Toyota Tundra (2019 year). Instruction - part 28

433

6-3. Using the storage features

6

Interio

r features



Front bench type seat

Auxiliary boxes

(

P. 445)

• Card holder

(

P. 436)

• Map holder

(

P. 438)

• Tissue pocket

(

P. 440)

Bottle holders

 (

P. 444)

Card holder

(

P. 436)

Overhead console (

P. 441)

Glove box

(

P. 434)

Front cup holders (

P. 442)

Pen holder

(

P. 439)

Rear cup holders (if equipped)

 (

P. 443)

Storage box (if equipped)

(

P. 447)

1

2

3

4

5

6

7

8

9

434

6-3. Using the storage features

Open (pull the lever up)
Lock
Unlock

WARNING

■

Items that should not be left in the storage spaces
Do not leave glasses, lighters or spray cans in the storage spaces, as this
may result in the following when cabin temperature becomes high:

●

Glasses  may  be  deformed  by  heat  or  cracked  if  they  come  into  contact
with other stored items.

●

Lighters or spray cans may explode. If they come into contact with other
stored items, the lighter may catch fire or the spray can may release gas,
causing a fire hazard.

■

When driving or when the storage compartments are not in use
Keep the lids closed.
In the event of sudden braking or sudden swerving, an accident may occur
due to an occupant being struck by an open lid or the items stored inside.

Glove box

1

2

3

435

6-3. Using the storage features

6

Interio

r features

Pull the knob up and lift the lid

■

Passing a cable from the console box

Console box (front separated type seat)

436

6-3. Using the storage features

■

Overhead console

■

Console box (front separated type seats)
Pull the knob up and lift the lid

Card holder

437

6-3. Using the storage features

6

Interio

r features

■

Back of the front center seatback (front bench type seat)
Pull the lever up and fold down
the seatback

Push the knob and lift the lid

1

2

438

6-3. Using the storage features

Pull the lever up and fold down
the seatback

Push the knob and lift the lid

Map holder (front bench type seat)

1

2

439

6-3. Using the storage features

6

Interio

r features



Front separated type seats

Pull the knob up and lift the lid



Front bench type seat

Pull the lever up and fold down
the seatback

Pen holder

440

6-3. Using the storage features



Front separated type seats

Pull the knob up and lift the lid



Front bench type seat

Pull the lever up and fold down
the seatback

Tissue pocket

1

441

6-3. Using the storage features

6

Interio

r features

Push the knob and lift the lid

The overhead console is useful for temporarily storing sunglasses and
similar small items.
Push the knob forward to open the
console

2

Overhead console

442

6-3. Using the storage features

■

Front



Separated type seats



Bench type seat

Pull the lever up and fold down
the seatback

Cup holders

443

6-3. Using the storage features

6

Interio

r features

■

Rear



Double Cab models with front separated type seats

Pull the lid down



Double Cab models with front bench type seat

Pull the lid down



CrewMax models

Pull the armrest down

WARNING

■

Items unsuitable for the cup holder
Do not place anything other than cups or beverage cans in the cup holders.
Other items may be thrown out of the holders in the event of an accident or
sudden  braking  and  cause  injury.  If  possible,  cover  hot  drinks  to  prevent
burns.

444

6-3. Using the storage features



Front door



Rear door (CrewMax models)

Bottle holders

WARNING

■

Items unsuitable for the bottle holders
Do not place anything other than a bottle in the bottle holders.
Other items may be thrown out of the holders in the event of an accident or
sudden braking and cause injury.

NOTICE

■

Items that should not be stowed in the bottle holders
Put the cap on before stowing a bottle. Do not place open bottles in the bot-
tle holders, or glasses and paper cups containing liquid. The contents may
spill and glasses may break.

445

6-3. Using the storage features

6

Interio

r features



Type A

Pull the strap



Type B

Pull the lever up and fold down
the seatback

Push the knob and lift the lid

Auxiliary boxes (front bench type seat)

1

2

446

6-3. Using the storage features



Type C

Pull the lever up and fold down
the seatback

Push the knob and lift the lid

1

2

447

6-3. Using the storage features

6

Interio

r features

■

Using the storage box
Pull  the  lever  up  and  raise  the
rear seat cushion

Open the lid

Turn the knob in the “OPEN”
direction
Lift the lid

Storage box (if equipped)

1

2

1

2

448

6-3. Using the storage features

■

Remove the storage box
Pull  the  lever  up  and  raise  the
rear seat cushion

Open the lid

Turn the knob in the “OPEN”
direction
Lift the lid

Remove the storage box

Remove the lids
Turn the knobs counterclock-
wise
Remove the storage box

1

2

1

2

3

1

2

3

WARNING

■

To prevent damage to the storage box
Do not put heavy loads on the lids.
