142

3-1. Key information

CAMRY_U

■

If you lose your keys

New genuine keys can be made by your Toyota dealer using the other key
(vehicles without a smart key system) or the other mechanical key (vehicles
with a smart key system) and the key number stamped on your key number
plate. Keep the plate in a safe place such as your wallet, not in the vehicle.

■

When riding in an aircraft

When  bringing  a  key  with  wireless  remote  control  function  onto  an  aircraft,
make sure you do not press any button on the key while inside the aircraft
cabin. If you are carrying the key in your bag etc., ensure that the buttons are
not likely to be pressed accidentally. Pressing a button may cause the key to
emit radio waves that could interfere with the operation of the aircraft.

■

Conditions affecting operation



Vehicles without a smart key system

The wireless remote control function may not operate normally in the follow-
ing situations:

●

When the wireless key battery is depleted

●

Near a TV tower, electric power plant, gas station, radio station, large dis-
play, airport or other facility that generates strong radio waves or electrical
noise

●

When carrying a portable radio, cellular phone or other wireless communi-
cation devices

●

When the wireless key is in contact with, or is covered by a metallic object

●

When other wireless key (that emit radio waves) is being used nearby

●

If window tint with a metallic content or metallic objects are attached to the
rear window



Vehicles with a smart key system



P. 163

143

3-1. Key information

3

Op
eration

 o

f each

 compo

nen
t

CAMRY_U

■

Key battery depletion



Vehicles without a smart key system

●

The standard battery life is 1 to 2 years.

●

Even if the key is not used, the battery may become depleted and the fol-
lowing symptoms may occur. Replace the battery with a new one when nec-
essary. (



P. 504)

• The wireless remote control function does not operate.
• The area in which the wireless remote control function can be operated

becomes smaller.



Vehicles with a smart key system

●

The standard battery life is 1 to 2 years.

●

If the battery becomes low, an alarm will sound in the cabin when the engine
stops.

●

As the electronic key always receives radio waves, the battery will become
depleted even if the electronic key is not used. The following symptoms indi-
cate  that  the  electronic  key  battery  may  be  depleted.  Replace  the  battery
when necessary. (



P. 504)

• The smart key system or the wireless remote control does not operate.
• The detection area becomes smaller.
• The LED indicator on the key surface does not turn on.

●

To reduce key battery depletion when the electronic key is to not be used for
long periods of time, set the electronic key to the battery-saving mode.
(



P. 163)

●

To avoid serious deterioration, do not leave the electronic key within 3 ft. (1
m) of the following electrical appliances that produce a magnetic field:
• TVs
• Personal computers
• Cellular phones, cordless phones and battery chargers
• Recharging cellular phones or cordless phones
• Table lamps
• Induction cookers

■

Replacing the battery



P. 504

■

Confirmation of the registered key number

The number of keys already registered to the vehicle can be confirmed. Ask
your Toyota dealer for details.

■

If a wrong key is used

The key cylinder rotates freely to isolate inside mechanism.

144

3-1. Key information

CAMRY_U

■

Certification  for  the  wireless  remote  control  (vehicles  without  a  smart
key system)



For vehicles sold in the U.S.A.

145

3-1. Key information

3

Op
eration

 o

f each

 compo

nen
t

CAMRY_U



For vehicles sold in Canada

146

3-1. Key information

CAMRY_U

■

Certification for wireless remote control (vehicles with a smart key sys-
tem)



P. 167

NOTICE

■

To prevent key damage

●

Do not drop the keys, subject them to strong shocks or bend them.

●

Do not expose the keys to high temperatures for long periods of time.

●

Do not get the keys wet or wash them in an ultrasonic washer etc.

●

Do not attach metallic or magnetic materials to the keys or place the keys
close to such materials.

●

Do not disassemble the keys.

●

Do not attach a sticker or anything else to the surface of the electronic key
and key (with a wireless remote control function).

●

Vehicles with a smart key system: Do not place the keys near objects that
produce magnetic fields, such as TVs, audio systems and induction cook-
ers, or medical electrical equipment, such as low-frequency therapy equip-
ment.

■

Carrying the electronic key on your person (vehicles with a smart key
system)

Carry the electronic key 3.9 in. (10 cm) or more away from electric appli-
ances  that  are  turned  on.  Radio  waves  emitted  from  electric  appliances
within 3.9 in. (10 cm) of the electronic key may interfere with the key, caus-
ing the key to not function properly.

■

In case of a smart key system malfunction or other key-related prob-
lems (vehicles with a smart key system)

Take your vehicle with all the electronic keys provided with your vehicle to
your Toyota dealer.

■

When an electronic key is lost (vehicles with a smart key system)

If the electronic key remains lost, the risk of vehicle theft increases signifi-
cantly.  Visit  your  Toyota  dealer  immediately  with  all  remaining  electronic
keys that were provided with your vehicle.

147

3

Op
eration

 o

f each

 compo

nen
t

CAMRY_U

3-2. Opening, closing and locking the doors

◆

Smart key system (if equipped)

Carry the electronic key to enable this function.

Grip the driver’s door handle
to  unlock  the  door.  Holding
the  driver’s  door  handle  for
approximately  2  seconds
unlocks  all  the  doors.  Grip
the  front  passenger’s  door
handle  to  unlock  all  the
doors.

*

Make sure to touch the sensor on the back of the handle.
The doors cannot be unlocked for 3 seconds after the doors are locked.

*

: The door unlock settings can be changed. (



P. 153)

Touch  the  lock  sensor  (the  indentation  on  the  side  of  the  door
handle) to lock the doors.

Check that the door is securely locked.

Doors

Unlocking and locking the doors from the outside

1

2

148

3-2. Opening, closing and locking the doors

CAMRY_U

◆

Wireless remote control

Locks all the doors

Check that the door is securely locked.

Unlocks all the doors

Pressing the button unlocks the driver’s door. Pressing the button again
within 3 seconds unlocks the other doors.

Press and hold to open the windows

*

1

 and the moon roof

*

1, 2

 or pan-

oramic moon roof.

*

1, 2

(



P. 182, 186, 190)

*

1

: This setting must be customized at your Toyota dealer.

*

2

: If equipped



Vehicles without a smart key
system



Vehicles with a smart key sys-
tem

1

2

149

3-2. Opening, closing and locking the doors

3

Op
eration

 o

f each

 compo

nen
t

CAMRY_U

◆

Key

Turning the key operates the doors as follows:



Vehicles without a smart key system

Locks all the doors

Turn and hold to close the win-
dows

*

1

  and  moon  roof.

*

1,  2

(



P. 182, 186)

Unlocks the door

Turning  the  key  unlocks  the
driver's door. Turning the key
again  unlocks  the  other
doors.
Turn and hold to open the windows

*

1

 and moon roof.

*

1, 2

(



P. 182, 186)

*

1

: This setting must be customized at your Toyota dealer.

*

2

: If equipped



Vehicles with a smart key system

The  doors  can  also  be  locked  and  unlocked  with  the  mechanical
key. (



P. 569)

1

2

150

3-2. Opening, closing and locking the doors

CAMRY_U

■

Operation signals

Doors:
A buzzer sounds and the emergency flashers flash to indicate that the doors
have been locked/unlocked. (Locked: Once; Unlocked: Twice)
Windows and moon roof or panoramic moon roof:
A buzzer sounds to indicate that the windows and moon roof or panoramic
moon roof are operating.

■

Security feature

If a door is not opened within approximately 60 seconds after the vehicle is
unlocked, the security feature automatically locks the vehicle again.

■

When the door cannot be locked by the lock sensor on the surface of the
door handle (vehicles with a smart key system)

■

Door lock buzzer

If an attempt to lock the doors using the smart key system is made when a
door is not fully closed, a buzzer sounds continuously. Fully close the door to
stop the buzzer, and lock the vehicle once more.

■

Alarm

Locking the doors will set the alarm system. (



P. 82)

■

If the smart key system or the wireless remote control does not operate
properly (vehicles with a smart key system)

Use the mechanical key to lock and unlock the doors. (



P. 569)

Replace the key battery with a new one if it is depleted. (



P. 504)

When  the  door  cannot  be  locked  even  if
the lock sensor on the surface of the door
handle  is  touched  by  a  finger,  touch  the
lock sensor with the palm.
When gloves are being worn, remove the
gloves.

151

3-2. Opening, closing and locking the doors

3

Op
eration

 o

f each

 compo

nen
t

CAMRY_U

◆

Door lock switches

Locks all the doors
Unlocks all the doors

◆

Inside lock buttons

Locks the door
Unlocks the door

The  front  doors  can  be  opened
by  pulling  the  inside  handle
even  if  the  lock  buttons  are  in
the lock position.

Move the inside lock button to the lock position.
Close the door.



Vehicles without a smart key system
The door cannot be locked if either of the front doors is open and
the key is in the engine switch.



Vehicles with a smart key system
The door cannot be locked if the engine switch is in ACCESSORY
or IGNITION ON mode, or the electronic key is left inside the vehi-
cle.

The key may not be detected correctly and the door may be locked.

Unlocking and locking the doors from the inside

1

2

1

2

Locking the front doors from the outside without a key

1

2

152

3-2. Opening, closing and locking the doors

CAMRY_U

The door cannot be opened from
inside the vehicle when the lock is
set.

Unlock
Lock

These locks can be set to prevent
children  from  opening  the  rear
doors.  Push  down  on  each  rear
door switch to lock both rear doors.

The following functions can be set or cancelled:

For instructions on customizing, refer to P. 618.

Rear door child-protector lock

1

2

Automatic door locking and unlocking systems

Function

Operation

Speed linked door locking function

All  doors  are  automatically  locked
when  vehicle  speed  is  approxi-
mately 12 mph (20 km/h) or higher.

Shift position linked door locking
function

All  doors  are  automatically  locked
when shifting the shift lever out of P.

Shift position linked door unlocking
function

All doors are automatically unlocked
when shifting the shift lever to P.

Driver’s door linked door unlocking
function

All doors are automatically unlocked
when driver’s door is opened.

153

3-2. Opening, closing and locking the doors

3

Op
eration

 o

f each

 compo

nen
t

CAMRY_U

■

Switching the door unlock function (vehicles with a smart key system)

It is possible to set which doors the entry function unlocks using the wireless
remote control.

Turn the engine switch off.

When the indicator light on the key surface is not on, press and hold

,

  or

  for  approximately  5  seconds  while  pressing  and  holding

.

The setting changes each time an operation is performed, as shown below.
(When changing the setting continuously, release the buttons, wait for at least
5 seconds, and repeat step

.)

*

1

: 4.2-inch display

*

2

: 7-inch display

To  prevent  unintended  triggering  of  the  alarm,  unlock  the  doors  using  the
wireless  remote  control  and  open  and  close  a  door  once  after  the  settings
have been changed. (If a door is not opened within 60 seconds after

 is

pressed, the doors will be locked again and the alarm will automatically be
set.)
In case that the alarm is triggered, immediately stop the alarm. (



P. 83)

1

2

2

Multi-information

display

Unlocking function

Beep



Holding  the  driver’s  door
handle  unlocks  only  the
driver’s door.

Exterior:  Beeps  3
times
Interior: Pings once

Holding  the  front  passen-
ger’s  door  handle  unlocks
all the doors.



Holding  either  front  door
handle  unlocks  all  the
doors.

Exterior:

Beeps

twice
Interior: Pings once

*

1

*

2

*

1

*

2

154

3-2. Opening, closing and locking the doors

CAMRY_U

■

Impact detection door lock release system

In the event that the vehicle is subject to a strong impact, all the doors are
unlocked. Depending on the force of the impact or the type of accident, how-
ever, the system may not operate.

■

Open door warning buzzer

If the vehicle reaches a speed of 3 mph (5 km/h), the master warning light
flashes  and  a  buzzer  sounds  to  indicate  that  the  door(s)  are  not  yet  fully
closed.
The open door(s) is displayed on the multi-information display.

■

Conditions affecting the operation of the smart key system or wireless
remote control



Vehicles without a smart key system



P. 142



Vehicles with a smart key system



P. 163

■

Rear seat reminder function

In order to remind you not to forget luggage, etc. in the rear seat, when the
engine  switch  is  turned  off  after  any  of  the  following  conditions  are  met,  a
buzzer will sound and a message will be displayed on the multi-information
display for approximately 6 seconds.

●

The  engine  is  started  within  10  minutes  after  opening  and  closing  a  rear
door.

●

A rear door has been opened and closed after the engine was started.

However, if a rear door is opened and then closed within approximately 2 sec-
onds, the rear seat reminder function may not operate.
The  rear  seat  reminder  function  determines  that  luggage,  etc.  has  been
placed in a rear seat based on opening and closing of a rear door. Therefore,
depending on the situation, the rear seat reminder function may not operate
and  you  may  still  forget  luggage,  etc.  in  the  rear  seat,  or  it  may  operate
unnecessarily.
The rear seat reminder function can be enabled/disabled. (



P. 104, 121)

■

Customization

Some functions can be customized. (



P. 616)

155

3-2. Opening, closing and locking the doors

3

Op
eration

 o

f each

 compo

nen
t

CAMRY_U

WARNING

■

To prevent an accident

Observe the following precautions while driving the vehicle.
Failure to do so may result in a door opening and an occupant falling out,
resulting in death or serious injury.

●

Ensure that all doors are properly closed.

●

Do not pull the inside handle of the doors while driving.
Be  especially  careful  for  the  front  doors,  as  the  doors  may  be  opened
even if the inside lock buttons are in locked position.

●

Set the rear door child-protector locks when children are seated in the rear
seats.

■

When opening or closing a door

Check the surroundings of the vehicle such as whether the vehicle is on an
incline,  whether  there  is  enough  space  for  a  door  to  open  and  whether  a
strong wind is blowing.
When opening or closing the door, hold the door handle tightly to prepare
for any unpredictable movement.

156

3-2. Opening, closing and locking the doors

CAMRY_U

Press  and  hold  the  trunk  opener
switch.

◆

Smart key system (if equipped)

While  carrying  the  electronic
key,  press  the  button  on  the
trunk lid.

When all the doors are unlocked
using one of the following meth-
ods,  the  trunk  can  be  opened
without the electronic key:

• Entry function
• Wireless remote control
• Door lock switches
• Automatic door unlocking system
• Mechanical key

Trunk

The  trunk  can  be  opened  using  the  trunk  opener  switch,  entry
function  (vehicles  with  a  smart  key  system),  wireless  remote
control or key.

Opening the trunk from inside the vehicle

Opening the trunk from outside the vehicle

157

3-2. Opening, closing and locking the doors

3

Op
eration

 o

f each

 compo

nen
t

CAMRY_U

◆

Wireless remote control

Press and hold the switch.

A buzzer sounds.

◆

Key



Vehicles without a smart key system

Turn  the  key  clockwise  to
release the trunk lid.



Vehicles with a smart key system

The trunk can be also opened using the mechanical key. (



P. 570)



Vehicles without a smart key
system



Vehicles with a smart key sys-
tem

158

3-2. Opening, closing and locking the doors

CAMRY_U

■

Trunk light

The trunk light turns on when the trunk is opened.

■

Function to prevent the trunk being locked with the electronic key inside
(vehicles with a smart key system)

●

When all doors are locked, closing the trunk lid with the electronic key left
inside the trunk will sound an alarm.
In this case, the trunk lid can be opened by pressing the trunk release but-
ton on the trunk lid.

●

If the spare electronic key is put in the trunk with all the doors locked, the
key  confinement  prevention  function  is  activated  so  the  trunk  can  be
opened.  In  order  to  prevent  theft,  take  all  electronic  keys  with  you  when
leaving the vehicle.

●

If the electronic key is put in the trunk with all the doors locked, the key may
not be detected depending on the location of the key and the surrounding
radio wave conditions. In this case, the key confinement prevention function
cannot  be  activated,  causing  the  doors  to  lock  when  the  trunk  is  closed.
Make sure to check where the key is before closing the trunk.

●

The key confinement prevention function cannot be activated if any one of
the doors is unlocked. In this case, open the trunk using the trunk opener.

■

Open trunk warning buzzer

If the vehicle reaches a speed of 3 mph (5 km/h), the master warning light
flashes and a buzzer sounds to indicate that the trunk is not yet fully closed.

■

Internal trunk release lever

■

If the smart key system or the wireless remote control does not operate
properly (vehicles with a smart key system)

Use the mechanical key to unlock the trunk. (



P. 570)

Replace the key battery with a new one if it is depleted. (



P. 504)

■

Customization

Some functions can be customized. (



P. 616)

The trunk lid can be opened by pulling up
the  glow-in-the-dark  lever  located  on  the
inside of the trunk lid.
The  lever  will  continue  to  glow  for  some
time after the trunk lid is closed.

159

3-2. Opening, closing and locking the doors

3

Op
eration

 o

f each

 compo

nen
t

CAMRY_U

WARNING

Observe the following precautions.
Failure to do so may result in death or serious injury.

■

Before driving

●

Make sure that the trunk lid is fully closed. If the trunk lid is not fully closed,
it may open unexpectedly while driving and hit near-by objects or luggage
in the trunk may be thrown out, causing an accident.

●

Do not allow children to play in the trunk.
If  a  child  is  accidentally  locked  in  the  trunk,  they  could  suffer  from  heat
exhaustion, suffocation or other injuries.

●

Do not allow a child to open or close the trunk lid.
Doing  so  may  cause  the  trunk  lid  to  open  unexpectedly,  or  cause  the
child’s hands, head, or neck to be caught by the closing trunk lid.

■

Important points while driving

Never let anyone sit in the trunk. In the event of sudden braking or a colli-
sion, they are susceptible to death or serious injury.

160

3-2. Opening, closing and locking the doors

CAMRY_U

WARNING

■

Using the trunk

Observe the following precautions.
Failure to do so may cause parts of the body to be caught, resulting in seri-
ous injury.

●

Remove any heavy loads, such as snow and ice, from the trunk lid before
opening it. Failure to do so may cause the trunk lid to suddenly shut again
after it is opened.

●

When opening or closing the trunk lid, thoroughly check to make sure the
surrounding area is safe.

●

If anyone is in the vicinity, make sure they are safe and let them know that
the trunk is about to open or close.

●

Use caution when opening or closing the trunk lid in windy weather as it
may move abruptly in strong wind.

●

On an incline it is more difficult to open or close the trunk lid than on a level
surface,  so  beware  of  the  trunk  lid  unexpectedly  opening  or  closing  by
itself. Make sure that the trunk lid is fully open and secure before using the
trunk.

●

Do not attach any accessories other than genuine Toyota parts to the trunk
lid. Such additional weight on the trunk lid may cause the lid to suddenly
shut again after it is opened.

●

When  opening  the  trunk  lid,  take  care
so that it does not hit anyone in the face
or any other part of the body.

●

When  closing  the  trunk  lid,  take  extra
care  to  prevent  your  fingers  etc.  from
being caught.

●

When closing the trunk lid, make sure to
press it lightly on its outer surface.

161

3-2. Opening, closing and locking the doors

3

Op
eration

 o

f each

 compo

nen
t

CAMRY_U

●

Locks and unlocks the doors (



P. 147)

●

Opens the trunk (



P. 156)

●

Starts the engine (



P. 213)

■

Antenna location

■

Effective range (areas within which the electronic key is detected)

Smart key system





: If equipped

The  following  operations  can  be  performed  simply  by  carrying
the electronic key on your person, for example in your pocket.
(The driver should always carry the electronic key.)

Antennas outside the cabin
Antennas inside the cabin
Antenna inside the trunk
Antenna outside the trunk

When  locking  or  unlocking  the
doors

The  system  can  be  operated  when
the electronic key is within about 2.3
ft.  (0.7  m) of  either of  the  front  out-
side  door  handles.  (Only  the  doors
detecting the key can be operated.)

When starting the engine or changing engine switch modes

The  system  can  be  operated  when  the  electronic  key  is  inside  the
vehicle.

When opening the trunk

The system can be operated when the electronic key is within about
2.3 ft. (0.7 m) of the trunk release button.

1

2

3

4

162

3-2. Opening, closing and locking the doors

CAMRY_U

■

Alarms and warning indicators

A combination of  exterior and interior alarms as well as warning messages
shown on the multi-information display are used to prevent theft of the vehicle
and  accidents  resulting  from  erroneous  operation.  Take  appropriate  mea-
sures in response to any warning message on the multi-information display.
(



P. 548)

When only an alarm sounds, circumstances and correction procedures are as
follows.

Alarm

Situation

Correction procedure

Exterior  alarm  sounds
once for 5 seconds

An  attempt  was  made
to lock the vehicle while
a door was open.

Close  all  of  the  doors
and  lock  the  doors
again.

The  trunk  was  closed
while the electronic key
was still inside the trunk
and  all  the  doors  were
locked.

Retrieve  the  electronic
key  from  the  trunk  and
close the trunk lid.

Interior alarm pings
repeatedly

The engine  switch was
turned to ACCESSORY
mode while the driver’s
door  was  open  (The
driver’s

door

was

opened

when

the

engine  switch  was  in
ACCESSORY mode).

Turn  the  engine  switch
off  and  close  the
driver’s door.

The engine  switch was
turned  off  while  the
driver’s door was open.

Close the driver’s door.

163

3-2. Opening, closing and locking the doors

3

Op
eration

 o

f each

 compo

nen
t

CAMRY_U

■

Battery-saving function

The battery-saving function will be activated in order to prevent the electronic
key battery and the vehicle battery from being discharged while the vehicle is
not in operation for a long time.

●

In  the  following  situations,  the  smart  key  system  may  take  some  time  to
unlock the doors.
• The electronic key has been left in an area of approximately 6 ft. (2 m) of

the outside of the vehicle for 10 minutes or longer.

• The smart key system has not been used for 5 days or longer.

●

If the smart key system has not been used for 14 days or longer, the doors
cannot be unlocked at any doors except the driver’s door. In this case, take
hold of the driver’s door handle, or use the wireless remote control or the
mechanical key, to unlock the doors.

■

Electronic Key Battery-Saving Function

When battery-saving mode is set, battery depletion is minimized by stopping
the electronic key from receiving radio waves.

■

Conditions affecting operation

The smart key system, wireless remote control and engine immobilizer sys-
tem  use  weak  radio  waves.  In  the  following  situations,  the  communication
between the electronic key and the vehicle may be affected, preventing the
smart  key  system,  wireless  remote  control  and  engine  immobilizer  system
from operating properly. (Ways of coping:



P. 569)

●

When the electronic key battery is depleted

●

Near a TV tower, electric power plant, gas station, radio station, large dis-
play, airport or other facility that generates strong radio waves or electrical
noise

●

When  the  electronic  key  is  in  contact  with,  or  is  covered  by  the  following
metallic objects
• Cards to which aluminum foil is attached
• Cigarette boxes that have aluminum foil inside
• Metallic wallets or bags
• Coins
• Hand warmers made of metal
• Media such as CDs and DVDs

Press

  twice  while  pressing  and

holding

. Confirm that the electronic

key indicator flashes 4 times.
While the battery-saving mode is set, the
smart  key  system  cannot  be  used.  To
cancel the function, press any of the elec-
tronic key buttons.

164

3-2. Opening, closing and locking the doors

CAMRY_U

●

When other wireless keys (that emit radio waves) are being used nearby

●

When  carrying  the  electronic  key  together  with  the  following  devices  that
emit radio waves
• Portable radio, cellular phone, cordless phone or other wireless commu-

nication devices

• Another vehicle’s electronic key, another electronic key of your vehicle, or

a wireless key that emits radio waves

• Personal computers or personal digital assistants (PDAs)
• Digital audio players
• Portable game systems

●

If window tint with a metallic content or metallic objects are attached to the
rear window

●

When  the  electronic  key  is  placed  near  a  battery  charger  or  electronic
devices

●

When  the  vehicle  is  parked  in  a  pay  parking  spot  where  radio  waves  are
emitted.

■

Note for the entry function

●

Even when the electronic key is within the effective range (detection areas),
the system may not operate properly in the following cases:
• The electronic key is too close to the window or outside door handle, near

the ground, or in a high place when the doors are locked or unlocked.

• The electronic key is near the ground or in a high place, or too close to

the rear bumper center when the trunk is opened.

• The electronic key is on the instrument panel, rear package tray or floor,

or in the door pockets or glove box when the engine is started or engine
switch modes are changed.

●

Do not leave the electronic key on top of the instrument panel or near the
door pockets when exiting the vehicle. Depending on the radio wave recep-
tion conditions, it may be detected by the antenna outside the cabin and the
door will become lockable from the outside, possibly trapping the electronic
key inside the vehicle.

●

As long as the electronic key is within the effective range, the doors may be
locked or unlocked by anyone. However, only the doors detecting the elec-
tronic key can be used to unlock the vehicle.

●

Even if the electronic key is not inside the vehicle, it may be possible to start
the engine if the electronic key is near the window.

●

The  doors may unlock or lock  if a  large  amount  of water  splashes on  the
door handle, such as in the rain or in a car wash, when the electronic key is
within  the  effective  range.  (The  doors  will  automatically  be  locked  after
approximately 60 seconds if the doors are not opened and closed.)

165

3-2. Opening, closing and locking the doors

3

Op
eration

 o

f each

 compo

nen
t

CAMRY_U

●

If the wireless remote control is used to lock the doors when the electronic
key  is  near  the  vehicle,  there  is  a  possibility  that  the  door  may  not  be
unlocked by the entry function. (Use the wireless remote control to unlock
the doors.)

●

Touching the door lock sensor while wearing gloves may delay or prevent
lock operation. Remove the gloves and touch the lock sensor again.

●

When the lock operation is performed using the lock sensor, recognition sig-
nals  will  be  shown  up  to  two  consecutive  times. After  this,  no  recognition
signals will be given.

*

●

If the door handle becomes wet while the electronic key is within the effec-
tive range, the door may lock and unlock repeatedly. In this case, follow the
following correction procedures to wash the vehicle:
• Place the electronic key in a location 6 ft. (2 m) or more away from the

vehicle. (Take care to ensure that the key is not stolen.)

• Set  the  electronic  key  to  battery-saving  mode  to  disable  the  smart  key

system. (



P. 163)

●

If the electronic key is inside the vehicle and a door handle becomes wet
during a car wash, a message may be shown on the multi-information dis-
play and a buzzer will sound outside the vehicle. To turn off the alarm, lock
all the doors.

●

The  lock  sensor  may  not  work  properly  if  it  comes  into  contact  with  ice,
snow, mud, etc. Clean the lock sensor and attempt to operate it again.

●

A sudden approach to the effective range or door handle may prevent the
doors from being unlocked. In this case, return the door handle to the origi-
nal position and check that the doors unlock before pulling the door handle
again.

●

If there is another electronic key in the detection area, it may take slightly
longer to unlock the doors after the door handle is gripped.

●

Fingernails may scrape against the door during operation of the door han-
dle. Be careful not to injure fingernails or damage the surface of the door.

*

: This setting can be customized at your Toyota dealer.

166

3-2. Opening, closing and locking the doors

CAMRY_U

■

When the vehicle is not driven for extended periods

●

To prevent theft of the vehicle, do not leave the electronic key within 6 ft. (2
m) of the vehicle.

●

The smart key system can be deactivated in advance. (



P. 616)

●

Setting the electronic key to battery-saving mode helps to reduce key bat-
tery depletion. (



P. 163)

■

To operate the system properly

Make sure to carry the electronic key when operating the system. Do not get
the electronic key too close to the vehicle when operating the system from the
outside of the vehicle.
Depending on the position and holding condition of the electronic key, the key
may not be detected correctly and the system may not operate properly. (The
alarm may go off accidentally, or the door lock prevention function may not
operate.)

■

If the smart key system does not operate properly

●

Locking and unlocking the doors and trunk: Use the mechanical key.
(



P. 569)

●

Starting the engine:



P. 570

■

Customization

Some functions can be customized. (



P. 616)

■

If the smart key system has been deactivated in a customized setting

●

Locking and unlocking the doors and opening the trunk:
Use the wireless remote control or mechanical key. (



P. 148, 157, 569)

●

Starting the engine and changing engine switch modes:



P. 570

●

Stopping the engine:



P. 214

167

3-2. Opening, closing and locking the doors

3

Op
eration

 o

f each

 compo

nen
t

CAMRY_U

■

Certification for the smart key system



For vehicles sold in the U.S.A.

168

3-2. Opening, closing and locking the doors

CAMRY_U



For vehicles sold in Canada

WARNING

■

Caution regarding interference with electronic devices

●

People  with  implantable  cardiac  pacemakers,  cardiac  resynchronization
therapy-pacemakers or implantable cardioverter defibrillators should keep
away from the smart key system antennas. (



P. 161)

The radio waves may affect the operation of such devices. If necessary,
the entry function can be disabled. Ask your Toyota dealer for details, such
as  the  frequency  of  radio  waves  and  timing  of  the  emitted  radio  waves.
Then, consult your doctor to see if you should disable the entry function.

●

Users  of  any  electrical  medical  device  other  than  implantable  cardiac
pacemakers,  cardiac  resynchronization  therapy-pacemakers  or  implant-
able  cardioverter  defibrillators  should  consult  the  manufacturer  of  the
device  for  information  about  its  operation  under  the  influence  of  radio
waves.
Radio  waves  could  have  unexpected  effects  on  the  operation  of  such
medical devices.

Ask your Toyota dealer for details for disabling the entry function.

169

3

Op
eration

 o

f each

 compo

nen
t

CAMRY_U

3-3. Adjusting the seats



Manual seat

Seat position adjustment lever
Seatback  angle  adjustment
lever
Vertical height adjustment lever



Power seat

Seat position adjustment switch
Seatback  angle  adjustment
switch
Seat  cushion  (front)  angle
adjustment switch
Vertical

height

adjustment

switch
Lumbar  support  adjustment
switch (driver’s side only)

Front seats

Adjustment procedure

1

2

3

1

2

3

4

5

170

3-3. Adjusting the seats

CAMRY_U

WARNING

■

When adjusting the seat position

●

Take care when adjusting the seat position to ensure that other passen-
gers are not injured by the moving seat.

●

Do not put your hands under the seat or near the moving parts to avoid
injury.
Fingers or hands may become jammed in the seat mechanism.

●

Make sure to leave enough space around the feet so they do not get stuck.

■

Seat adjustment

●

Be careful that the seat does not hit passengers or luggage.

●

To  reduce  the risk  of sliding  under  the lap  belt during a  collision,  do  not
recline the seat more than necessary.
If the seat is too reclined, the lap belt may slide past the hips and apply
restraint  forces  directly  to  the  abdomen,  or  your  neck  may  contact  the
shoulder belt, increasing the risk of death or serious injury in the event of
an accident.
Adjustments should not be made while driving as the seat may unexpect-
edly move and cause the driver to lose control of the vehicle.

●

Manual  seat  only:  After  adjusting  the  seat,  make  sure  that  the  seat  is
locked in position.

NOTICE

■

When adjusting a front seat

When  adjusting  a  front  seat,  make  sure  that  the  head  restraint  does  not
contact the headliner. Otherwise, the head restraint and headliner may be
damaged.

171

3-3. Adjusting the seats

3

Op
eration

 o

f each

 compo

nen
t

CAMRY_U

Pull the seatback lever in the trunk
for  the  seatback  you  wish  to  fold
down  and  then  fold  the  seatback
down.

Rear seats (folding type)





: If equipped

The seatbacks of the rear seats can be folded down.

Folding down the rear seatbacks

172

3-3. Adjusting the seats

CAMRY_U

WARNING

■

When folding the seatbacks down

Observe the following precautions. Failure to do so may result in death or
serious injury.

●

Do not fold the seatbacks down while driving.

●

Stop the vehicle on level ground, set the parking brake and shift the shift
lever to P.

●

Do not allow anyone to sit on a folded seatback or in the trunk while driv-
ing.

●

Do not allow children to enter the trunk.

■

When returning the seat to its original position

●

Ensure that the seat belt does not get caught between or behind the seats.

●

If the seat belt has been released from its guide, pass the seat belt through
its guide. (



P. 30)

■

Seat adjustment

Be careful not to get hands or feet pinched between the rear console box
and the rear seat when folding down the rear seatback.

■

After returning the seatback to the upright position

Observe the following precautions. Failure to do so may result in death or
serious injury.

●

Make sure the seatback is securely locked by pressing it forward and rear-
ward on the top.

●

Check that the seat belts are not twisted or caught in the seatback.

●

Make sure that the seat belt is passed through its guide.

NOTICE

■

When the right seatback is folded down

Make  sure  the  luggage  loaded  in  the  enlarged  trunk  will  not  damage  the
webbing of the rear center seat belt.

173

3-3. Adjusting the seats

3

Op
eration

 o

f each

 compo

nen
t

CAMRY_U



Adjustable type

Up

Pull the head restraint up.

Down

Push the head restraint down while
pressing the lock release button.



Integrated type

Head restraints cannot be adjusted or removed.

■

Removing the head restraints

Head restraints

Head restraints are provided for all seats.

Lock release button

1

2

Pull  the  head  restraint  up  while  pressing
the lock release button.
Front seats: If the head restraint touches
the  ceiling,  making  the  removal  difficult,
change the seat height or angle.
(



P. 169)

Lock
release
button

174

3-3. Adjusting the seats

CAMRY_U

■

Installing the head restraints



Front seats



Rear seats

■

Adjusting the height of the head restraints

Align  the  head  restraint  with  the  installa-
tion  holes  and  push  it  down  to  the  lock
position.
Press  and  hold  the  lock  release  button
when lowering the head restraint.

Align  the  head  restraint  with  the  installa-
tion holes and push it down to the lowest
lock  position  while  pressing  the  lock
release button.

Make  sure  that  the  head  restraints  are
adjusted  so  that  the  center  of  the  head
restraint is closest to the top of your ears.

WARNING

■

Head restraint precautions

Observe the following precautions regarding the head restraints. Failure to
do so may result in death or serious injury.

●

Use the head restraints designed for each respective seat.

●

Adjust the head restraints to the correct position at all times.

●

After  adjusting  the  head  restraints,  push  down  on  them  and  make  sure
they are locked in position.

●

Do not drive with the head restraints removed.
(However, if a head restraint interferes with installation of a child restraint
system,  the  head  restraint  can  be  removed  to  accommodate  the  child
restraint system: →P. 54)

Lock release
button

Lock release
button

175

3

Op
eration

 o

f each

 compo

nen
t

CAMRY_U

3-4. Adjusting the steering wheel and mirrors

Hold  the  steering  wheel  and
push the lever down.

Adjust  to  the  ideal  position  by
moving the steering wheel hori-
zontally and vertically.

After  adjustment,  pull  the  lever  up
to secure the steering wheel.

To  sound  the  horn,  press  on  or
close to the

 mark.

Steering wheel

Adjustment procedure

1

2

Horn

176

3-4. Adjusting the steering wheel and mirrors

CAMRY_U

WARNING

■

Caution while driving

Do not adjust the steering wheel while driving.
Doing so may cause the driver to mishandle the vehicle and cause an acci-
dent, resulting in death or serious injury.

■

After adjusting the steering wheel

Make sure that the steering wheel is securely locked.
Otherwise,  the  steering  wheel  may  move  suddenly,  possibly  causing  an
accident,  and  resulting  in  death  or  serious  injury. Also,  the  horn  may  not
sound if the steering wheel is not securely locked.

177

3-4. Adjusting the steering wheel and mirrors

3

Op
eration

 o

f each

 compo

nen
t

CAMRY_U

The height of the rear view mirror can be adjusted to suit your driving
posture.
Adjust the height of the rear view
mirror by moving it up and down.



Manual anti-glare inside rear view mirror

Reflected light from the headlights of vehicles behind can be reduced
by operating the lever.

Normal position
Anti-glare position

Inside rear view mirror

The rear view mirror’s position can be adjusted to enable suffi-
cient confirmation of the rear view.

Adjusting the height of rear view mirror

Anti-glare function

1

2

178

3-4. Adjusting the steering wheel and mirrors

CAMRY_U



Auto anti-glare inside rear view mirror

Responding  to  the  level  of  brightness  of  the  headlights  of  vehicles
behind, the reflected light is automatically reduced.
Changing  automatic  anti-glare
function mode
On/off

When  the  automatic  anti-glare
function is in ON mode, the indica-
tor illuminates.
The  function  will  set  to  ON  mode
each  time  the  engine  switch  is
turned to IGNITION ON mode.
Pressing the button turns the func-
tion  to  OFF  mode.  (The  indicator
also turns off.)

■

To prevent sensor error (vehicles with an auto anti-glare inside rear view
mirror)

Indicator

To ensure that the sensors operate prop-
erly, do not touch or cover them.

WARNING

Do not adjust the position of the mirror while driving.
Doing  so  may  lead  to  mishandling  of  the  vehicle  and  cause  an  accident,
resulting in death or serious injury.

179

3-4. Adjusting the steering wheel and mirrors

3

Op
eration

 o

f each

 compo

nen
t

CAMRY_U

To select a mirror to adjust, turn
the switch.

Left
Right

To adjust the mirror, operate the
switch.

Up
Right
Down
Left

Push the mirror back in the direc-
tion of the vehicle’s rear.

Outside rear view mirrors

Adjustment procedure

1

1

2

2

1

2

3

4

Folding the mirrors

180

3-4. Adjusting the steering wheel and mirrors

CAMRY_U

■

Mirror angle can be adjusted when



Vehicles without a smart key system

The engine switch is in the “ACC” or “ON” position.



Vehicles with a smart key system

The engine switch is in ACCESSORY or IGNITION ON mode.

■

When the mirrors are fogged up (vehicles with outside rear view mirror
defoggers)

The outside rear view mirrors can be cleared using the mirror defoggers. Turn
on the rear window defogger to turn on the outside rear view mirror defog-
gers. (



P. 393, 399, 407)

WARNING

■

Important points while driving

Observe the following precautions while driving.
Failure to do so may result in loss of control of the vehicle and cause an
accident, resulting in death or serious injury.

●

Do not adjust the mirrors while driving.

●

Do not drive with the mirrors folded.

●

Both the driver and passenger side mirrors must be extended and properly
adjusted before driving.

■

When a mirror is moving

To avoid personal injury and mirror malfunction, be careful not to get your
hand caught by the moving mirror.

■

When  the  mirror  defoggers  are  operating  (vehicles  with  outside  rear
view mirror defoggers)

Do not touch the rear view mirror surfaces, as they can become very hot
and burn you.

181

3

Op
eration

 o

f each

 compo

nen
t

CAMRY_U

3-5. Opening and closing the windows

The power windows can be opened and closed using the switches.
Operating the switch moves the windows as follows:

Closing
One-touch closing

*

Opening
One-touch opening

*

*

: To stop the window partway, oper-

ate the switch in the opposite direc-
tion.

This function can be used to prevent children from accidentally open-
ing or closing a passenger window.
Press the switch.

The indicator will come on and the
passenger windows will be locked.
The  passenger  windows  can  still
be  opened  and  closed  using  the
driver’s  switch  even  if  the  lock
switch is on.

■

The power windows can be operated when



Vehicles without a smart key system

The engine switch is in the “ON” position.



Vehicles with a smart key system

The engine switch is in IGNITION ON mode.

Power windows

Opening and closing procedures

1

2

3

4

Preventing accidental operation (window lock switch)

Indicator

182

3-5. Opening and closing the windows

CAMRY_U

■

Operating the power windows after turning the engine off



Vehicles without a smart key system

The  power  windows  can  be  operated  for  approximately  45  seconds  even
after the engine switch is turned to the “ACC” or “LOCK” position. They can-
not, however, be operated once either front door is opened.



Vehicles with a smart key system

The  power  windows  can  be  operated  for  approximately  45  seconds  even
after the engine switch is turned to ACCESSORY mode or turned off. They
cannot, however, be operated once either front door is opened.

■

Jam protection function

If  an  object  becomes  jammed  between  the  window  and  the  window  frame
while the window is closing, window movement is stopped and the window is
opened slightly.

■

Catch protection function

If an object becomes caught between the door and window while the window
is opening, window movement is stopped.

■

When the window cannot be opened or closed

When  the  jam  protection  function  or  catch  protection  function  operates
unusually and the door window cannot be opened or closed, perform the fol-
lowing operations with the power window switch of that door.

●

Vehicles  without  a  smart  key  system:  Stop  the  vehicle.  With  the  engine
switch in the “ON” position, within 4 seconds of the jam protection function
or catch protection function activating, continuously operate the power win-
dow switch in the one-touch closing direction or one-touch opening direction
so that the door window can be opened and closed.
Vehicles with a smart key system: Stop the vehicle. With the engine switch
in IGNITION ON mode, within 4 seconds of the jam protection function or
catch  protection  function  activating,  continuously  operate  the  power  win-
dow switch in the one-touch closing direction or one-touch opening direc-
tion so that the door window can be opened and closed.

183

3-5. Opening and closing the windows

3

Op
eration

 o

f each

 compo

nen
t

CAMRY_U

●

If the door window cannot be opened and closed even when performing the
above operations, perform the following procedure for function initialization.

Vehicles without a smart key system:
Turn the engine switch to the “ON” position.
Vehicles with a smart key system:
Turn the engine switch to IGNITION ON mode.
Pull and hold the power window switch in the one-touch closing direction
and completely close the door window.
Release  the  power  window  switch  for  a  moment,  resume  pulling  the
switch  in  the  one-touch  closing  direction,  and  hold  it  there  for  approxi-
mately 6 seconds or more.
Press and hold the power window switch in the one-touch opening direc-
tion. After  the  door  window  is  completely  opened,  continue  holding  the
switch for an additional 1 second or more.
Release  the  power  window  switch  for  a  moment,  resume  pushing  the
switch in the one-touch opening direction, and hold it there for approxi-
mately 4 seconds or more.
Pull and hold the power window switch in the one-touch closing direction
again. After the door window is completely closed, continue holding the
switch for a further 1 second or more.

If  you  release  the  switch  while  the  window  is  moving,  start  again  from  the
beginning.
If the window reverses and cannot be fully closed or opened, have the vehicle
inspected by your Toyota dealer.

■

Door lock linked window operation

●

Vehicles without a smart key system: The power windows can be opened
and closed using the key.

*

 (



P. 149)

Vehicles with a smart key system: The power windows can be opened and
closed using the mechanical key.

*

 (



P. 569)

●

The  power  windows  can  be  opened  using  the  wireless  remote  control.

*

(



P. 148)

*

: These settings must be customized at your Toyota dealer.

■

Alarm

The alarm may be triggered if the alarm is set and a power window is closed
using the door lock linked power window operation function. (



P. 83)

■

Power windows open warning buzzer

A buzzer sounds and a message is shown on the multi-information display in
the instrument cluster when the engine switch is turned off and the driver’s
door is opened with the power windows open.

■

Customization

Some functions can be customized. (



P. 616)

1

2

3

4

5

6

184

3-5. Opening and closing the windows

CAMRY_U

WARNING

Observe the following precautions.
Failure to do so may result in death or serious injury.

■

Closing the windows

●

The driver is responsible for all the power window operations, including the
operation  for  the  passengers.  In  order  to  prevent  accidental  operation,
especially by a child, do not let a child operate the power windows. It is
possible for children and other passengers to have body parts caught in
the power window. Also, when riding with a child, it is recommended to use
the window lock switch.(



P. 181)

●

When using the wireless remote control, key or mechanical key and oper-
ating  the  power  windows,  operate  the  power  window  after  checking  to
make sure that there is no possibility of any passenger having any of their
body parts caught in the window. Also do not let a child operate window by
the wireless remote control, key or mechanical key. It is possible for chil-
dren and other passengers to get caught in the power window.

●

When exiting the vehicle, turn the engine switch off, carry the key and exit
the vehicle along with the child. There may be accidental operation, due to
mischief, etc., that may possibly lead to an accident.

■

Jam protection function

●

Never use any part of your body to intentionally activate the jam protection
function.

●

The jam protection function may not work if something gets jammed just
before  the  window  is  fully  closed.  Be  careful  not  to  get  any  part  of  your
body jammed in the window.

■

Catch protection function

●

Never  use  any  part  of  your  body  or  clothing  to  intentionally  activate  the
catch protection function.

●

The catch protection function may not work if something gets caught just
before the window is fully opened. Be careful not to get any part of your
body or clothing caught in the window.

●

Check to make sure that all passengers
do not have any part of their body in a
position where it could be caught when
a window is being operated.

185

3-5. Opening and closing the windows

3

Op
eration

 o

f each

 compo

nen
t

CAMRY_U

Opens the moon roof

*

The moon roof stops slightly before
the  fully  open  position  to  reduce
wind noise.
Press the switch again to fully open
the moon roof.

Closes the moon roof

*

*

: Lightly  press  either  side  of  the

moon roof switch to stop the moon
roof partway.

Tilts the moon roof up

*

Tilts the moon roof down

*

*

: Lightly  press  either  side  of  the

moon roof switch to stop the moon
roof partway.

Moon roof





: If equipped

Use the overhead switches to open and close the moon roof and
tilt it up and down.

Opening and closing

1

2

Tilting up and down

1

2

186

3-5. Opening and closing the windows

CAMRY_U

■

The moon roof can be operated when



Vehicles without a smart key system

The engine switch is in the “ON” position.



Vehicles with a smart key system

The engine switch is in IGNITION ON mode.

■

Operating the moon roof after turning the engine off



Vehicles without a smart key system

The  moon  roof  can  be  operated  for  approximately  45  seconds  after  the
engine switch is turned to the “ACC” or “LOCK” position. It cannot, however,
be operated once either front door is opened.



Vehicles with a smart key system

The  moon  roof  can  be  operated  for  approximately  45  seconds  after  the
engine switch is turned to ACCESSORY mode or turned off. It cannot, how-
ever, be operated once either front door is opened.

■

Jam protection function

If an object is detected between the moon roof and the frame while the moon
roof  is  closing  or  tilting  down,  travel  is  stopped  and  the  moon  roof  opens
slightly.

■

Sunshade

The sunshade can be opened and closed manually. However, the sunshade
will open automatically when the moon roof is opened.

■

Door lock linked moon roof operation

●

Vehicles  without  a  smart  key  system: The  moon  roof  can  be  opened  and
closed using the key.

*

(



P. 149)

Vehicles  with  a  smart  key  system:  The  moon  roof  can  be  opened  and
closed using the mechanical key.

*

(



P. 569)

●

The moon roof can be opened using the wireless remote control.

*

(



P. 148)

*

: These settings must be customized at your Toyota dealer.

187

3-5. Opening and closing the windows

3

Op
eration

 o

f each

 compo

nen
t

CAMRY_U

■

When the moon roof does not close normally

Perform the following procedure:

●

If the moon roof closes but then re-opens slightly

Stop the vehicle.
Press and hold the “CLOSE” switch.

*

1

The  moon  roof  will  close,  reopen  and  pause  for  approximately  10  sec-
onds.

*

2

 Then it will close again, tilt up and pause for approximately 1 sec-

ond. Finally, it will tilt down, open and close.
Check  to  make  sure  that  the  moon  roof  is  completely  closed  and  then
release the switch.

●

If the moon roof tilts down but then tilts back up

Stop the vehicle.
Press and hold the “UP” switch

*

1

 until the moon roof moves into the tilt

up position and stops.
Release the “UP” switch once and then press and hold the “UP” switch
again.

*

1

The moon roof will pause for approximately 10 seconds in the tilt up posi-
tion.

*

2

 Then it will adjust slightly and pause for approximately 1 second.

Finally, it will tilt down, open and close.
Check  to  make  sure  that  the  moon  roof  is  completely  closed  and  then
release the switch.

*

1

: If the switch is released at the incorrect time, the procedure will have to

be performed again from the beginning.

*

2

: If  the  switch  is  released  after  the  above  mentioned  10  second  pause,

automatic  operation  will  be  disabled.  In  that  case,  press  and  hold  the
“CLOSE”  or  “UP”  switch,  and  the  moon  roof  will  tilt  up  and  pause  for
approximately 1 second. Then it will tilt down, open and close. Check to
make sure that the moon roof is completely closed and then release the
switch.

If the moon roof does not fully close even after performing the above proce-
dure correctly, have the vehicle inspected by your Toyota dealer.

■

Alarm

The alarm may be triggered if the alarm is set and the moon roof is closed
using the door lock linked moon roof operation function. (



P. 83)

■

Moon roof open warning buzzer

A buzzer sounds and a message is shown on the multi-information display in
the instrument cluster when the engine switch is turned off and the driver's
door is opened with the moon roof open.

■

Customization

Some functions can be customized. (



P. 616)

1

2

3

1

2

3

4

188

3-5. Opening and closing the windows

CAMRY_U

WARNING

Observe the following precautions.
Failure to do so may cause death or serious injury.

■

Opening the moon roof

●

Do not allow any passengers to put their hands or heads outside the vehi-
cle while it is moving.

●

Do not sit on top of the moon roof.

■

Closing the moon roof

●

The driver is responsible for moon roof opening and closing operations.
In order to prevent accidental operation, especially by a child, do not let a
child operate the moon roof. It is possible for children and other passen-
gers to have body parts caught in the moon roof.

●

When exiting the vehicle, turn the engine switch off, carry the key and exit
the vehicle along with the child. There may be accidental operation, due to
mischief, etc., that may possibly lead to an accident.

■

Jam protection function

●

Never use any part of your body to intentionally activate the jam protection
function.

●

The  jam  protection  function  may  not  work  if  something  gets  caught  just
before the moon roof is fully closed. Also, the jam protection function is not
designed to operate while the switch is being pressed. Take care so that
your fingers, etc. do not get caught.

●

Check to make sure that all passengers
do not have any part of their body in a
position where it could be caught when
the moon roof is being operated.

●

When  using  the  wireless  remote  con-
trol, key or mechanical key and operat-
ing  the  moon  roof,  operate  the  moon
roof  after  checking  to  make  sure  that
there is no possibility of any passenger
having any of their body parts caught in
the  moon  roof. Also,  do  not  let  a  child
operate  moon  roof  by  the  wireless
remote  control,  key  or  mechanical  key.
It is possible for children and other pas-
sengers to get caught in the moon roof.

189

3-5. Opening and closing the windows

3

Op
eration

 o

f each

 compo

nen
t

CAMRY_U

Opens the electronic sunshade

Slide  and  hold  the

  switch

backward.  The  electronic  sun-
shade  will  fully  open  automati-
cally.

*

Closes the electronic sunshade

Slide and hold the

 switch for-

ward. The electronic sunshade will
fully close automatically.

*

*

: Quickly slide  and release the

  switch  in either direction  to  stop the

electronic sunshade partway.

Tilts the panoramic moon roof up
(press)

*

When the panoramic moon roof is
tilted  up,  the  electronic  sunshade
will  open  to  the  half-open  position
of the roof.

*

: Lightly  press  the

  switch

again to stop the panoramic moon
roof partway.

Tilts the panoramic moon roof down (press and hold)

The panoramic moon roof can be tilted down only when it is in the tilt-up
position.

Panoramic moon roof





: If equipped

Use the overhead switches to operate the panoramic moon roof
and electronic sunshade.

Opening and closing the electronic sunshade

1

2

Tilting the panoramic moon roof up and down

190

3-5. Opening and closing the windows

CAMRY_U

Opens the panoramic moon roof

*

Slide  and  hold  the

  switch

backward.  The  panoramic  moon
roof  and  electronic  sunshade  will
open automatically.

The  panoramic  moon  roof  can  be
opened from the tilt-up position.

*

: Quickly slide and release the

switch in either direction to stop the
panoramic moon roof partway.

Closes the panoramic moon roof
Slide  and  hold  the

  switch

forward.  The  panoramic  moon
roof will fully close automatically.

■

The panoramic moon roof can be operated when

The engine switch is in IGNITION ON mode.

■

Operating the panoramic moon roof after turning the engine off

The  panoramic  moon  roof  and  electronic  sunshade  can  be  operated  for
approximately 45 seconds after the engine switch is turned to ACCESSORY
mode or turned off. They cannot, however, be operated once either front door
is opened.

■

Jam protection function

If an object is detected between the panoramic moon roof and the frame in
the following situations, travel is stopped and the panoramic moon roof opens
slightly:

●

The panoramic moon roof is closing or tilting down.

●

The electronic sunshade is closing.

■

Door lock linked panoramic



moon roof operation

●

The panoramic moon roof can be opened and closed using the mechanical
key.

*

(



P. 569)

●

The  panoramic  moon  roof  can  be  opened  using  the  wireless  remote  con-
trol.

*

(



P. 148)

*

: These settings must be customized at your Toyota dealer.

Opening and closing the panoramic moon roof

191

3-5. Opening and closing the windows

3

Op
eration

 o

f each

 compo

nen
t

CAMRY_U

■

Closing both the panoramic moon roof and electronic



sunshade

Slide the



switch forward.

The electronic sunshade will close to the half-open position and pause. The
panoramic moon roof will then fully close. Then the electronic sunshade will
fully close.

■

When the panoramic moon roof or electronic



sunshade does not close

normally

Perform the following procedure:

Stop the vehicle.
Turn the engine switch to IGNITION ON mode.
Slide and hold the

 switch or

 switch forward. Continue pressing

the switch for approximately 10 seconds after the panoramic moon roof or
electronic  sunshade  closes  and  reopens.  The  panoramic  moon  roof  and
electronic sunshade will start to close.

*

Check  that  the  panoramic  moon  roof  and  electronic  sunshade  are  fully
closed and release the switch.

*

: If the switch is released at the incorrect time, the procedure will have to be

performed again from the beginning.

If the panoramic moon roof or electronic sunshade does not fully close even
after performing the above procedure correctly, have the vehicle inspected by
your Toyota dealer.

■

Alarm

The alarm may be triggered if the alarm is set and the panoramic moon roof is
closed  using  the  door  lock  linked  panoramic  moon  roof  operation  function.
(



P. 83)

■

Panoramic moon roof open warning buzzer

A buzzer sounds and a message is shown on the multi-information display in
the instrument cluster when the engine switch is turned off and the driver’s
door is opened with the panoramic moon roof open.

■

Customization

Some functions can be customized. (



P. 616)

1

2

3

4

192

3-5. Opening and closing the windows

CAMRY_U

WARNING

Observe the following precautions.
Failing to do so may cause death or serious injury.

■

Opening and closing the electronic sunshade

■

Opening and closing the panoramic moon roof

●

The  driver  is  responsible  for  panoramic  moon  roof  opening  and  closing
operations.
In order to prevent accidental operation, especially by a child, do not let a
child operate the panoramic moon roof. It is possible for children and other
passengers to have body parts caught in the panoramic moon roof.

●

When exiting the vehicle, turn the engine switch off, carry the key and exit
the vehicle along with the child. There may be accidental operation, due to
mischief, etc., that may possibly lead to an accident.

●

Check to make sure that all passengers
do not have any part of their body in a
position where it could be caught when
the  electronic  sunshade  is  being  oper-
ated.

●

Do not let a child operate the electronic
sunshade.  Closing  the  electronic  sun-
shade on someone can cause death or
serious injury.

●

Check to make sure that all passengers
do not have any part of their body in a
position where it could be caught when
the panoramic moon roof is being oper-
ated.

●

When using the wireless remote control
or  mechanical  key  and  operating  the
panoramic moon roof, operate the pan-
oramic  moon  roof  after  checking  to
make sure that there is no possibility of
any passenger having any of their body
parts  caught  in  the  panoramic  moon
roof.  Also,  do  not  let  a  child  operate
panoramic  moon  roof  by  the  wireless
remote  control  or  mechanical  key.  It  is
possible for children and other passen-
gers  to  get  caught  in  the  panoramic
moon roof.

193

3-5. Opening and closing the windows

3

Op
eration

 o

f each

 compo

nen
t

CAMRY_U

WARNING

■

Jam protection function

●

Never use any part of your body to intentionally activate the jam protection
function.

●

The  jam  protection  function  may  not  work  if  something  gets  caught  just
before  the  panoramic  moon  roof  or  electronic  sunshade  is  fully  closed.
Also,  the  jam  protection  function  is  not  designed  to  operate  while  the
switch  is  being  pressed.  Take  care  so  that  your  fingers,  etc.  do  not  get
caught.

■

To prevent burns or injuries

Do not touch the area between the underside of the panoramic moon roof
and  the  electronic  sunshade.  Your  hand  may  get  caught  and  you  could
injure yourself. Also, if the vehicle is left in direct sunlight for a long time, the
underside  of  the  panoramic  moon  roof  could  become  very  hot  and  could
cause burns.

NOTICE

■

To prevent damage to the panoramic moon roof

●

Before opening the panoramic moon roof, make sure that there are no for-
eign objects, such as stones or ice, around the opening.

●

Do  not  hit  the  surface  or  edge  of  the  panoramic  moon  roof  with  hard
objects.

●

Do  not  continuously  press  the

  switch  after  the  panoramic  moon

roof has been fully opened or closed.

■

After the vehicle has been washed or rained on

Before opening the panoramic moon roof, wipe any water off the panoramic
moon  roof.  Otherwise,  water  may  enter  the  cabin  when  the  panoramic
moon roof is opened.

194

3-5. Opening and closing the windows

CAMRY_U

195

4

Driving

CAMRY_U

4-1.  Before driving

Driving the vehicle............. 196
Cargo and luggage ........... 205
Vehicle load limits ............. 208
Trailer towing..................... 209
Dinghy towing ................... 210

4-2.  Driving procedures

Engine (ignition) switch

(vehicles without a
smart key system)........... 211

Engine (ignition) switch

(vehicles with a
smart key system)........... 213

Automatic transmission..... 219
Turn signal lever................ 225
Parking brake .................... 226
Electric parking brake........ 227
Brake Hold ........................ 231

4-3.  Operating the lights

and wipers

Headlight switch ................ 233
AHB (Automatic High

Beam) ............................. 238

Windshield wipers and

washer ............................ 242

4-4.  Refueling

Opening the fuel tank

cap .................................. 246

4-5.  Using the driving

support systems

Toyota Safety Sense

2.5+................................. 250

PCS (Pre-Collision

System)........................... 258

LTA (Lane Tracing

Assist) ............................. 274

RSA (Road Sign Assist).... 289
Dynamic radar cruise

control with full-speed
range............................... 294

Dynamic radar cruise

control ............................. 310

Driving assist systems ...... 326
BSM (Blind Spot

Monitor)........................... 334
• BSM function ................ 339

Intuitive parking assist....... 342
RCTA (Rear Cross Traffic

Alert) ............................... 350
• RCTA function .............. 352

Rear Camera Detection

Function .......................... 357

PKSB (Parking Support

Brake) ............................. 361

Parking Support

Brake function
(static objects)................. 368

Parking Support Brake

function (rear-crossing
vehicles).......................... 377

Driving mode select

switches .......................... 384

4-6.  Driving tips

Winter driving tips ............. 386

196

CAMRY_U

4-1. Before driving



P. 211, 213

With the brake pedal depressed, shift the shift lever to D.
(



P. 219)

Release the parking brake. (



P. 226, 227)

Gradually release the brake pedal and gently depress the accelera-
tor pedal to accelerate the vehicle.

With the shift lever in D, depress the brake pedal.
If necessary, set the parking brake.

If the vehicle is to be stopped for an extended period of time, shift the shift
lever to P or N. (



P. 219)

With the shift lever in D, depress the brake pedal.
Set the parking brake (



P. 226, 227), and shift the shift lever to P

(



P. 219).

Vehicles without a smart key system:
Turn the engine switch to the “LOCK” position to stop the engine.
Vehicles with a smart key system:
Press the engine switch to stop the engine.
Lock the door, making sure that you have the key on your person.

If parking on a hill, block the wheels as needed.

Make sure that the parking brake is set and shift the shift lever to D.
Gently depress the accelerator pedal.
Release the parking brake.

Driving the vehicle

The  following  procedures  should  be  observed  to  ensure  safe
driving:

Starting the engine

Driving

Stopping

Parking the vehicle

Starting off on a steep uphill

1

2

3

1

2

1

2

3

4

1

2

3

197

4-1. Before driving

4

Drivin

g

CAMRY_U

When the following unusual operation is performed with the accelera-
tor pedal depressed, the engine output may be restrained.

• When the shift lever is shifted to R

*

.

• When  the  shift  lever  is  shifted  from  P  or  R  to  forward  drive  shift

position such as D

*

.

When the system operates, a message appears on the multi-informa-
tion display. Read the message and follow the instruction.

*

: Depending on the situation, the shift position may not be changed.

■

When starting off on a uphill

The hill-start assist control will activate. (



P. 327)

■

Driving in the rain

●

Drive carefully when it is raining, because visibility will be reduced, the win-
dows may become fogged-up, and the road will be slippery.

●

Drive carefully when it starts to rain, because the road surface will be espe-
cially slippery.

●

Refrain  from  high  speeds  when  driving  on  an  expressway  in  the  rain,
because there may be a layer of water between the tires and the road sur-
face, preventing the steering and brakes from operating properly.

■

Engine speed while driving

In the following conditions, the engine speed may become high while driving.
This is due to automatic up-shifting control or down-shifting implementation to
meet driving conditions. It does not indicate sudden acceleration.

●

The vehicle is judged to be driving uphill or downhill

●

When the accelerator pedal is released

■

Restraining the engine output (Brake Override System)

●

When the accelerator and brake pedals are depressed at the same time, the
engine output may be restrained.

●

A warning message is displayed on the multi-information display while the
system is operating.

■

Drive-Start Control (DSC)

When the TRAC is turned off (



P. 329), sudden start restraint control also

does not operate. If your vehicle have trouble escaping from the mud or fresh
snow by operating sudden start restraint control, deactivate TRAC (



P. 329)

so that the vehicle may become able to escape from the mud or fresh snow.

Sudden start restraint control (Drive-Start Control [DSC])

198

4-1. Before driving

CAMRY_U

■

Breaking in your new Toyota

To extend the life of the vehicle, observing the following precautions is recom-
mended:

●

For the first 186 miles (300 km):
Avoid sudden stops.

●

For the first 621 miles (1000 km):
• Do not drive at extremely high speeds.
• Avoid sudden acceleration.
• Do not drive continuously in low gears.
• Do not drive at a constant speed for extended periods.

■

Drum-in-disc type parking brake system

Your vehicle has a drum-in-disc type parking brake system. This type of brake
system needs bedding-down of the brake shoes periodically or whenever the
parking brake shoes and/or drum are replaced. Have your Toyota dealer per-
form the bedding down operation.

■

Operating your vehicle in a foreign country

Comply with the relevant vehicle registration laws and confirm the availability
of the correct fuel. (



P. 600)

■

Eco-friendly driving



P. 107, 124, 129

199

4-1. Before driving

4

Drivin

g

CAMRY_U

WARNING

Observe the following precautions.
Failure to do so may result in death or serious injury.

■

When starting the vehicle

Always  keep  your  foot  on  the  brake  pedal  while  stopped  with  the  engine
running. This prevents the vehicle from creeping.

■

When driving the vehicle

●

Do not drive if you are unfamiliar with the location of the brake and accel-
erator pedals to avoid depressing the wrong pedal.
• Accidentally  depressing  the  accelerator  pedal  instead  of  the  brake

pedal will result in sudden acceleration that may lead to an accident.

• When backing up, you may twist your body around, leading to a diffi-

culty in operating the pedals. Make sure to operate the pedals properly.

• Make  sure  to  keep  a  correct  driving  posture  even  when  moving  the

vehicle only slightly. This allows you to depress the brake and accelera-
tor pedals properly.

• Depress  the  brake  pedal  using  your  right  foot.  Depressing  the  brake

pedal using your left foot may delay response in an emergency, result-
ing in an accident.

●

Do not drive the vehicle over or stop the vehicle near flammable materials.
The exhaust system and exhaust gases can be extremely hot. These hot
parts may cause a fire if there is any flammable material nearby.

●

During  normal  driving,  do  not  turn  off  the  engine. Turning  the  engine  off
while  driving  will  not  cause  loss  of  steering  or  braking  control,  but  the
power assist to these systems will be lost. This will make it more difficult to
steer and brake, so you should pull over and stop the vehicle as soon as it
is safe to do so.
However, in the event of an emergency, such as if it becomes impossible
to stop the vehicle in the normal way:



P. 527

●

Use  engine  braking  (downshift)  to  maintain  a  safe  speed  when  driving
down a steep hill.
Using the brakes continuously may cause the brakes to overheat and lose
effectiveness. (



P. 220)

●

Do not adjust the display, the positions of the steering wheel, the seat, or
the inside or outside rear view mirrors while driving.
Doing so may result in a loss of vehicle control.

●

Always check that all passengers’ arms, heads or other parts of their body
are not outside the vehicle.

●

AWD models: Do not drive the vehicle off-road.
This is not an AWD vehicle designed for off-road driving. Proceed with all
due caution if it becomes unavoidable to drive off-road.

200

4-1. Before driving

CAMRY_U

WARNING

Observe the following precautions.
Failure to do so may result in death or serious injury.

■

When driving the vehicle

●

Do not drive in excess of the speed limit. Even if the legal speed limit per-
mits it, do not drive over 85 mph (140 km/h) unless your vehicle has high-
speed capability tires. Driving over 85 mph (140 km/h) may result in tire
failure, loss of control and possible injury. Be sure to consult a tire dealer
to  determine whether the  tires on your  vehicle are high-speed capability
tires or not before driving at such speeds.

■

When driving on slippery road surfaces

●

Sudden  braking,  acceleration  and  steering  may  cause  tire  slippage  and
reduce your ability to control the vehicle.

●

Sudden acceleration, engine braking due to shifting, or changes in engine
speed could cause the vehicle to skid.

●

After  driving  through  a  puddle,  lightly  depress  the  brake  pedal  to  make
sure that the brakes are functioning properly. Wet brake pads may prevent
the brakes from functioning properly. If the brakes on only one side are wet
and not functioning properly, steering control may be affected.

■

When shifting the shift lever

●

Do not let the vehicle roll backward while the shift lever is in a driving posi-
tion, or roll forward while the shift lever is in R.
Doing so may cause the engine to stall or lead to poor brake and steering
performance, resulting in an accident or damage to the vehicle.

●

Do not shift the shift lever to P while the vehicle is moving.
Doing so can damage the transmission and may result in a loss of vehicle
control.

●

Do not shift the shift lever to R while the vehicle is moving forward.
Doing so can damage the transmission and may result in a loss of vehicle
control.

●

Do not shift the shift lever to a driving position while the vehicle is moving
backward.
Doing so can damage the transmission and may result in a loss of vehicle
control.

●

Shifting the shift lever to N while the vehicle is moving will disengage the
engine from the transmission. Engine braking is not available when N is
selected.

●

Be careful not to shift the shift lever with the accelerator pedal depressed.
Shifting the shift lever to a gear other than P or N may lead to unexpected
rapid acceleration of the vehicle that may cause an accident and result in
death or serious injury.

201

4-1. Before driving

4

Drivin

g

CAMRY_U

WARNING

Observe the following precautions.
Failure to do so may result in death or serious injury.

■

If you hear a squealing or scraping noise (brake pad wear limit indica-
tors)

Have the brake pads checked and replaced by your Toyota dealer as soon
as possible.
Rotor damage may result if the pads are not replaced when needed.
It is dangerous to drive the vehicle when the wear limits of the brake pads
and/or those of the brake discs are exceeded.

■

When the vehicle is stopped

●

Do not race the engine.
If the shift lever is any position other than P or N, the vehicle may acceler-
ate suddenly and unexpectedly, causing an accident.

●

In order to prevent accidents due to the vehicle rolling away, always keep
depressing  the  brake  pedal  while  the  engine  is  running,  and  apply  the
parking brake as necessary.

●

If the vehicle is stopped on an incline, in order to prevent accidents caused
by the vehicle rolling forward or backward, always depress the brake pedal
and securely apply the parking brake as needed.

●

Avoid revving or racing the engine.
Running the engine at high speed while the vehicle is stopped may cause
the exhaust system to overheat, which could result in a fire if combustible
material is nearby.

202

4-1. Before driving

CAMRY_U

WARNING

Observe the following precautions.
Failure to do so may result in death or serious injury.

■

When the vehicle is parked

●

Do not leave glasses, cigarette lighters, spray cans, or soft drink cans in
the vehicle when it is in the sun.
Doing so may result in the following:
• Gas may leak from a cigarette lighter or spray can, and may lead to a

fire.

• The  temperature  inside  the  vehicle  may  cause  the  plastic  lenses  and

plastic material of glasses to deform or crack.

• Soft  drink  cans  may  fracture,  causing  the  contents  to  spray  over  the

interior of the vehicle, and may also cause a short circuit in the vehicle’s
electrical components.

●

Do not leave cigarette lighters in the vehicle. If a cigarette lighter is in a
place such as the glove box or on the floor, it may be lit accidentally when
luggage is loaded or the seat is adjusted, causing a fire.

●

Do not attach adhesive discs to the windshield or windows. Do not place
containers such as air fresheners on the instrument panel or dashboard.
Adhesive discs or containers may act as lenses, causing a fire in the vehi-
cle.

●

Do not leave a door or window open if the curved glass is coated with a
metallized film such as a silver-colored one. Reflected sunlight may cause
the glass to act as a lens, causing a fire.

●

Always apply the parking brake, shift the shift lever to P, stop the engine
and lock the vehicle.
Do not leave the vehicle unattended while the engine is running.
If the vehicle is parked with the shift lever in P but the parking brake is not
set, the vehicle may start to move, possibly leading to an accident.

●

Do not touch the exhaust pipes while the engine is running or immediately
after turning the engine off.
Doing so may cause burns.

203

4-1. Before driving

4

Drivin

g

CAMRY_U

WARNING

Observe the following precautions.
Failure to do so may result in death or serious injury.

■

When taking a nap in the vehicle

Always  turn  the  engine  off.  Otherwise,  if  you  accidentally  move  the  shift
lever or depress the accelerator pedal, this could cause an accident or fire
due to engine overheating. Additionally, if the vehicle is parked in a poorly
ventilated area, exhaust gases may collect and enter the vehicle, leading to
death or a serious health hazard.

■

When braking

●

When the brakes are wet, drive more cautiously.
Braking distance increases when the brakes are wet, and this may cause
one side of the vehicle to brake differently than the other side. Also, the
parking brake may not securely hold the vehicle.

●

If the brake booster device does not operate, do not follow other vehicles
closely and avoid hills or sharp turns that require braking.
In  this  case,  braking  is  still  possible,  but  the  brake  pedal  should  be
depressed more firmly than usual. Also, the braking distance will increase.
Have your brakes fixed immediately.

●

Do not pump the brake pedal if the engine stalls.
Each push on the brake pedal uses up the reserve for the power-assisted
brakes.

●

The brake system consists of 2 individual hydraulic systems; if one of the
systems  fails,  the  other  will  still  operate.  In  this  case,  the  brake  pedal
should be depressed more firmly than usual and the braking distance will
increase.
Have your brakes fixed immediately.

■

If the vehicle becomes stuck (AWD models)

Do not spin the wheels excessively when any of the tires is up in the air, or
the vehicle is stuck in sand, mud, etc. This may damage the driveline com-
ponents or propel the vehicle forward or backward, causing an accident.

204

4-1. Before driving

CAMRY_U

NOTICE

■

When driving the vehicle

●

Do not depress the accelerator and brake pedals at the same time during
driving, as this may restrain driving torque.

●

Do  not  use  the  accelerator  pedal  or  depress  the  accelerator  and  brake
pedals at the same time to hold the vehicle on a hill.

■

When parking the vehicle

Always set the parking brake and shift the shift lever to P. Failure to do so
may cause the vehicle to move or the vehicle may accelerate suddenly if
the accelerator pedal is accidentally depressed.

■

Avoiding damage to vehicle parts

●

Do not turn the steering wheel fully in either direction and hold it there for
an extended period of time.
Doing so may damage the power steering motor.

●

When driving over bumps on the road, drive as slowly as possible to avoid
damaging the wheels, underside of the vehicle, etc.

■

If you get a flat tire while driving

A flat or damaged tire may cause the following situations. Hold the steering
wheel firmly and gradually depress the brake pedal to slow down the vehi-
cle.

●

It may be difficult to control your vehicle.

●

The vehicle will make abnormal sounds or vibrations.

●

The vehicle will lean abnormally.

Information on what to do in case of a flat tire (



P. 553)

■

When encountering flooded roads

Do not drive on a road that has flooded after heavy rain etc. Doing so may
cause the following serious damage to the vehicle:

●

Engine stalling

●

Short in electrical components

●

Engine damage caused by water immersion

In the event that you drive on a flooded road and the vehicle is flooded, be
sure to have your Toyota dealer check the following:

●

Brake function

●

Changes in quantity and quality of oil and fluid used for the engine, tran-
saxle, transfer (AWD models), rear differential (AWD models), etc.

●

Lubricant condition for the bearings and suspension joints (where possi-
ble), and the function of all joints, bearings, etc.

205

4-1. Before driving

4

Drivin

g

CAMRY_U

Cargo capacity depends on the total weight of the occupants.
(Cargo capacity) = (Total load capacity) — (Total weight of occupants)

Steps for Determining Correct Load Limit —

(1) Locate  the  statement  “The  combined  weight  of  occupants  and

cargo should never exceed XXX kg or XXX lbs.” on your vehicle’s
placard.

(2) Determine the combined weight of the driver and passengers that

will be riding in your vehicle.

(3) Subtract  the  combined  weight  of  the  driver  and  passengers  from

XXX kg or XXX lbs.

(4) The resulting figure equals the available amount of cargo and lug-

gage load capacity.
For example, if the “XXX” amount equals 1400 lbs. and there will be
five  150  lb  passengers  in  your  vehicle,  the  amount  of  available
cargo and luggage load capacity is 650 lbs. (1400



 750 (5



150) =

650 lbs.)

(5) Determine the combined weight of luggage and cargo being loaded

on  the  vehicle.  That  weight  may  not  safely  exceed  the  available
cargo and luggage load capacity calculated in Step 4.

(6) If your vehicle will be towing a trailer, load from your trailer will be

transferred to your vehicle. Consult this manual to determine how
this reduces the available cargo and luggage load capacity of your
vehicle.
(



P. 208)

Toyota  does  not  recommend  towing  a  trailer  with  your  vehicle.  Your

vehicle is not designed for trailer towing.

Cargo and luggage

Take  notice of the following information about storage  precau-
tions, cargo capacity and load:

Capacity and distribution
