Toyota Corolla Hybrid (2021 year). Manual in english - part 5

To use the Bluetooth

audio, it is

necessary to register an audio
player with the system.
Once the player has been regis-
tered, it is possible to use the
Bluetooth

audio.

This operation cannot be per-
formed while driving.
For details about registering a
Bluetooth

device:



P.268

Turn the Bluetooth

connec-

tion setting of your audio
player on.

This function is not available when
the Bluetooth

connection setting

of your audio player is set to off.

Press the “AUDIO” button.

Select “Source” on the audio
screen or press “AUDIO” but-
ton again.

Select “Bluetooth”.

Select “Yes” to register an
audio player.

Follow the steps in “Register-
ing a Bluetooth

phone for

the first time” from step

(



This system supports the follow-
ing services.

■

Bluetooth

Core Specifica-

tion

Ver. 2.0 (Recommended: Ver.
4.1 +EDR)

■

Profiles



HFP (Hands Free Profile) Ver.
1.0 (Recommended: Ver. 1.7)

This is a profile to allow hands-free
phone calls using a cellular phone.
It has outgoing and incoming call
functions.



OPP (Object Push Profile)
Ver. 1.1 (Recommended: Ver.

Registering a Bluetooth

audio player for the first
time

Profiles

-------------------------------------------------------------------------------------------------------------------------------------------------------------

272

5-3. Connectivity settings

COROLLA HV_U

1.2)

This is a profile to transfer contacts
data.



PBAP (Phone Book Access
Profile) Ver. 1.0 (Recom-
mended: Ver. 1.2)

This is a profile to transfer phone-
book data.



MAP (Message Access Pro-
file) Ver. 1.0 (Recommended:
Ver. 1.2)

This is a profile to use phone mes-
sage functions.



SPP (Serial Port Profile) Rec-
ommended: Ver. 1.2

This is a profile to use the Toyota
audio multimedia function.



A2DP (Advanced Audio Dis-
tribution Profile) Ver. 1.0 (Rec-
ommended: Ver. 1.3)

This is a profile to transmit stereo
audio or high quality sound to the
audio/visual system.



AVRCP (Audio/Video Remote
Control Profile) Ver. 1.0 (Rec-
ommended: Ver. 1.6)

This is a profile to allow remote
control the A/V equipment.

Press the “MENU” button.

Select “Setup”.

Select “Bluetooth”.

Setting Bluetooth

details

When an Apple CarPlay
connection is established,
this function will be unavail-
able.

When an Android Auto con-
nection is established,
some functions will be
unavailable.

: This function is not made avail-

able in some countries or
areas.

Displaying the Blue-
tooth

setup screen

-------------------------------------------------------------------------------------------------------------------------------------------------------------

273

5-3. Connectivity settings

COROLLA HV_U

Audio

Select the desired item to be
set.

Connecting a Bluetooth

device and editing the Blue-
tooth

device information

(



P.273, 276)

Registering a Bluetooth

device (



P.275)

Deleting a Bluetooth

device

(



P.275)

Setting the Bluetooth

sys-

tem (



Up to 5 Bluetooth

devices

(Phones (HFP) and audio play-
ers (AVP)) can be registered.

If more than 1 Bluetooth

device

has been registered, select
which device to connect to.

Display the Bluetooth

set-

tings screen. (

Select “Registered Device”.

Select the device to be con-
nected.

: Phone

: Audio player

: Phone/Toyota apps services



The profile icon for a currently
connected device will be dis-
played in color.



Selecting a profile icon which
is not currently connected will
switch the connection to the
function.



If the desired Bluetooth

device is not on the list, select
“Add New Device” to register
the device. (

P.275)

Bluetooth

setup screen

Connecting a Bluetooth

device

-------------------------------------------------------------------------------------------------------------------------------------------------------------

274

5-3. Connectivity settings

COROLLA HV_U

Select the desired connec-
tion.

“Device Info”: Select to confirm and
change the Bluetooth

device infor-

mation. (



P.276)

When another Bluetooth

device is connected

To disconnect the Bluetooth

device, select “Yes”.

Check that a confirmation
screen is displayed when the
connection is complete.

If an error message is displayed,

follow the guidance on the screen

to try again.

●

It may take time if the device con-

nection is carried out during Blue-
tooth

audio playback.

●

Depending on the type of Blue-
tooth

device being connected, it

may be necessary to perform

additional steps on the device.

●

When disconnecting a Bluetooth

device, it is recommended to dis-

connect using the system.

■

Connecting a Bluetooth

device in a different way
(from phone top screen)



P.345

■

Connecting a Bluetooth

device in a different way
(from phone setup screen)

P.358

■

Connecting a Bluetooth

device in a different way
(from Bluetooth

audio

screen)

P.317

■

Auto connection mode

To turn auto connection mode
on, set “Bluetooth Power” to on.
(



P.277) Leave the Bluetooth

device in a location where the
connection can be established.



When the power switch is in
ACC or ON, the system
searches for a nearby regis-
tered device.



The system will connect with
the registered device that was
last connected, if it is nearby.
When automatic connection
priority is set to on and there
is more than one registered
Bluetooth

phone available,

the system will automatically
connect to the Bluetooth

phone with the highest prior-
ity. (

■

Connecting manually

When the auto connection has
failed or “Bluetooth Power” is
turned off, it is necessary to con-
nect the Bluetooth

device man-

ually.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

275

5-3. Connectivity settings

COROLLA HV_U

Audio

Display the Bluetooth

set-

tings screen. (



Follow the steps in “Connect-
ing a Bluetooth

device” from

step

. (

P.273)

■

Reconnecting the Blue-
tooth

phone

If a Bluetooth

phone is discon-

nected due to poor reception
from the Bluetooth

network

when the power switch is in
ACC or ON, the system auto-
matically reconnects the Blue-
tooth

phone.

Up to 5 Bluetooth

devices can

be registered.

Bluetooth

compatible phones

(HFP) and audio players (AVP)
can be registered simultane-
ously.
This operation cannot be per-
formed while driving.

Display the Bluetooth

set-

tings screen. (



Select “Add New Device”.



When another Bluetooth

device is connected

To disconnect the Bluetooth

device, select “Yes”.



When 5 Bluetooth

devices

have already been registered

A registered device needs to be
replaced. Select “Yes”, and select
the device to be replaced.

Follow the steps in “Register-
ing a Bluetooth

phone for

the first time” from step

(



This operation cannot be per-
formed while driving.

Display the Bluetooth

set-

tings screen. (

Select “Remove Device”.

Select the desired device.

Select “Yes” when the confir-
mation screen appears.

Check that a confirmation
screen is displayed when the
operation is complete.

When deleting a Bluetooth

phone,

the contact data will be deleted at

the same time.

Registering a Bluetooth

device

Deleting a Bluetooth

device

-------------------------------------------------------------------------------------------------------------------------------------------------------------

276

5-3. Connectivity settings

COROLLA HV_U

The Bluetooth

device’s infor-

mation can be displayed on the
screen. The displayed informa-
tion can be edited.
This operation cannot be per-
formed while driving.

Display the Bluetooth

set-

tings screen. (



Select “Registered Device”.

Select the desired device to
be edited.

Select “Device Info”.

Confirm and change the
Bluetooth

device informa-

tion.

The name of the Bluetooth

device is displayed. It can be
changed to a desired name.
(



Select to set the Bluetooth

audio player connection
method. (

Device address is unique to
the device and cannot be
changed.
Phone number is unique to
the Bluetooth

phone and

cannot be changed.
Compatibility profile is unique
to the Bluetooth

device and

cannot be changed.
Select to reset all setup
items.

Editing the Bluetooth

device information

-------------------------------------------------------------------------------------------------------------------------------------------------------------

277

5-3. Connectivity settings

COROLLA HV_U

Audio

●

If 2 Bluetooth

devices have been

registered with the same device

name, the devices can be distin-

guished referring to the device’s

address.

●

Depending on the type of Blue-
tooth

phone, some information

may not be displayed.

Select “Device Name”.

Enter the name and select
“OK”.

Even if the device name is changed,

the name registered in your Blue-
tooth

device does not change.

Select “Connect Audio Player
From”.

Select the desired connec-
tion method.

“Vehicle”: Select to connect the

audio player from the vehicle’s

audio/visual system.
“Device”: Select to connect the

vehicle’s audio/visual system from

the audio player.
Depending on the audio player, the

“Vehicle” or “Device” connection

method may be best. As such, refer

to the manual that comes with the

audio player.

The Bluetooth

settings can be

confirmed and changed.

Display the Bluetooth

set-

tings screen. (

Select “Detailed Settings”.

Select the desired item to be
set.

Select to set Bluetooth

con-

nection on/off. (



Select to change the auto-
matic connection priority of
the registered Bluetooth

devices. (

Select to edit the system
information. (



Select to reset all setup
items.

Select “Bluetooth Power”.

When “Bluetooth Power” is on:
The Bluetooth

device is auto-

Changing a device name

Setting audio player con-
nection method

“Detailed Settings”
screen

Changing “Bluetooth
Power”

-------------------------------------------------------------------------------------------------------------------------------------------------------------

278

5-3. Connectivity settings

COROLLA HV_U

matically connected when the
power switch is in ACC or ON.
When “Bluetooth Power” is off:
The Bluetooth

device is dis-

connected, and the system will
not connect to it next time.

While driving, the auto connection

state can be changed from off to on,

but cannot be changed from on to

off.

The automatic connection prior-
ity of the registered Bluetooth

devices can be changed.

Select “Preferred Device Set-
tings”.

Select the desired item to be
set.

Select to set automatic con-
nection priority on/off.
Select to change the auto-
matic connection priority of
the registered Bluetooth

phones. (



Select to change the auto-
matic connection priority of
the registered Bluetooth

audio players. (

Select to reset all setup
items.

■

Changing Bluetooth

device automatic connec-
tion priority

Select “Preferred Phones” or
“Preferred Audio Players”.

Select the desired Bluetooth

device and select “Move Up”
or “Move Down” to change
the preferred order.

A newly registered Bluetooth

device will automatically be given

the highest automatic connection

priority.

Select “System Information”.

Setting automatic connec-
tion priority

Editing the system infor-
mation

-------------------------------------------------------------------------------------------------------------------------------------------------------------

279

5-3. Connectivity settings

COROLLA HV_U

Audio

Select the desired item to be
set.

Displays system name. Can
be changed to a desired
name. (



P.279)

PIN code used when the
Bluetooth

device was regis-

tered. Can be changed to a
desired code. (

P.279)

Device address is unique to
the device and cannot be
changed.
Select to set the connection
status display of the phone
on/off.
Select to set the connection
status display of the audio
player on/off.
Compatibility profile of the
system
Select to reset all setup
items.

■

Editing the system name

Select “System Name”.

Enter a name and select
“OK”.

■

Editing the PIN code

Select “System PIN Code”.

Enter a PIN code and select
“OK”.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

280

5-3. Connectivity settings

COROLLA HV_U

: If equipped

Enable the Wi-Fi

Hotspot

function. (

Disable the “Hide Access
Point” function. (

P.280)

Search for the vehicle access
point using the device you
wish to connect.

For details about operating the

device, refer to the documentation

which came with it.

Operate the device to con-
nect it to the vehicle access
point.

To check the vehicle access point

password, check “Password”.

(



Hints for connecting to the vehicle
via Wi-Fi

can be displayed.

(



Enable the Wi-Fi

Hotspot

function. (



Enable the “Hide Access
Point” function. (



P.280)

Enter the access point name
(SSID) into the device you
wish to connect and connect
it.



To check the vehicle access
point password, check “Pass-
word”. (



The security settings on the
device must be the same as
that displayed for “Security”.
(





For details about operating
the device, refer to the docu-
mentation which came with it.

Wi-Fi

Hotspot

By connecting a device to
the vehicle via Wi-Fi

, it can

access the internet through
the DCM.



To use this function, a
Wi-Fi

Hotspot service sub-

scription from Verizon Wire-
less is required. Contact
your Toyota dealer for
details.



This function is not made
available in some countries
or areas.

Connecting a device to
the in-vehicle access
point

Searching for and con-
necting a device to the
vehicle access point

Connecting a device to the
in-vehicle access point
using the access point
name (SSID)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

281

5-3. Connectivity settings

COROLLA HV_U

Audio

Press the “MENU” button.

Select “Setup”.

Select “Wi-Fi

”.

: Wi-Fi

is a registered trademark

of Wi-Fi Alliance

Select the desired item to be
set.

Select to enable/disable the
Wi-Fi

Hotspot function.

(



Select to check/change the
access point password.
(



Select to display hints for
connecting to the vehicle via
Wi-Fi

Select to make the access
point searchable/unsearch-
able.
Select to check/change the
security protocol of the
access point (for authentica-
tion and encryption).
(



Select to change the access
point name (SSID). (



Select to change the Wi-Fi

connection channel (within
the 2.4GHz frequency band).
(



If any settings have been changed,

it will be necessary to reset the
Wi-Fi

system to complete the

changes. To reset the Wi-Fi

sys-

tem, select “Yes” on the pop-up dis-

played after changing the settings.

When the Wi-Fi

Hotspot func-

tion is enabled, the system
checks for a valid Hotspot ser-
vice subscription.
If a hotspot service subscription
has not been started, connect
your device to the in-vehicle
access point to start your sub-

Changing the Wi-Fi

set-

tings

Enabling/disabling the
Wi-Fi

Hotspot function

-------------------------------------------------------------------------------------------------------------------------------------------------------------

282

5-3. Connectivity settings

COROLLA HV_U

scription. A trial subscription
may be available.

Select “Password”.

Check that the following
screen is displayed.

Displays the password
Select to display/hide the
entered password.
Select to change the pass-
word.

Select “Change Password”.

Enter the desired password
and select “OK”.

When setting/changing a pass-

word, observe the following guide-

lines to help prevent the password

from being cracked by a third party:



Use an 8-character or longer
password consisting of letters
and numbers. (Non-ASCII
characters will not be recog-
nized by the system.)



Change the password regu-
larly.



If you write the password
down, do not leave it some-
where where it would be visi-
ble.



Do not use the same or a sim-
ilar password to that for other
accounts.



Avoid using easy to identify
words, such as your vehicle’s
model name or license plate
number, simple dictionary
words, or words with simple
obfuscation, such as c@t (for
cat), as your password.

Select “Security”.

Select the desired security
protocol.

Select “Access Point Name”.

Enter the desired access
point name (SSID) and select
“OK”.

Select “Channel”.

Checking/changing the
password

Changing the password

Changing the security pro-
tocol

Changing the access point
name (SSID)

Selecting a Wi-Fi

connec-

tion channel

-------------------------------------------------------------------------------------------------------------------------------------------------------------

283

5-3. Connectivity settings

COROLLA HV_U

Audio

Check that the following
screen is displayed.

Select to change the chan-
nel selection to auto-
matic/manual.
When “Manual” is selected,
select to change the channel.

Set “Select Channel” to
“Manual”.

Select “Channel Number”.

Enter the desired channel
number and select “OK”.

Channels 1 through 11 can be

selected.

■

Wi-Fi

function operating hints

●

If a connected device is taken out
of the Wi-Fi

connection area, the

connection will be severed.

●

If the vehicle is driven out of the

cellular communication coverage

area, connecting to the internet
via the Wi-Fi

Hotspot will not be

possible.

●

If a Bluetooth

device is used

while a device is connected using

the Wi-Fi

Hotspot function, the

communication speed may

decrease.

●

If the vehicle is near a radio

antenna, radio station or other

source of strong radio waves and

electrical noise, communication

may be slow or impossible.

The condition of Wi-Fi

connec-

tion appears on the right upper
side of the screen. (

P.256)

Changing the channel

Wi-Fi

function operating

hints

WARNING

●

Use Wi-Fi

devices only when

safe and legal to do so.

●

Your audio unit is fitted with
Wi-Fi

antennas. People with

implantable cardiac pacemak-

ers, cardiac resynchronization

therapy-pacemakers or implant-

able cardioverter defibrillators

should maintain a reasonable

distance between themselves
and the Wi-Fi

antennas.

The radio waves may affect the

operation of such devices.

●

Before using Wi-Fi

devices,

users of any electrical medical

device other than implantable

cardiac pacemakers, cardiac

resynchronization ther-

apy-pacemakers or implantable

cardioverter defibrillators should

consult the manufacturer of the

device for information about its

operation under the influence of

radio waves.

Radio waves could have unex-

pected effects on the operation

of such medical devices.

Conditions displayed with
Wi-Fi

icon

-------------------------------------------------------------------------------------------------------------------------------------------------------------

284

5-3. Connectivity settings

COROLLA HV_U



Communication standards
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n (2.4GHz)



Security
WPA™
WPA2™

• WPA™ and WPA2™ are trade-

marks of Wi-Fi Alliance

: This function is not made avail-

able in some countries or areas.

Enable Siri on the device to
be connected.

Specifications

Apple CarPlay/

Android Auto

Apple CarPlay allows some
applications, such as Map,
Phone, and Music, to be
used on the system.

When an Apple CarPlay
connection is established,
Apple CarPlay compatible
applications will be dis-
played on the system dis-
play.



Compatible devices

Apple iPhone (iOS Ver. 9.3 or
later) that supports Apple Car-
Play.

For details, refer to
https://www.apple.com/ios/car
play/.

Android™ devices with Android
OS Ver. 5.0 or higher which sup-
port Android Auto and have the
Android Auto application
installed.
For details, refer to

https://www.android.com/auto/
.

: Some devices may not operate

with this system.

Establishing an Apple
CarPlay connection

-------------------------------------------------------------------------------------------------------------------------------------------------------------

285

5-3. Connectivity settings

COROLLA HV_U

Audio

Connect the device to the
USB port. (



Select “Always Enable” or
“Enable Once”.



If “Do Not Enable” is selected,
an Apple CarPlay connection
will not be established. In this
case, the device can be oper-
ated as a normal Apple
device, such as an iPod.



Depending on the device con-
nected, it may take approxi-
mately 3 to 6 seconds before
an Apple CarPlay connection
is established.

Check that home screen of
Apple CarPlay is displayed.

Select to display the home
screen of Apple CarPlay.
Touch and hold to activate
Siri.
Select to start the application.
User can use any iPhone

application supported by
Apple CarPlay.
Select to display the system
screen.

Check that the Android Auto
application is installed to the
device to be connected.

Connect the device to the
USB port. (

Select “On” to enable the
function.



“Off”: Select to not enable
Android Auto. Android Auto
will remain off until “Android
Auto” of “Projection Settings”
on the general settings screen
is turned on.



Depending on the device con-
nected, it may take approxi-
mately 3 to 6 seconds before
the system returns to previous
screen.



The screen may change to
“step

” depending on the

system.

Establishing an Android
Auto connection

-------------------------------------------------------------------------------------------------------------------------------------------------------------

286

5-3. Connectivity settings

COROLLA HV_U

Press the “MENU” button.

Select “Android Auto”.

Check that home screen of
Android Auto is displayed.

●

When an Apple CarPlay/Android

Auto connection is established,

the function of some system but-

tons will change.

●

When an Apple CarPlay/Android

Auto connection is established,

some system functions, such as

the following, will be replaced by

similar Apple CarPlay/Android

Auto functions or will become

unavailable:

• iPod (Audio Playback)

• Hands-free Phone

• USB audio/USB video
• Bluetooth

audio

• Bluetooth

phone (Apple CarPlay

only)

• Toyota apps

●

When an Apple CarPlay/Android

Auto connection is established,

voice command system (Siri/Goo-

gle Assistant) and map application

voice guidance volume can be

changed by selecting “Voice Vol-

ume” on the voice settings screen.

It cannot be changed by “POWER

VOLUME” knob on Audio control

panel. (

P.295)

●

Apple CarPlay/Android Auto is an

application developed by Apple

Inc/Google LLC. Its functions and

services may be terminated or

changed without notice depending

on the connected device’s opera-

tion system, hardware and soft-

ware, or due to changes in Apple

CarPlay/Android Auto specifica-

tions.

●

For a list of the apps supported by

Apple CarPlay or Android Auto,

refer to their respective website.

●

While using these functions, vehi-

cle and user information, such as

location and vehicle speed, will be

shared with the respective appli-

cation publisher and the cellular

service provider.

●

By downloading and using each

application, you agree to their

●

Data for these functions is trans-

mitted using the internet and may

incur charges.

For information about data trans-

mission fees, contact your cellular

service provider.

●

Depending on the application, cer-

tain functions, such as music play-

back, may be restricted.

●

As the applications for each func-

tion are provided by a third-party,

they may be subject to change or

discontinuation without notice.

For details, refer to the website of

the function.

●

If the USB cable is disconnected,

operation of Apple Car-

Play/Android Auto will end.

At this time, sound output will stop

and change to the system screen.

●

Use of the Apple CarPlay logo

means that a vehicle user inter-

face meets Apple performance

standards. Apple is not responsi-

ble for the operation of this vehicle

-------------------------------------------------------------------------------------------------------------------------------------------------------------

287

5-3. Connectivity settings

COROLLA HV_U

Audio

or its compliance with safety and

regulatory standards. Please note

that the use of this product with

iPhone or iPod may affect wire-

less performance.

●

Apple CarPlay is a trademark of

Apple Inc.

●

Compatible models

Made for

• iPhone X

• iPhone 8

• iPhone 8 Plus

• iPhone 7

• iPhone 7 Plus

• iPhone SE

• iPhone 6s

• iPhone 6s Plus

• iPhone 6

• iPhone 6 Plus

• iPhone 5s

• iPhone 5c

• iPhone 5

●

Android and Android Auto are

trademarks of Google LLC.

If you are experiencing difficulties with Apple CarPlay/Android Auto,
check the following table.

WARNING

Do not connect iPhone or operate

the controls while driving.

NOTICE

●

Do not leave your iPhone in the

vehicle. In particular, high tem-

peratures inside the vehicle

may damage the iPhone.

●

Do not push down on or apply

unnecessary pressure to the

iPhone while it is connected as

this may damage the iPhone or

its terminal.

●

Do not insert foreign objects into

the port as this may damage the

iPhone or its terminal.

Troubleshooting

-------------------------------------------------------------------------------------------------------------------------------------------------------------

288

5-3. Connectivity settings

COROLLA HV_U

Symptom

Solution

An Apple Car-
Play/Android Auto con-
nection cannot be
established.

Check if the device supports Apple Car-
Play/Android Auto.
Check if Apple CarPlay/Android Auto is
enabled on the connected device.
Check if that the Android Auto application is
installed to the device to be connected.
For details, refer to
Apple CarPlay:
https://www.apple.com/ios/carplay/.
Android Auto:
https://www.android.com/auto/.

Check if “Apple CarPlay”/“Android Auto” of
“Projection Settings” on the general settings
screen is set to on. (

Check if the USB cable being used is securely
connected to the device and USB port.
Check that the device is connected directly to
the USB port of the system and not connected
to a USB hub.
For Apple CarPlay: Check if the Lightning cable
being used is certified by Apple. Check if Siri is
enabled.

After checking all of the above, try to establish
an Apple CarPlay/Android Auto connection.
(

P.284, 285)

When an Apple Car-
Play/Android Auto con-
nection is established and
a video is being played,
the video is not displayed,
but audio is output
through the system.

As the system is not designed to play video
through Apple CarPlay/Android Auto, this is not
a malfunction.

Although an Apple Car-
Play/Android Auto con-
nection is established,
audio is not output
through the system.

The system may muted or the volume may be
low. Increase the system volume.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

289

5-3. Connectivity settings

COROLLA HV_U

Audio

The Apple Car-
Play/Android Auto screen
has artifacts and/or audio
from Apple Car-
Play/Android Auto has
noise.

Check if the USB cable being used to connect
the device to the system is damaged.
To check if the USB cable is damaged inter-
nally, connect the device to another system,
such as a PC, and check if the device is recog-
nized by the connected system. (The device
should begin charging when connected.)

After checking all of the above, try to establish
an Apple CarPlay/Android Auto connection.
(

P.284, 285)

The map display of the
Apple CarPlay Maps app
cannot be enlarged or
contracted with pinch
multi-touch gestures.

As the Apple CarPlay Maps app is not compati-
ble with pinch multi-touch gestures, this is not a
malfunction.

During Apple CarPlay
music application (Apple
Music, Spotify, etc.) play-
back, if the iPhone is
operated to start and play
audio from an application
that is not compatible with
Apple CarPlay* and the
onboard device volume is
changed, the audio of the
incompatible application
stops and the system
resumes playback of the
original music application.

This operation is performed according to the
specification of the onboard device, this is not a
malfunction.

After interrupt audio (such
as navigation route guid-
ance) is played from an
application that is not
compatible with Apple
CarPlay while the onboard
device is playing audio,
the system does not
resume playback of the
original audio.

This operation is performed according to the
specification of the onboard device, this is not a
malfunction.
Manually change the audio source by yourself.
Or, do not use applications that are not compat-
ible with Apple CarPlay.

Due to some naviga-

tion applications are compatible from iOS 12,
update to the latest iOS and application ver-
sions.

Symptom

Solution

-------------------------------------------------------------------------------------------------------------------------------------------------------------

290

5-3. Connectivity settings

COROLLA HV_U

: Applications not compatible with Apple CarPlay are applications installed

on the iPhone that are not displayed on the Apple CarPlay screen appli-
cation list. (such as visual voicemail)

When using Apple Car-
Play, route guidance
arrows and turn by turn
navigation are not dis-
played on the multi-infor-
mation display and
system display.
When using Android Auto,
turn by turn navigation is
not displayed on the
multi-information display
and system display.

This is not a malfunction as display of these
items is not possible with this function.

When using Android Auto,
hands-free call audio can-
not be heard from the
vehicle’s speakers.

Disconnect the phone from the USB cable and
check if hands-free call audio can be heard
using the hands-free system.

Connect the phone to the system using Android
Auto, turn up the volume on the system and
check if hands-free call audio can be heard.
Check if other sounds can be heard from the
vehicle’s speakers.

Symptom

Solution

-------------------------------------------------------------------------------------------------------------------------------------------------------------

291

5-4. Other settings

COROLLA HV_U

Audio

5-4.Other settings

Press the “MENU” button.

Select “Setup”.

If the general settings screen is not

displayed, select “General”.

Select the desired items to
be set.



“Clock”

Select to change the time zone and
select “On” or “Off” for daylight sav-
ing time, automatic adjustment of
the clock, etc. (

P.292)



“Language”

Select to change the language. The
language setting of Apple Car-
Play/Android Auto can only be
changed on the connected device.



“Customize Home Screen”

Select to change the display infor-
mation/area on the home screen
and the home screen layout.
(



P.262)



“Theme Setting”

Select to change the screen theme
setting.



“Beep”

Select to turn the beep sound
on/off.



“Units of Measurement”

Select to change the unit of mea-
sure for distance/fuel consumption.



“Keyboard Layout”

Select to change the keyboard lay-
out.



“Delete Keyboard History”

Select to delete the keyboard his-
tory.



“Memorize Keyboard History”

Select to set the memorize key-
board history on/off.



“Animation”

Select to turn the animations on/off.



“Projection Settings”

Select to set automatic Apple Car-
Play/Android Auto connection
establishment on/off. (



P.293)



“Driver Setting”

Select to change the driver set-

General settings

Settings are available for
clock, operation sounds,
etc.

Displaying the general
settings screen

General settings screen

-------------------------------------------------------------------------------------------------------------------------------------------------------------

292

5-4. Other settings

COROLLA HV_U

tings. (

P.293)



“Delete Personal Data”

Select to delete personal data.
(

P.294)



“Software Update”

Select to update software versions.
For details, contact your Toyota
dealer.



“Software Update Setting”

Select to set software update set-
ting. (



P.294)



“Gracenote Database
Update”

Select to update Gracenote

data-

base versions. For details, contact
your Toyota dealer.



“Software Information”

Select to display the software infor-
mation. Notices related to third
party software used in this product
are enlisted. (This includes instruc-
tions for obtaining such software,
where applicable.)



“SW Sensitivity Level”

Select to change the capacitive
touch screen button sensitivity to 1
(low), 2 (medium), or 3 (high).

:This function is not made avail-

able in some countries or areas.

:If equipped

Display the general settings
screen. (

Select “Clock”.

Select the desired items to
be set.

Select to change the time
zone. (



P.292)

Select to set daylight saving
time on/off.
Select to set automatic
adjustment of the clock by
GPS on/off.
When set to off, the clock can
be manually adjusted.
(

P.292)

Select to set the 24 hour time
format on/off.
When set to off, the clock is
displayed in 12 hour time for-
mat.

Select “Time Zone”.

Select the desired time zone.

When “Auto Adjust by GPS” is
turned off, the clock can be
manually adjusted.

Select “Auto Adjust by GPS”
to set to off.

Clock settings

Setting the time zone

Manual clock setting

-------------------------------------------------------------------------------------------------------------------------------------------------------------

293

5-4. Other settings

COROLLA HV_U

Audio

Adjust the clock manually.

Select “+” to set the time for-
ward one hour and “-” to set
the time back one hour.
Select “+” to set the time for-
ward one minute and “-” to
set the time back one minute.
Select to round to the nearest
hour.
e.g.
1:00 to 1:29



1:00

1:30 to 1:59



2:00

: This function is not made avail-

able in some countries or areas.

Display the general settings
screen. (

Select “Projection Settings”.

Select the desired items to
be set.

Select to turn Apple CarPlay

connection establishment
on/off when a compatible
iPhone is connected to the
system via USB. (



P.284)

Depending on the system,
this setting cannot be
changed when a device is
connected to the system via
USB. Disconnect the device
before attempting to change
the setting.
Select to turn Android Auto
connection establishment
on/off when a compatible
device is connected to the
system via USB. (



P.285)

Depending on the system,
this setting cannot be
changed when a device is
connected to the system via
USB. Disconnect the device
before attempting to change
the setting.

The driver settings feature will
allow the system to link some
preferences (such as audio pre-
sets, screen theme, language,
etc.) to a paired Bluetooth

phone.

Display the general settings
screen. (



Select “Driver Setting”.

Projection settings

Driver settings

-------------------------------------------------------------------------------------------------------------------------------------------------------------

294

5-4. Other settings

COROLLA HV_U

Select “Enable This Feature”.

Select “Manually Select
Linked Settings”.

Select the desired phone.

After a few seconds, loaded screen
automatically switches to the home
screen.

Registered or changed per-
sonal settings will be deleted or
returned to their default condi-
tions.

Display the general settings
screen. (

Select “Delete Personal
Data”.

Select “Delete”.

Select “Yes” when the confir-
mation screen appears.

Examples of settings that can be

returned to their default conditions:



Audio settings



Phone settings

etc.

: This function is not made avail-

able in some countries or areas.

When the automatic update
check function is enabled, if a
software update is available
from the Toyota response cen-
ter, a message will be displayed.

Display the general settings
screen. (



Select “Software Update Set-
ting”.

Select “Automatic Update
Check” to enable/disable the
automatic update check func-
tion.

When software update information

is displayed, contact your Toyota

dealer.

Manually select linked set-
tings

Deleting personal data

Software update settings

-------------------------------------------------------------------------------------------------------------------------------------------------------------

296

5-4. Other settings

COROLLA HV_U

Press the “MENU” button.

Select “Setup”.

Select “Vehicle”.

Select the desired items to
be set.

Select to set vehicle customi-
zation. (



P.544)

Select to set valet mode.
(



P.296)

The security system can be set
to on by entering a security code
(4-digit number).
When set to on, the system will
become inoperative once the
electrical power source is dis-
connected until the security
code is entered.

Display the vehicle settings
screen. (



P.296)

Select “Valet Mode”.

Enter the 4-digit personal
code and select “OK”.

Enter the same 4-digit per-
sonal code again and select
“OK”.



The system will request that
you input the security code
again to confirm that you
remember it correctly.



When valet mode activates,
the system stops and a secu-
rity code (4-digit number)
standby screen is displayed.

If the 4-digit personal code is forgot-

ten, please contact your Toyota

dealer.

Enter the 4-digit personal code
and select “OK”.

If an incorrect security code (4-digit

number) is entered 6 times, the sys-

tem will not accept another security

Vehicle settings

Settings are available for
vehicle customization, etc.

Displaying the vehicle
settings screen

Vehicle settings screen

Setting the valet mode

If the valet mode has been
activated

-------------------------------------------------------------------------------------------------------------------------------------------------------------

298

5-5. Using the audio/visual system

COROLLA HV_U

5-5.Using the audio/visual system

The audio control screen can be reached by the following methods:



From the “AUDIO” button

Press the “AUDIO” button.



From the “MENU” button

Press the “MENU” button, then select “Audio”.

• Using the radio (



P.303)

• Playing a USB memory (

P.309)

• Playing an iPod/iPhone (Apple CarPlay

) (

P.311)

• Using the Android Auto

(



P.314)

• Playing a Bluetooth

device (



P.315)

• Using the steering wheel audio switches (



P.319)

• Audio system settings (

: This function is not made available in some countries or areas.

Quick reference

Functional overview

-------------------------------------------------------------------------------------------------------------------------------------------------------------

299

5-5. Using the audio/visual system

COROLLA HV_U

Audio

“POWER VOLUME” knob:
Press to turn the audio/visual
system on and off. The system
turns on in the last mode used.
Turn this knob to adjust the vol-
ume.

Press the “AUDIO” button.

Select “Source” or press
“AUDIO” button again.

Select the desired source.

●

Dimmed screen buttons cannot be

operated.

●

When there are two pages, select

to change the page.

●

When an Apple CarPlay/Android

Auto connection is established,

some system functions, such as

the following, will be replaced by

similar Apple CarPlay/Android

Auto function or will become
unavailable

• iPod (Audio Playback)

• USB audio/USB video
• Bluetooth

audio

• Toyota apps

: This function is not made avail-

able in some countries or areas.

Display the audio source
selection screen. (

Select “Reorder”.

Some basics

This section describes
some of the basic features
of the audio/visual system.
Some information may not
pertain to your system.

Your audio/visual system
works when the power
switch is in ACC or ON.

NOTICE

To prevent the battery from being

discharged, do not leave the

audio/visual system on longer

than necessary when the hybrid

system is not running.

Turning the system on
and off

Selecting an audio source

Reordering the audio
source

-------------------------------------------------------------------------------------------------------------------------------------------------------------

300

5-5. Using the audio/visual system

COROLLA HV_U

Select the desired audio
source then

to reor-

der.

Select “OK”.

Connect a device.

Turn on the power of the device if it
is not turned on.

●

If a USB hub is plugged-in, two

devices can be connected at a

time.

●

Even if a USB hub is used to con-

nect more than two USB devices,

only the first two connected

devices will be recognized.

●

If a USB hub that has more than

two ports is connected to the USB

port, devices connected to the

USB hub may not charge or be

inoperable, as the supply of cur-

rent may be insufficient.

Display the audio control
screen. (

Select “Sound”.

Select the desired item to be
set.

Select to set the tre-
ble/mid/bass. (



Select to set the fader/bal-
ance. (



P.301)

Select to set the automatic
sound levelizer. (

P.301)

■

Treble/Mid/Bass

How good an audio program
sounds is largely determined by
the mix of the treble, mid and
bass levels. In fact, different
kinds of music and vocal pro-
grams usually sound better with
different mixes of treble, mid
and bass.

Select “Treble/Mid/Bass”.

Select the desired screen
button.

Select “+” or “-” to adjust
high-pitched tones.

USB port

Sound settings

-------------------------------------------------------------------------------------------------------------------------------------------------------------

301

5-5. Using the audio/visual system

COROLLA HV_U

Audio

Select “+” or “-” to adjust
mid-pitched tones.
Select “+” or “-” to adjust
low-pitched tones.

■

Fader/Balance

A good balance of the left and
right stereo channels and of the
front and rear sound levels is
also important.
Keep in mind that when listening
to a stereo recording or broad-
cast, changing the right/left bal-
ance will increase the volume of
1 group of sounds while
decreasing the volume of
another.

Select “Fader/Balance”.

Select the desired screen
button.

Select to adjust the sound
balance between the front
and rear speakers.
Select to adjust the sound
balance between the left and
right speakers.

■

Automatic sound levelizer
(ASL)

The system adjusts to the opti-
mum volume and tone quality

according to vehicle speed to
compensate for increased road
noise, wind noise, or other
noises while driving.

Select “Automatic Sound
Levelizer”.

Select “High”, “Mid”, “Low” or
“Off”.

■

Screen format settings

The screen format can be
selected for USB video.

Press the “MENU” button.

Select “Setup”.

Select “Audio”.

Select “Common”.

Select “Screen Format”.

Select the desired item to be
adjusted.

Select to display a 4 : 3
screen, with either side in
black.
Select to enlarge the image
horizontally and vertically to
full screen.
Select to enlarge the image
by the same ratio horizontally

Audio screen adjustment

-------------------------------------------------------------------------------------------------------------------------------------------------------------

302

5-5. Using the audio/visual system

COROLLA HV_U

and vertically.

■

Contrast and brightness
adjustment

The contrast and brightness of
the screen can be adjusted.

Press the “MENU” button.

Select “Setup”.

Select “Audio”.

Select “Common”.

Select “Display”.

Select the desired item to be
adjusted.



“Contrast”

“+”: Select to strengthen the con-
trast of the screen.
“-”: Select to weaken the contrast of
the screen.



“Brightness”

“+”: Select to brighten the screen.
“-”: Select to darken the screen.

Depending on the audio source,

some functions may not be avail-

able.

Press this switch to operate
the voice command system.

The voice command system and its

list of commands can be operated.

(



P.334)

Voice command system

-------------------------------------------------------------------------------------------------------------------------------------------------------------

303

5-6. Radio operation

COROLLA HV_U

Audio

5-6.Radio operation

: If equipped

The radio operation screen can
be reached by the following
methods:



Select to display the audio
source selection screen.
Select to display the preset
stations screen. (



P.303)

Select to display a list of
receivable stations. (

P.304)

Select to display the radio
options screen. (



P.304)

Select to display the sound
setting screen. (

Select to tune to preset sta-
tions/channels. (

P.303)

Press to seek for stations in
the relevant program type.
Press and hold for continu-
ous seek.
Turn to step up/down fre-
quencies.
Turn to move up/down the
station. Also, the knob can be
used to enter selections on
the list screens by pressing it.

The radio automatically changes to

stereo reception when a stereo

broadcast is received.

Radio mode has a mix preset
function, which can store up to
36 stations (6 stations per page
x 6 pages) from any of the AM,
FM or SXM bands.

Tune in the desired station.

AM radio/FM radio/Siri-

usXM

Satellite

Radio(SXM)

Overview

Control screen

Control panel

Presetting a station

-------------------------------------------------------------------------------------------------------------------------------------------------------------

304

5-6. Radio operation

COROLLA HV_U

Select and hold “(Hold Edit)”.



To change the preset station
to a different one, select and
hold the preset station.

The number of preset radio stations

displayed on the screen can be

changed. (

Select “Station List”.

Select “AM”, “FM” or “SXM”.

Select the desired program genre

when the genre selection screen is

displayed.

Select the desired station.

■

Refreshing the station list

Select “Refresh”.

“Cancel Refresh”: Select to can-
cel the refresh.
“Source”: Select to change to
another audio source while
refreshing.

●

The audio/visual system sound is

muted during refresh operation.

●

In some situations, it may take

some time to update the station

list.

Select “Options”.

Select the desired item to be
set.

When “SXM Tune Start” is
turned on, the current song is
played from the beginning
when you select the channel.
Analog FM only: Select to
display RBDS text mes-
sages.
Select to scan for receivable
stations.

This audio/visual system is
equipped with Radio Broadcast
Data Systems (RBDS). RBDS
mode allows text messages to
be received from radio stations
that utilize RBDS transmitters.
When RBDS is on, the radio can
do the following functions.
• Only selecting stations of a

particular program type

• Displaying messages from

radio stations

• Searching for a stronger sig-

Selecting a station from
the list

Radio options

Radio Broadcast Data
System

-------------------------------------------------------------------------------------------------------------------------------------------------------------

305

5-6. Radio operation

COROLLA HV_U

Audio

nal station

RBDS features are available
only when listening to an FM
station that broadcasts RBDS
information and the “FM Info”
function is on. (



P.304)

All SiriusXM services, including
satellite radio and data services,
plus streaming services, require
a subscription, sold separately
or as a package by Sirius XM
Radio Inc. (or in Canada, Sirius
XM Canada Inc.), after any trial
subscription which may be
included with your vehicle pur-
chase or lease. To subscribe
after your trial subscription, call
1-877-447-0011 (U.S.A.) or
1-877-438-9677 (Canada).

■

Important information
about your subscription

Your SiriusXM services will
automatically stop at the end of
your trial unless you decide to
subscribe. If you decide to con-
tinue service, the paid subscrip-
tion plan you choose will
automatically renew and you will
be charged the rate in effect at
that time and according to your
chosen payment method. Fees
and taxes apply. You may can-
cel at any time by calling
1-866-635-2349. See SiriusXM
Customer Agreement for com-

plete terms at www.siri-
usxm.com (U.S.A.) or
www.siriusxm.ca (Canada). All
fees and programming subject
to change. Traffic information
not available in all markets.

●

About SiriusXM Services

• Most in-car trials today include

SiriusXM’s best package — All

Access. It includes every channel

available on your radio, plus

streaming.

●

SiriusXM All Access Subscription

• Listen everywhere with All

Access. You get every channel

available in your ride, plus you can

listen on the app and online — so

you can enjoy the best SiriusXM

has to offer, anywhere life takes

you. It’s the only package that

gives you all of our premium pro-

gramming, including Howard
Stern, every NFL, MLB

and NBA

How to subscribe to Siri-
usXM Radio Services

NOTICE

●

It is prohibited to copy, decom-

pile, disassemble, reverse engi-

neer, hack, manipulate, or

otherwise make available any

technology or software incorpo-

rated in receivers compatible

with the SiriusXM Satellite

Radio System or that support

the SiriusXM website, the

streaming service or any of its

content. Furthermore, the
AMBE

voice compression soft-

ware included in this product is

protected by intellectual prop-

erty rights including patent

rights, copyrights, and trade

secrets of Digital Voice Sys-

tems, Inc.

●

Note: this applies to SiriusXM

Satellite Radio receivers only

and not SiriusXM Ready

devices.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

306

5-6. Radio operation

COROLLA HV_U

game, every NASCAR

race,

NHL

games, 24/7 talk channels

dedicated to the biggest leagues,

and more. You get all kinds of

commercial-free music, including

artist-dedicated channels and

more, plus sports, news, talk and

entertainment.

●

Radio operation

• Look for the Sirius, XM, SiriusXM,

Band, SAT, AUX, Radio or Source

button and you’re in. If you can’t

hear us, it’s easy to get started:

U.S.A.:

Locate your Radio ID by turning to

Channel 0. If you don’t see your

number there, go to siri-

usxm.com/activationhelp to find it.

Visit siriusxm.com/refresh or call

1-855-MYREFRESH (697-3373)

to send a refresh signal to your

radio.

Canada:

Locate your Radio ID by turning to

Channel 0.

Visit siriusxm.ca/refresh to send a

refresh signal to your radio or call

1-888-539-7474 for service.

Each SiriusXM tuner is identified
with a unique radio ID. The radio
ID is required when activating
an SiriusXM service or when
reporting a problem.



If “Ch 000” is selected using
the “TUNE SCROLL” knob,
the ID code, which is 8 alpha-
numeric characters, will be
displayed. If another channel
is selected, the ID code will no
longer be displayed. The
channel (000) alternates
between displaying the radio
ID and the specific radio
code.

When problems occur with the SiriusXM tuner, a message will
appear on the screen. Referring to the table below to identify the
problem, take the suggested corrective action.

Displaying the radio ID

Refer to the table below to identify the problem and take
the suggested corrective action

Message

Explanation

“Check
Antenna”

The SiriusXM antenna is not connected. Check whether the
SiriusXM antenna cable is attached securely. Contact your
Toyota dealer for assistance.

A short circuit occurs in the antenna or the surrounding
antenna cable. Contact your Toyota dealer for assistance.

“No Signal”

The SiriusXM signal is too weak at the current location. Wait
until your vehicle reaches a location with a stronger signal.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

308

5-6. Radio operation

COROLLA HV_U

●

Other applications can be acti-

vated while listening to internet

radio.

●

Some parts of applications can be

adjusted using the switches on the

steering wheel.

●

For additional information, refer to

https://www.toyota.com/

audio-multimedia or call

1-800-331-4331 in the United

States,

https://www.toyota.ca/connected

or call

1-888-869-6828 in Canada, and

http://www.toyotapr.com/

audio-multimedia or call

1-877-855-8377 in Puerto Rico.

Display the audio source
selection screen. (



Select the desired application
screen button.



The internet radio application
screen is displayed.



Perform operations accord-
ing to the displayed applica-
tion screen.



For the instrument panel
operation method:



If a compatible phone is

already registered, it will be
connected automatically.

Internet radio

One of Toyota apps Connect
features is the ability to lis-
ten to internet radio. In
order to use this service, a
compatible phone and the
system needs to be set up.
For details:



P.379

Listening to internet radio

-------------------------------------------------------------------------------------------------------------------------------------------------------------

309

5-7. Media operation

COROLLA HV_U

Audio

5-7.Media operation

The USB memory operation
screen can be reached by the
following methods:



Connecting a USB memory
(

When an Apple CarPlay/Android
Auto connection is established,
this function will be unavailable

: This function is not made avail-

able in some countries or areas.



USB audio

Select to display the audio
source selection screen.
Select to return to the top
screen.
Select to display a song list
screen.
Select to display the play
mode selection screen.
Select to display the sound
setting screen. (



Select to set repeat playback.
(

P.310)

Select to change the
file/track.
Select and hold to fast
rewind.
Select to play/pause.
Select to change the
file/track.
Select and hold to fast for-
ward.
Select to set random play-
back. (

P.311)

Select to change the
folder/album.
Displays cover art

USB memory

WARNING

Do not operate the player’s con-

trols or connect the USB memory

while driving.

NOTICE

●

Do not leave your portable

player in the car. In particular,

high temperatures inside the

vehicle may damage the porta-

ble player.

●

Do not push down on or apply

unnecessary pressure to the

portable player while it is con-

nected as this may damage the

portable player or its terminal.

●

Do not insert foreign objects into

the port as this may damage the

portable player or its terminal.

Overview

Control screen

-------------------------------------------------------------------------------------------------------------------------------------------------------------

310

5-7. Media operation

COROLLA HV_U

Select to change the artist.



USB video

Select “Browse”.

Select “Videos”.

Select the desired folder and
file.

Select to change the file.
Select and hold to fast
rewind.
Select to play/pause.
Select to change the file.
Select and hold to fast for-
ward.
Select to display a full screen
image.
Select to change the folder.

Press to change the
file/track.
Press and hold to fast for-
ward/rewind.
Turn to change the file/track.
Turn to move up/down the
list. Also, the knob can be
used to enter selections on
the list screens by pressing it.

●

While the vehicle is being driven,

this function can only output

sound.

●

If tag information exists, the

file/folder names will be changed

to track/album names.

The file/track or folder/album
currently being listened to can
be repeated.

Select

●

Each time

is selected, the

mode changes as follows:



When random playback is off

File/track repeat



folder/album

repeat



off



When random playback is on

File/track repeat



off

Control panel

Repeating

-------------------------------------------------------------------------------------------------------------------------------------------------------------

311

5-7. Media operation

COROLLA HV_U

Audio

Files/tracks or folders/albums
can be automatically and ran-
domly selected.

Select

Each time

is selected, the

mode changes as follows:
Random (1 folder/album random)



folder/album random (all

folder/album random)



off

: This function is not made avail-

able in some countries or areas.

The iPod/iPhone(Apple Car-
Play) operation screen can be
reached by the following meth-
ods:

Connecting an iPod/iPhone
(



P.284, 300)

When an Android Auto connec-
tion is established, this function
will be unavailable.

: This function is not made avail-

able in some countries or areas.



An Apple CarPlay connection
is not established

Random order

iPod/iPhone (Apple

CarPlay

)

Overview

Control screen

-------------------------------------------------------------------------------------------------------------------------------------------------------------

312

5-7. Media operation

COROLLA HV_U



An Apple CarPlay connection
is established

Select to set repeat playback.
(



P.313)

Select to change the track.
Select and hold to fast
rewind.
Select to play/pause.
Select to change the track.
Select and hold to fast for-
ward.
Select to set random play-
back. (



P.313)

Displays cover art
Select to change the album.
Select to change the artist.
Select to change the playlist.
Select to display the audio

control screen of Apple Car-
Play.

Press to change the track.
Press and hold to fast for-
ward/rewind.
Turn to change the track.
Turn to move up/down the
list. Also, the knob can be
used to enter selections on
the list screens by pressing it.

●

Some functions may not be avail-

able depending on the type of

model.

●

When an iPod/iPhone is con-

nected using a genuine

iPod/iPhone cable, the

iPod/iPhone starts charging its

battery.

●

Depending on the iPod/iPhone,

the video sound may not be able

to be heard.

●

Depending on the iPod/iPhone

and the songs in the iPod/iPhone,

a cover art may be displayed. This

function can be changed to “On”

or “Off”. (



P.321) It may take time

to display the cover art, and the

iPod/iPhone may not be operated

while the cover art display is in

process.

●

When an iPod/iPhone is con-

nected and the audio source is

Control panel

-------------------------------------------------------------------------------------------------------------------------------------------------------------

313

5-7. Media operation

COROLLA HV_U

Audio

changed to iPod/iPhone mode,

the iPod/iPhone will resume play-

ing from the same point it was last

used.

●

Tracks selected by operating a

connected iPod/iPhone may not

be recognized or displayed prop-

erly.

●

The system may not function

properly if a conversion adapter is

used to connect a device.

The track currently being lis-
tened to can be repeated.

Select

●

Each time

is selected, the

mode changes as follows:



When shuffle is off (iPhone 5 or

later)

• Track repeat



album repeat



off



When shuffle is off (iPhone 4s or

earlier)

• Track repeat



off



When shuffle is on

• Track repeat



off

Tracks or albums can be auto-
matically and randomly
selected.

Select

●

Each time

is selected, the

mode changes as follows:

• Shuffle (1 album shuffle)



album

shuffle (all album shuffle)



off

Repeating

Random order

WARNING

Do not operate the player’s con-

trols or connect the iPod/iPhone

while driving.

NOTICE

●

Do not leave your portable

player in the vehicle. In particu-

lar, high temperatures inside the

vehicle may damage the porta-

ble player.

●

Do not push down on or apply

unnecessary pressure to the

portable player while it is con-

nected as this may damage the

portable player or its terminal.

●

Do not insert foreign objects into

the port as this may damage the

portable player or its terminal.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

314

5-7. Media operation

COROLLA HV_U

: This function is not made avail-

able in some countries or areas.

The Android Auto operation
screen can be reached by the
following methods:



Connecting an Android device
(

P.284, 30 0)

When an Apple CarPlay con-
nection is established, this func-
tion will be unavailable.

: This function is not made avail-

able in some countries or areas.

Select to display the audio
source selection screen.
Select to return to the top
screen.
Select to display the sound
setting screen. (

Select to display the audio
control screen of Android
Auto.
Select to change the track.

Select to play/pause.
Select to change the track.
Displays cover art

Press to change the track.
Turn to change the track.

Android Auto

Overview

Control screen

Control panel

WARNING

Do not connect smartphone or

operate the controls while driving.

NOTICE

●

Do not leave your smartphone

in the vehicle. In particular, high

temperatures inside the vehicle

may damage the smartphone.

●

Do not push down on or apply

unnecessary pressure to the

smartphone while it is con-

nected as this may damage the

smartphone or its terminal.

●

Do not insert foreign objects into

the port as this may damage the

smartphone or its terminal.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

315

5-7. Media operation

COROLLA HV_U

Audio

●

Depending on the Bluetooth

device that is connected to the

system, the music may start play-
ing when selecting

while it is

paused. Conversely, the music
may pause when selecting

while it is playing.

●

In the following conditions, the

system may not function:

• The Bluetooth

device is turned

off.

• The Bluetooth

device is not con-

nected.

• The Bluetooth

device has a low

battery.

●

When using the Bluetooth

audio

and Wi-Fi

Hotspot functions at

the same time, the following prob-

lems may occur:

• It may take longer than normal to

connect to the Bluetooth

device.

• The sound may cut out.

●

It may take time to connect the

phone when Bluetooth

audio is

being played.

●

For operating the portable player,

see the instruction manual that

comes with it.

●

If the Bluetooth

device is discon-

nected due to poor reception from
the Bluetooth

network when the

power switch is in ACC or ON, the

system automatically reconnects

the portable player.

●

If the Bluetooth

device is discon-

nected on purpose, such as it was

turned off, this does not happen.

Reconnect the portable player

manually.

●

Bluetooth

device information is

registered when the Bluetooth

device is connected to the Blue-
tooth

audio system. When selling

or disposing of the vehicle,
remove the Bluetooth

audio

information from the system.

(



P.294)

●

In some situations, sound output
via the Bluetooth

audio system

may be out of sync with the con-

nected device or output intermit-

tently.

Bluetooth

audio

The Bluetooth

audio sys-

tem enables users to enjoy
listening to music that is
played on a portable player
on the vehicle speakers via
wireless communication.

This audio/visual system
supports Bluetooth

, a wire-

less data system capable of
playing portable audio
music without cables. If
your device does not sup-
port Bluetooth

, the Blue-

tooth

audio system will not

function.

WARNING

●

Do not operate the player’s con-

trols or connect to the Blue-
tooth

audio system while

driving.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

316

5-7. Media operation

COROLLA HV_U

The Bluetooth

audio operation

screen can be reached by the
following methods:



Connecting a Bluetooth

audio

device (

Depending on the type of porta-
ble player connected, some
functions may not be available

and/or the screen may look dif-
ferently than shown in this man-
ual.
When an Apple CarPlay/Android
Auto connection is established,
Bluetooth

audio will be sus-

pended and become unavail-
able

: This function is not made avail-

able in some countries or areas.

Select to display the sound
setting screen. (



Select to set repeat playback.
(

Select to change the track.
Select and hold to fast

WARNING

●

Your audio unit is fitted with
Bluetooth

antennas. People

with implantable cardiac pace-

makers, cardiac resynchroniza-

tion therapy-pacemakers or

implantable cardioverter defibril-

lators should maintain a reason-

able distance between
themselves and the Bluetooth

antennas. The radio waves may

affect the operation of such

devices.

●

Before using Bluetooth

devices, users of any electrical

medical device other than

implantable cardiac pacemak-

ers, cardiac resynchronization

therapy-pacemakers or implant-

able cardioverter defibrillators

should consult the manufacturer

of the device for information

about its operation under the

influence of radio waves. Radio

waves could have unexpected

effects on the operation of such

medical devices.

NOTICE

Do not leave your portable player

in the vehicle. In particular, high

temperatures inside the vehicle

may damage the portable player.

Overview

Control screen

-------------------------------------------------------------------------------------------------------------------------------------------------------------

317

5-7. Media operation

COROLLA HV_U

Audio

rewind.
Select to play/pause.
Select to change the track.
Select and hold to fast for-
ward.
Select to set random play-
back. (



Select to change the album.
Displays cover art

The track or album currently
being listened to can be
repeated.

Select

●

Each time

is selected, the

mode changes as follows:



When random playback is off

Track repeat



album repeat



off



When random playback is on

Track repeat



off

Tracks or albums can be auto-
matically and randomly
selected.

Select

Each time

is selected, the

mode changes as follows:
Random (1 album random)



album random (all album random)



off

To use the Bluetooth

audio

system, it is necessary to regis-
ter a Bluetooth

device with the

system.



Registering an additional
device

Display the Bluetooth

audio

control screen. (



P.316)

Select “Connect”.

Select “Add Device”.

When another Bluetooth

device is

connected, a confirmation screen

will be displayed. To disconnect the
Bluetooth

device, select “Yes”.

Follow the steps in “Register-
ing a Bluetooth

phone for

Control panel

Repeating

Random order

Registering/Connecting a
Bluetooth

device

-------------------------------------------------------------------------------------------------------------------------------------------------------------

318

5-7. Media operation

COROLLA HV_U

the first time” from step

(





Selecting a registered device

Display the Bluetooth

audio

control screen. (

P.316)

Select “Connect”.

Select the desired device to
be connected.

Check that a confirmation
screen is displayed when the
connection is complete.

If an error message is displayed,

follow the guidance on the screen

to try again.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

319

5-8. Audio/visual remote controls

COROLLA HV_U

Audio

5-8.Audio/visual remote controls

Some parts of the audio/visual
system can be adjusted using
the switches on the steering
wheel.

Volume control switch

“MODE” switch

:If equipped

:If cached radio is enabled, press-

ing and holding the “MODE”
switch pauses the broadcast.
(Press and hold again to play
back the cached radio program.)

:When an Apple CarPlay is estab-

lished, this function will be
unavailable.

:When an Android Auto is estab-

lished, this function will be
unavailable.

switch

Steering switches

Steering switch operation

Mode

Operation/function

All

Press: Volume
up/down

Press and hold
(0.8 sec. or more):
Volume up/down
continuously

Mode

Operation/function

AM/FM/

SXM

Press: Change
audio modes

Press and hold
(0.8 sec. or more):
Mute

(Press and

hold again to
resume the
sound.)

USB

*3, 4

iPod/iPhone

Android

Auto

, Blue-

tooth

audio

*3,

, APPS

*3, 4

Press: Change
audio modes

Press and hold
(0.8 sec. or more):
Pause (Press and
hold again to
resume the play
mode.)

Mode

Operation/function

AM/FM

Press: Preset
channel up/down

Press and hold
(0.8 sec. or more):
Seek up/down

Press and hold
(1.5 sec. or more):
Seek up/down con-
tinuously while the
switch is being
pressed

Mode

Operation/function

-------------------------------------------------------------------------------------------------------------------------------------------------------------

320

5-8. Audio/visual remote controls

COROLLA HV_U

:If equipped

:When an Apple CarPlay is estab-

lished, this function will be
unavailable.

:When an Android Auto is estab-

lished, this function will be
unavailable.

In the APPS mode, some operation

may be done on the screen depend

on the selected APPS.

SXM

Press: Preset
channel up/down

Press and hold
(0.8 sec. or more):
Seek for stations in
the relevant pro-
gram type/channel
category

Press and hold
(1.5 sec. or more):
Fast channel
up/down

USB

*2, 3

iPod/iPhone

Bluetooth

audio

*2, 3

Press: Track/file
up/down

Press and hold
(0.8 sec. or more):
Fast for-
ward/rewind

Android Auto

Press: Track
up/down

Mode

Operation/function

-------------------------------------------------------------------------------------------------------------------------------------------------------------

321

5-9. Audio settings

COROLLA HV_U

Audio

5-9.Audio settings

Press the “MENU” button.

Select “Setup”.

Select “Audio”.

Select the desired items to
be set.

Select to set the common
settings. (

Select to set the radio set-
tings. (



Display the audio settings
screen. (



Select “Common”.

Select the desired items to
be set.

Select to set the cover art
display on/off.
Select to prioritize the display
of information from the Gra-
cenote database.
Select to change the screen
size.

(



P.301)

Select to display the image
quality adjustment screen.

(

P.302)

: Only in USB video mode

Display the audio settings
screen. (


