer as

soon as possible.

Rotor damage may result if the

pads are not replaced when

needed.

It is dangerous to drive the vehicle

when the wear limits of the brake

pads and/or those of the brake

discs are exceeded.

■

When the vehicle is stopped

●

Do not depress the accelerator

pedal unnecessarily.

If the shift position is in any

position other than P or N, the

vehicle may accelerate sud-

denly and unexpectedly, caus-

ing an accident.

●

In order to prevent accidents

due to the vehicle rolling away,

always keep depressing the

brake pedal while stopped with

the “READY” indicator is illumi-

nated, and apply the parking

brake as necessary.

●

If the vehicle is stopped on an

incline, in order to prevent acci-

dents caused by the vehicle roll-

ing forward or backward, always

depress the brake pedal and

securely apply the parking

brake as needed.

■

When the vehicle is parked

●

Do not leave glasses, cigarette

lighters, spray cans, or soft

drink cans in the vehicle when it

is in the sun.

Doing so may result in the fol-

lowing:

• Gas may leak from a cigarette

lighter or spray can, and may

lead to a fire.

• The temperature inside the

vehicle may cause the plastic

lenses and plastic material of

glasses to deform or crack.

• Soft drink cans may fracture,

causing the contents to spray

over the interior of the vehicle,

and may also cause a short cir-

cuit in the vehicle’s electrical

components.

●

Do not leave cigarette lighters in

the vehicle. If a cigarette lighter

is in a place such as the glove

box or on the floor, it may be lit

accidentally when luggage is

loaded or the seat is adjusted,

causing a fire.

165

5-1. Before driving

Owners Manual_USA_M62102_en

5

Dr

iv

ing

WARNING

●

Do not attach adhesive discs to

the windshield or windows. Do

not place containers such as air

fresheners on the instrument

panel or dashboard. Adhesive

discs or containers may act as

lenses, causing a fire in the

vehicle.

●

Do not leave a door or window

open if the curved glass is

coated with a metallized film

such as a silver-colored one.

Reflected sunlight may cause

the glass to act as a lens, caus-

ing a fire.

●

Always apply the parking brake,

shift the shift position to P, stop

the fuel cell system and lock the

vehicle.

Do not leave the vehicle unat-

tended while the “READY” indi-

cator is illuminated.

If the vehicle is parked with the

shift position in P but the park-

ing brake is not set, the vehicle

may start to move, possibly

leading to an accident.

■

When taking a nap in the vehi-

cle

Always turn the fuel cell system

off. Otherwise, if you accidentally

move the shift lever or depress

the accelerator pedal, causing the

vehicle to unintentionally move,

which can lead to an accident,

resulting in death or serious injury.

■

When braking

●

When the brakes are wet, drive

more cautiously.

Braking distance increases

when the brakes are wet, and

this may cause one side of the

vehicle to brake differently than

the other side. Also, the parking

brake may not securely hold the

vehicle.

●

If the electronically controlled

brake system does not operate,

do not follow other vehicles

closely and avoid hills or sharp

turns that require braking.

In this case, braking is still pos-

sible, but the brake pedal

should be depressed more

firmly than usual. Also, the brak-

ing distance will increase. Have

your brakes fixed immediately.

●

The brake system consists of 2

or more individual hydraulic sys-

tems; if one of the systems fails,

the other(s) will still operate. In

this case, the brake pedal

should be depressed more

firmly than usual and the brak-

ing distance will increase. Have

your brakes fixed immediately.

NOTICE

■

When driving the vehicle

●

Do not depress the accelerator

and brake pedals at the same

time during driving, as this may

restrain the fuel cell system out-

put.

●

Do not use the accelerator

pedal or depress the accelera-

tor and brake pedals at the

same time to hold the vehicle on

a hill.

■

When parking the vehicle

Always set the parking brake, and

shift the shift position to P. Failure

to do so may cause the vehicle to

move or the vehicle may acceler-

ate suddenly if the accelerator

pedal is accidentally depressed.

166

5-1. Before driving

Owners Manual_USA_M62102_en

NOTICE

■

Avoiding damage to vehicle

parts

●

Do not turn the steering wheel

fully in either direction and hold

it there for an extended period

of time.

Doing so may damage the

power steering motor.

●

When driving over bumps in the

road, drive as slowly as possible

to avoid damaging the wheels,

underside of the vehicle, etc.

■

If you get a flat tire while driv-

ing

A flat or damaged tire may cause

the following situations. Hold the

steering wheel firmly and gradu-

ally depress the brake pedal to

slow down the vehicle.

●

It may be difficult to control your

vehicle.

●

The vehicle will make abnormal

sounds or vibrations.

●

The vehicle will lean abnor-

mally.

Information on what to do in case

of a flat tire (



P.457)

■

When encountering flooded

roads

Do not drive on a road that has

flooded after heavy rain, etc.

Doing so may cause the following

serious damage to the vehicle:

●

Fuel cell system stalling

●

Short in electrical components

●

Fuel cell system damage

caused by water immersion

In the event that you drive on a

flooded road and the vehicle is

flooded, be sure to have your Toy-

ota dealer check the following:

●

Fuel cell system

●

Brake function

●

Changes in quantity and quality

of transmission fluid, etc.

●

Lubricant condition for the bear-

ings and suspension joints

(where possible), and the func-

tion of all joints, bearings, etc.

If the shift control system is dam-

aged by flooding, it may not be

possible to shift the shift position

to P, or from P to other positions.

In this case, contact your Toyota

dealer.

167

5-1. Before driving

Owners Manual_USA_M62102_en

5

Dr

iv

ing

Cargo capacity depends on the
total weight of the occupants.
(Cargo capacity) = (Total load
capacity) — (Total weight of
occupants)
Steps for Determining Correct
Load Limit —
(1) Locate the statement “The
combined weight of occupants
and cargo should never exceed
XXX kg or XXX lbs.” on your
vehicle’s placard.
(2) Determine the combined
weight of the driver and passen-
gers that will be riding in your
vehicle.
(3) Subtract the combined
weight of the driver and passen-
gers from XXX kg or XXX lbs.
(4) The resulting figure equals
the available amount of cargo
and luggage load capacity.
For example, if the “XXX”
amount equals 1400 lbs. and
there will be five 150 lb passen-
gers in your vehicle, the amount
of available cargo and luggage
load capacity is 650 lbs. (1400 −

750 (5



 150) = 650 lbs.)

(5) Determine the combined
weight of luggage and cargo
being loaded on the vehicle.
That weight may not safely
exceed the available cargo and
luggage load capacity calcu-
lated in Step 4.
(6) If your vehicle will be towing
a trailer, load from your trailer
will be transferred to your vehi-
cle. Consult this manual to
determine how this reduces the
available cargo and luggage
load capacity of your vehicle.
(



P.169)

Toyota does not recommend towing
a trailer with your vehicle. Your
vehicle is not designed for trailer
towing.

Cargo capacity

Total load capacity (vehicle
capacity weight) (



P.484)

When 2 people with the com-
bined weight of A lb. (kg) are rid-
ing in your vehicle, which has a

Cargo and luggage

Take notice of the following
information about storage
precautions, cargo capacity
and load:

Capacity and distribution

Calculation formula for
your vehicle

168

5-1. Before driving

Owners Manual_USA_M62102_en

total load capacity (vehicle
capacity weight) of B lb. (kg),
the available amount of cargo
and luggage load capacity will
be C lb. (kg) as follows:

B

*2

 lb. (kg) - A

*1

 lb. (kg) = C

*3

 lb.

(kg)

*1

:A =Weight of people

*2

:B =Total load capacity

*3

:C =Available cargo and luggage

load

In this condition, if 3 more passen-
gers with the combined weight of D
lb. (kg) get on, the available cargo
and luggage load will be reduced E
lb. (kg) as follows:

C lb. (kg) - D

*4

 lb. (kg) = E

*5

 lb.

(kg)

*4

:D =Additional weight of people

*5

:E =Available cargo and luggage

load

As shown in the example above,
if the number of occupants
increases, the cargo and lug-
gage load will be reduced by an
amount that equals the
increased weight due to the
additional occupants. In other
words, if an increase in the num-
ber of occupants causes an
excess of the total load capacity
(combined weight of occupants
plus cargo and luggage load),
you must reduce the cargo and
luggage on your vehicle.

WARNING

■

Things that must not be car-

ried in the trunk

The following things may cause a

fire if loaded in the trunk:

●

Receptacles containing gaso-

line

●

Aerosol cans

■

Storage precautions

Observe the following precau-

tions.

Failure to do so may prevent the

pedals from being depressed

properly, may block the driver’s

vision, or may result in items hit-

ting the driver or passengers, pos-

sibly causing an accident.

●

Stow cargo and luggage in the

trunk whenever possible.

●

Do not place cargo or luggage

in or on the following locations.

• At the feet of the driver

• On the front passenger or rear

seats (when stacking items)

• On the package tray

• On the instrument panel

• On the dashboard

●

Secure all items in the occupant

compartment.

■

Capacity and distribution

●

Do not exceed the maximum

axle weight rating or the total

vehicle weight rating.

●

Even if the total load of occu-

pant’s weight and the cargo

load is less than the total load

capacity, do not apply the load

unevenly. Improper loading may

cause deterioration of steering

or braking control which may

cause death or serious injury.

169

5-1. Before driving

Owners Manual_USA_M62102_en

5

Dr

iv

ing

■

Total load capacity and seating

capacity

These details are also described on

the tire and loading information

label. (



P.417)

NOTICE

■

Roof film (vehicles with elec-

tronic sunshade)

Do not attach a roof carrier on the

roof film. It may damage the film

surface.

Vehicle load limits

Vehicle load limits include
total load capacity, seating
capacity, towing capacity
and cargo capacity.



Total load capacity (vehicle
capacity weight):



P.484

Total load capacity means the
combined weight of occu-
pants, cargo and luggage.



Seating capacity:



P.484

Seating capacity means the
maximum number of occu-
pants whose estimated aver-
age weight is 150 lb. (68 kg)
per person.



TWR (Trailer Weight Rat-
ing)

Toyota does not recommend
towing a trailer with your vehi-
cle.



Cargo capacity

Cargo capacity may increase
or decrease depending on the
weight and the number of
occupants.

170

5-1. Before driving

Owners Manual_USA_M62102_en

WARNING

■

Overloading the vehicle

Do not overload the vehicle.

It may not only cause damage to

the tires, but also degrade steer-

ing and braking ability, resulting in

an accident.

Trailer towing

Toyota does not recom-
mend towing a trailer with
your vehicle. Toyota also
does not recommend the
installation of a tow hitch or
the use of a tow hitch carrier
for a wheelchair, scooter,
bicycle, etc. Your vehicle is
not designed for trailer tow-
ing or for the use of tow
hitch mounted carriers.

171

5-1. Before driving

Owners Manual_USA_M62102_en

5

Dr

iv

ing

Dinghy towing

Your vehicle is not designed
to be dinghy towed (with 4
wheels on the ground)
behind a motor home.

NOTICE

■

To avoid serious damage to

your vehicle

Do not tow your vehicle with the

four wheels on the ground.

172

5-2. Driving procedures

Owners Manual_USA_M62102_en

5-2.Driving procedures

1

Pull the parking brake switch
to check that the parking
brake is set. (



P.184)

The parking brake indicator will

come on.

2

Firmly depress the brake
pedal.

 and a message will be dis-

played on the multi-information dis-

play.

If it is not displayed, the fuel cell

system cannot be started.
When the shift position is N, the

fuel cell system cannot start. Shift

the shift position to P when starting

the fuel cell system. (



P.180)

3

Press the power switch
shortly and firmly.

When operating the power switch,

one short, firm press is enough. It is

not necessary to press and hold the

switch.
If the “READY” indicator turns on,

the fuel cell system will operate nor-

mally.
Continue depressing the brake

pedal until the “READY” indicator is

illuminated.
The fuel cell system can be started

from any power switch mode.

4

Check that the “READY” indi-
cator is illuminated.

The vehicle cannot be driven if the

“READY” indicator is off.

■

Starting the fuel cell system in

cold temperatures

●

When the fuel cell system is

started during cold temperatures,

the fuel cell stack quickly warms

up using waste heat during power

generation. Operation noises will

be louder than usually, but this is

not a malfunction. Depending on

the situation, the operation noises

may also continue for a fixed

period of time after the “READY”

indicator turn ON. (



P.75)

●

When the temperatures a cold, it

may take more time than usual

until the “READY” indicator turns

on. In those cases, the progress

state is displayed in the multi-

information display.

“FCV System is Warmed Up
Waiting...”

●

When starting the fuel cell system

during cold weather, “FCV System

Power switch

Performing the following
operations when carrying
the electronic key on your
person starts the fuel cell
system or changes power
switch modes.

Starting the fuel cell sys-
tem

173

5-2. Driving procedures

Owners Manual_USA_M62102_en

5

Dr

iv

ing

Shutdown Due to Freezing Stop in

a Safe Place See Owner’s Man-

ual” may be displayed in the multi-

information display.

The fuel cell system is frozen and
cannot be started. Contact your Toy-
ota dealer.

●

The power output will be tempo-

rarily limited until the fuel cell sys-

tem reaches full operating

temperature.

●

When the traction battery is

extremely cold (below approxi-

mately -22˚F [-30˚C]) under the

influence of outside temperature,

it may not be possible to start the

fuel cell system. In this case, try to

start the fuel cell system again

after the temperature of the trac-

tion battery increases due to the

outside temperature increase etc.

■

If the fuel cell system does not

start

●

The immobilizer system may not

have been deactivated. (



P.69)

Contact your Toyota dealer.

●

If a message related to start-up is

shown on the multi-information

display, read the message and fol-

low the instructions.

●

Check that the fuel door is closed.

When the fuel door is open, the

fuel cell system cannot be started.

Close the fuel door before starting

the system. (



P.205)

■

Sounds and vibrations specific

to a fuel cell vehicle



P.75

■

If the 12-volt battery is dis-

charged

The fuel cell system cannot be

started using the smart key system.

Refer to P.473to restart the fuel cell

system.

■

Electronic key battery depletion



P.118

■

Conditions affecting operation



P.131

■

Notes for the entry function



P.132

■

If “Smart Key System Malfunc-

tion See Owner’s Manual” is

displayed on the multi-informa-

tion display

The system may be malfunctioning.

Have the vehicle inspected by your

Toyota dealer immediately.

■

Steering lock function

●

After turning the power switch off

and opening and closing the

doors, the steering wheel will be

locked due to the steering lock

function. Operating the power

switch again automatically can-

cels the steering lock.

●

When the steering lock cannot be

released, “Push Power Switch

while Turning Steering Wheel in

Either Direction” will be displayed

on the multi-information display.

Press the power switch shortly

and firmly while turning the steer-

ing wheel left and right.

●

To prevent the steering lock motor

from overheating, the motor may

be suspended if the fuel cell sys-

tem is turned on and off repeat-

edly in a short period of time. In

this case, refrain from operating

the power switch. After about 10

seconds, the steering lock motor

will resume functioning.

■

If the “READY” indicator does

not come on

In the event that the “READY” indi-

cator does not come on even after

174

5-2. Driving procedures

Owners Manual_USA_M62102_en

performing the proper procedures

for starting the vehicle, contact your

Toyota dealer immediately.

■

If the fuel cell system is mal-

functioning



P.453

■

Electronic key battery



P.425

■

Operation of the power switch

●

If the switch is not pressed shortly

and firmly, the power switch mode

may not change or the fuel cell

system may not start.

●

If attempting to restart the fuel cell

system immediately after turning

the power switch off, the fuel cell

system may not start in some

cases. After turning the power

switch off, please wait a few sec-

onds before restarting the fuel cell

system.

■

Customization

If the smart key system has been

deactivated in a customized setting,

refer to P.470.

1

Stop the vehicle completely.

2

Set the parking brake.
(



P.184)

3

Shift the shift position to P.
(



P.180)

Check that the shift position indica-

tor shows P and the parking brake

indicator is illuminated.

4

Press the power switch.

The fuel cell system will stop, and

the meter display will be extin-

guished (the shift position indicator

will be extinguished a few seconds

after the meter display).

5

Release the brake pedal and
check that “ACCESSORY” or
“IGNITION ON” is not shown
on the meter.

■

Stopping the fuel cell system in

cold temperatures

●

When the power switch is pressed

and the fuel cell system is stopped

WARNING

■

When starting the fuel cell

system

Always start the fuel cell system

while sitting in the driver’s seat.

Do not depress the accelerator

pedal while starting the fuel cell

system under any circumstances.

Doing so may cause an accident

resulting in death or serious injury.

■

Caution while driving

If fuel cell system failure occurs

while the vehicle is moving, do not

lock or open the doors until the

vehicle reaches a safe and com-

plete stop. The steering lock func-

tion will activate and this may lead

to an accident, resulting in death

or serious injury.

NOTICE

■

When starting the fuel cell

system

If the fuel cell system becomes

difficult to start, have your vehicle

checked by your Toyota dealer

immediately.

■

Symptoms indicating a mal-

function with the power

switch

If the power switch seems to be

operating somewhat differently

than usual, such as the switch

sticking slightly, there may be a

malfunction. Contact your Toyota

dealer immediately.

Stopping the fuel cell sys-
tem

175

5-2. Driving procedures

Owners Manual_USA_M62102_en

5

Dr

iv

ing

during cold temperatures, the time

for water purge from the tailpipe

may be longer than usual to pre-

vent liquid in the fuel cell stack

from freezing.

●

If the “FCV System Purge in Prog-

ress Purge will Stop Automati-

cally” is displayed in the multi-

information display, however it no

problem to exit the vehicle.

●

The water purge time may also be

long if the system is stopped

before fuel cell system warm-up is

completed.

●

It is normal to hear hissing and

other sounds during purge.

(



P.75)

●

It is not a problem to do refueling

operations while the system is

purging.

The purging process is carried out

automatically after several min-

utes and a white mist may be

emitted, however this is not a mal-

function.

■

Parking the vehicle during cold

weather

●

Water may automatically purge

from the tailpipe, even when the

fuel cell system is off, in order to

prevent liquid in the fuel cell stack,

hydrogen pipelines, etc., from

freezing. Also, water vapor may

be purged, but this is not malfunc-

tion.

●

It is normal to hear hissing and

other sounds during purge.

(



P.75)

■

Automatic fuel cell system shut

off feature

●

The vehicle is equipped with a

feature that automatically shuts off

the fuel cell system when the shift

position is in P with the fuel cell

system operating for an extended

period.

●

The fuel cell system will automati-

cally shut off after approximately 1

hour if it has been left running

while the shift position is in P.

●

The timer for the automatic fuel

cell system shut off feature will

reset if the brake pedal is

depressed or if the shift position is

in a position other than P.

●

After the vehicle is parked, if the

door is locked with the door lock

switch (



P.123) from the inside or

the mechanical key from the out-

side, the automatic fuel cell sys-

tem shut off feature will be

disabled. The timer for the auto-

matic fuel cell system shut off fea-

ture will be re-enabled if the

driver’s door is opened.

■

When the shift control system

malfunctions

When attempting to turn the power

switch off while there is a malfunc-

tion in the shift control system, the

power switch mode may change to

ACC. In this case, ACC may be

turned off by applying the parking

brake and pressing the power

switch again.
If there is a malfunction in the sys-

tem, have the vehicle inspected by

your Toyota dealer immediately.

■

Automatic P position selection

function



P.180

■

Water release (H

2

O switch)



P.190

176

5-2. Driving procedures

Owners Manual_USA_M62102_en

Modes can be changed by
pressing the power switch with
the brake pedal released. (The
mode changes each time the
switch is pressed.)

“ACCESSORY”

“IGNITION ON”

1

OFF

The emergency flashers can be
used.

2

ACC

Some electrical components such
as the audio system can be used.
“ACCESSORY” will be displayed
on the meter.

3

ON

All electrical components can be
used.
“IGNITION ON” will be displayed on
the meter.

■

Auto power off function

If the vehicle is left in ACC for more

than 20 minutes or ON (with fuel cell

system not operating) for more than

an hour with the shift position in P,

the power switch will automatically

turn off. However, this function can-

not entirely prevent the 12-volt bat-

tery discharge. Do not leave the

vehicle with the power switch in

ACC or ON for long periods of time

when the fuel cell system is not

operating.

WARNING

■

Stopping the fuel cell system

in an emergency

●

If you want to stop the fuel cell

system in an emergency while

driving the vehicle, press and

hold the power switch for more

than 2 seconds, or press it

briefly 3 times or more in suc-

cession. (



P.434)

However, do not touch the

power switch while driving

except in an emergency. Turn-

ing the fuel cell system off while

driving will not cause loss of

steering or braking control, how-

ever, power assist to the steer-

ing will be lost. This will make it

more difficult to steer smoothly,

so you should pull over and stop

the vehicle as soon as it is safe

to do so.

●

If the power switch is operated

while the vehicle is running, a

warning message will be shown

on the multi-information display

and a buzzer sounds.

●

When restarting the fuel cell

system after an emergency

shutdown, press the power

switch.

Changing power switch
modes

177

5-2. Driving procedures

Owners Manual_USA_M62102_en

5

Dr

iv

ing

Br mode is not a shift position.
(



P.182)

■

For the shift positions

●

When the power switch is off or in

ACC, the shift position cannot be

changed.

●

When the power switch is in ON

(the fuel cell system is not operat-

ing), the shift position can only be

changed to N.

●

When the “READY” indicator is

on, the shift position can be

changed from P to D, N or R.

●

When the “READY” indicator is

flashing, the shift position cannot

be changed from P to another

position even if the shift lever is

operated. Wait until the “READY”

indicator changes from a flashing

to a solid light, and then operate

the shift lever again.

●

The shift position can only be

changed to Br mode directly from

D.

NOTICE

■

To prevent 12-volt battery dis-

charge

●

Do not leave the power switch

in ACC or ON for long periods of

time without the fuel cell system

on.

●

If “ACCESSORY” or “IGNITION

ON” is displayed on the meter,

the power switch is not off. Exit

the vehicle after turning the

power switch off.

Shift position

Select the shift position
depending on your pur-
pose and situation.

Shift position purpose
and functions

Shift posi-

tion

Objective or function

P

Parking the vehi-

cle/starting the fuel cell

system

R

Reversing

N

Neutral

D

Normal driving

178

5-2. Driving procedures

Owners Manual_USA_M62102_en

In addition, if an attempt is made to

change the shift position by moving

the shift lever or by pressing the P

position switch in any of the follow-

ing situations, the buzzer will sound

and the shifting operation will be dis-

abled or the shift position will auto-

matically change to N. When this

happens, select an appropriate shift

position.

●

Situations where the shifting oper-

ation will be disabled:

• When an attempt is made to

change the shift position from P to

other positions by moving the shift

lever without depressing the brake

pedal.

• When the shift lever is moved to

attempt to change the shift posi-

tion from P or N with the accelera-

tor pedal depressed and the

vehicle stopped

• When an attempt is made to

change the shift position from P or

N to Br mode by moving the shift

lever.

• When the P position switch is

pressed while the vehicle is run-
ning.

*1

●

Situations where the shift position

will automatically change to N:

• When an attempt is made to

select the R position by moving

the shift lever when the vehicle is
moving forward.

*2

• When an attempt is made to

select the D position by moving

the shift lever when the vehicle is
moving in reverse.

*3

• When the shift position is changed

from R to Br mode.

●

If N is selected while driving at a

certain speed, even if the shift

lever is not held in the N position,

the shift position changes to N. In

this situation, the buzzer sounds

and a confirmation message is

displayed on the multi-information

display to inform the driver that the

shift position has changed to N.

*1

:Shift position may be changed to

P when driving at extremely low
speeds.

*2

:Shift position may be changed to

R when driving at low speeds.

*3

:Shift position may be changed to

D when driving at low speeds.

■

Reverse warning buzzer

When shifting into R, a buzzer will

sound to inform the driver that the

shift position is in R.

■

When driving with the dynamic

radar cruise control with full-

speed range activated

Even when performing the following

actions with the intent of enabling

regenerative braking, regenerative

braking will not change, because

the dynamic radar cruise control

with full-speed range will not be can-

celed.

●

When switching the driving mode

to sport mode while driving in the

D position (



P.314)

■

Restraining sudden start (Drive-

Start Control)



P.160

■

If a message about a shift oper-

ation is shown

To prevent the shift position from

being selected incorrectly or the

vehicle from moving unexpectedly,

the shift position may be changed

automatically or operating the shift

lever may be required. In this case,

change the shift position following

the messages on the multi-informa-

tion display.

■

After recharging/reconnecting

the 12-volt battery



P.402

■

Customization

Reverse warning buzzer can be

customized. (



P.500)

179

5-2. Driving procedures

Owners Manual_USA_M62102_en

5

Dr

iv

ing

Shift lever

Operate the shift lever gently and
securely in the direction of the
arrow on the shift position indicator.
To shift to N, slide the shift lever in
the direction of the arrow and hold
it.
Release the shift lever after each
shifting operation to allow it to

return to its regular position (

).

Shifting to Br mode is only possible
when the shift position is in D.
When shifting from P to N, D or R,
from N, D, Br mode or R to P, from
D or Br mode to R, or from R to D,
ensure that the brake pedal is being
depressed and the vehicle is sta-
tionary.

Shift position indicator

Meter display:
The current shift position is high-

WARNING

■

When driving on slippery

road surfaces

Do not accelerate or shift the shift

position suddenly.

Sudden changes in regenerative

braking may cause the vehicle to

spin or skid, resulting in an acci-

dent.

NOTICE

■

Situations where shift control

system malfunctions are pos-

sible

If any of the following situations

occurs, shift control system mal-

functions are possible.

Immediately stop the vehicle in a

safe place on level ground, apply

the parking brake, and then con-

tact your Toyota dealer.

●

When the warning message

indicating the shift control sys-

tem appears on the multi-infor-

mation display.

●

The display indicates that no

shift position is selected for

more than a few seconds.

Shifting the shift lever

180

5-2. Driving procedures

Owners Manual_USA_M62102_en

lighted.

P position switch

■

When shifting the shift posi-
tion to P

Fully stop the vehicle and set
the parking brake, and then
press the P position switch.

When the shift position is changed
to P, the switch illuminates.
Check that the shift position indica-
tor shows P.

■

Shifting the shift position
from P to other positions



While depressing the brake
pedal firmly, operate the shift
lever. If the shift lever is oper-
ated without depressing the
brake pedal, the buzzer will
sound and the shifting opera-
tion will be disabled.



When selecting the shift posi-
tion, make sure that the shift
position has been changed to
the desired position by check-
ing the shift position indicator
provided on the instrument
cluster.



The shift position cannot be
changed from P to Br mode
directly.

■

Automatic P position selection

function

In the following situations, the shift

position is automatically changed to

P.

●

When pressing the power switch

with the vehicle stopped while the

power switch is in ON and the shift

position is in a position other than

P (after the shift position has

changed to P, the power switch
will turn off)

*

●

If the driver’s door is opened and

all of the following conditions are

met, while the shift position is in a

position other than P

• The power switch is in ON.

• The driver is not wearing the seat

belt.

• The brake pedal is not depressed.
To start off the vehicle after the shift
position is changed to P, operate the
shift lever again.

WARNING

■

For the shift lever

●

Do not remove the shift lever

knob or use anything but a gen-

uine Toyota shift lever knob.

Also, do not hang anything on

the shift lever.

Doing so could prevent the shift

lever from returning to position,

causing unexpected accidents

to occur when the vehicle is in

motion.

●

In order to prevent the shift

position from accidentally being

changed, do not touch the shift

lever when not using them.

P position switch

181

5-2. Driving procedures

Owners Manual_USA_M62102_en

5

Dr

iv

ing

●

When the vehicle is stopped after

the fuel cell system has been

stopped in an emergency while

driving

●

When voltage of the 12-volt bat-

tery drops while the shift position

is in a position other than P

*

: When the power switch is pressed

while driving at extremely slow
speeds, such as immediately
before stopping the vehicle, the
shift position may automatically
change to P. Make sure that the
vehicle is completely stopped
before pressing the power switch.

■

If the shift position cannot be

shifted from P

There is a possibility that the 12-volt

battery is discharged. Check the 12-

volt battery in this situation.

(



P.473)



Performing the following oper-
ations allows the power
switch to be set to ACC with
the shift position held in N.

1

Operate the shift lever and
change the shift position to N
when the fuel cell system is
operating.

2

Return the shift lever to its

regular position (

).

3

Operate the shift lever to N
and hold it there until the
buzzer sounds.

WARNING

■

P position switch

●

Do not press the P position

switch while the vehicle is mov-

ing.

If the P position switch is

pressed when driving at very

low speeds (for example,

directly before stopping the

vehicle), the vehicle may stop

suddenly when the shift position

switches to P, which could lead

to an accident.

●

In order to prevent the shift

position from accidentally being

changed, do not touch the P

position switch when not using

them.

NOTICE

■

Notes regarding shift lever

and P position switch opera-

tion

Avoid repeatedly operating the

shift lever and P position switch in

quick succession.

The system protection function

may activate and it will not be

temporarily possible to shift the

shift position other than P. If this

happens, please wait for a while

before attempting to change the

shift position again.

■

When exiting the vehicle

(driver’s seat only)

Check that the shift position indi-

cator shows P and that the park-

ing brake indicator is illuminated

before opening the door and exit-

ing the vehicle.

When the power switch is
changed to ACC with the
shift position held in N

182

5-2. Driving procedures

Owners Manual_USA_M62102_en

4

Press the power switch within
5 seconds after the buzzer
sounds.

The power switch will be set to
ACC with the shift position in N.

*



Make sure to check that the buzzer

sounds and “Holding N Push P

Switch When Done” is displayed on

the multi-information display.



To change to a shift position
other than N, press the P
position switch. The shift posi-
tion will be changed to P.



Even if the fuel cell system is
not operating, by operating
the shift lever and the power
switch, the power switch may
be changed to ACC with the
shift position held in N. Make
sure that the fuel cell system
is operating before performing
the operation.

*

: To keep this state, do not operate

the power switch. If the power
switch is operated repeatedly, the
power switch will turn off after the
shift position has automatically
changed to P.

■

Driving mode



P.314

■

Snow mode



P.315

■

Br mode

Suitable for driving that requires
strong deceleration force, such

as down-hill driving, etc.
To select Br mode, shift the shift
lever down.

The Br mode indicator will illumi-
nate on the meter.

To return to normal driving
mode, depress the accelerator
pedal or select the D position
again with the shift lever.

■

Br mode

Depending on the condition of the

traction battery, Br mode may not be

available. In that case, a message is

displayed on the multi-information

display.

■

Sounds when in Br mode



P.75

Selecting the driving
mode

183

5-2. Driving procedures

Owners Manual_USA_M62102_en

5

Dr

iv

ing

1

Right turn

2

Lane change to the right
(move the lever partway and
release it)

The right hand signals will flash 3
times.

3

Lane change to the left
(move the lever partway and
release it)

The left hand signals will flash 3
times.

4

Left turn

■

Turn signals can be operated

when

The power switch is in ON.

■

If the indicator flashes faster

than usual

Check that a light bulb in the front or

rear turn signal lights has not

burned out.

■

If the turn signals stop flashing

before a lane change has been

performed

Operate the lever again.

■

Customization

Some functions can be customized.

(



P.500)

Turn signal lever

Operating instructions

184

5-2. Driving procedures

Owners Manual_USA_M62102_en

■

Using the manual mode

The parking brake can be set
and released manually.

U.S.A.

Canada

1

Pull the switch to set the
parking brake

The parking brake indicator light
will turn on.

Pull and hold the parking brake
switch if an emergency occurs and
it is necessary to operate the park-
ing brake while driving.

2

Push the switch to release
the parking brake

• Operate the parking brake switch

while depressing the brake pedal.

• Using the parking brake auto-

matic release function, the park-
ing brake can be released by
depressing the accelerator pedal.
When using this function, slowly
depress the accelerator pedal.

Make sure that the parking brake
indicator light turn off.

■

Turns automatic mode on

While the vehicle is stopped,
pull and hold the parking brake
switch until a message is shown
on the multi-information display.

“EPB Shift Interlock Function
Activated”

When the automatic mode is
turned on, the parking brake
operates as follows.



When the shift position is
shifted from P, the parking
brake will be released, and
the parking brake indicator
light will turn off.

Parking brake

The parking brake can be
set or released automati-
cally or manually.

In automatic mode, the
parking brake can be set or
released automatically
according to the shift lever
operation. Also, even in
automatic mode, the park-
ing brake can be set or
released manually.

Operating instructions

185

5-2. Driving procedures

Owners Manual_USA_M62102_en

5

Dr

iv

ing



When the shift position is
shifted to P, the parking brake
will be set, and the parking
brake indicator light will turn
on.

Operate the shift lever and P
position switch with the vehicle
stopped and the brake pedal
depressed.

■

Turns automatic mode off

While the vehicle is stopped,
press and hold the parking
brake switch until a message is
shown on the multi-information
display.

“EPB Shift Interlock Function
Deactivated”

Operate the shift lever and P
position switch with the vehicle
stopped and the brake pedal
depressed.

■

Parking brake operation

●

When the power switch is not in

ON, the parking brake cannot be

released using the parking brake

switch.

●

When the power switch is not in

ON, automatic mode (automatic

brake setting and releasing) is not

available.

■

Parking brake automatic

release function

●

When the shift position is shifted

from P, the parking brake will be

released in automatic mode.

●

When all of the following condi-

tions are met in manual mode, the

parking brake can be released by

depressing the accelerator pedal.

• The driver’s door is closed

• The driver is wearing the seat belt

• The shift position is in D or R

■

If “Parking Brake Temporarily

Unavailable” is displayed on

the multi-information display

If the parking brake is operated

repeatedly over a short period of

time, the system may restrict opera-

tion to prevent overheating. If this

happens, refrain from operating the

parking brake. Normal operation will

return after about 1 minute.

■

If “Parking Brake Unavailable”

is displayed on the multi-infor-

mation display

Operate the parking brake switch. If

the message does not disappear

after operating the switch several

times, the system may be malfunc-

tioning. Have the vehicle inspected

by your Toyota dealer.

■

Parking brake operation sound

When the parking brake operates, a

motor sound (whirring sound) may

be heard. This does not indicate a

malfunction.

■

Parking brake operation

●

Depending on the power switch

mode, the parking brake indicator

light will turn on and stay on as

described below:

ON: Comes on until the parking

brake is released.

Not in ON: Stays on for approxi-

mately 15 seconds.

●

When the power switch is turned

off with the parking brake set, the

parking brake indicator light will

stay on for about 15 seconds. This

186

5-2. Driving procedures

Owners Manual_USA_M62102_en

does not indicate a malfunction.

■

When the parking brake switch

malfunctions

Automatic mode (automatic brake

setting and releasing) will be turned

on automatically.

■

Parking the vehicle



P.160

■

Parking brake engaged warning

buzzer

A buzzer will sound if the vehicle is

driven with the parking brake

engaged. “Parking Brake ON” is dis-

played on the multi-information dis-

play. (with the vehicle reached a

speed of 3 mph [5 km/h])

■

If the parking brake indicator

flashes



P.449

■

Usage in winter time



P.321

WARNING

■

When parking the vehicle

Do not leave a child in the vehicle

alone. The parking brake may be

released unintentionally and there

is the danger of the vehicle mov-

ing that may lead to an accident

resulting in death or serious injury.

NOTICE

■

When parking the vehicle

Before you leave the vehicle, set

the parking brake, shift the shift

position to P and make sure that

the vehicle does not move.

■

When the system malfunc-

tions

Stop the vehicle in a safe place

and check the warning messages.

■

When the parking brake can-

not be released due to a mal-

function

Driving the vehicle with the park-

ing brake set will lead to brake

components overheating, which

may affect braking performance

and increase brake wear.
Have the vehicle inspected by

your Toyota dealer immediately if

this occurs.

187

5-2. Driving procedures

Owners Manual_USA_M62102_en

5

Dr

iv

ing

Turns the brake hold system on

The brake hold standby indicator
(green)

 comes on. While the

system is holding the brake, the
brake hold operated indicator (yel-
low)

 comes on.

■

Brake hold system operating

conditions

The brake hold system cannot be

turned on in the following condi-

tions:

●

The driver’s door is not closed.

●

The driver is not wearing the seat

belt.

●

The parking brake is engaged.

If any of the conditions above are

detected when the brake hold sys-

tem is enabled, the system will turn

off and the brake hold standby indi-

cator light will go off. In addition, if

any of the conditions are detected

while the system is holding the

brake, a warning buzzer will sound

and a message will be shown on the

multi-information display. The park-

ing brake will then be set automati-

cally.

■

Brake hold function

●

If the brake pedal is left released

for a period of about 3 minutes

after the system has started hold-

ing the brake, the parking brake

will be set automatically. In this

case, a warning buzzer sounds

and a message is shown on the

multi-information display.

●

To turn the system off while the

system is holding the brake, firmly

depress the brake pedal and

press the button again.

●

The brake hold function may not

hold the vehicle when the vehicle

is on a steep incline. In this situa-

tion, it may be necessary for the

driver to apply the brakes. A warn-

ing buzzer will sound and the

multi-information display will

inform the driver of this situation. If

a warning message is shown on

the multi-information display, read

the message and follow the

instructions.

■

When the parking brake is set

automatically while the system

is holding the brakes

Perform any of the following opera-

tions to release the parking brake.

●

Depress the accelerator pedal.

(The parking brake will not be

released automatically if the seat

belt is not fastened.)

●

Operate the parking brake switch

with the brake pedal depressed.

Brake Hold

The brake hold system
keeps the brake applied
when the shift position is in
D or N with the system on
and the brake pedal has
been depressed to stop the
vehicle. The system
releases the brake when the
accelerator pedal is
depressed with the shift
position in D to allow
smooth start off.

Enabling the system

188

5-2. Driving procedures

Owners Manual_USA_M62102_en

Make sure that the parking brake

indicator light goes off. (



P.184)

■

When an inspection at your

Toyota dealer is necessary

When the brake hold standby indi-

cator (green) does not illuminate

even when the brake hold switch is

pressed with the brake hold system

operating conditions met, the sys-

tem may be malfunctioning. Have

the vehicle inspected at your Toyota

dealer.

■

If “Brake Hold Malfunction

Press Brake to Deactivate Visit

Your Dealer” or “Brake Hold

Malfunction Visit Your Dealer”

is displayed on the multi-infor-

mation display

The system may be malfunctioning.

Have the vehicle inspected by your

Toyota dealer.

■

Warning messages and buzzers

Warning messages and buzzers are

used to indicate a system malfunc-

tion or to inform the driver of the

need for caution. If a warning mes-

sage is shown on the multi-informa-

tion display, read the message and

follow the instructions.

■

If the brake hold operated indi-

cator flashes



P.448

WARNING

■

When the vehicle is on a

steep incline

When using the brake hold sys-

tem on a steep incline exercise

caution. The brake hold function

may not hold the vehicle in such a

situation.

■

When stopped on a slippery

road

The system cannot stop the vehi-

cle when the gripping ability of the

tires has been exceeded. Do not

use the system when stopped on

a slippery road.

NOTICE

■

When parking the vehicle

The brake hold system is not

designed for use when parking

the vehicle for a long period of

time. Turning the power switch off

while the system is holding the

brake may release the brake,

which would cause the vehicle to

move. When operating the power

switch, depress the brake pedal,

shift the shift position to P and set

the parking brake.

189

5-2. Driving procedures

Owners Manual_USA_M62102_en

5

Dr

iv

ing

*

: If equipped

Turns the ASC on/off

When the ASC is on, the indicator
illuminates on the ASC switch.

■

Operating conditions

When the driving mode select

switch is not in Eco drive mode.

■

Temporary cancelation of the

ASC system functions

The ASC system may be temporar-

ily canceled depending on the driv-

ing conditions, such as when the

tires slip due to sudden accelera-

tion.
The tones may not sound if the driv-

ing mode is switched continuously

in short time periods.

ASC (Active Sound

Control)

*

The ASC is a system that
conveys the operating con-
ditions, such as accelera-
tion and deceleration of the
vehicle, with sounds to the
driver. The vehicle’s reac-
tion with regards to the
driver’s acceleration and
brake operations are con-
veyed with sound. The
respective tone changes for
normal mode and sport
mode. (



P.314)

Turning the ASC on/off

190

5-2. Driving procedures

Owners Manual_USA_M62102_en

When the H

2

O switch pressed

while the “READY” indicator is
on, the vehicle purges water.
When the switch is pressed
again, purging stops.

System purging and purging com-
plete messages are displayed in
the multi-information display.

■

Water release function during

cold weather

In the following cases, the fuel cell

system automatic drainage may not

operate. It may not be possible to

start the fuel cell system due to the

fuel cell stack, hydrogen pipes, etc.,

being frozen.

●

When transporting or towing the

vehicle in frozen areas

●

When the 12-volt battery terminals

are disconnected and remain as

such in frozen areas

Operate the water release function
with the following procedure before-
hand to prevent water from freezing
in the system.

1

Turn the power switch to ON and

press the H

2

O switch.

Check that the “Active Purge Mode

ON” message is displayed in the

multi-information display.

2

While depressing the brake,

press the power switch to start

the fuel cell system.

Check that the “READY” indicator

turns on.

3

Press the power switch to stop

the fuel cell system.

The water release is automatically

performed. (Longer than normal

water purge)

■

Purging while parked

The water release function does not

completely prevent purging while

parked. The purge capacity while

parked changes depending on out-

side temperature and operating con-

ditions.
If the “READY” indicator continues

to remain on after water release has

been performed, water may be gen-

erated and purged when parked.

Water release (H

2

O

switch)

When the fuel cell system is
stopped, water is automati-
cally purged from the tail-
pipe.

To minimize water accumu-
lation at parking garages,
etc., purge can be done
manually before parking.

H

2

O switch

191

5-3. Operating the lights and wipers

Owners Manual_USA_M62102_en

5

Dr

iv

ing

5-3.Operating the lights and wipers

Operating the

 switch

turns on the lights as follows:

U.S.A.

Canada

1

 The side marker, parking,

tail, license plate, instrument
panel lights, and daytime run-
ning lights (



P.191) turn on.

2

 The headlights and all

lights listed above (except
daytime running lights) turn
on.

3

 The headlights, daytime

running lights (



P.191) and

all the lights listed above turn
on and off automatically.

4

 (if equipped) Off

■

AUTO mode can be used when

The power switch is in ON.

■

Daytime running light system

●

The daytime running lights illumi-

nate using the same lights as the

parking lights and illuminate

brighter than the parking lights.

(On some models: Using the

same lights as the headlights and

illuminate darker than the head-

lights.)

●

To make your vehicle more visible

to other drivers during daytime

driving, the daytime running lights

turn on automatically when all of

the following conditions are met.

(The daytime running lights are

not designed for use at night.)

• The fuel cell system is operating

• The parking brake is released

• The headlight switch is in the



or

*

 position

*

: When the surroundings are bright

●

The daytime running lights remain

on after they illuminate, even if the

parking brake is set again.

●

For the U.S.A.: Daytime running

lights can be turned off by operat-

ing the switch.

●

Compared to turning on the head-

lights, the daytime running light

system offers greater durability

and consumes less electricity, so

it can help improve fuel economy.

Headlight switch

The headlights can be oper-
ated manually or automati-
cally.

Operating instructions

192

5-3. Operating the lights and wipers

Owners Manual_USA_M62102_en

■

Headlight control sensor

The sensor may not function prop-

erly if an object is placed on the sen-

sor, or anything that blocks the

sensor is affixed to the windshield.

Doing so interferes with the sensor

detecting the level of ambient light

and may cause the automatic head-

light system to malfunction.

■

Automatic light off system

●

When the headlights are on: The
headlights and tail lights turn off
30 seconds after the driver’s door
is opened and closed if the power
switch is turned to ACC or off.
(The lights turn off immediately if

 on the key is pressed after all

the doors are closed.)

●

When only the tail lights are on:

The tail lights turn off automati-

cally if the power switch is turned

to ACC or off and the driver’s door

is opened.

To turn the lights on again, turn the
power switch to ON, or turn the light
switch off once and then back to

 or

.

■

Light reminder buzzer

A buzzer sounds when the power

switch is turned off or turned to ACC

and the driver’s door is opened

while the lights are turned on.

■

Automatic headlight leveling

system (if equipped)

The level of the headlights is auto-

matically adjusted according to the

number of passengers and the load-

ing condition of the vehicle to

ensure that the headlights do not

interfere with other road users.

■

Windshield wiper linked head-

light illumination

When driving during daytime with
the headlight switch turned to

, if

the windshield wipers are used, the
headlights will turn on automatically
after several seconds to help
enhance the visibility of your vehi-
cle.

■

12-volt battery-saving function

In order to prevent the 12-volt bat-

tery of the vehicle from discharging,

if the headlights and/or tail lights are

on when the power switch is turned

off the 12-volt battery saving func-

tion will operate and automatically

turn off all the lights after approxi-

mately 20 minutes. When the power

switch is turned to ON, the 12-volt

battery-saving function will be dis-

abled.

When any of the following are per-

formed, the 12-volt battery-saving

function is canceled once and then

reactivated. All the lights will turn off

automatically 20 minutes after the

12-volt battery-saving function has

been reactivated:

●

When the headlight switch is oper-

ated

●

When a door or the trunk is

opened or closed

■

Customization

Some functions can be customized.

(



P.500)

NOTICE

■

To prevent 12-volt battery dis-

charge

Do not leave the lights on longer

than necessary when the fuel cell

system is off.

193

5-3. Operating the lights and wipers

Owners Manual_USA_M62102_en

5

Dr

iv

ing

1

With the headlights on, push
the lever away from you to
turn on the high beams.

Pull the lever toward you to the
center position to turn the high
beams off.

2

Pull the lever toward you and
release it to flash the high
beams once.

You can flash the high beams with
the headlights on or off.

1

Press the Automatic High
Beam switch.

Turning on the high beam
headlights

AHB (Automatic High

Beam)

The Automatic High Beam
uses a front camera located
behind the upper portion of
the windshield to assess the
brightness of the lights of
vehicles ahead, street-
lights, etc., and automati-
cally turns the high beams
on or off as necessary.

WARNING

■

Limitations of the Automatic

High Beam

Do not overly rely on the Auto-

matic High Beam. Always drive

safely, taking care to observe your

surroundings and turning the high

beams on or off manually if nec-

essary.

■

To prevent incorrect opera-

tion of the Automatic High

Beam system

Do not overload the vehicle.

Activating the Automatic
High Beam

194

5-3. Operating the lights and wipers

Owners Manual_USA_M62102_en

2

Turn the headlight switch to

the

 or

 position.

When the headlight switch lever is

in the low beam position, the AHB

system will be enabled and the

AHB indicator will illuminate.

■

Conditions to turn the high

beams on/off automatically

●

When all of the following condi-

tions are met, the high beams will

be turned on automatically (after

approximately 1 second):

• The vehicle speed is approxi-

mately 21 mph (34 km/h) or more.

• The area ahead of the vehicle is

dark.

• There are no vehicles ahead with

headlights or tail lights turned on.

• There are few streetlights on the

road ahead.

●

If any of the following conditions

are met, the high beams will turn

off automatically:

• The vehicle speed is below

approximately 17 mph (27 km/h).

• The area ahead of the vehicle is

not dark.

• Vehicles ahead have their head-

lights or tail lights turned on.

• There are many streetlights on the

road ahead.

■

Front camera detection infor-

mation

●

The high beams may not be auto-

matically turned off in the following

situations:

• When a vehicle suddenly appears

from around a curve

• When the vehicle is cut in front of

by another vehicle

• When vehicles ahead cannot be

detected due to repeated curves,

road dividers or roadside trees

• When vehicles ahead appear in a

faraway lane on a wide road

• When the lights of vehicles ahead

are not on

●

The high beams may be turned off

if a vehicle ahead that is using fog

lights without its headlights turned

on is detected.

●

House lights, street lights, traffic

signals, and illuminated billboards

or signs and other reflective

objects may cause the high

beams to change to the low

beams, or the low beams to

remain on.

●

The following factors may affect

the amount of time taken for the

high beams to turn on or off:

• The brightness of the headlights,

fog lights, and tail lights of vehi-

cles ahead

• The movement and direction of

vehicles ahead

• When a vehicle ahead only has

operational lights on one side

• When a vehicle ahead is a two-

wheeled vehicle

• The condition of the road (gradi-

ent, curve, condition of the road

surface, etc.)

• The number of passengers and

amount of luggage in the vehicle

●

The high beams may turn on or off

unexpectedly.

●

Bicycles or similar vehicles may

not be detected.

●

In the following situations the sys-

tem may not be able to correctly

detect the surrounding brightness

level. This may cause the low

beams to remain on or the high

beams to flash or dazzle pedestri-

ans or vehicles ahead. In such a

case, it is necessary to manually

switch between the high and low

beams.

195

5-3. Operating the lights and wipers

Owners Manual_USA_M62102_en

5

Dr

iv

ing

• When driving in inclement weather

(heavy rain, snow, fog, sand-

storms, etc.)

• When the windshield is obscured

by fog, mist, ice, dirt, etc.

• When the windshield is cracked or

damaged

• When the front camera is

deformed or dirty

• When the temperature of the front

camera is extremely high

• When the surrounding brightness

level is equal to that of headlights,

tail lights or fog lights

• When headlights or tail lights of

vehicles ahead are turned off,

dirty, changing color, or not aimed

properly

• When the vehicle is hit by water,

snow, dust, etc., from a preceding

vehicle

• When driving through an area of

intermittently changing brightness

and darkness

• When frequently and repeatedly

driving ascending/descending

roads, or roads with rough, bumpy

or uneven surfaces (such as

stone-paved roads, gravel roads,

etc.)

• When frequently and repeatedly

taking curves or driving on a wind-

ing road

• When there is a highly reflective

object ahead of the vehicle, such

as a sign or mirror

• When the back of a preceding

vehicle is highly reflective, such as

a container on a truck

• When the vehicle’s headlights are

damaged or dirty, or are not aimed

properly

• When the vehicle is listing or titling

due to a flat tire, a trailer being

towed, etc.

• When the headlights are changed

between the high beams and low

beams repeatedly in an abnormal

manner

• When the driver believes that the

high beams may be flashing or

dazzling pedestrians or other driv-

ers

■

Temporarily lowering sensor

sensitivity

The sensitivity of the sensor can be

temporarily lowered.

1

Turn the power switch off while

the following conditions are met.

●

The headlight switch is in

 or

.

●

The headlight switch lever is in

low beam position.

●

Automatic High Beam switch is

on.

2

Turn the power switch to ON.

3

Within 60 seconds after step

2

,

repeat pushing the headlight

switch lever to the high beam

position then pulling it to the orig-

inal position quickly 10 times,

then leave the lever in the origi-

nal position.

4

If the sensitivity is changed, the

AHB indicator is turn on and off 3

times.

■

Switching to the high
beams

Push the lever away from you.

The AHB indicator will turn off and
the high beam indicator will turn on.
Pull the lever to its original position
to activate the Automatic High
Beam system.

Turning the high beams
on/off manually

196

5-3. Operating the lights and wipers

Owners Manual_USA_M62102_en

■

Switching to the low beams

Press the Automatic High Beam
switch.

The AHB indicator will turn off.
Press the switch to activate the
Automatic High Beam system
again.

■

Temporarily switching to
the low beams

Pull the lever toward you and
then return it to its original posi-
tion.

The high beams are on while the
lever is pulled toward you. How-
ever, after the lever is returned to its
original position, the low beams
remain on for a certain period of
time. Afterwards, the Automatic
High Beam system will be activated
again.

■

Temporarily switching to the

low beams

It is recommended to switch to the

low beams when the high beam

may cause problems or distress to

other drivers or pedestrians nearby.

197

5-3. Operating the lights and wipers

Owners Manual_USA_M62102_en

5

Dr

iv

ing

Operate the

 lever oper-

ates the wipers or washer as fol-
lows:



Intermittent windshield wip-
ers with interval adjuster

When intermittent windshield
wiper operation is selected, the
wiper interval can be also
adjusted.

1

 (U.S.A.) or



(Canada)
Off

2

 (U.S.A.) or

 (Can-

ada)
Intermittent operation

3

 (U.S.A.) or

 (Can-

ada)
Low speed wiper operation

4

 (U.S.A.) or

 (Can-

ada)
High speed wiper operation

5

 (U.S.A.) or

 (Can-

ada)
Temporary operation

Wiper intervals can be adjusted
when intermittent operation is
selected.

6

Increases the intermittent
windshield wiper frequency

7

Decreases the intermittent
windshield wiper frequency

Windshield wipers and

washer

Operating the lever can
switch between automatic
operation and manual oper-
ation, or can use the
washer.

NOTICE

■

When the windshield is dry

Do not use the wipers, as they

may damage the windshield.

Operating the wiper lever

198

5-3. Operating the lights and wipers

Owners Manual_USA_M62102_en

8

 Washer/wiper dual

operation

Pulling the lever operates the wip-
ers and washer.
(After operating several times, the
wipers operate once more time
after a short delay to prevent drip-
ping. However, the dripping preven-
tion does not operate while the
vehicle is moving.)



Rain-sensing windshield wip-
ers

When

 is selected, the wip-

ers will operate automatically
when the sensor detects falling
rain. The system automatically
adjusts wiper timing in accor-
dance with rain volume and
vehicle speed.

1

 (U.S.A.) or

 (Canada)

Off

2

 Rain-sensing wiper oper-

ation

The wipers will operate automati-
cally when the sensor detects fall-
ing rain. The system automatically
adjusts wiper timing in accordance
with rain volume and vehicle speed.

3

 (U.S.A.) or

 (Canada)

Low speed wiper operation

4

 (U.S.A.) or

 (Canada)

High speed wiper operation

5

 (U.S.A.) or

 (Canada)

Temporary operation

When

 is selected, the sen-

sor sensitivity can be adjusted
by turning the switch ring.

199

5-3. Operating the lights and wipers

Owners Manual_USA_M62102_en

5

Dr

iv

ing

6

Increases the sensitivity

7

Decreases the sensitivity

8

 Washer/wiper dual

operation

Pulling the lever operates the wip-
ers and washer.
(After operating several times, the
wipers operate once more time
after a short delay to prevent drip-
ping. However, the dripping preven-
tion does not operate while the
vehicle is moving.)

9

*

 Rear camera washer

operation

Pushing the lever operates the rear
camera washer and cleans the rear
camera and the camera for the Dig-
ital Rearview Mirror.

*

: Vehicles with Digital Rearview

Mirror

■

The windshield wiper and

washer can be operated when

The power switch is in ON.

■

Effects of vehicle speed on

wiper operation (vehicles with

rain-sensing windshield wipers)

Even when the wipers are not in

AUTO mode, vehicle speed affects

the time until the drip prevention

wiper sweep occurs.
With low speed windshield wiper

operation selected, wiper operation

will be switched from low speed to

intermittent wiper operation only

when the vehicle is stationary.

(However, when the sensor sensitiv-

ity is adjusted to the highest level,

the mode cannot be switched.)

■

Raindrop sensor (vehicles with

rain-sensing windshield wipers)

●

The raindrop sensor judges the

amount of raindrops.

An optical sensor is adopted. It

may not operate properly when

sunlight from the rising or setting

of the sun intermittently strikes the

windshield, or if bugs, etc., are

present on the windshield.

●

If the wiper is turned to AUTO

mode while the power switch is in

ON, the wipers will operate once

to show that AUTO mode is acti-

vated.

●

If the temperature of the raindrop

sensor is 185°F (85°C) or higher,

or 5°F (-15°C) or lower, automatic

operation may not occur. In this

case, operate the wipers in any

mode other than AUTO mode.

200

5-3. Operating the lights and wipers

Owners Manual_USA_M62102_en

■

If no windshield washer fluid

sprays

Check that the washer nozzles are

not blocked if there is washer fluid in

the windshield washer fluid reser-

voir.

■

Front door opening linked wind-

shield wiper stop function

(vehicles with rain-sensing

windshield wipers)

When

 is selected and the wind-

shield wipers are operating, if a front
door is opened while the vehicle is
stopped and the P shift position is
selected, operation of the wind-
shield wipers will be stopped to pre-
vent anyone near the vehicle from
being sprayed by water from the
wipers. When the front door is
closed, wiper operation will resume.

■

When stopping fuel cell system

in an emergency while driving

If the windshield wipers are operat-

ing when fuel cell system is

stopped, the windshield wipers will

operate in high speed operation.

After the vehicle is stopped, opera-

tion will return to normal when the

power switch is turned to ON, or

operation will stop when the driver’s

door is opened.

When the windshield wipers are
not being used, they retract to
below the hood. To enable the
windshield wipers to be lifted

WARNING

■

Caution regarding the use of

windshield wipers in AUTO

mode (vehicles with rain-

sensing windshield wipers)

The windshield wipers may oper-

ate unexpectedly if the sensor is

touched or the windshield is sub-

ject to vibration in AUTO mode.

Take care that your fingers or any-

thing else do not become caught

in the windshield wipers.

■

Caution regarding the use of

washer fluid

When it is cold, do not use the

washer fluid until the windshield

becomes warm. The fluid may

freeze on the windshield and

cause low visibility. This may lead

to an accident, resulting in death

or serious injury.

NOTICE

■

When there is no washer fluid

spray from the nozzle

Damage to the washer fluid pump

may be caused if the lever is

pulled toward you and held con-

tinually.

■

When a nozzle becomes

blocked

In this case, contact your Toyota

dealer.

Do not try to clear it with a pin or

other object. The nozzle will be

damaged.

Changing the windshield
wiper rest position/Lifting
the windshield wipers

201

5-3. Operating the lights and wipers

Owners Manual_USA_M62102_en

5

Dr

iv

ing

when parking in cold conditions
or when replacing a windshield
wiper insert, change the rest
position of the windshield wipers
to the service position using the
wiper lever.

■

Raising the wipers to the
service position

Within approximately 45 sec-
onds of turning the power switch
off, move the wiper lever to the

 (U.S.A.) or

 (Canada)

position and hold it for approxi-
mately 2 seconds or more.

The wipers will move to the service
position.

■

Lifting the windshield wip-
ers

While holding the hook portion

 of the wiper arm, lift the wind-

shield wiper from the wind-

shield.

■

Lowering the windshield wipers

to the retracted position

With the windshield wipers placed

on the windshield, turn the power

switch to ON and then move the

wiper lever to an operating position.

When the wiper switch is turned off,

the windshield wipers will stop at the

retracted position. Even if the wipers

deviate while the power switch is off,

the wipers will return to the normal

position.

NOTICE

■

When lifting the windshield

wipers

●

Do not lift the windshield wipers

when they are in the retracted

position below the hood. Other-

wise, they may contact the

hood, possibly resulting in dam-

age to a windshield wiper and/or

the hood.

●

Do not lift a windshield wiper by

the wiper blade. Otherwise, the

wiper blade may be deformed.

202

5-3. Operating the lights and wipers

Owners Manual_USA_M62102_en

NOTICE

●

Do not operate the wiper lever

when the windshield wipers are

lifted. Otherwise, the wind-

shield wipers may contact the

hood, possibly resulting in dam-

age to the windshield wipers

and/or hood.

203

5-4. Refueling

Owners Manual_USA_M62102_en

5

Dr

iv

ing

5-4.Refueling



Close the all the doors and
windows.



Set the parking brake.



Shift the shift position to P.



Turn the power switch off.



Turn off the headlights.

■

Fuel types



P.485

■

Notes on fueling

●

Fueling will not be possible if the

pressure inside the vehicle’s

hydrogen tanks is higher than the

supply pressure of the hydrogen

station. If the hydrogen tanks are

more than half full, the vehicle will

be unable to fuel at a H35 dis-

penser. A hydrogen station with a

H70 dispenser (supply pressure of
10150 psi) [70 MPa, 714 kgf/cm

2

,

700 bar] is necessary to com-

pletely fill hydrogen tanks.

●

If the fueling cannot be completed

due to trouble with the station

equipment, call the number indi-

cated on the equipment.

Opening the fuel door



Fuel with compressed
hydrogen gas only at hydro-
gen stations.



Fuel at hydrogen stations
conforming with the Society
of Automotive Engineers
(SAE) J2601 fueling proto-
col or laws that may super-
sede such SAE protocols.



Refer to the Mirai Station
Finder Application in Con-
nected services,
https://www.toyota.com/
connected-services/ (for
U.S. owners) or
https://www.toyota.ca/toy-
ota/en/about/connected-ser-
vices (for Canadian
owners), or call 1-800-331-
4331 (for U.S. owners) or 1-
888-869-6828 (for Cana-
dian owners).



Observe any notices or
instructions shown at hydro-
gen stations.



The filling time and amount
of fuel may depend on out-
side temperature and the
equipment at that hydrogen
station.



Vehicles with expired hydro-
gen tanks must not be used.
Check P.80 to learn how
and when to check the expi-
ration. Consult your Toyota
dealer.

Before filling

WARNING

■

When filling

Observe the following precautions

while fueling the vehicle. Failure

to do so may result in death or

serious injury.

204

5-4. Refueling

Owners Manual_USA_M62102_en

1

Press the opener switch.

If the “READY” indicator is on or the

power switch is in ON, the fuel door

WARNING

●

Turn the power switch off before

fueling.

●

Ensure the hydrogen gas noz-

zle is locked onto the vehicle

receptacle before filling. This

can be done by pulling on the

hydrogen gas nozzle to check

that it cannot be pulled off. Fail-

ure to do so may result in injury

or damage to the hydrogen gas

nozzle or vehicle.

●

Do not smoke while fueling.

●

Because the fuel is cold, the

hydrogen gas nozzle and vehi-

cle receptacle surface will

become cold, and frost may

develop. After fueling is com-

pleted, remove the hydrogen

gas nozzle by the plastic handle

only. Do not touch any other

parts of the hydrogen gas noz-

zle or vehicle receptacle with

bare hands immediately after

fueling, as frostbite may occur.

NOTICE

■

When filling

●

Fuel only with compressed

hydrogen gas at stations com-

pliant with the Society of Auto-

motive Engineers (SAE) J2601

fueling protocol or laws that may

supersede such SAE protocols.

If improper fuels are used, the

fuel cell stack will be damaged.

●

Do not swing or drop the hydro-

gen gas nozzle, or subject it to a

large amount of force. Doing so

may cause damage.

●

If the hydrogen gas nozzle can-

not be removed after fueling, it

may be frozen to the vehicle

receptacle. Wait for the hydro-

gen gas nozzle to thaw before

attempting to remove. Do not

pull or rotate the hydrogen gas

nozzle forcibly. Failure to follow

these precautions may cause

damage.

●

Be sure to replace the cap after

filling. If foreign material gets in

the vehicle receptacle, it may

cause damage.

●

Do not put anything sharp, such

as a screwdriver, blade, or any

foreign object into the opening

of the vehicle receptacle. If the

vehicle receptacle is damaged,

hydrogen gas may leak during

fueling.

●

If you notice anything unusual

about the vehicle receptacle,

please notify your Toyota

dealer.

●

If you notice anything unusual

with the hydrogen dispenser or

hydrogen gas nozzle, please

notify the hydrogen station

operator. Contact information is

usually displayed on the dis-

penser.

Opening the fuel door

205

5-4. Refueling

Owners Manual_USA_M62102_en

5

Dr

iv

ing

will not be unlocked.

2

Remove the cap and attach it
to the holder.

■

If “Stop in a Safe Place Turn

Power OFF Open Hydrogen

Filler Door” is displayed on the

multi-information display

Stop the vehicle in a safe place and

press the fuel door opener switch

once more with the following proce-

dure:

1

Shift the shift position to P.

2

Turn the power switch off.

3

Press the fuel door opener

switch.

■

Sounds during filling

When fueling with compressed

hydrogen gas, noises from gas flow-

ing through the hydrogen gas noz-

zle and hydrogen tank valves can

sometimes be heard. (



P.75)

1

Replace the cap.

2

Close the fuel door.

■

Error operation prevention

function

When the fuel door is open, the fuel

cell system will not start. When the

“READY” indicator is on, the fuel

door will not open.

■

If “Open Filler Door Detected

Stop in a Safe Place Close

Hydrogen Filler Door” is dis-

played on the multi-information

display

The fuel door is open. Stop the vehi-

cle in a safe place and close the fuel

door.

■

If “Open Filler Door Detected

Close Hydrogen Filler Door

Restart Vehicle” is displayed on

the multi-information display

The fuel door is open and the fuel

cell system cannot be started. Shift

the shift position to P and, turn the

power switch off, then:

Closing the fuel door
