Toyota Camry (2020 year). Manual in english

1-2. Child safety

CAMRY_U

WARNING

■

When installing a child restraint system

Observe the following precautions.
Failure to do so may result in death or serious injury.

●

Firmly attach the top tether strap and make sure that the belt is not twisted.

●

Do not attach the top tether strap to anything other than the anchor
bracket.

●

After securing a child restraint system, never adjust the seat.

●

Follow all installation instructions provided by the child restraint system
manufacturer.

●

When installing the child restraint system with the head restraint being
raised, after the head restraint has been raised and then the anchor
bracket has been fixed, do not lower the head restraint.

NOTICE

■

Anchor brackets (for top tether strap)

When not in use, make certain to close the lid. If it remains open, the lid
may be damaged.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Fo
r safety and securi

CAMRY_U

1-3. Emergency assistance

■

System components

Microphone
LED light indicators
“SOS” button

Safety Connect



: If equipped

Safety  Connect  is  a  subscription-based  telematics  service  that
uses Global Positioning System (GPS) data and embedded cel-
lular technology to provide safety and security features to sub-
scribers.  Safety  Connect  is  supported  by  Toyota’s  designated
response  center,  which  operates  24  hours  per  day,  7  days  per
week.
Safety  Connect  service  is  available  by  subscription  on  select,
telematics hardware-equipped vehicles.
By  using  the  Safety  Connect  service,  you  are  agreeing  to  be
bound  by  the  Telematics  Subscription  Service Agreement  and
its Terms and Conditions, as in effect and amended from time to
time, a current copy of which is available at Toyota.com in the
United  States,  Toyotapr.com  in  Puerto  Rico  and  Toyota.ca  in
Canada. All use of the Safety Connect service is subject to such
then-applicable Terms and Conditions.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

1-3. Emergency assistance

CAMRY_U

■

Services

Subscribers have the following Safety Connect services available:

●

Automatic Collision Notification

Helps drivers receive necessary response from emergency ser-
vice providers. (



P. 76)

: U.S. Patent No. 7,508,298 B2

●

Stolen Vehicle Location
Helps drivers in the event of vehicle theft. (



P. 76)

●

Emergency Assistance Button (“SOS”)
Connects drivers to response-center support. (



P. 76)

●

Enhanced Roadside Assistance
Provides drivers various on-road assistance. (



P. 77)

■

Subscription

After you have signed the Telematics Subscription Service Agree-
ment and are enrolled, you can begin receiving services.
A variety of subscription terms are available for purchase. Contact
your Toyota dealer, call the following appropriate Customer Experi-
ence Center or push the “SOS” button in your vehicle for further
subscription details.

• The United States

1-800-331-4331

• Canada

1-888-869-6828

• Puerto Rico

1-877-855-8377

-------------------------------------------------------------------------------------------------------------------------------------------------------------

1-3. Emergency assistance

Fo
r safety and securi

CAMRY_U

■

Safety Connect Services Information

●

Phone calls using the vehicle’s Bluetooth

technology will not be possible

when Safety Connect is active and in use.

●

Safety Connect is available beginning Fall 2009 on select Toyota models (in
the  contiguous  United  States  only).  Contact  with  the  Safety  Connect
response center is dependent upon the telematics device being in operative
condition, cellular connection availability, and GPS satellite signal reception,
which  can  limit  the  ability  to  reach  the  response  center  or  receive  emer-
gency  service  support.  Enrollment  and  Telematics  Subscription  Service
Agreement  are  required.  A  variety  of  subscription  terms  are  available;
charges vary by subscription term selected and location.

●

Automatic Collision Notification, Emergency Assistance and Stolen Vehicle
Location are available in the United States, including Hawaii and Alaska,
Puerto Rico and Canada, and Enhanced Roadside Assistance are available
in the United States, Puerto Rico and Canada.

●

Automatic Collision Notification, Emergency Assistance, Stolen Vehicle and
Enhanced Road Assistance are not available in the U.S. Virgin Islands.
For vehicles first sold in the U.S. Virgin Islands, no Safety Connect services
will function in or outside the U.S. Virgin Islands.

●

Safety Connect services are not subject to section 255 of the Telecommuni-
cations Act and the device is not TTY compatible.

■

Languages

The Safety Connect response center will offer support in multiple languages.
The Safety Connect system will offer voice prompts in English, Spanish, and
French. Please indicate your language of choice when enrolling.

■

When contacting the response center

You may be unable to contact the response center if the network is busy.

When the engine switch is turned to IGNITION ON mode, the red indi-
cator light comes on for 2 seconds then turns off. Afterward, the green
indicator light comes on, indicating that the service is active.
The following indicator light patterns indicate specific system usage
conditions:

●

Green indicator light on = Active service

●

Green indicator light flashing = Safety Connect call in process

●

Red indicator light (except at vehicle start-up) = System malfunction
(contact your Toyota dealer)

●

No indicator light (off) = Safety Connect service not active

Safety Connect LED light Indicators

-------------------------------------------------------------------------------------------------------------------------------------------------------------

1-3. Emergency assistance

CAMRY_U

■

Automatic Collision Notification

In case of either airbag deployment or severe rear-end collision, the
system is designed to automatically call the response center. The
responding  agent  receives  the  vehicle’s  location  and  attempts  to
speak with the vehicle occupants to assess the level of emergency.
If  the  occupants  are  unable  to  communicate,  the  agent  automati-
cally  treats the call  as  an  emergency,  contacts  the  nearest emer-
gency services provider to describe the situation, and requests that
assistance be sent to the location.

■

Stolen Vehicle Location

If your vehicle is stolen, Safety Connect can work with local author-
ities to assist them in locating and recovering the vehicle. After filing
a police report, call the Customer Experience Center at 1-800-331-
4331 in the United States, 1-877-855-8377 in Puerto Rico or 1-888-
869-6828 in Canada, and follow the prompts for Safety Connect to
initiate this service.
In addition to assisting law enforcement with recovery of a stolen
vehicle, Safety-Connect-equipped vehicle location data may, under
certain circumstances, be shared with third parties to locate your
vehicle. Further information is available at Toyota.com in the United
States, Toyotapr.com in Puerto Rico and Toyota.ca in Canada.

■

Emergency Assistance Button (“SOS”)

In the event of an emergency on the road, push the “SOS” button to
reach the Safety Connect response center. The answering agent
will determine your vehicle’s location, assess the emergency, and
dispatch the necessary assistance required.

If you accidentally press the “SOS” button, tell the response-center
agent that you are not experiencing an emergency.

Safety Connect services

-------------------------------------------------------------------------------------------------------------------------------------------------------------

1-3. Emergency assistance

Fo
r safety and securi

CAMRY_U

■

Enhanced Roadside Assistance

Enhanced  Roadside  Assistance  adds  GPS  data  to  the  already
included warranty-based Toyota roadside service.
Subscribers can press the “SOS” button to reach a Safety Connect
response-center agent, who can help with a wide range of needs,
such as: towing, flat tire, fuel delivery, etc. For a description of the
Enhanced  Roadside  Assistance  services  and  their  limitations,
please  see  the  Safety  Connect  Terms  and  Conditions,  which  are
available  at  Toyota.com  in  the  United  States,  Toyotapr.com  in
Puerto Rico and Toyota.ca in Canada.

Important! Read this information before using Safety Connect.

■

Exposure to radio frequency signals

The Safety Connect system installed in your vehicle is a low-power
radio transmitter and receiver. It receives and also sends out radio
frequency (RF) signals.
In August 1996, the Federal Communications Commission (FCC)
adopted RF exposure guidelines with safety levels for mobile wire-
less phones. Those guidelines are consistent with the safety stan-
dards previously set by the following U.S. and international
standards bodies.

●

ANSI (American National Standards Institute) C95.1 [1992]

●

NCRP (National Council on Radiation Protection and Measure-
ment) Report 86 [1986]

●

ICNIRP (International Commission on Non-Ionizing Radiation
Protection) [1996]

Those standards were based on comprehensive and periodic eval-
uations of the relevant scientific literature. Over 120 scientists, engi-
neers, and physicians from universities, and government health
agencies and industries reviewed the available body of research to
develop the ANSI Standard (C95.1).
The design of Safety Connect complies with the FCC guidelines in
addition to those standards.

Safety information for Safety Connect

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Fo
r safety and securi

CAMRY_U

1-4. Theft deterrent system

Vehicles without a smart key sys-
tem:
The  indicator  light  flashes  after
the  key  has  been  removed  from
the  engine  switch  to  indicate  that
the system is operating.
The  indicator  light  stops  flashing
after the registered key has been
inserted into the engine switch to
indicate that the system has been
canceled.
Vehicles with a smart key system:
The indicator light flashes after the engine switch has been turned off
to indicate that the system is operating.
The  indicator  light  stops  flashing  after  the  engine  switch  has  been
turned  to ACCESSORY  or  IGNITION  ON  mode  to  indicate  that  the
system has been canceled.

■

System maintenance

The vehicle has a maintenance-free type engine immobilizer system.

■

Conditions that may cause the system to malfunction

●

If the grip portion of the key is in contact with a metallic object

●

If the key is in close proximity to or touching a key to the security system
(key with a built-in transponder chip) of another vehicle

Engine immobilizer system

The vehicle’s keys have built-in transponder chips that prevent
the engine from starting if a key has not been previously regis-
tered in the vehicle’s on-board computer.
Never leave the keys inside the vehicle when you leave the vehi-
cle.
This system is designed to help prevent vehicle theft but does
not guarantee absolute security against all vehicle thefts.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

1-4. Theft deterrent system

CAMRY_U

The alarm uses light and sound to give an alert when an intrusion is
detected.
The alarm is triggered in the following situations when the alarm is
set:



Vehicles without a smart key system

●

A locked door is unlocked or opened in any way other than using
the wireless remote control or key. (The doors will lock again auto-
matically.)

●

The trunk is opened in any way other than using the wireless
remote control.

●

The hood is opened.



Vehicles with a smart key system

●

A locked door is unlocked or opened in any way other than using
the entry function, wireless remote control or mechanical key. (The
doors will lock again automatically.)

●

The trunk is opened in any way other than using the entry function
or wireless remote control.

●

The hood is opened.

Close the doors, trunk and hood,
and lock all the doors. The system
will be set automatically after 30
seconds.

The indicator light changes from
being on to flashing when the sys-
tem is set.

Alarm



: If equipped

The alarm

Setting the alarm system

-------------------------------------------------------------------------------------------------------------------------------------------------------------

1-4. Theft deterrent system

Fo
r safety and securi

CAMRY_U

Do one of the following to deactivate or stop the alarm:



Vehicles without a smart key system

●

Unlock the doors.

●

Open the trunk using the wireless remote control.

●

Turn the engine switch to the “ACC” or “ON” position, or start the
engine. (The alarm will be deactivated or stopped after a few sec-
onds.)



Vehicles with a smart key system

●

Unlock the doors.

●

Open the trunk using the entry function or wireless remote control.

●

Turn the engine switch to ACCESSORY or IGNITION ON mode, or
start the engine. (The alarm will be deactivated or stopped after a
few seconds.)

■

System maintenance

The vehicle has a maintenance-free type alarm system.

■

Items to check before locking the vehicle

To prevent unexpected triggering of the alarm and vehicle theft, make sure of
the following:

●

Nobody is in the vehicle.

●

The windows and moon roof or panoramic moon roof are closed before the
alarm is set.

●

No valuables or other personal items are left in the vehicle.

Deactivating or stopping the alarm

-------------------------------------------------------------------------------------------------------------------------------------------------------------

1-4. Theft deterrent system

CAMRY_U

■

Triggering of the alarm

The alarm may be triggered in the following situations:
(Stopping the alarm deactivates the alarm system.)

■

Alarm-operated door lock

In the following cases, depending on the situation, the door may automatically
lock to prevent improper entry into the vehicle:

●

When a person remaining in the vehicle unlocks the door and the alarm is
activated.

●

While the alarm is activated, a person remaining in the vehicle unlocks the
door.

●

When recharging or replacing the battery

●

Vehicles without a smart key system:
The trunk is opened using the key.

●

Vehicles with a smart key system: The
trunk is opened using the mechanical
key.

●

A person inside the vehicle opens a door
or the trunk or hood, or unlocks the vehi-
cle.

●

The battery is recharged or replaced
when the vehicle is locked. (



P. 536)

NOTICE

■

To ensure the system operates correctly

Do not modify or remove the system. If modified or removed, the proper
operation of the system cannot be guaranteed.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

2. Instrument cluster

Instru

me
nt clu

ster

CAMRY_U

Warning lights inform the driver of malfunctions in the indicated vehi-
cle’s systems.

Warning lights

(U.S.A.)

Brake system warning
light (



P. 500)

(U.S.A.)

Parking brake indicator
(



P. 501)

(Canada)

(Red)

Brake system warning
light (



P. 500)

(Canada)

Parking brake indicator
(



P. 501)

(if equipped)

(Yellow)

Brake system warning
light (



P. 500)

1, 2

(if equipped)

Brake hold operated
indicator (



P. 501)

(U.S.A.)

Malfunction indicator
lamp (



P. 500)

(Red/yellow)

Electric power steering
system warning light
(



P. 501)

(Canada)

Malfunction indicator
lamp (



P. 500)

(if equipped)

(Yellow)

LDA (Lane Departure
Alert) indicator
(



P. 501)

SRS warning light
(



P. 500)

1, 2

(if equipped)

(Flashes or
illuminates)

PCS warning light
(



P. 502)

(U.S.A.)

ABS warning light
(



P. 500)

1, 2

(if equipped)

ICS OFF indicator
(



P. 502)

(Canada)

ABS warning light
(



P. 500)

Slip indicator (



P. 502)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

2. Instrument cluster

CAMRY_U

: These lights turn on when the engine switch is turned to the “ON” position

(vehicles without a smart key system) or IGNITION ON mode (vehicles
with a smart key system) to indicate that a system check is being per-
formed. They will turn off after the engine is started, or after a few seconds.
There may be a malfunction in a system if a light does not come on, or turn
off. Have the vehicle inspected by your Toyota dealer.

: This light flashes to indicate a malfunction.

: This light illuminates on the center panel.

Low fuel level warning
light (



P. 503)

(Type B)

Rear passengers’ seat
belt reminder lights
(



P. 503)

Driver’s and front
passenger’s seat belt
reminder light (



P. 503)

Master warning light
(



P. 503)

(Type A)

Rear passengers’ seat
belt reminder lights
(



P. 503)

Tire pressure warning
light (



P. 503)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

2. Instrument cluster

Instru

me
nt clu

ster

CAMRY_U

The indicators inform the driver of the operating state of the vehicle’s
various systems.

Indicators

Turn signal indicator
(



P. 219)

Brake hold standby
indicator (



P. 225)

(U.S.A.)

Headlight indicator
(



P. 227)

Cruise control indicator
(



P. 269, 28 3, 297)

(Canada)

Tail light indicator
(



P. 227)

(if equipped)

Dynamic radar cruise
control indicator
(



P. 269, 28 3)

Headlight high beam
indicator (



P. 228)

Cruise control “SET”
indicator
(



P. 269, 28 3, 297)

(if equipped)

Automatic High Beam
indicator (



P. 231)

1, 3

(if equipped)

PCS warning light
(



P. 249)

1, 2

Eco driving indicator
(



P. 105, 1 19)

1, 3

(if equipped)

ICS OFF indicator
(



P. 335)

(U.S.A.)

Parking brake indicator
(



P . 220, 221)

(if equipped)

(White)

LDA (Lane Departure
Alert) indicator
(



P. 259)

(Canada)

Parking brake indicator
(



P . 220, 221)

(if equipped)

(Green)

LDA (Lane Departure
Alert) indicator
(



P. 259)

(if equipped)

Brake hold operated
indicator (



P. 225)

(if equipped)

(Yellow)

LDA (Lane Departure
Alert) indicator
(



P. 259)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

2. Instrument cluster

CAMRY_U

1, 4

Slip indicator (



P. 303)

1, 7

(Type A for

Canada)

“AIRBAG ON/OFF”
indicator (



P. 47)

1, 3

VSC OFF indicator
(



P. 305)

1, 7

(Type B for

Canada)

“AIRBAG ON/OFF”
indicator (



P. 47)

(if equipped)

“BSM” indicator
(



P. 310)

Security indicator
(



P. 79, 82)

(if equipped)

“RCTA” indicator
(



P. 310)

(if equipped)

Intuitive parking assist
indicator (



P. 324)

5, 6

(if equipped)

BSM (Blind Spot Moni-
tor) outside rear view
mirror indicators
(



P. 310)

(if equipped)

“SPORT” indicator
(



P. 353)

1, 7

(Type A for

U.S.A.)

“AIRBAG ON/OFF”
indicator (



P. 47)

(if equipped)

“ECO MODE” indicator
(



P. 353)

1, 7

(Type B for

U.S.A.)

“AIRBAG ON/OFF”
indicator (



P. 47)

Low outside tempera-
ture indicator (



P. 92)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

2. Instrument cluster

Instru

me
nt clu

ster

CAMRY_U

: These lights turn on when the engine switch is turned to the “ON” position

: This light does not turn on when the system is disabled.

: This light turns on when the system is off.

: This light flashes to indicate that the system is operating.

: These indicators will illuminate in the following situations to indicate that

the system initial check is being performed:

• When the BSM function or RCTA function is enabled and the engine

switch is turned to the “ON” position (vehicles without a smart key sys-
tem) or IGNITION ON mode (vehicles with a smart key system).

• When the engine switch is in the “ON” position (vehicles without a smart

key system) or IGNITION ON mode (vehicles with a smart key system)
and the BSM function is enabled.

• When the engine switch is in the “ON” position (vehicles without a smart

key system) or IGNITION ON mode (vehicles with a smart key system)
and the RCTA function is enabled. (At this time, a buzzer will also
sound.)
The indicators will turn off after a few seconds. If the indicators do not
illuminate or turn off, or if a buzzer does not sound when the RCTA func-
tion is enabled, the system may be malfunctioning. Have the vehicle
inspected by your Toyota dealer.

: This light illuminates on the outside rear view mirrors.

: This light illuminates on the center panel.

: When the outside temperature is approximately 37°F (3°C) or lower, this

indicator will flash for approximately 10 seconds, then stay on.

WARNING

■

If a safety system warning light does not come on

Should a safety system light such as the ABS and SRS warning lights not
come on when you start the engine, this could mean that these systems are
not available to help protect you in an accident, which could result in death
or serious injury. Have the vehicle inspected by your Toyota dealer immedi-
ately if this occurs.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

2. Instrument cluster

Instru

me
nt clu

ster

CAMRY_U

Tachometer

Displays the engine speed in revolutions per minute

Shift position (



P. 213)

Outside temperature

Displays the outside temperature within the range of -40°F (-40°C) to
122°F (50°C). Low outside temperature indicator comes on when the
ambient temperature is 37°F (3°C) or lower.

Multi-information display

Presents the driver with a variety of vehicle data (



P. 95, 107)

Displays warning messages in case of a malfunction (



P. 510)

Speedometer
Fuel gauge
Odometer and trip meter (



P. 104, 1 18)

Engine coolant temperature gauge

Displays the engine coolant temperature

The brightness of the instrument panel lights can be adjusted.

Darker
Brighter

• The brightness of the instrument

panel lights can be adjusted
individually for day mode and
night mode

• If the brightness is adjusted

when  the  surroundings  are
bright  and  the  tail  lights  are  on
(day  mode  brightness  adjust-
ment),  the  brightness  level  of
night  mode  will  be  adjusted  at
the same time.

: Day mode and night mode:



P. 94

Instrument panel light control

-------------------------------------------------------------------------------------------------------------------------------------------------------------

2. Instrument cluster

CAMRY_U

■

The meters and display illuminate when



Vehicles without a smart key system

The engine switch is in the “ON” position.



Vehicles with a smart key system

The engine switch is in IGNITION ON mode.

■

Brightness of the meters (day mode and night mode)

●

The brightness of the meters is changed between day mode and night
mode.
• Day mode: When the tail lights are off or when the tail lights are on but

the surrounding area is bright

• Night mode: When the tail lights are on and the surrounding area is dark

●

When in night mode, the brightness will be reduced slightly unless the
meters are set to the maximum brightness level.

■

Outside temperature display

In the following situations, the correct outside temperature may not be dis-
played, or the display may take longer than normal to change:

●

When stopped, or driving at low speeds (less than 16 mph [25 km/h])

●

When the outside temperature has changed suddenly (at the entrance/exit
of a garage, tunnel, etc.)

●

When “



” or “E” is displayed, the system may be malfunctioning.

Take your vehicle to your Toyota dealer.

NOTICE

■

To prevent damage to the engine and its components

●

Do not let the indicator needle of the tachometer enter the red zone, which
indicates the maximum engine speed.

●

The engine may be overheating if the engine coolant temperature gauge is
in the red zone (H). In this case, immediately stop the vehicle in a safe
place, and check the engine after it has cooled completely. (



P. 538)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

2. Instrument cluster

Instru

me
nt clu

ster

CAMRY_U

The multi-information display presents the driver with a variety of driv-
ing-related data, such as the current outside temperature. The multi-
information display can also be used to change the display settings
and other settings.

Shift position (



P. 213)

Menu icon display area

Displays the following items.
When a menu icon is not selected, the outside temperature and clock are
displayed.

• Menu icons (



P. 97)

• Outside temperature (



P. 92)

• Clock

: For clock settings, refer to “NAVIGATION AND MULTIMEDIA SYSTEM

OWNER’S MANUAL”.

Content display area

A variety of information can be displayed by selecting a menu icon. Addi-
tionally, warning or suggestion/advice pop-up displays will be displayed in
some situations.

• Menu icon content (



P. 97)

• Suggestion function (

• Warning message (

Odometer/trip meter (



P. 104)

Indicators (



P. 86)

Multi-information display (4.2-inch display)

Summary of functions

-------------------------------------------------------------------------------------------------------------------------------------------------------------

2. Instrument cluster

CAMRY_U

“ODO/TRIP” switch (



P. 96)

Meter control switches (



P. 96)

◆

Using the content display area

The content display area is operated using the meter control
switches.

Scroll screens

, change the

displayed content

and move

the cursor
Press: Enter/Set
Press and hold: Reset
Return to the previous
screen

Pressing and holding the switch
will display the first screen of the
selected menu icon.

Call sending/receiving and history display

Linked with the hands-free system, sending or receiving call is dis-
played. For details regarding the hands-free system, refer to “NAVIGA-
TION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”.

: When the screen can be scrolled or different content can be displayed,

a mark, such as an arrow, will be displayed to suggest which switch to
operate.

◆

Using the odometer/trip meter

Items in this area are operated using the “ODO/TRIP” switch.
Press: Change displayed item

Each time the switch is pressed,
the displayed item will be
changed.

Press and hold: Reset

Display the desired trip meter
and press and hold the switch to
reset the trip meter.

Using the multi-information display

-------------------------------------------------------------------------------------------------------------------------------------------------------------

2. Instrument cluster

Instru

me
nt clu

ster

CAMRY_U

Select a menu icon to display its content.

Drive information (



P. 98)

Select to display various drive data.

Audio system-linked display

Select to enable selection of an audio source or track on the meter
using the meter control switches.

Driving assist system information

Select to display the operational status of the following systems:

• Cruise control (if equipped) (→P. 297)
• Dynamic radar cruise control (if equipped) (



P. 283)

• LDA (Lane Departure Alert with steering control) (if equipped)

(



P. 259)

Warning message display (



P. 510)

Select to display warning messages and measures to be taken if a mal-
function is detected.

Settings display (



P. 100)

Select to change the meter display settings and other settings.

Menu icons

-------------------------------------------------------------------------------------------------------------------------------------------------------------

2. Instrument cluster

CAMRY_U

■

Trip (after start)

Average fuel economy

Displays the average fuel con-
sumption since engine start.

Average vehicle speed

Displays the average vehicle
speed since engine start.

Elapsed time

Displays the time elapsed since
engine start.

: Use the displayed fuel consumption as a reference only.

■

Total (after reset)

Current fuel consumption

Displays the instantaneous cur-
rent fuel consumption.

Average fuel economy

1, 2

Displays the average fuel con-
sumption since the display was
reset.

Average

vehicle

speed/

Elapsed time

Displays the average vehicle speed since reset or elapsed time since
reset, as selected in

. (



P. 100)

: Pressing and holding

will reset the average fuel consumption and

average vehicle speed/elapsed time.

: Use the displayed fuel consumption as a reference only.

Drive information (

)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

2. Instrument cluster

Instru

me
nt clu

ster

CAMRY_U

■

Tank (after refuel)

Driving range

1, 2

Displays the driving range with
remaining fuel.

Average fuel economy

1, 3

Displays the average fuel con-
sumption since the vehicle was
refueled.

: When only a small amount of fuel is added to the tank, the display may

not be updated.
When refueling, turn the engine switch off. If the vehicle is refueled with-
out turning the engine switch off, the display may not be updated.

: This distance is computed based on your average fuel consumption. As

a result, the actual distance that can be driven may differ from that dis-
played.

: Use the displayed fuel consumption as a reference only.

■

Eco Driving Indicator



P. 105

■

Speedometer

Displays the vehicle speed.

■

Tire pressure (vehicles with a tire inflation pressure display
function)



P. 447

■

Blank (No items)

Displays no drive information contents.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

100

2. Instrument cluster

CAMRY_U

◆

Changing settings

Use the meter control switches on the steering wheel to change
settings.

Press

to select

Operate the switches to select a desired item.
Change the setting by referring to the message displayed on the
screen.

◆

Setting items

■

LDA (Lane Departure Alert with steering control)

(if equipped) (



P. 259)

The following LDA system settings can be changed:

Settings display (

)

Item

Settings

Details

Steering assist

Select to enable/disable steering
wheel assistance.

Off

Alert sensitivity

High

Select to set the warning sensi-
tivity.

Normal

Sway warning

Select to enable/disable the vehi-
cle sway warning.

Off

Sway sensitivity

High

Select to set the vehicle sway
warning sensitivity.

Medium

Low

-------------------------------------------------------------------------------------------------------------------------------------------------------------

101

2. Instrument cluster

Instru

me
nt clu

ster

CAMRY_U

■

PCS (Pre-Collision System) (if equipped) (



P. 249)

The following pre-collision system settings can be changed:

■

BSM (Blind Spot Monitor) function (if equipped) (



P. 310)

■

RCTA (Rear Cross Traffic Alert) function (if equipped)
(



P. 310)

Item

Settings

Details

PCS

Select to enable/disable the pre-
collision system.

Off

Warning sensitivity

Select to change the warning
timing.

Item

Settings

Details

BSM

Select to enable/disable the
Blind Spot Monitor function.

Off

Item

Settings

Details

RCTA

Select to enable/disable the Rear
Cross Traffic Alert function.

Off

-------------------------------------------------------------------------------------------------------------------------------------------------------------

102

2. Instrument cluster

CAMRY_U

■

Vehicle settings

Item

Settings

Details

BSM (Blind Spot Monitor) (if equipped) (



P. 310)

Outside rear view
mirror

indicator

brightness

Bright

Select to change the brightness
of the outside rear view mirror
indicators.

Dim

RCTA (Rear Cross Traffic Alert) (if equipped) (



P. 310)

RCTA buzzer vol-
ume

1 (Low)

Select to change the volume of
the RCTA buzzer.

2 (Medium)

3 (Loud)

TPWS (Tire pressure warning system) (



P. 447)

Set pressure (tire pressure warning sys-
tem initialization)

Select to initialize the tire pres-
sure warning system. To per-
form initialization, press and hold
the

switch.

Before performing initialization,
make sure to adjust the inflation
pressure of each tire to the spec-
ified level. (



P. 448)

Change  wheel  (change  the  tire  pres-
sure  warning  system  sensor  ID  code
set)
(vehicles  without  a  tire  inflation  pres-
sure display function)

Select  to  change  the  tire  pres-
sure  warning  system  sensor  ID
code set.
To enable this function, a second
set of tire pressure warning sys-
tem  sensor  ID  codes  must  be
registered  by  a  Toyota  dealer.
For information regarding chang-
ing  the  registered  ID  code  set,
contact your Toyota dealer.
(



P. 450)

Change wheel (register tire pressure
warning system sensor ID codes)
(vehicles with a tire inflation pressure
display function)

Select to register the ID codes of
the tire pressure sensors to the
tire pressure warning system.
To register the ID codes, press
and hold the

switch.

(



P. 450)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

103

2. Instrument cluster

Instru

me
nt clu

ster

CAMRY_U

■

Meter settings

Scheduled maintenance display (if equipped)

Maintenance data reset

Select to reset the message indi-
cating maintenance is required,
after the required maintenance is
performed. (



P. 423)

Item

Settings

Details

Item

Settings

Details

Language

Select to change the language
displayed.

Units

Select to change the units of
measure displayed.

(Eco Driving

Indicator Light)

Select to enable/disable the Eco
Driving Indicator Light. (



P. 105)

Off

Drive information
(total [after reset])

Average vehicle
speed

Select to change the display
between average speed/elapsed
time.

Elapsed time

Pop-up display

Incoming calls

Select to enable/disable the pop-
up display.

Brightness adjust-
ment

Default setting

Select to reset the meter display
settings to the default setting.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

104

2. Instrument cluster

CAMRY_U

■

Odometer

Displays the total distance the vehicle has been driven.

■

Trip meter A/trip meter B

Displays the distance the vehicle has been driven since the meter
was last reset. Trip meters A and B can be used to record and dis-
play different distances independently.

To reset, display the desired trip meter and press and hold the “ODO/
TRIP” switch.

Displays suggestions to the driver in the following situations. To select
a response to a displayed suggestion, use the meter control switches.

The suggestion function can be turned on/off.
(Customizable features:



P. 575)

■

Suggestion to turn off the headlights

If the headlights are left on for a certain amount of time after the
engine switch has been turned off, if the headlight switch is in the
“AUTO” position, a suggestion message will be displayed asking if
you wish to turn the headlights off. To turn the headlights off, select
“Yes”.

If a front door is opened after the engine switch is turned off, this sug-
gestion message will not be displayed.

Odometer/trip meter

Suggestion function

-------------------------------------------------------------------------------------------------------------------------------------------------------------

105

2. Instrument cluster

Instru

me
nt clu

ster

CAMRY_U

■

Eco Driving Indicator

Eco Driving Indicator will not operate under the following conditions:

●

The shift lever is in any position other than D.

●

A paddle shift switch (if equipped) is operated.

●

The vehicle speed is approximately 80 mph (130 km/h) or higher.

■

Suspension of the settings display

●

Some settings cannot be changed while driving. When changing settings,
park the vehicle in a safe place.

●

If a warning message is displayed, operation of the settings display will be
suspended.

■

Tire pressure (vehicles with a tire inflation pressure display function)

●

It may take a few minutes to display the tire inflation pressure after the
engine switch is turned to the “ON” position (vehicles without a smart key
system) or IGNITION ON mode (vehicles with a smart key system). It may
also take a few minutes to display the tire inflation pressure after inflation
pressure has been adjusted.

●

“---” may be displayed if the tire position information cannot be determined
due to unfavorable radio wave conditions.

●

Tire inflation pressure changes with temperature. The displayed values may
also be different from the values measured using a tire pressure gauge.

■

Liquid crystal display

Small spots or light spots may appear on the display. This phenomenon is
characteristic of liquid crystal displays, and there is no problem continuing to
use the display.

■

Customization

Some functions can be customized. (



P. 100, 575)

Eco Driving Indicator Light
During  Eco-friendly  acceleration  (Eco
driving), the Eco Driving Indicator Light
will  turn  on.  When  the  acceleration
exceeds  the  Zone  of  Eco  driving,  or
when  the  vehicle  is  stopped,  the  light
turns off.
Eco Driving Indicator Zone Display
Suggests  the  Zone  of  Eco  driving  with
current  Eco  driving  ratio  based  on
acceleration.
Eco driving ratio based on acceleration
If the acceleration exceeds the Zone of
Eco  driving,  the  right  side  of  the  Eco
Driving  Indicator  Zone  Display  will  illu-
minate.
Zone of Eco driving

-------------------------------------------------------------------------------------------------------------------------------------------------------------

106

2. Instrument cluster

CAMRY_U

WARNING

■

Caution for use while driving

●

When operating the multi-information display while driving, pay extra
attention to the safety of the area around the vehicle.

●

Do not look continuously at the multi-information display while driving as
you may fail to see pedestrians, objects on the road, etc. ahead of the
vehicle.

■

The information display at low temperatures

Allow the interior of the vehicle to warm up before using the liquid crystal
information display. At extremely low temperatures, the information display
monitor may respond slowly, and display changes may be delayed.
For example, there is a lag between the driver’s shifting and the new gear
number appearing on the display. This lag could cause the driver to down-
shift again, causing rapid and excessive engine braking and possibly an
accident resulting in death or injury.

■

Cautions during setting up the display

As the engine needs to be running during setting up the display, ensure that
the vehicle is parked in a place with adequate ventilation. In a closed area
such as a garage, exhaust gases including harmful carbon monoxide (CO)
may collect and enter the vehicle. This may lead to death or a serious
health hazard.

NOTICE

■

While setting up the display

To prevent battery discharge, ensure that the engine is running while setting
up the display features.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

107

2. Instrument cluster

Instru

me
nt clu

ster

CAMRY_U

Indicators (



P. 89)

Driving assist system status display area

Displays the operational status of the following systems:

• Cruise control (if equipped) (



P. 297)

• Dynamic radar cruise control with full-speed range (if equipped)

(



P. 269)

• Dynamic radar cruise control (if equipped) (



P. 283)

• LDA (Lane Departure Alert with steering control) (if equipped) (



P. 259)

Speed limit display (vehicles with a navigation system)
(U.S.A. only)
Clock

For clock settings, refer to “NAVIGATION AND MULTIMEDIA SYSTEM
OWNER’S MANUAL”.

Speedometer

The speedometer display can be enabled/disabled in

on the multi-

information display. (



P. 112)

Multi-information display (7-inch display)

Summary of functions

-------------------------------------------------------------------------------------------------------------------------------------------------------------

108

2. Instrument cluster

CAMRY_U

Content display area

A variety of information can be displayed by selecting a menu icon. Addi-
tionally, warning or suggestion/advice pop-up displays will be displayed in
some situations.

• Menu icon content (



P. 109)

• Suggestion function (

• Warning message (

Odometer/trip meter (



P. 118)

Shift position (



P. 213)

Outside temperature (



Menu icons (

“ODO/TRIP” switch (

Meter control switches (



P. 108)

◆

Using the content display area

The content display area is operated using the meter control
switches.

Scroll screens

, change the

displayed content

and move

the cursor
Press: Enter/Set
Press and hold: Reset/Dis-
play the next screen
Return to the previous
screen

Pressing and holding the switch will display the first screen of the
selected menu icon.

Call sending/receiving and history display

Linked with the hands-free system, sending or receiving call is dis-
played. For details regarding the hands-free system, refer to “NAVIGA-
TION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”.

: When the screen can be scrolled or different content can be displayed,

a mark, such as an arrow, will be displayed to suggest which switch to
operate.

Using the multi-information display

-------------------------------------------------------------------------------------------------------------------------------------------------------------

109

2. Instrument cluster

Instru

me
nt clu

ster

CAMRY_U

◆

Using the odometer/trip meter

Items in this area are operated using the “ODO/TRIP” switch.
Press: Change displayed item

Each time the switch is pressed,
the displayed item will be
changed.

Press and hold: Reset

Display the desired trip meter
and press and hold the switch to
reset the trip meter.

Select a menu icon to display its content.

Warning message display (



P. 510)

This menu icon will be displayed only when a warning message can be
displayed.
Select to display warning messages and measures to be taken if a mal-
function is detected.

Eco-friendly driving information (



P. 110)

Select to display fuel consumption data in various forms.

Driving assist system information

Select to perform the following:
Display the operational status of the following systems:

• Cruise control (if equipped) (



P. 297)

• Dynamic radar cruise control with full-speed range (if equipped)

(



P. 269)

• Dynamic radar cruise control (if equipped) (



P. 283)

• LDA (Lane Departure Alert with steering control) (if equipped)

(



P. 259)

Display the following navigation system-linked information (if equipped):

• Route guidance
• Compass display (heading-up display)

Audio system-linked display

Select to enable selection of an audio source or track on the meter
using the meter control switches.

Menu icons

-------------------------------------------------------------------------------------------------------------------------------------------------------------

110

2. Instrument cluster

CAMRY_U

Vehicle information

Select to perform the following:
Display the following information:

• Tire inflation pressure (



P. 447)

Enable/Disable the following systems:

• Intuitive parking assist (if equipped) (



P. 324)

• BSM (Blind Spot Monitor) function (if equipped) (



P. 310)

• RCTA (Rear Cross Traffic Alert) function (if equipped) (



P. 310)

This function can also be enabled/disabled on

Settings display (



P. 112)

Select to change the meter display settings and other settings.

■

Fuel consumption

Current fuel consumption

Displays the instantaneous cur-
rent fuel consumption.

Average fuel economy (after
start)

Displays the average fuel con-
sumption since engine start.

Driving range

Displays the driving range with remaining fuel.

2, 3

Gadget

The following items can be displayed by changing the settings for gad-
get content and fuel economy type on

. (



P. 112)

Eco-friendly driving information (

)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

111

2. Instrument cluster

Instru

me
nt clu

ster

CAMRY_U

Average fuel economy

Displayed item (listed below) can be changed on the fuel economy type
screen of

. (



P. 112)

●

Total (after reset)

Displays the average fuel consumption since the display was reset.

1, 5

●

Tank (after refuel)

Displays the average fuel consumption since the vehicle was refu-
eled.

1, 2

: Use the displayed fuel consumption as a reference only.

: When only a small amount of fuel is added to the tank, the display may

not be updated.
When refueling, turn the engine switch off. If the vehicle is refueled with-
out turning the engine switch off, the display may not be updated.

: This distance is computed based on your average fuel consumption. As

a result, the actual distance that can be driven may differ from that dis-
played.

: The default setting is no display.

: This display can be reset by pressing and holding

while it is dis-

played.

Displayable item

Content

Gadget
content

Fuel economy

type

Average
vehicle
speed

Trip
(after start)

Displays the average vehicle speed since
engine start.

Total
(after reset)

Displays the average vehicle speed since the
display was reset.

Distance

Trip
(after start)

Displays the distance driven since vehicle
start.

Total
(after reset)

Displays the distance driven since the display
was reset.

Elapsed
time

Trip
(after start)

Displays the elapsed time since engine start.

Total
(after reset)

Displays the elapsed time since the display
was reset.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

112

2. Instrument cluster

CAMRY_U

■

Eco indicator

• Eco Driving Indicator



P. 119

• Driving range

Displays the driving range with remaining fuel.

When only a small amount of fuel is added to the tank, the display may
not be updated.
When refueling, turn the engine switch off. If the vehicle is refueled with-
out turning the engine switch off, the display may not be updated.
This distance is computed based on your average fuel consumption. As
a result, the actual distance that can be driven may differ from that dis-
played.

◆

Changing settings

Use the meter control switches on the steering wheel to change
settings.

Press

to select

Operate the switches to select a desired item.

Press or press and hold

The available settings will differ depending on if

is pressed or

pressed and held. Follow the instructions on the display.

◆

Setting items

■

LDA (Lane Departure Alert with steering control) (if

equipped) (



P. 259)

Press and hold

to change the settings of the following items:

Settings display (

)

Item

Settings

Details

Steering assist

Select to enable/disable steering
wheel assistance.

Off

Alert sensitivity

High

Select to set the warning sensi-
tivity.

Normal

Sway warning

Select to enable/disable the vehi-
cle sway warning.

Off

-------------------------------------------------------------------------------------------------------------------------------------------------------------

113

2. Instrument cluster

Instru

me
nt clu

ster

CAMRY_U

■

PCS (Pre-Collision System) (if equipped) (



P. 249)

Press and hold

to change the settings of the following items:

■

BSM (Blind Spot Monitor) (if equipped) (



P. 310)

Press

to enable/disable the Blind Spot Monitor function.

Press and hold

to change the settings of the following item:

Sway sensitivity

High

Select to set the vehicle sway
warning sensitivity.

Medium

Low

Item

Settings

Details

Item

Settings

Details

PCS

Select to enable/disable the pre-
collision system.

Off

Warning sensitivity

Select to change the warning
timing.

Item

Settings

Details

BSM

Select to enable/disable the
Blind Spot Monitor function.

Off

Item

Settings

Details

Outside rear view
mirror

indicator

brightness

Bright

Select to change the brightness
of the outside rear view mirror
indicators.

Dim

-------------------------------------------------------------------------------------------------------------------------------------------------------------

114

2. Instrument cluster

CAMRY_U

■

RCTA (Rear Cross Traffic Alert) (if equipped) (



P. 310)

Press

to enable/disable the Rear Cross Traffic Alert function.

Press and hold

to change the settings of the following item:

■

ICS (Intelligent Clearance Sonar) (if equipped) (



P. 332)

Press

to enable/disable the Intelligent Clearance Sonar.

■

Intuitive parking assist (if equipped) (



P. 324)

Press

to enable/disable the Intuitive parking assist.

Press and hold

to change the settings of the following item:

Item

Settings

Details

RCTA

Select to enable/disable the Rear
Cross Traffic Alert function.

Off

Item

Settings

Details

RCTA buzzer vol-
ume

1 (Low)

Select to change the volume of
the RCTA buzzer.

2 (Medium)

3 (Loud)

Item

Settings

Details

ICS

Select to enable/disable the
Intelligent Clearance Sonar sys-
tem.

Off

Item

Settings

Details

Intuitive

parking

assist

Select to enable/disable the intui-
tive parking assist.

Off

Item

Settings

Details

Volume

1 (Low)

Select to change the volume of
the intuitive parking assist
buzzer.

2 (Medium)

3 (Loud)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

115

2. Instrument cluster

Instru

me
nt clu

ster

CAMRY_U

■

HUD (Head-up display) (if equipped) (



P. 121)

Press

to enable/disable the head-up display.

Press and hold

to change the settings of the following items:

Item

Settings

Details

HUD

Select to enable/disable the
head-up display.

Off

Item

Settings

Details

HUD Brightness/Position

Select to adjust the brightness/
position of the head-up display.
• Press the

switch to

adjust the display brightness.

• Press the

switch to

adjust the display position.

HUD Driving sup-
port

Tachometer set-
tings

Select to change the display
between the following:
• Eco Driving Indicator
• Tachometer
• No content

Navigation

sys-

tem (if equipped)

Select to enable/disable head-up
display content.

Driving Assist

Compass
(if equipped)

Audio system

Rotation

Select to adjust the angle of the
head-up display.
Press the

switch to

adjust the display angle.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

116

2. Instrument cluster

CAMRY_U

■

Vehicle settings

Press and hold

to change the settings of the following items:

Item

Settings

Details

TPWS (Tire pressure warning system) (



P. 447)

Set pressure (tire pressure warning sys-
tem initialization)

Select to initialize the tire pres-
sure warning system. To per-
form initialization, press and hold
the

switch.

Before performing initialization,
make sure to adjust the inflation
pressure of each tire to the spec-
ified level. (



P. 448)

Change wheel (register tire pressure
warning system sensor ID codes)

Select to register the ID codes of
the tire pressure sensors to the
tire pressure warning system. To
register the ID codes, press and
hold the

switch.

(



P. 450)

Scheduled maintenance display (if equipped)

Maintenance data reset

Select to reset the message indi-
cating maintenance is required,
after the required maintenance is
performed. (



P. 423)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

117

2. Instrument cluster

Instru

me
nt clu

ster

CAMRY_U

■

Meter settings

Press and hold

to change the settings of the following items:

: Selecting this item will only change the gadget.

: Selecting this item will turn the display of the gadget off.

Item

Settings

Details

Language

Select to change the language
displayed.

Units

Select to change the units of
measure displayed.

(Eco Driving

Indicator Light)

Select to enable/disable the Eco
Driving Indicator Light. (



P. 119)

Off

Speedometer

Select to enable/disable the
speedometer display.

Off

Gadget content

Off

No display

Average vehicle
speed

Select to turn the display of a
gadget.

Distance

Elapsed time

Fuel economy type

Trip (after start)

Select to change the average
fuel consumption display and an
item to be displayed as gadget.

Total (after reset)

Tank
(after refuel)

Multi-information display off

Select to turn the multi-informa-
tion display off.
To turn the multi-information dis-
play on again, press any direc-
tion switch (

Pop-up display

Intersection guid-
ance (if equipped)

Select to enable/disable the pop-
up display.

Incoming calls

Brightness adjust-
ment

Default setting

Select to reset the meter display
settings to the default setting.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

118

2. Instrument cluster

CAMRY_U

■

Odometer

Displays the total distance the vehicle has been driven.

■

Trip meter A/trip meter B

Displays the distance the vehicle has been driven since the meter
was last reset. Trip meters A and B can be used to record and dis-
play different distances independently.

To reset, display the desired trip meter and press and hold the “ODO/
TRIP” switch.

Displays suggestions to the driver in the following situations. To select
a response to a displayed suggestion, use the meter control switches.

The suggestion function can be turned on/off.
(Customizable features:



P. 575)

■

Suggestion to turn off the headlights

If a front door is opened after the engine switch is turned off, this sug-
gestion message will not be displayed.

Odometer/trip meter

Suggestion function

-------------------------------------------------------------------------------------------------------------------------------------------------------------

119

2. Instrument cluster

Instru

me
nt clu

ster

CAMRY_U

■

Eco Driving Indicator

Eco Driving Indicator will not operate under the following conditions:

●

The shift lever is in any position other than D.

●

A paddle shift switch (if equipped) is operated.

●

Neither normal mode nor Eco drive mode is selected. (



P. 353)

●

The vehicle speed is approximately 80 mph (130 km/h) or higher.

■

Suspension of the settings display

●

Some settings cannot be changed while driving. When changing settings,
park the vehicle in a safe place.

●

If a warning message is displayed, operation of the settings display will be
suspended.

■

Tire pressure

●

It may take a few minutes to display the tire inflation pressure after the
engine switch is turned to IGNITION ON mode. It may also take a few min-
utes to display the tire inflation pressure after inflation pressure has been
adjusted.

●

“---” may be displayed if the tire position information cannot be determined
due to unfavorable radio wave conditions.

●

Tire inflation pressure changes with temperature. The displayed values may
also be different from the values measured using a tire pressure gauge.

■

Liquid crystal display

Small spots or light spots may appear on the display. This phenomenon is
characteristic of liquid crystal displays, and there is no problem continuing to
use the display.

■

Customization

Some functions can be customized. (



P. 112, 575)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

120

2. Instrument cluster

CAMRY_U

WARNING

■

Caution for use while driving

●

When operating the multi-information display while driving, pay extra
attention to the safety of the area around the vehicle.

●

Do not look continuously at the multi-information display while driving as
you may fail to see pedestrians, objects on the road, etc. ahead of the
vehicle.

■

The information display at low temperatures

■

Cautions during setting up the display

NOTICE

■

While setting up the display

To prevent battery discharge, ensure that the engine is running while setting
up the display features.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

121

2. Instrument cluster

Instru

me
nt clu

ster

CAMRY_U

The head-up display is linked to the meters and navigation system (if
equipped) and projects a variety of information in front of the driver,
such as the current vehicle speed.

Driving assist system status/navigation system-linked display area
(if equipped) (



P. 123)

The following pop-up displays will be displayed in certain situations:

• Pre-collision warning (pre-collision system)
• Alert from the Intelligent Clearance Sonar system (if equipped)

Shift position/speed limit display area

• Shift position (



P. 213)

• Speed limit (vehicles with a navigation system) (U.S.A. only)

Vehicle speed display
Eco Driving Indicator/Tachometer (



P. 124)

Information display area (



P. 124)

The following pop-up displays will be displayed in certain situations:

• Warning/message
• Hands-free system status
• Audio system operation status

Head-up display



: If equipped

Summary of functions

-------------------------------------------------------------------------------------------------------------------------------------------------------------

122

2. Instrument cluster

CAMRY_U

Select

on the multi-information display (



P. 112) and then

◆

Enabling/disabling the head-up display

Press

to enable/disable the head-up display.

◆

Changing the head-up display settings

Press and hold

to change the following settings:

■

Eco Driving Indicator/Tachometer

Select to display Eco Driving Indicator/tachometer/no content.

■

Display brightness/position

Select to adjust the brightness and position of the head-up display.

■

Display content

Select to enable/disable the following items:

• Route guidance to destination (if equipped)
• Driving assist system status
• Compass (if equipped)
• Audio system operation status

■

Display angle

Select to adjust the angle of the head-up display.

Using the head-up display

-------------------------------------------------------------------------------------------------------------------------------------------------------------

123

2. Instrument cluster

Instru

me
nt clu

ster

CAMRY_U

◆

Driving assist system status display

Displays the operational status of the following systems:

• Dynamic radar cruise control with full-speed range (



P. 269)

• LDA (Lane Departure Alert with steering control) (



P. 259)

• Intuitive parking assist (if equipped) (



P. 324)

◆

Navigation system-linked display area (if equipped)

Displays the following items, which are linked to the navigation sys-
tem:

■

Street name

When the navigation system is performing route guidance, the
name of the next street will be displayed on the top of the display
area.

■

Route guidance to destination

Displayed when the navigation system is performing route guid-
ance. When approaching an intersection, an arrow will be displayed
to indicate the suggested direction of travel.

■

Compass

Displays the direction of travel.

Driving assist system status/navigation system-linked display
area (if equipped)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

124

2. Instrument cluster

CAMRY_U

■

Eco Driving Indicator

Eco Driving Indicator Zone
Display
Eco driving ratio based on
acceleration
Zone of Eco driving

Displayed content is the same
as that displayed on the multi-
information display (Eco Driving
Indicator). For details, refer to
P. 119.

■

Tachometer

Displays the engine speed in revolutions per minute.

Displays the following items in the appropriate situation:

■

Warning/Message

●

Alert from the LDA (Lane Departure Alert with steering control)

●

Dynamic radar cruise control with full-speed range

●

message

Displayed when a suggestion/advice pop-up display is displayed on the
multi-information display. (



P. 118)

●

message

Displayed when a warning message is displayed on the multi-informa-
tion display. (



P. 510)

●

Outside temperature

Displayed in the following situations:

• When the engine switch is turned to IGNITION ON mode
• When the low outside temperature indicator is flashing

Displayed content is the same as that displayed on the multi-information
display. For details, refer to the explanation of the outside temperature
display on the multi-information display. (



P. 92)

■

Hands-free system status

Displayed when the hands-free system is operated.

■

Audio system operation status

Displayed when the audio system is operated.

Eco Driving Indicator/Tachometer

Information display area

-------------------------------------------------------------------------------------------------------------------------------------------------------------

125

2. Instrument cluster

Instru

me
nt clu

ster

CAMRY_U

■

Head-up display

The head-up display may seem dark or hard to see when viewed through
sunglasses, especially polarized sunglasses.
Adjust the brightness of the head-up display or remove your sunglasses.

■

Display brightness

The brightness of the head-up display can be adjusted on

of the multi-

information display. Also, it is automatically adjusted according to the ambient
brightness.

■

Enabling/disabling of the head-up display

If the head-up display is disabled, it will remain disabled when the engine
switch is turned off then back to IGNITION ON mode.

■

Street name display (vehicles with a navigation system)

Only street names which are included in the map data will be displayed.

WARNING

■

Before using the head-up display

●

Check that the position and brightness of the head-up display image does
not interfere with safe driving. Incorrect adjustment of the image’s position
or brightness may obstruct the driver’s view and lead to an accident,
resulting in death or serious injury.

●

Do not continuously look at the head-up display while driving as you may
fail to see pedestrians, objects on the road, etc. ahead of the vehicle.

■

Caution for changing settings of the head-up display

As the engine needs to be running while changing the settings of the head-
up display, ensure that the vehicle is parked in a place with adequate venti-
lation. In a closed area such as a garage, exhaust gases including harmful
carbon monoxide (CO) may collect and enter the vehicle. This may lead to
death or a serious health hazard.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

126

2. Instrument cluster

CAMRY_U

NOTICE

■

To prevent damage to components

■

When changing the settings of the head-up display

To prevent battery discharge, ensure that the engine is running while the
changing the settings of the head-up display.

●

Do not place any drinks near the head-
up display projector. If the projector gets
wet, electrical malfunctions may result.

●

Do not place anything on or put stickers
onto the head-up display projector.
Doing so could interrupt head-up dis-
play indications.

●

Do not touch the inside of the head-up
display projector or thrust sharp edges
or the like into the projector.
Doing so could cause mechanical mal-
functions.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

127

2. Instrument cluster

Instru

me
nt clu

ster

CAMRY_U



Audio (vehicles without Data Communication Module) or Audio
Plus (vehicles without Data Communication Module)

Press the “MENU” button.
Select “Info” on the “Menu”
screen.

If the “History” screen is displayed,
select “Trip Information”.

Fuel consumption information

Fuel consumption information can be displayed on the audio
system screen.

Trip information

-------------------------------------------------------------------------------------------------------------------------------------------------------------

128

2. Instrument cluster

CAMRY_U



Audio (vehicles with Data Communication Module), Audio Plus
(vehicles with Data Communication Module) and Premium Audio

Press the “MENU” button.
Select “Info” on the “Menu”
screen.
Select “ECO” on the “Informa-
tion” screen.

If the “History” screen is displayed,
select “Trip Information”.

Resetting the consumption data
Average vehicle speed since
the engine was started
Elapsed time since the engine
was started
Fuel consumption in the past 15
minutes
Cruising range (



P. 130)

Current fuel consumption

Vehicles without a smart key system:
Average fuel consumption for the past 15 minutes is divided by color
into past averages and averages attained since the engine switch was
last turned to the “ON” position. Use the displayed average fuel con-
sumption as a reference.
Vehicles with a smart key system:
Average fuel consumption for the past 15 minutes is divided by color
into past averages and averages attained since the engine switch was
last turned to IGNITION ON mode. Use the displayed average fuel
consumption as a reference.

This image is an example only.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

129

2. Instrument cluster

Instru

me
nt clu

ster

CAMRY_U



Audio (vehicles without Data Communication Module) or Audio
Plus (vehicles without Data Communication Module)
Press the “MENU” button.
Select “Info” on the “Menu” screen.

If the “Trip Information” screen is displayed, select “History”.



Audio (vehicles with Data Communication Module), Audio Plus
(vehicles with Data Communication Module) and Premium Audio
Press the “MENU” button.
Select “Info” on the “Menu” screen.
Select “ECO” on the “Information” screen.

If the “Trip Information” screen is displayed, select “History”.

Resetting the past record data
Best recorded fuel consumption
Current fuel economy
Previous

fuel

consumption

record



Audio and Audio Plus

Displays the daily average fuel
consumption. (Instead of the date,
“Trip 1” through “Trip 5” will be dis-
played.)



Premium Audio

Displays the daily average fuel consumption.

Updating the average fuel consumption data

The average fuel consumption history is divided by color into past
averages and the average fuel consumption since the last updated.
Use the displayed average fuel consumption as a reference.

This image is an example only.

History

-------------------------------------------------------------------------------------------------------------------------------------------------------------

132

CAMRY_U

3-1. Key information

The following keys are provided with the vehicle.



Vehicles without a smart key system

Keys

Operating the wireless remote con-
trol function (



P. 133)

Key number plate



Vehicles with a smart key system

Electronic keys

• Operating the smart key system

(



P. 154)

• Operating the wireless remote

control function (



P. 133)

Mechanical keys
Key number plate

Keys

The keys

-------------------------------------------------------------------------------------------------------------------------------------------------------------

133

3-1. Key information

Op
eration

f each

compo

nen
t

CAMRY_U



Vehicles without a smart key system

Locks all the doors (



P. 142)

Unlocks all the doors (



P. 142)

Pressing the button unlocks the
driver’s door. Pressing the button
again within 3 seconds unlocks the
other doors.

Opens the windows

and the

moon roof

1, 2

(



P. 142)

Opens the trunk (



P. 150)

Sounds the alarm (



P. 135)

: If equipped

: This setting must be customized at your Toyota dealer.



Vehicles with a smart key system

Locks all the doors (



P. 142)

Unlocks all the doors (



P. 142)

Pressing the button unlocks the
driver’s door. Pressing the button
again within 3 seconds unlocks the
other doors.

Opens the windows

and the

moon roof

1, 2

or panoramic

moon roof

1, 2

(



P. 142)

Opens the trunk (



P. 150)

Sounds the alarm (



P. 135)

: If equipped

: This setting must be customized at your Toyota dealer.

Wireless remote control

-------------------------------------------------------------------------------------------------------------------------------------------------------------

134

3-1. Key information

CAMRY_U

Releasing

To release the key, press the but-
ton.

Folding

To stow the key, press the button
then fold the key.

To take out the mechanical key,
slide the release lever and take
the key out.

The  mechanical  key  can  only  be
inserted  in  one  direction,  as  the
key only has grooves on one side.
If  the  key  cannot  be  inserted  in  a
lock  cylinder,  turn  it  over  and  re-
attempt to insert it.
After  using  the  mechanical  key,  store  it  in  the  electronic  key.  Carry  the
mechanical key together with the electronic key. If the electronic key bat-
tery  is  depleted  or  the  entry  function  does  not  operate  properly,  you  will
need the mechanical key. (



P. 530)

Using the key (vehicles without a smart key system)

Using the mechanical key (vehicles with a smart key system)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

135

3-1. Key information

Op
eration

f each

compo

nen
t

CAMRY_U

■

Panic mode



Vehicles without a smart key system



Vehicles with a smart key system

■

When required to leave the vehicle’s key with a parking attendant (vehi-
cles with a smart key system)

Lock the glove box as circumstances demand. (



P. 387)

Remove the mechanical key for your own use and provide the attendant with
the electronic key only.

When

is pressed for longer than

about  one  second,  an  alarm  will  sound
intermittently  and  the  vehicle  lights  will
flash  to  deter  any  person  from  trying  to
break into or damage your vehicle.
To stop the alarm, press any button on the
wireless remote control.

When

is pressed for longer than

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Toyota Camry (2020 year). Manual in english - part 2
