Toyota Land Cruiser (2021 year). Manual in english - part 7

400

5-1. Using the air conditioning system and defogger

LC200_OM_OM60T03U_(U)

■

Defogging the rear window and outside rear view mirrors

Defoggers are used to defog the rear window, and to remove rain-
drops, dew and frost from the outside rear view mirrors.

Press

.

Press the switch again to turn the defogger off.

■

Micro dust and pollen filter

Press

 on the control screen.

Press

.

Outside air mode switches to recirculated air mode. Pollen is removed
from the air and the air flows to the upper part of the body.
Usually the system will turn off automatically approximately 1 to 3 min-
utes.
To stop the operation, press

 again.

■

Windshield wiper de-icer (if equipped)

This  feature  is  used  to  prevent  ice  from  building  up  on  the  wind-
shield and wiper blades.

Press

 on the control screen.

Press

.

Press

 again to turn the de-icer off.

1

2

1

2

LC200_OM_OM60T03U_(U)

401

5-1. Using the air conditioning system and defogger

5

In

te

rior

fe

at

ures

■

Location of air outlets

The  air  outlets  and  air  volume
changes  according  to  the
selected air flow mode.

■

Adjusting  the  air  flow  direction  and  opening/closing  the  air
outlets

Direct air flow to the left or right, up or down.
Turn the knob to open or close the vent.

Air outlets



Front outlets



Rear outlets

1
2

402

5-1. Using the air conditioning system and defogger

LC200_OM_OM60T03U_(U)

■

Using automatic mode

Fan speed is adjusted automatically according to the temperature setting and
the ambient conditions.
Therefore, the fan may stop for a while until warm or cool air is ready to flow

immediately after

 is pressed.

■

Fogging up of the windows

●

The  windows  will  easily  fog  up  when  the  humidity  in  the  vehicle  is  high.
Turning “A/C” on will dehumidify the air from the outlets and defog the wind-
shield effectively.

●

If you turn “A/C” off, the windows may fog up more easily.

●

The windows may fog up if the recirculated air mode is used.

■

When driving on dusty roads

Close all windows. If dust thrown up by the vehicle is still drawn into the vehi-
cle after closing the windows, it is recommended that the air intake mode be
set to outside air mode and the fan speed to any setting except off.

■

Outside/recirculated air mode

●

Setting to the recirculated air mode temporarily is recommended in prevent-
ing dirty air from entering the vehicle interior and helping to cool the vehicle
when the outside air temperature is high.

●

Outside/recirculated  air  mode  may  automatically  switch  depending  on  the
temperature setting or the inside temperature.

■

When outside air temperature is low

The dehumidification function may not operate even when “A/C” is pressed.

■

When the outside temperature exceeds 75°F (24°C) and the air condition-
ing system is on

●

In order to reduce the air conditioning power consumption, the air condition-
ing system may switch to recirculated air mode automatically. This may also
reduce fuel consumption.

●

Recirculated air mode is selected as a default mode when the engine switch
is turned to IGNITION ON mode.

●

It  is  possible  to  switch  to  outside  air  mode  at  any  time  by  pressing

.

LC200_OM_OM60T03U_(U)

403

5-1. Using the air conditioning system and defogger

5

In

te

rior

fe

at

ures

■

Micro dust and pollen filter

●

In order to prevent the windows from fogging up when the outside air is cold,
the following may occur.
• Outside air mode does not switch to recirculated air mode.
• The dehumidification function operates.
• The operation cancels after approximately 1 minute.

●

In rainy weather, the windows may fog up. Press

.

●

In extremely humid weather, the windows may fog up.

●

The pollens are filtered out even if the micro dust and pollen filter is turned
off.

■

Ventilation and air conditioning odors

●

To let fresh air in, set the air conditioning system to the outside air mode.

●

During use, various odors from inside and outside the vehicle may enter into
and accumulate in the air conditioning system. This may then cause odor to
be emitted from the vents.

●

To reduce potential odors from occurring:
• It is recommended that the air conditioning system be set to outside air

mode prior to turning the vehicle off.

• The start timing of the blower may be delayed for a short period of time

immediately  after  the  air  conditioning  system  is  started  in  automatic
mode.

■

The  rear  window  defogger  and  windshield  wiper  de-icer  (if  equipped)
can be operated when

The engine switch is in IGNITION ON mode.

■

When the windshield wiper de-icer (if equipped) is on

The windshield wiper de-icer will automatically turn off after approximately 15
minutes.

■

Using the voice command system

Air conditioning system can be operated using voice commands. For details,
refer to the “NAVIGATION SYSTEM OWNER’S MANUAL”.

■

While the cool box is on (if equipped)

The front air conditioning system cannot be turned off.

■

Air conditioning filter



P. 497

404

5-1. Using the air conditioning system and defogger

LC200_OM_OM60T03U_(U)

■

Air conditioning system refrigerant

●

The meaning of each symbol on the label are as follows:

■

Customization

Settings (e.g. A/C automatic mode switch operation) can be changed.
(Customizable features:



P. 594)

●

A  label  regarding  the  refrigerant  of  the
air conditioning system is attached to the
hood at the location shown in the follow-
ing illustration.

Caution

Air conditioning system

Air conditioning system lubricant type

Requires registered technician to ser-
vice air conditioning system

Flammable refrigerant

LC200_OM_OM60T03U_(U)

405

5-1. Using the air conditioning system and defogger

5

In

te

rior

fe

at

ures

WARNING

■

To prevent the windshield from fogging up

●

Do  not  use

  during  cool  air  operation  in  extremely  humid

weather. The  difference  between  the  temperature  of  the  outside  air  and
that of the windshield can cause the outer surface of the windshield to fog
up, blocking your vision.

■

To prevent burns

●

Do not touch the rear view mirror surfaces when the outside rear view mir-
ror defoggers are on.

●

Do not touch the glass at lower part of the windshield or to the side of the
front pillars when the windshield wiper de-icer is on. (vehicles with wind-
shield wiper de-icer)

NOTICE

■

To prevent battery discharge

Do not leave the air conditioning system on longer than necessary when the
engine is not running.

■

When repairing/replacing parts of the air conditioning system

Have repair/replacement performed by your Toyota dealer. When a part of
the  air  conditioning  system,  such  as  the  evaporator,  is  to  be  replaced,  it
must be replaced with a new one.

●

Do not place anything on the instrument
panel  which  may  cover  the  air  outlets.
Otherwise,  air  flow  may  be  obstructed,
preventing  the  windshield  defoggers
from defogging.

406

LC200_OM_OM60T03U_(U)

5-1. Using the air conditioning system and defogger

Rear air conditioning system

■

Adjusting the temperature setting

Press “



” to increase the temperature and “



” to decrease the tem-

perature on

.

The temperature for the right-hand and left-hand seats can be set sepa-
rately.

■

Adjusting the fan speed setting

Press “



” (increase) or “



” (decrease) on

.

The fan speed is shown on the display. (7 levels)

Press

to turn the fan off.

Air outlets and fan speed are automatically adjusted according
to the temperature setting.

LC200_OM_OM60T03U_(U)

407

5-1. Using the air conditioning system and defogger

5

In

te

rior

fe

at

ures

■

Changing the air flow mode

Press

.

The  air  flow  mode  switches
each time the button is pressed.

Air flows to the upper body
Air  flows  to  the  upper  body
and feet
Air flows to the feet

1
2

3

408

5-1. Using the air conditioning system and defogger

LC200_OM_OM60T03U_(U)

■

Using the automatic mode

Press

.

Adjust the temperature setting.

To stop the operation, press

.

■

If the system is operated manually in automatic mode

If the fan speed setting or air flow modes are operated, the auto-
matic mode indicator goes off. However, automatic mode for func-
tions other than that operated is maintained.

■

Location of air outlets

The  air  outlets  and  air  volume
changes  according  to  the
selected air flow mode.

■

Adjusting the position of and opening and closing the air out-
lets

Direct  air  flow  to  the  left  or
right, up or down.
Turn  the  knob  fully  to  the
back  of  the  vehicle  to  close
the vent.

Air conditioning controls

Air outlets

1

2

3

1

2

LC200_OM_OM60T03U_(U)

409

5-1. Using the air conditioning system and defogger

5

In

te

rior

fe

at

ures

NOTICE

■

To prevent battery discharge

Do not leave the air conditioning system on longer than necessary when the
engine is not running.

410

LC200_OM_OM60T03U_(U)

5-1. Using the air conditioning system and defogger

Heated steering wheel



/seat heaters/seat

ventilators



: If equipped

Heated steering wheel and seat heaters heat the side grips of the
steering wheel and seats. Seat ventilators maintain good airflow
by blowing air from the seats.

WARNING

●

Care should be taken to prevent injury if anyone in the following categories
comes in contact with the steering wheel and seats when the heater is on:
• Babies,  small  children,  the  elderly,  the  sick  and  the  physically  chal-

lenged

• Persons with sensitive skin
• Persons who are fatigued
• Persons who have taken alcohol or drugs that induce sleep (sleeping

drugs, cold remedies, etc.)

●

Observe the following precautions to prevent the minor burns or overheat-
ing:
• Do  not  cover  the  seat  with  a  blanket  or  cushion  when  using  the  seat

heater.

• Do not use seat heater more than necessary.

NOTICE

●

Do not put heavy objects that have an uneven surface on the seat and do
not stick sharp objects (needles, nails, etc.) into the seat.

●

To prevent battery discharge, do not use the functions when the engine is
not running.

LC200_OM_OM60T03U_(U)

411

5-1. Using the air conditioning system and defogger

5

In

te

rior

fe

at

ures

Turns  the  heated  steering  wheel
on/off

The indicator light comes on when
the heated steering wheel is oper-
ating.

●

The heated steering wheel can be used when the engine switch is in IGNI-
TION ON mode.

●

The heated steering wheel will automatically turn off after about 30 minutes.

●

If  the  indicator  light  flashes,  press  the  switch  to  turn  the  heated  steering
wheel off and then press the switch again. If the indicator light still flashes, a
malfunction may be occurring. Turn the heated steering wheel off and have
the vehicle inspected by your Toyota dealer.

Seat heater switches

The  indicator  light  (yellow)  on  the
switch  comes  on  when  the  seat
heater is operating.

Seat ventilator switches

The  indicator  light  (green)  on  the
switch  comes  on  when  the  seat
ventilator is operating.

Level indicator lights

The  seat  heater  temperature  level
or  the  seat  ventilator  fan  speed
level  (for  front  seats  only)  is  dis-
played.

“AUTO” indicator lights

Heated steering wheel (if equipped)

Front seat heaters and ventilators

1

2

3

4

412

5-1. Using the air conditioning system and defogger

LC200_OM_OM60T03U_(U)

■

Modes and indicators

The mode can be changed by pressing the switch.

*

: When  automatic  mode  is  selected,  the  level  automatically  changes

depending on the air conditioning settings.

■

The seat heaters and ventilators can be used when

The engine switch is in IGNITION ON mode.

■

Replacing the air filters

Filters are installed in the seat ventilators. For replacement of the filters, con-
tact your Toyota dealer.

■

Customization

The  automatic  mode  settings  for  the  seat  heaters  and  ventilators  can  be
changed. (



P. 594)

Mode

“AUTO” indicator light

Level indicator lights

Off

Off

Off

Automatic*

On

3 to 1, or off

Hi

Off

3

Mid

Off

2

Lo

Off

1

LC200_OM_OM60T03U_(U)

413

5-1. Using the air conditioning system and defogger

5

In

te

rior

fe

at

ures

For left-hand second seat
For right-hand second seat
High heating temperature
Low heating temperature

To  turn  on  the  seat  heater,  press
“HI” or “LO”.

Off

■

The seat heaters can be used when

The engine switch is in IGNITION ON mode.

Second outboard seat heaters (if equipped)

1
2
3
4

45

414

LC200_OM_OM60T03U_(U)

5-2. Using the interior lights

Interior lights list

Front interior lights (



P. 415)

Front personal lights (



P. 416)

Rear interior lights (



P. 415)

Rear personal lights (



P. 416)

Inside door handle lights

Footwell lights
Scuff lights
Engine switch light
Door courtesy lights
Door trim lights

1
2
3
4
5

6
7
8
9

10

LC200_OM_OM60T03U_(U)

415

5-2. Using the interior lights

5

In

te

rior

fe

at

ures



Front

Door position on/off
Turns the light on/off



Rear

On/door position on

Interior lights

1
2

416

LC200_OM_OM60T03U_(U)

5-2. Using the interior lights



Front

Turns the light on/off



Rear

Turns the light on/off

■

Illuminated entry system

The  lights  automatically  turn  on/off  according  to  engine  switch  mode,  the
presence of the electronic key, whether the doors are locked/unlocked, and
whether the doors are open/closed.

■

To prevent battery discharge

If the interior lights remain on when the engine switch is turned off, the lights
will go off automatically after 20 minutes:

■

Customization

Settings (e.g. adjust the time elapsed before the interior lights automatically
turn off) can be changed. (Customizable features:



P. 594)

Personal lights

NOTICE

To prevent battery discharge, do not leave the lights on longer than neces-
sary when the engine is not running.

417

LC200_OM_OM60T03U_(U)

5-3. Using the storage features

5

In

te

rior

fe

at

ures

List of storage features

Card holders (



P. 424)

Overhead console (



P. 420)

Glove box (



P. 418)

Bottle holders (



P. 423)

Door pockets
Auxiliary boxes (



P. 424)

Console box (



P. 419)

Cool box (if equipped)
(



P. 428)

Cup holders (



P. 421)

Auxiliary  box  (if  equipped)
(



P. 424)

Wireless charger (if equipped)
(



P. 434)

WARNING

■

Items that should not be left in the storage spaces

Do not leave glasses, lighters or spray cans in the storage spaces, as this
may cause the following when cabin temperature becomes high:

●

Glasses  may  be  deformed  by  heat  or  cracked  if  they  come  into  contact
with other stored items.

●

Lighters or spray cans may explode. If they come into contact with other
stored items, the lighter may catch fire or the spray can may release gas,
causing a fire hazard.

1
2
3
4
5
6

7

8
9

418

LC200_OM_OM60T03U_(U)

5-3. Using the storage features

Open (push button)
Lock with the mechanical key
Unlock with the mechanical key

■

Glove box light

The glove box light turns on when the tail lights are on.

■

Removing the separate tray

Glove box

1
2
3

Pull out the separate tray while releasing
the clips.

WARNING

Keep the glove box closed while driving.
Injuries may result in the event of sudden braking, sudden swerving or an
accident.

LC200_OM_OM60T03U_(U)

419

5-3. Using the storage features

5

In

te

rior

fe

at

ures

Your vehicle is equipped with either a lower console box or cool box.
For vehicles with the cool box, refer to page 428.



Upper console box

Press the tab to open.



Lower console box (if equipped)

Lift the lever to open.

Remove the tray.

Console box

1

2

WARNING

Keep the console box closed while driving.
Injuries may result in the event of sudden braking, sudden swerving or an
accident.

420

LC200_OM_OM60T03U_(U)

5-3. Using the storage features

Press the button.

Overhead console

WARNING

■

Items unsuitable for storing

Do not store items heavier than 0.4 lb. (0.2 kg).
Doing  so  may  cause  the  overhead  console  to  open  and  the  items  inside
may fall out, resulting in an accident.

■

While driving

Do not leave the overhead console open.
Items may fall out and cause injury.

LC200_OM_OM60T03U_(U)

421

5-3. Using the storage features

5

In

te

rior

fe

at

ures

Cup holders



Front seats



Second seats

Press down and release the lid.

You can adjust or remove the sep-
arator inside.

To  open,  pull  down  the  armrest,
press the button and release the
rear cup holder on the armrest.



Third seats (if equipped)



Luggage

compartment

(if

equipped)

422

LC200_OM_OM60T03U_(U)

5-3. Using the storage features

■

Removing the cup holder insert (front cup holders)

Pull up the insert.

Cup  holder  insert  may  be  removed  for
cleaning.

WARNING

■

Items unsuitable for the cup holder

Do not place anything other than cups or beverage cans in the cup holders.
Even with the lid is closed, items must not be stored in the cup holders.
Other items may be thrown out of the holders in the event of an accident or
sudden braking, cause injury. If possible, cover hot drinks to prevent burns.

■

When not in use

Keep the cup holders closed.
Injuries may result in the event of sudden braking, sudden swerving or an
accident.

NOTICE

■

To prevent damage to the cup holders (vehicles with a rear cup holder)

Stow the cup holders before stowing the rear armrest.

LC200_OM_OM60T03U_(U)

423

5-3. Using the storage features

5

In

te

rior

fe

at

ures

Bottle holders



Front seats



Second seats

NOTICE

■

Items that should not be stowed in the bottle holders

Put the cap on before stowing a bottle. Do not place open bottles in the bot-
tle holders, or glasses and paper cups containing liquid. The contents may
spill and glasses may break.

424

LC200_OM_OM60T03U_(U)

5-3. Using the storage features

Your vehicle is equipped with either a front auxiliary box or wireless
charger.
For vehicles with wireless charger, refer to page 434.

Card holders



Sun visor



Instrument panel

Auxiliary boxes



Front (if equipped)



Rear (type A)

Press the lid to open.



Rear (type B)

Press the button to open.

425

LC200_OM_OM60T03U_(U)

5-3. Using the storage features

5

In

te

rior

fe

at

ures

Luggage compartment features

Raise the hook to use.

The  cargo  hooks  are  provided  for
securing loose items.

To  hang  the  cargo  net,  use  the
cargo net hooks and rear tie-down
hooks.

The cargo net itself is not included
as an original equipment.

Remove the cover. Hold the warn-
ing reflector with the bands.

The  warning  reflector  itself  is  not
included as an original equipment.

Cargo hooks

Cargo net hooks

Warning reflector holder

426

LC200_OM_OM60T03U_(U)

5-3. Using the storage features

Remove the cover. Hold the first-
aid kit with a band.

The first-aid kit itself is not included
as an original equipment.

■

Using the luggage cover

Pull out the luggage cover and
hook it on the anchors.

■

Removing the luggage cover

Retract  the  cover  and  release
both ends, then lift it out.

After  removing  the  luggage
cover, place it somewhere other
than  the  passenger  compart-
ment.

First-aid kit holder

Luggage cover (if equipped)

LC200_OM_OM60T03U_(U)

427

5-3. Using the storage features

5

In

te

rior

fe

at

ures

■

When installing the luggage cover (if equipped)

Keep  the  “TOP”  mark  on  the  luggage
cover ends upward.

WARNING

●

To avoid injury, always return the cargo hooks to their positions when not
in use.

●

Keep the auxiliary box closed. In the event of sudden braking or sudden
swerving, an accident may occur due to an occupant being struck by an
open auxiliary box or the items stored inside.

●

Do not allow children to climb on the luggage cover. Climbing on the lug-
gage cover could result in damage to the luggage cover, possibly causing
death or serious injury to the child.

NOTICE

■

To prevent damage to the cargo net hooks

Avoid hanging things other than a cargo net on it.

428

LC200_OM_OM60T03U_(U)

5-4. Using the other interior features

Other interior features

While the engine is running, the cool box, which is cooled by the air
conditioning, can be used.

Lift  the  lid  while  pulling  up  the
lower lever to release the lock.

Turns the cool box on/off

When on, the indicator light comes
on.
If  the  front  air  conditioning  system
is not in use, the front air condition-
ing  system  is  automatically  turned
on when the cool box is turned on.

■

While the cool box is on

The front air conditioning system cannot be turned off.

■

When the outside temperature is 32



F (0



C) or below

The cool box may not operate.

Cool box (if equipped)

1

2

LC200_OM_OM60T03U_(U)

429

5-4. Using the other interior features

5

In

te

rior

fe

at

ures

WARNING

Keep the cool box closed while driving.
Injuries may result in the event of sudden braking, sudden swerving or an
accident.

NOTICE

To prevent battery discharge, do not leave the cool box on longer than nec-
essary when the engine is not running.

430

LC200_OM_OM60T03U_(U)

5-4. Using the other interior features



Main sun visor

To  set  the  visor  in  the  forward
position, flip it down.
To set the visor in the side posi-
tion,  flip  down,  unhook,  and
swing it to the side.
To use the side extender, place
the  visor  in  the  side  position,
then slide it backward.



Sub sun visor

Flip down with the main sun visor
in position

 or

.

Slide the cover to open.

The  light  turns  on  when  the  cover
is opened.

If the vanity lights remain on when the engine switch is turned off, the lights
will go off automatically after 20 minutes.

Sun visors

1

2

3

2

3

Vanity mirror

NOTICE

To prevent battery discharge, do not leave the vanity lights on for extended
periods when the engine is not running.

LC200_OM_OM60T03U_(U)

431

5-4. Using the other interior features

5

In

te

rior

fe

at

ures

Refer  to  “NAVIGATION  SYSTEM
OWNER’S  MANUAL”  for  adjust-
ment.

■

The clock is displayed when

The engine switch is in ACCESSORY or IGNITION ON mode.

The

displayed

temperature

ranges  from  -22



F  (-30



C)  up  to

122



F (50



C).

■

The outside temperature is displayed when

The engine switch is in IGNITION ON mode.

■

When --- is displayed

The system may be malfunctioning. Take your vehicle to your Toyota dealer.

■

Display

In  the  following  situations,  the  correct  outside  temperature  may  not  be  dis-
played, or the display may take longer than normal to change.

●

When stopped, or driving at low speeds (less than 12 mph [20 km/h])

●

When the outside temperature has changed suddenly (at the entrance/exit
of a garage, tunnel, etc.)

Clock

Outside temperature display

432

LC200_OM_OM60T03U_(U)

5-4. Using the other interior features

The power outlet can be used for the following components:
12 V DC: Accessories that run on less than 10 A
120 V AC: Accessories that use less than 100 W

■

Center of console



Front (12 V DC)

Press the lid to open.



Rear (12 V DC)

Power outlets

LC200_OM_OM60T03U_(U)

433

5-4. Using the other interior features

5

In

te

rior

fe

at

ures

■

Luggage compartment (120 V AC)

■

The power outlet can be used when

12 V DC: The engine switch is in ACCESSORY or IGNITION ON mode.
120 V AC: The engine switch is in IGNITION ON mode.

■

When turning the engine switch off

Disconnect electrical devices with charging functions, such as mobile battery
packs.
If such devices are left connected, the engine switch may not be turned off
normally.

NOTICE

■

To avoid damaging the power outlets

Close the power outlet lid when not in use.
Foreign objects or liquids that enter the power outlet may cause a short cir-
cuit.

■

To prevent the fuse from being blown

12 V DC: Do not use an accessory that uses more than 12 V 10 A.
120 V AC: Do not use a 120 V AC appliance that requires more than 100 W.

If a 120 V AC appliance that consumes more than 100 W is used, the pro-
tection circuit will cut the power supply.

■

To prevent the battery from being discharged

Do not use the power outlet longer than necessary when the engine is not
running.

■

Appliances that may not operate properly (120 V AC)

The  following  120 V AC  appliances  may  not  operate  even  if  their  power
consumption is under 100 W.

●

Appliances with high initial peak wattage

●

Measuring devices that process precise data

●

Other appliances that require an extremely stable power supply

434

LC200_OM_OM60T03U_(U)

5-4. Using the other interior features

A portable device can be charged by just placing Qi standard wireless
charge compatible portable devices according to the Wireless Power
Consortium, such as smart phones and mobile batteries, etc., on the
charge area.
This  function  cannot  be  used  with  portable  devices  that  are  larger
than the charging area. Also, depending on the portable device, it may
not operate as normal. Please read the operation manual for portable
devices to be used.

■

The “Qi” symbol

The “Qi” symbol is a trademark of the Wireless Power Consortium.

■

Name for all parts

Power supply switch
Operation indicator light
Charge area

Wireless charger (if equipped)

1
2
3

LC200_OM_OM60T03U_(U)

435

5-4. Using the other interior features

5

In

te

rior

fe

at

ures

■

Using the wireless charger

Press the lid to open.

Press  the  power  supply
switch  of  the  wireless  char-
ger.

Switches  on  and  off  with  each
press  of  the  power  supply
switch.
When  turned  on,  the  operation
indicator light (green) comes on.
Even with the engine off, the on/
off  state  of  the  power  supply
switch is memorized.

Place  the  charging  side  of
the portable device down.

When  charging,  the  operation
indicator  light  (orange)  comes
on.
If  charging  is  not  occurring,  try
placing  the  portable  device  as
close  to  the  center  of  the
charging area as possible.
When charging is complete, the operation indicator light (green) comes
on.

●

Recharging function

• When charging is complete and after a fixed time in the charge

suspension state, charging restarts.

• When the portable device is moved, charging is stopped for a

moment and then it restarts.

1

2

3

436

LC200_OM_OM60T03U_(U)

5-4. Using the other interior features

■

Lighting conditions of operation indicator light

*

: Depending  on  the  portable  device,  there  are  cases  where  the  operation

indicator light will continue being lit up orange even after the charging is
complete.

●

When the operation indicator light flashes
When  an  error  occurs,  the  operation  indicator  light  flashes  an
orange color. Handle the error based on the following table.

Operation indicator light

Conditions

Turning off

When  the  Wireless  charger  power  supply  is
off

Green (comes on)

On Standby (charging possible state)

When charging is complete

*

Orange (comes on)

When  placing  the  portable  device  on  the
charging area (detecting the portable device)

Charging

Operation indicator

light

Suspected causes

Handling method

Flashing

repeatedly

once  every  second
(Orange)

Vehicle  to  charger  com-
munication failure.

Contact  your  Toyota
dealer.

Repeatedly

flashes

3 times  continuously
(Orange)

A  foreign  substance  is
between  the  portable
device and charge area.

Remove  the  foreign
substance

from

between

portable

device  and  the  charge
area.

The  portable  device  is
out  of  sync  due  to  the
device being shifted from
its position.

Place

the

portable

device  near  the  center
of the charge area.

Repeatedly

flashes

4 times  continuously
(Orange)

Temperature

rising

within  the  wireless  char-
ger.

Stop  charging  at  once
and

start

charging

again after for a while.

LC200_OM_OM60T03U_(U)

437

5-4. Using the other interior features

5

In

te

rior

fe

at

ures

■

The wireless charger can be operated when

The engine switch is in ACCESSORY or IGNITION ON mode.

■

Usable portable devices

Qi standard wireless charge standard can be used on compatible devices.
However, not all Qi standard devices and compatibility are guaranteed.
Starting with mobile phones and smart phones, it is aimed for low power elec-
trically supplied portable devices of no more than 5W.

■

When covers and accessories are attached to portable devices

Do not charge in situations where cover and accessories not able to handle
Qi are attached to the portable device. Depending on the type of cover and
accessory, it may not be possible to charge. When charging is not performed
even with the portable device placed on the charge area, remove the cover
and accessories.

■

While charging, noise enters the AM radio

Turn off the wireless charger and confirm that the noise has decreased. If the
noise decreases, continuously pushing the power supply switch of the wire-
less charger for 2 seconds, the frequency of the charger can be changed and
the noise can be reduced.
Also, on that occasion, the operation indicator light will flash orange 2 times.

■

Important points of the wireless charger

●

If the electronic key cannot be detected within the vehicle interior, charging
cannot  be  done.  When  the  door  is  opened  and  closed,  charging  may  be
temporarily suspended.

●

When  charging,  the  wireless  charging  device  and  portable  device  will  get
warmer, however this is not a malfunction.
When a portable device gets warm while charging, charging may stop due
to the protection function on the portable device side. In this case, when the
temperature of the portable device drops significantly, charge again.

■

Operation sounds

When the power supply is turned on, while searching for the portable device a
sound will be produced, however this is not a malfunction.

438

LC200_OM_OM60T03U_(U)

5-4. Using the other interior features

■

Certification for the wireless charger

LC200_OM_OM60T03U_(U)

439

5-4. Using the other interior features

5

In

te

rior

fe

at

ures

440

LC200_OM_OM60T03U_(U)

5-4. Using the other interior features

WARNING

■

Caution while driving

When charging a portable device, for safety reasons, the driver should not
operate the portable device while driving.

■

Caution regarding interference with electronic devices

People  with  implantable  cardiac  pacemakers,  cardiac  resynchronization
therapy-pacemakers  or  implantable  cardioverter  defibrillators,  as  well  as
any other electrical medical device, should consult their physician about the
usage of the wireless charger. The operations of the wireless charger may
have an affect on medical devices.

■

To prevent damage or burns

Observe the following precautions.
Failure to do so may result in a possibility of equipment failure and damage,
catch fire, burns due to overheat.

●

Do not insert any metallic objects between the charging area and the por-
table device while charging

●

Do not attach stickers, metallic objects, etc., to the charger area or porta-
ble device

●

Do not cover with cloth, etc., and charge

●

Do not charge portable devices other than designated

●

Do not attempt to dismantle for disassembly or modifications

●

Do not hit or apply a strong force

LC200_OM_OM60T03U_(U)

441

5-4. Using the other interior features

5

In

te

rior

fe

at

ures

NOTICE

■

Conditions in which the function may not operate correctly

In the following conditions, the wireless charger may not operate correctly

●

The portable device is fully charged

●

There is foreign matter between the charge area and portable device

●

The temperature of the portable device gets higher from charging

●

The charging surface of the portable device is facing up

●

The placement of the portable device is out of alignment with the charge
area

●

Near a TV tower, electric power plant, gas station, radio station, large dis-
play, airport or other facility that generates strong radio waves or electrical
noise

●

When the electronic key is in contact with, or is covered by the following
metallic objects
• Cards to which aluminum foil is attached
• Cigarette boxes that have aluminum foil inside
• Metallic wallets or bags
• Coins
• Hand warmers made of metal
• Media such as CDs and DVDs

●

When other wireless keys (that emit radio waves) are being used nearby

In addition, excluding the above-mentioned, when the charger does not per-
form  normally  or  the  operation  indicator  light  is  flashing  continuously,  it  is
considered that the wireless charger is malfunctioning. Contact your Toyota
dealer.

■

To prevent failure or damage to data

●

Do not bring magnetic cards, such as credit cards, or magnetic recording
media, etc., close to the charger while charging, otherwise, data may dis-
appear  under  the  influence  of  magnetism. Also,  do  not  bring  precision
instruments  such  as  wrist  watches,  etc.,  close  to  the  charger,  as  such
objects may break.

●

Do  not  leave  portable  devices  in  the  cabin.  The  temperature  inside  the
cabin may become high, when under the sun, and cause damage to the
device.

■

To prevent battery discharge

When  the  engine  is  stopped,  do  not  use  the  wireless  charger  for  a  long
time.

442

LC200_OM_OM60T03U_(U)

5-4. Using the other interior features

Fold down the armrest for use.

The coat hooks are provided with
the second seat assist grips.

Armrest

NOTICE

To prevent damage, do not apply too much load on the armrest.

Coat hooks

WARNING

Do not hang coat hangers or other hard or sharp objects on the hook. If the
SRS  curtain  shield  airbags  deploy,  these  items  may  become  projectiles,
causing death or serious injury.

LC200_OM_OM60T03U_(U)

443

5-4. Using the other interior features

5

In

te

rior

fe

at

ures

An assist grip (Type A) can be used to support your body while sitting
on the seat.
An assist grip (Type B) can be used when getting in or out of the vehi-
cle and others.

Assist grip (Type A)
Assist grip (Type B)

Assist grips

1
2

WARNING

Do not use the assist grip (Type A) when getting in or out of the vehicle or
rising from your seat.

NOTICE

To prevent damage, do not hang heavy objects or put a heavy load on the
assist grip.

444

LC200_OM_OM60T03U_(U)

5-4. Using the other interior features

Garage door opener

The HomeLink

®

 wireless control system in your vehicle has 3 buttons

which can be programmed to operate 3 different devices. Refer to the
programming  methods  on  the  following  pages  to  determine  the
method which is appropriate for the device.

HomeLink

®

 indicator light

Garage  door  operation  indica-
tors
HomeLink

®

 icon

Illuminates  while  HomeLink

®

  is

operating.

Buttons

■

Before programming HomeLink

®

●

During programming, it is possible that garage doors, gates, or
other devices may operate. For this reason, make sure that peo-
ple and objects are clear of the garage door or other devices to
prevent injury or other potential harm.

●

It  is  recommended  that  a  new  battery  be  placed  in  the  remote
control transmitter for more accurate programming.

●

Garage  door  opener  motors  manufactured  after  1995  may  be
equipped with rolling code protection. If this is the case, you may
need  a  stepladder  or  other  sturdy,  safe  device  to  reach  the
“Learn” or “Smart” button on the garage door opener motor.

The garage door opener can be programmed to operate garage
doors,  gates,  entry  doors,  door  locks,  home  lighting  systems,
security systems, and other devices.

Programming the HomeLink

®

1
2

3

4

LC200_OM_OM60T03U_(U)

445

5-4. Using the other interior features

5

In

te

rior

fe

at

ures

■

Programming HomeLink

®

Steps

 through

 must be performed within 60 seconds, other-

wise the indicator light will stop flashing and programming will not
be able to be completed.

Press  and  release  the  HomeLink

®

  button  you  want  to  program

and check that the HomeLink

®

 indicator light flashes (orange).

Point  the  remote  control
transmitter  for  the  device  at
the rear view mirror, 1 to 3 in.
(25  to  75  mm)  from  the
HomeLink

®

 buttons.

Keep  the  HomeLink

®

  indicator

light in view while programming.

Program a device.



Programming  a  device  other  than  an  entry  gate  (for  U.S.A.
owners)

Press  and  hold  the  remote  control  transmitter  button  until  the
HomeLink

®

 indicator light changes from slowly flashing orange to

rapidly  flashing  green  (rolling  code)  or  continuously  lit  green
(fixed code), then release the button.



Programming an entry gate (for U.S.A. owners)

Press and release the remote control transmitter button at 2 sec-
ond  intervals,  repeatedly,  until  the  HomeLink

®

  indicator  light

changes from slowly flashing (orange) to rapidly flashing (green)
(rolling code) or continuously lit (green) (fixed code).

1

3

1

2

3

446

LC200_OM_OM60T03U_(U)

5-4. Using the other interior features

Test  the  HomeLink

®

  operation  by  pressing  the  newly  pro-

grammed button and observing the indicator light:

●

Indicator light illuminates: Programming of a fixed code device
has completed. The garage door or other device should oper-
ate when a HomeLink

®

 button is pressed and released.

●

Indicator light flashes rapidly: The garage door opener motor
or  other  device  is  equipped  with  a  rolling  code. To  complete
programming, firmly press and hold the HomeLink

®

 button for

2 seconds then release it.

●

If the garage door or other device does not operate, proceed
to “Programming a rolling code system”.

Repeat the steps above to program another device for any of the
remaining HomeLink

®

 buttons.

■

Programming a rolling code system

2 or more people may be necessary to complete rolling code pro-
gramming.

Locate the “Learn” or “Smart”
button  on  the  garage  door
opener motor in the garage.

This button can usually be found
where the hanging antenna wire
is  attached  to  the  unit.  The
name  and  color  of  the  button
may  vary  by  manufacturer.
Refer  to  the  owner’s  manual
supplied  with  the  garage  door
opener motor for details.

Press  and  release  the
“Learn” or “Smart” button.
Perform

  within  30  sec-

onds after performing

.

4

5

1

2

3

2

LC200_OM_OM60T03U_(U)

447

5-4. Using the other interior features

5

In

te

rior

fe

at

ures

Press  and  hold  the  desired
HomeLink

®

 button (inside the

vehicle)  for  2  seconds  and
release  it.  Repeat  this
sequence

(press/hold/

release)  up  to  3  times  to
complete programming.
If  the  garage  door  opener
motor  operates  when  the
HomeLink

®



button

is

pressed,  the  garage  door
opener motor recognizes the
HomeLink

®

 signal.

■

Enabling 2-way communication with a garage door (only avail-
able for compatible devices)

When enabled, 2-way communication allows you to check the sta-
tus of the opening and closing of a garage door through indicators
in your vehicle.
2-way  communication  is  only  available  if  the  garage  door  opener
motor used is a compatible device. (To check device compatibility,
refer to www.HomeLink.com.)

Within 5 seconds after programming the garage door opener has
been  completed,  if  the  garage  door  opener  motor  is  trained  to
HomeLink

®

, both garage door operation indicators will flash rap-

idly  (green) and  the  light  on  the  garage  door  opener  motor  will
blink twice, indicating that 2-way communication is enabled.

If the indicators do not flash, perform



and

 within the first 10

presses  of  the  HomeLink

®

  button  after  programming  has  been

completed.

Press  a  programmed  HomeLink

®

  button  to  operate  a  garage

door.
Within  1  minute  of  pressing  the  HomeLink

®

  button,  after  the

garage door operation has stopped, press the “Learn” or “Smart”
button on the garage door opener motor. Within 5 seconds of the
establishment  of  2-way  communication  with  the  garage  door
opener,  both  garage  door  operation  indicators  in  the  vehicle  will
flash rapidly (green) and the light on the garage door opener motor
will blink twice, indicating that 2-way communication is enabled.

3

1

2

3

2

3

448

LC200_OM_OM60T03U_(U)

5-4. Using the other interior features

■

Reprogramming a single HomeLink

®

 button

When the following procedure is performed, buttons which already
have devices registered to them can be overwritten:

With one hand, press and hold the desired HomeLink

®

 button.

When the HomeLink

®

 indicator starts flashing (orange), continue

to hold the HomeLink

®

 button and perform “Programming Home-

Link

®

”

  (it  takes  20  seconds  for  the  HomeLink

®

  indicator  to

start flashing).

Press  the  appropriate  HomeLink

®

  button.  The  HomeLink

®

  indicator

light should turn on.

The  status  of  the  opening  and
closing of a garage door is shown
by the indicators.

Opening
Closing

This function is only available if the
garage door opener motor used is
a  compatible  device.  (To  check
device  compatibility,  refer  to
www.HomeLink.com.)

The indicators can operate within approximately 820 ft. (250 m) of the
garage door. However, if there are obstructions between the garage
door  and  the  vehicle,  such  as  houses  and  trees,  feedback  signals
from the garage door may not be received.
To recall the previous door operation status, press and release either

HomeLink

®

  buttons

  and

  or

  and

  simultaneously.

The last recorded status will be displayed for 3 seconds.

Operating HomeLink

®

Garage door operation indicators

1

2

1

1
2

Color

Status

Orange (flashing)

Currently opening/closing

Green

Opening/closing has completed

Red (flashing)

Feedback signals cannot be received

LC200_OM_OM60T03U_(U)

449

5-4. Using the other interior features

5

In

te

rior

fe

at

ures

Press and hold the 2 outside but-
tons  for  10  seconds  until  the
HomeLink

®



indicator

light

changes  from  continuously  lit
(orange)  to  rapidly  flashing
(green).

If you sell your vehicle, be sure to
erase  the  programs  stored  in  the
HomeLink

®

 memory.

■

Codes stored in the HomeLink

®

 memory

●

The  registered  codes  are  not  erased  even  if  the  battery  cable  is  discon-
nected.

●

If  learning  failed  when  registering  a  different  code  to  a  HomeLink

®

  button

that already has a code registered to it, the already registered code will not
be erased.

■

Before programming

●

Install a new battery in the transmitter.

●

The  battery  side  of  the  transmitter  must  be  pointed  away  from  the
HomeLink



.

■

Certification for the garage door opener

■

When support is necessary

Visit on the web at www.homelink.com/toyota or call 1-800-355-3515.

Erasing the entire HomeLink

®

 memory (all three codes)

450

LC200_OM_OM60T03U_(U)

5-4. Using the other interior features

WARNING

■

When programming a garage door or other remote control devices

The  garage  door  or  other  devices  may  operate,  so  ensure  people  and
objects are out of danger to prevent potential harm.

■

Conforming to federal safety standards

Do  not  use  the  HomeLink



  compatible  transceiver  with  any  garage  door

opener or device that lacks safety stop and reverse features as required by
federal safety standards.
This  includes  any  garage  door  that  cannot  detect  an  interfering  object. A
door or device without these features increases the risk of death or serious
injury.

■

When operating or programming HomeLink



Never allow a child to operate or play with the HomeLink



 buttons.

451

LC200_OM_OM60T03U_(U)

6

Maintenance and care

6-1. Maintenance and care

Cleaning and protecting

the vehicle exterior.......... 452

Cleaning and protecting

the vehicle interior........... 456

6-2. Maintenance

Maintenance

requirements................... 459

General maintenance........ 462
Emission inspection and

maintenance (I/M)
programs......................... 465

6-3. Do-it-yourself maintenance

Do-it-yourself service

precautions ..................... 466

Hood ................................. 468
Engine compartment......... 469
Tires .................................. 482
Tire inflation pressure ....... 492
Wheels .............................. 495
Air conditioning filter.......... 497
Electronic key battery........ 499
Checking and replacing

fuses ............................... 501

Headlight aim .................... 505
Light bulbs......................... 507

452

LC200_OM_OM60T03U_(U)

6-1. Maintenance and care

Cleaning and protecting the vehicle exterior

●

Working  from  top  to  bottom,  liberally  apply  water  to  the  vehicle
body, wheel wells and underside of the vehicle to remove any dirt
and dust.

●

Wash  the  vehicle  body  using  a  sponge  or  soft  cloth,  such  as  a
chamois.

●

For hard-to-remove marks, use car wash soap and rinse thoroughly
with water.

●

Wipe away any water.

●

Wax the vehicle when the waterproof coating deteriorates.

If  water  does  not  bead  on  a  clean  surface,  apply  wax  when  the  vehicle
body is cool.

■

Automatic car washes

●

Fold  the  mirrors  back  before  washing  the  vehicle.  Start  washing  from  the
front of the vehicle. Make sure to extend the mirrors before driving.

●

Brushes  used  in  automatic  car  washes  may  scratch  the  vehicle  surface,
parts (wheel, etc.) and harm your vehicle’s paint.

●

Rear  spoiler  (if  equipped)  may  not  be  washable  in  some  automatic  car
washes. There may also be an increased risk of damage to vehicle.

■

High pressure car washes

As  water  may  enter  the  cabin,  do  not  bring  the  nozzle  tip  near  the  gaps
around the doors or perimeter of the windows, or spray these areas continu-
ously.

■

Wheels and wheel ornaments

●

Remove any dirt immediately by using a neutral detergent.

●

Wash detergent off with water immediately after use.

●

To protect the paint from damage, make sure to observe the following pre-
cautions.
• Do not use acidic, alkaline or abrasive detergent
• Do not use hard brushes
• Do not use detergent on the wheels when they are hot, such as after driv-

ing or parking in hot weather

■

Bumpers and side moldings

Do not scrub with abrasive cleaners.

Perform  the  following  to  protect  the  vehicle  and  maintain  it  in
prime condition:

LC200_OM_OM60T03U_(U)

453

6-1. Maintenance and care

6

Mainten

ance an

d ca

re

■

Plated portions

If dirt cannot be removed, clean the parts as follows:

●

Use  a  soft  cloth  dampened  with  an  approximately  5%  solution  of  neutral
detergent and water to clean the dirt off.

●

Wipe the surface with a dry, soft cloth to remove any remaining moisture.

●

To remove oily deposits, use alcohol wet wipes or a similar product.

■

Notes for a smart key system

●

If the door handle becomes wet while the electronic key is within the effec-
tive range, the door may lock and unlock repeatedly. Place the key in a posi-
tion 6 ft. (2 m) or more separate from the vehicle while the vehicle is being
washed. (Take care to ensure that the key is not stolen.)

●

If the electronic key is inside the vehicle and a door handle becomes wet
during a car wash, a message may be shown on the multi-information dis-
play and a buzzer will sound outside the vehicle. To turn off the alarm, lock
all the doors.

454

LC200_OM_OM60T03U_(U)

6-1. Maintenance and care

WARNING

■

When washing the vehicle

Do not apply water to the inside of the engine compartment. Doing so may
cause the electrical components etc. to catch fire.

■

When  cleaning  the  windshield  (vehicles  with  rain-sensing  windshield
wiper)

●

When  the  upper  part  of  the  windshield  where  the  raindrop  sensor  is
located is touched by hand

●

When a wet rag or similar is held close to the raindrop sensor

●

If something bumps against the windshield

●

If you directly touch the raindrop sensor body or if something bumps into
the raindrop sensor

■

Precautions regarding the exhaust pipe

Exhaust gasses cause the exhaust pipe to become quite hot.
When  washing  the  vehicle,  be  careful  not  to  touch  the  pipe  until  it  has
cooled sufficiently, as touching a hot exhaust pipe can cause burns.

■

Precautions regarding the Blind Spot Monitor (if equipped)

If the paint of the rear bumper is chipped or scratched, the system may mal-
function.
If this occurs, consult your Toyota dealer.

Set the wiper switch to off.
If the wiper switch is in “AUTO”, the wip-
ers may operate unexpectedly in the fol-
lowing  situations,  and  may  result  in
hands being caught or other serious inju-
ries  and  cause  damage  to  the  wiper
blades.

OFF

AUTO

LC200_OM_OM60T03U_(U)

455

6-1. Maintenance and care

6

Mainten

ance an

d ca

re

NOTICE

■

To prevent paint deterioration and corrosion on the body and compo-
nents (aluminum wheels etc.)

●

Wash the vehicle immediately in the following cases:
• After driving near the sea coast
• After driving on salted roads
• If coal tar or tree sap is present on the paint surface
• If you see dead insects, insect droppings or bird droppings on the paint
• After driving in an area contaminated with soot, oily smoke, mine dust,

iron powder or chemical substances

• If the vehicle becomes heavily soiled in dust or mud
• If liquids such as benzene and gasoline are spilled on the paint surface

●

If the paint is chipped or scratched, have it repaired immediately.

●

To prevent the wheels from corroding, remove any dirt and store in a place
with low humidity when storing wheels.

■

Cleaning the exterior lights

●

Wash carefully. Do not use organic substances or scrub with a hard brush.
This may damage the surfaces of the lights.

●

Do not apply wax on the surfaces of the lights.
Wax may cause damage to the lenses.

■

When  using an  automatic car wash  (vehicles with  rain-sensing  wind-
shield wiper)

Turn off the wiper switch.
If  the  wiper  switch  is  in  “AUTO”,  the  wipers  may  operate  and  the  wiper
blades may be damaged.

■

When using a high pressure car wash

●

Do not bring the nozzle tip close to boots (rubber or resin manufactured
cover),  connectors  or  the  following  parts. The  parts  may  be  damaged  if
they come into contact with high-pressure water.
• Traction related parts
• Steering parts
• Suspension parts
• Brake parts

●

Keep the cleaning nozzle at least 11.9 in. (30 cm) away from the vehicle
body.  Otherwise  resin  section,  such  as  moldings  and  bumpers,  may  be
deformed and damaged. Also, do not continuously hold the nozzle in the
same place.

●

Do not spray the lower part of the windshield continuously. If water enters
the air conditioning system intake located near the lower part of the wind-
shield, the air conditioning system may not operate correctly.

●

Do  not  wash  the  underside  of  the  vehicle  using  a  high  pressure  car
washer.

456

LC200_OM_OM60T03U_(U)

6-1. Maintenance and care

Cleaning and protecting the vehicle interior

●

Remove dirt and dust using a vacuum cleaner. Wipe dirty surfaces
with a cloth dampened with lukewarm water.

●

If dirt cannot be removed, wipe it off with a soft cloth dampened with
neutral detergent diluted to approximately 1%.

●

Wring out any excess water from the cloth and thoroughly wipe off
remaining traces of detergent and water.

●

Remove dirt and dust using a vacuum cleaner.

●

Wipe  any  excess  dirt  and  dust  with  a  soft  cloth  dampened  with
diluted detergent.

Use a diluted water solution of approximately 5% neutral wool detergent.

●

Wring out any excess water from the cloth and thoroughly wipe off
all remaining traces of detergent.

●

Wipe  the  surface  with  a  dry,  soft  cloth  to  remove  any  remaining
moisture. Allow the leather to dry in a shaded ventilated area.

●

Remove dirt and dust using a vacuum cleaner.

●

Wipe it off with a soft cloth dampened with neutral detergent diluted
to approximately 1%.

●

Wring out any excess water from the cloth and thoroughly wipe off
remaining traces of detergent and water.

The following procedures will help protect your vehicle’s interior
and keep it in top condition:

Protecting the vehicle interior

Cleaning the leather areas

Cleaning the synthetic leather areas

LC200_OM_OM60T03U_(U)

457

6-1. Maintenance and care

6

Mainten

ance an

d ca

re

■

Caring for leather areas

Toyota recommends cleaning the interior of the vehicle at least twice a year to
maintain the quality of the vehicle’s interior.

■

Shampooing the carpets

There are several commercial foaming-type cleaners available. Use a sponge
or brush to apply the foam. Rub in overlapping circles. Do not use water. The
excellent results are obtained when keeping the carpet as dry as possible.

■

Seat belts

Clean  with  mild  soap  and  lukewarm  water  using  a  cloth  or  sponge.  Also
check the belts periodically for excessive wear, fraying or cuts.

WARNING

■

Water in the vehicle

●

Do not splash or spill liquid in the vehicle.
Doing  so  may  cause  electrical  components  etc.  to  malfunction  or  catch
fire.

●

Do not get any of the SRS components or wiring in the vehicle interior wet.
(



P. 42)

An electrical malfunction may cause the airbags to deploy or not function
properly, resulting in death or serious injury.

■

Cleaning the interior (especially instrument panel)

Do not use polish wax or polish cleaner. The instrument panel may reflect
off the windshield, obstructing the driver’s view and leading to an accident,
resulting in death or serious injury.

NOTICE

■

Cleaning detergents

●

Do not use the following types of detergent, as they may discolor the vehi-
cle interior or cause streaks or damage to painted surfaces:
• Non-seat  portions:  Organic  substances  such  as  benzene  or  gasoline,

alkaline or acidic solutions, dye, and bleach

• Seats: Alkaline or acidic solutions, such as thinner, benzene, and alco-

hol

●

Do not use polish wax or polish cleaner. The instrument panel’s or other
interior part’s painted surface may be damaged.

458

LC200_OM_OM60T03U_(U)

6-1. Maintenance and care

NOTICE

■

Preventing damage to leather surfaces

Observe the following precautions to avoid damage to and deterioration of
leather surfaces:

●

Remove any dust or dirt from leather surfaces immediately.

●

Do not expose the vehicle to direct sunlight for extended periods of time.
Park the vehicle in the shade, especially during summer.

●

Do not place items made of vinyl, plastic, or containing wax on the uphol-
stery, as they may stick to the leather surface if the vehicle interior heats
up significantly.

■

When  cleaning  the  inside  of  the  windshield  (vehicles  with  Toyota
Safety Sense P)

Do not allow glass cleaner to contact the lens. Also, do not touch the lens.
(



P. 250)

■

Water on the floor

Do not wash the vehicle floor with water.
Vehicle systems such as the audio system may be damaged if water comes
into contact with electrical components such as the audio system above or
under the floor of the vehicle. Water may also cause the body to rust.

■

Cleaning the inside of the rear quarter windows and rear window

●

Do not use glass cleaner to clean the rear quarter windows and rear win-
dow, as this may cause damage to the rear window defogger heater wires
or antenna. Use a cloth dampened with lukewarm water to gently wipe the
window clean. Wipe the window in strokes running parallel to the heater
wires or antenna.

●

Be careful not to scratch or damage the heater wires or antenna.

459

LC200_OM_OM60T03U_(U)

6-2. Maintenance

6

Mainten

ance an

d ca

re

Maintenance requirements

General maintenance should be performed on a daily basis. This can
be done by yourself or by a Toyota dealer.

Scheduled  maintenance  should  be  performed  at  specified  intervals
according to the maintenance schedule.
For  details  about  maintenance  items  and  schedules,  refer  to  the
“Scheduled Maintenance Guide” or “Owner’s Manual Supplement”.

You can perform some maintenance procedures by yourself.
Please be aware that do-it-yourself maintenance may affect warranty
coverage.

The use of Toyota repair manuals is recommended.
For details about warranty coverage, see the “Owner’s Warranty Informa-
tion Booklet” or “Owner’s Manual Supplement”.

To ensure safe and economical driving, day-to-day care and reg-
ular maintenance are essential. It is the owner’s responsibility to
perform regular checks. Toyota recommends the following main-
tenance:

General maintenance

Scheduled maintenance

Do-it-yourself maintenance

460

LC200_OM_OM60T03U_(U)

6-2. Maintenance

■

Repair and replacement

It is recommended that genuine Toyota parts be used for repairs to ensure
performance of each system. If non-Toyota parts are used in replacement or if
a repair shop other than a Toyota dealer performs repairs, confirm the war-
ranty coverage.

■

Resetting the message indicating maintenance is required

After  the  required  maintenance  is  performed  according  to  the  maintenance
schedule, please reset the message.
To reset the message, follow the procedures described below:

Press

 or

 of the meter control switches, select

.

Press

  or

  of  the  meter  control  switches,  select  “Scheduled

Maintenance” and then press

.

Select the “Yes” and press

.

A message is displayed on the multi-information display.

■

Allow inspection and repairs to be performed by a Toyota dealer

●

Toyota technicians are well-trained specialists and are kept up to date with
the latest service information. They are well informed about the operation of
all systems on your vehicle.

●

Keep  a  copy  of  the  repair  order.  It  proves  that  the  maintenance  that  has
been  performed  is  under  warranty  coverage.  If  any  problem  should  arise
while your vehicle is under warranty, your Toyota dealer will promptly take
care of it.

1

2

3

4

LC200_OM_OM60T03U_(U)

461

6-2. Maintenance

6

Mainten

ance an

d ca

re

WARNING

■

If your vehicle is not properly maintained

Improper  maintenance  could  result  in  serious  damage  to  the  vehicle  and
possible serious injury or death.

■

Handling of the battery

●

Engine exhaust, some of its constituents, and a wide variety of automobile
components contain or emit chemicals known to the State of California to
cause  cancer  and  birth  defects  and  other  reproductive  harm.  Work  in  a
well ventilated area.

●

Oils, fuels and fluids contained in vehicles as well as waste produced by
component wear contain or emit chemicals known to the State of Califor-
nia  to  cause  cancer  and  birth  defects  or  other  reproductive  harm. Avoid
exposure and wash any affected area immediately.

●

Battery  posts,  terminals  and  related  accessories  contain  lead  and  lead
compounds which  are known  to cause brain damage. Wash your hands
after handling. (



P. 478)

462

LC200_OM_OM60T03U_(U)

6-2. Maintenance

General maintenance

Listed below are the general maintenance items that should be
performed at the intervals specified in the “Warranty and Service
Guide”  or  “Owner’s  Manual  Supplement”.  It  is  recommended
that any problem you notice should be brought to the attention
of your Toyota dealer or qualified service shop for advice.

Engine compartment

Items

Check points

Battery

Check the connections.

(



P. 478)

Brake fluid

Is the brake fluid at the correct level? (



P. 475)

Engine coolant

Is the engine coolant at the correct level?

(



P. 474)

Engine oil

Is the engine oil at the correct level? (



P. 471)

Exhaust system

There  should  not  be  any  fumes  or  strange
sounds.

Power steering fluid

Is the power steering fluid at the correct level?

(



P. 477)

Radiator/condenser

The radiator and condenser should be free from
foreign objects.

(



P. 475)

Washer fluid

Is there sufficient washer fluid?

(



P. 481)

LC200_OM_OM60T03U_(U)

463

6-2. Maintenance

6

Mainten

ance an

d ca

re

Vehicle interior

Items

Check points

Accelerator pedal

• The accelerator pedal should move smoothly

(without uneven pedal effort or catching).

Automatic transmission
“Park” mechanism

• When parked on a slope and the shift lever is

in P, is the vehicle securely stopped?

Brake pedal

• Does the brake pedal move smoothly?
• Does the brake pedal have appropriate clear-

ance from the floor?

(



P. 578)

• Does  the  brake  pedal  have  the  correct

amount of free play?

(



P. 578)

Brakes

• The vehicle should not pull to one side when

the brakes are applied.

• The brakes should work effectively.
• The brake pedal should not feel spongy.
• The  brake  pedal  should  not  get  too  close  to

the floor when the brakes are applied.

Head restraints

• Do  the  head  restraints  move  smoothly  and

lock securely?

Indicators/buzzers

• Do  the  indicators  and  buzzers  function  prop-

erly?

Lights

• Do all the lights come on?
• Are the headlights aimed correctly? (



P. 505)

Parking brake

• Does the parking brake lever move smoothly?
• When  parked  on  a  slope  and  the  parking

brake is on, is the vehicle securely stopped?

Seat belts

• Do the seat belts operate smoothly?
• The seat belts should not be damaged.

Seats

• Do the seat controls operate properly?

Steering wheel

• Does the steering wheel rotate smoothly?
• Does  the  steering  wheel  have  the  correct

amount of free play?

• There should not be any strange sounds com-

ing from the steering wheel.
