FEATURES & OPERATIONS
Windshield wipers & washers
FRONT
With intermittent wiper
With AUTO rain-sensing wiper
Single wipe
Adjust
Single wipe
Adjust sensor
frequency1
sensitivity2
Auto wipe
Interval wipe
Slow
Slow
Pull to wash
Pull to wash
and wipe
and wipe
Fast
Fast
1 Intermittent windshield wiper frequency adjustment Rotate to increase/
decrease wipe frequency.
2 Rain-sensing windshield wiper Rotate to increase/decrease sensor sensitivity.
REAR
Normal
Turn end to
Intermittent
activate
Push to wash
and wipe
Windows-Power
Driver side
Window lock switch
Up
Down
All window auto up/down Push the switch completely down or pull it completely
up and release to fully open or close. To stop window midway, lightly push the
switch in the opposite direction.
Window lock switch Deactivates all passenger windows. Driver’s window remains
operable.
18
Rear view mirror-Outside
Automatic mode
Use switch to adjust mirror angle while in ACCESSORY or IGNITION ON mode.
Linked mirror function when reversing The outside rearview mirrors
automatically angle downwards when vehicle is in reverse. Will only operate when
switch is in “L” or “R” position.
Moonroof
SLIDING OPERATION
TILTING OPERATION
Push once to open partway;
Push once to open completely.
again to open completely.
Open
Tilt
Close
Close
Recommended open position to minimize
wind noise.
Lightly press either side of the moonroof switch while opening/tilting is in progress,
the moonroof stops partway.
19
FEATURES & OPERATIONS
Audio
NOTE: For more information, refer to the “Navigation System Owner’s Manual”
and “2019 Entune™ Audio Quick Reference Guide.”
Entune™ Premium JBL® Audio with Integrated Navigation and App Suite
Display
screen
Display home
Display
audio
screen
setup screen
Display map
Display hands-free
screen
screen
Display information
Audio/visual
screen
screen
Disc slot
Seek station/ track/
presets or rewind/FF
Eject disc
Mute/Pause
Turn to search selected
Push to turn
media (radio, CD, DVD,
ON/OFF,
etc.)
turn to adjust
the volume
NOTE: Concentrating on the road should always be your first priority while
driving. Do not use the Entune™ system if it will distract you.
20
USB media/AUX port
USB media port
By connecting a USB-compatible portable audio device or
USB memory stick into
the USB media port, you can listen to music through the vehicle’s speaker system.
AUX port
By inserting an AUX cable into the AUX port, you can listen to music from a
portable audio device through the vehicle’s speaker system while in AUX mode.
21
FEATURES & OPERATIONS
Automatic air conditioning/heating
FRONT AIR CONDITIONING
Control screen
Windshield defogger and airflow to feet
Fan speed
Airflow control display (see diagram below)
Airflow control display
(see diagram below)
Rear AC control
button (touch to
display
rear AC
control
screen)
Option controls
Temperature display
(driver
side
left,
passenger side right)
Control panel
Climate control OFF
Air intake
control (switch between
outside
air “
” and recirculated
air
Automatic
climate control ON
“
”
mode)
Adjusting
the temperature
setting
will
cause
the airflow vents, air intake
and
CLIMATE (push to display
fan to
adjust automatically.
AC control screen)
Temperature controls
Temperature controls
(driver side)
(passenger side)
Rear
Air Conditioning
Airflow controls
operation mode ON/OFF
(press to change airflow mode)
Outside rearview mirror/
Rear window defogger
Adjust airflow mode
Windshield
airflow/
defogger (outside air only)
upper
upper body
feet
body
& feet
feet & windshield
defogger
Refer to the Owner’s Manual for more details.
22
REAR AIR CONDITIONING
Temperature selector (left side)
Temperature selector (right side)
Automatic climate control ON
Climate control OFF
Fan speed
Airflow vent
Seat heaters/ventilators
FRONT SEATS
Automatically adjusts to
cabin temperature
Blows air from the seat
Turns the seat heater on
Press
or
to cycle through.
Auto
Hi
Mid
Lo
Note: Auto setting changes according to
Off
climate control temperature.
SECOND SEATS
Left
Right
second seat
second seat
The engine switch must be in the “IGNITION ON” mode.
23
FEATURES & OPERATIONS
Multi-Information Display (MID)
Select: To select an
Enter/Set: Press to enter/
item/change pages
set, press and hold to reset
enu/Display: Switch
Return: To previous
the top screen
screen
Push “Multi-Information switches” to view or change information in the following:
Drive information
Vehicle information display (if equipped)
Navigation system-linked display
Audio system linked display
Driving assist system information (if equipped)
Warning messages
Settings display
Steering wheel-Heater
The engine switch must be in the “IGNITION
ON” mode.
24
Steering wheel switches
& telephone controls (Bluetooth®)
Display
Microphone
Microphone
Steering wheel telephone switches
“
”
Use to search within the selected
audio medium (radio, etc.).
“
” and “+/-”
Use to raise or lower
volume.
Voice command switch
“MODE”
Push to turn audio ON and to
select an audio mode.
End call
Push and hold to mute or
pause the audio.
Start call/
Mobile Assistant access*
Bluetooth® technology allows dialing or receipt of calls without taking hands from
the steering wheel or using a cable to connect the telephone and the system.
* Push and hold to access Mobile Assistant. When a compatible smartphone is
Bluetooth® connected push and hold the off hook switch 2-3 seconds to access
Siri® Eyes Free.
Refer to the Navigation System Owner’s Manual for more details.
Refer to “Bluetooth® Device Pairing Section” in this guide and the “Navigation
System Owner’s Manual” for more information about phone connections and
compatibility.
NOTE: Concentrating on the road should always be your first priority while
driving. Do not use the hands-free phone system if it will distract you.
25
FEATURES & OPERATIONS
Crawl Control (with Turn Assist function)
CRAWL CONTROL SWITCH
Med
Med-Hi
Lo-Med
Lo
Hi
(1)
(2)
Speed selection switch
Speed modes
Crawl Control allows travel on extremely rough off-road surfaces at a fixed low
speed without pressing the accelerator or brake pedal. Operating status displays
on the MID.
Lo to Lo-Med - Rock, mogul (downhill) and gravel (downhill)
Lo-Med to Med - Mogul (uphill)
Med-Hi - Snow, mud, gravel (uphill), sand, dirt, mogul (uphill) and grass
TURN ASSIST FUNCTION
This function assists cornering performance in accordance with steering operation
when driving through a tight corner. It maintains vehicle speed while driving and
reduces the number of turns needed to navigate a corner that requires turning the
wheel in the opposite direction.
Refer to the Owner‘s Manual for limitations and more details on this system.
26
Multi-terrain Select
MOGUL
LOOSE ROCK
ROCK & DIRT
MUD & SAND
ROCK
Multi-terrain Select mode
Multi-terrain Select mode
select switch
Multi-terrain Select is a system that helps drivability in off-road situations.
When the Crawl Control is turned off, a mode which matches the road conditions
can be selected from among the following 5 modes.
MUD & SAND - Muddy roads, sandy roads, snow-covered roads, dirt trails and
other slippery or dirty conditions
LOOSE ROCK - Slippery conditions consisting of mixtures of earth and loose rock
MOGUL - Wide range of off-road conditions, particularly very bumpy conditions
ROCK & DIRT - Very bumpy road conditions, such as mogul or rocky roads.
ROCK - Rocky terrain
Refer to the Owner‘s Manual for limitations and more details on this system before
attempting to use it.
Multi-terrain Monitor
Press “
” switch while the engine switch is in IGNITION ON mode to check
vehicle surroundings.
Note: The amount of time that the screen is displayed changes according to
the vehicle speed at the time the VIEW switch was pressed. Speeds exceeding
approximately 7 mph (12 km/h) will cancel monitor viewing.
Refer to the Owner‘s Manual for limitations and more details on this system before
attempting to use it.
27
FEATURES & OPERATIONS
Intelligent parking assist (if equipped)
Multi-Information Display (MID)
Navigation system screen
Corner sensors
Corner sensors
Intuitive parking assist display
(front)
(front)
Intuitive parking
assist
Rear Cross
Traffic Alert
Corner sensors
Corner sensors
(if equipped)
(rear)
(rear)
Rear
center sensor
The parking assist sonar system operates when the vehicle approaches an
obstacle. The distance from your vehicle to nearby obstacles when parallel parking
or maneuvering into a garage is measured by sensors and communicated via the
Multi-Information Display (MID), the navigation system screen and audible beeps.
When the sensor detects an obstacle, the direction of and the approximate
distance to the obstacle are displayed on the MID display or the navigation system
screen by illuminating continuously (far) or blinking (near), and beeping sounds will
switch from intermittent to continuous as you approach and get closer to a detected
obstacle. When the sensors detect two or more obstacles, the audible alerts will
respond to the nearest zone.
Always check the surrounding area when using this system.
Refer to section Intuitive parking assist in the Owner’s Manual for more details.
28
Blind Spot Monitor with Rear Cross
Traffic Alert (BSM w/RCTA) (if equipped)
Outside rear view mirror indicators
Rear Cross Traffic Alert buzzer
Indicators
RCTA function
display
Indicators
The Blind Spot Monitor is a system that has two functions:
• The Blind Spot Monitor function (assists the driver in making the decision when
changing lanes)
• The Rear Cross Traffic Alert function (assists the driver when backing up)
The system is designed to use radar sensors to detect vehicles traveling in the
Land Cruiser’s blind spot and advises the driver of the vehicles’ presence via the
outside rear view mirror indicators.
Refer to the Owner‘s Manual for limitations and more details on this system before
attempting to use it.
Vehicle Stability
Control (VSC)/
TRAC OFF switch
The VSC OFF switch can be used to help free a stuck vehicle in surroundings like
mud, dirt or snow. While the vehicle is stopped, press switch to disable the TRAC
system.
To disable both VSC and TRAC systems, press and hold the switch for at least 3
seconds.
Refer to the Owner’s Manual for more limitations and details.
29
FEATURES & OPERATIONS
Garage door opener (HomeLink®)*
HomeLink® indicator light
HomeLink®
icon
Garage door
operation
indicators
Buttons
Garage door openers manufactured under license from HomeLink®* can be
programmed to operate garage doors, estate gates, security lighting, etc.
Refer to “Garage door opener,” Section 5-4 in the Owner’s Manual for more
details.
For programming assistance, contact HomeLink® at 1-800-355-3515, or visit
* HomeLink® is a registered trademark of Gentex Corporation.
Rear seat entertainment system (if equipped)
Displays
Remote control
Front audio system (DVD player)
A/V input port
(VTR and HDMI port)
Headphone volume control
and headphone jacks
For details, refer to the “Navigation System Owner’s Manual.”
30
Power outlets-12V DC
Front
Rear
The “ENGINE START STOP” switch must be in “ACCESSORY” or “IGNITION ON”
mode to be used.
Power outlet-120V AC
The “ENGINE START STOP” switch must be in “IGNITION ON” mode to be used.
31
FEATURES & OPERATIONS
Qi Wireless charger
(1)
(2)
Push to open door.
Push power supply charging button.
(3)
Place charging side of device on the
charge area.
A mobile device can be charged wirelessly on the tray. (1) Press the lid to open.
(2) Press the wireless charger power switch and the green operation indicator
light turns on. (3) Place a mobile device on the tray as shown in the illustration.
An amber indicator illuminates while charging is in progress. When charging is
complete, the indicator illuminates green. Some phones, cases or cover type
wireless chargers may not cause the green indicator to illuminate even though it is
fully charged.
Refer to the Owner‘s Manual for more details on this system before attempting to
use it.
32
Parking brake
Set
Release
(2) Push
Pull
(1) Pull slightly
(3) Lower
Cup holders
Front seats
Rear seats
Third seats
Removing the cup holder insert
(front cup holders)
Cool box
Indicator
Push “PWR” button to turn cool box ON; indicator will illuminate.
33
TOYOTA SAFETY SENSE
Quick overview-Toyota Safety Sense™ P (TSS-P)
Toyota Safety Sense (TSS) P is a set of active safety technologies designed to
help prevent or mitigate collisions across a wide range of traffic situations. TSS-P
is designed to help support the driver’s awareness, decision making and vehicle
operation contributing to a safe and comfortable driving experience.
Refer to the Owner’s Manual for operation, setting adjustments, limitations and
more details to understand these functions and complete safety precautions. For
more information, please go to http://www.toyota.com/safety-sense
Pre-Collision System with Pedestrian Detection (PCS w/PD)
PCS w/PD is designed to provide alert, mitigation, and/or avoidance
support in certain conditions, when the system detects a potential
collision with a preceding vehicle is likely to occur.
Advanced millimeter-wave radar sensor system is designed to work
with the camera sensor to help recognize a preceding pedestrian,
and provide an alert, mitigation and/or avoidance support in certain
conditions.
Lane Departure Alert (LDA)
LDA is designed to provide notification when the system detects an
unintended lane departure.
Dynamic Radar Cruise Control (DRCC)
DRCC is designed to help maintain a pre-set distance to a preceding
vehicle when the preceding vehicle is traveling at a lower speed.
Automatic High Beams (AHB)
AHB is designed to detect the headlights of oncoming vehicles and the
tail lights of preceding vehicles and switch between high beams and
low beams as appropriate.
Sensors
TSS-P Combines an in-vehicle camera mounted in front of the inside rear view
mirror and a millimeter-wave radar mounted in the front grill. These sensors support
the driver assist systems.
Radar sensor
Camera sensor
34
