Toyota Highlander Hybrid (2018 year). Instruction - part 29

476

6-4. Using the other interior features

Operating HomeLink®

Press the appropriate HomeLink® button. The HomeLink® indicator

light should turn on.

Garage door operation indicators

The status of the opening and

closing of a garage door is shown

by the indicators.

1

Opening

2

Closing

This function is only available if the

garage door opener motor used is

a compatible device.

(To check

device compatibility, refer to the

owner’s manual supplied with the

garage door opener motor.)

Color

Status

Orange (flashing)

Currently opening/closing

Green

Opening/closing has completed

Red (flashing)

Feedback signals cannot be received

The indicators can operate within approximately 820 ft. (250 m) of the

garage door. However, if there are obstacles between the garage door

and the vehicle, such as houses and trees, feedback signals from the

garage door may not be received.

To recall the previous door operation status, press and release either

HomeLink® buttons “1” and “2” or “2” and “3” simultaneously for 2 sec-

onds. The last recorded status will be displayed for 5 seconds.

HIGHLANDER_HV_U (OM0E032U)

6-4. Using the other interior features

477

Erasing the entire HomeLink® memory (all three programs)

Press and hold the 2 outside but-

tons for

10 seconds until the

HomeLink®

indicator

light

changes from continuously lit

(orange) to rapidly flashing

(green).

If you sell your vehicle, be sure to

erase the programs stored in the

HomeLink® memory.

■ Programs stored in the HomeLink® memory

● The registered codes are not erased even if the 12-volt battery cable is dis-

connected.

● If learning failed when registering a different code to a HomeLink® button

that already has a code registered to it, the already registered code is not

erased.

■Before programming

● Install a new battery in the transmitter.

● The battery side of the transmitter must be pointed away from the Home-

Link.

■Certification for the garage door opener

6

This device complies with FCC rules part 15 and Industry Canada RSS-210.

Operation is subject to the following two conditions: (1) This device may not

cause harmful interference, and (2) This device must accept any interference

that may be received including interference that may cause undesired opera-

tion.

WARNING:

The transmitter has been tested and complies with FCC and IC rules.

Changes or modifications not expressly approved by the party responsible for

compliance could void the user’s authority to operate the device.

The term “IC:” before the certification/registration number only signifies that

Industry Canada technical specifications were met.

HIGHLANDER_HV_U (OM0E032U)

478

6-4. Using the other interior features

Cet appareil est conforme aux normes FCC partie 15 et Industry Canada

RSS-210.

Son fonctionnement est soumis aux deux conditions suivantes: (1) Cet appa-

reil ne doit pas causer d’interférences nuisibles et (2) Cet appareil doit accep-

ter toute interférence qui peuvent être reçues y compris les interférences

pouvant provoquer un fonctionnement indésirable.

AVERTISSEMENT:

L’émetteur a été testé et est conforme aux régles de la FCC et IC. Les chan-

gements ou modifications non expressément approuvés par la partie respon-

sable de la conformité pourrait annuler l’autorité de l’utilisateur de faire

fonctionner le dispositif.

Le terme “IC:” devant le numéro de certification / enregistrement signifie seu-

lement que les spécifications techniques d’Industry Canada ont été respec-

tées.

■ For additional programming assistance with your HomeLink® Universal

Transceiver

Visit on the web at www.homelink.com or call 1-800-355-3515.

Consultez le site www.homelink.com ou appelez le 1-800-355-3515.

WARNING

■When programming a garage door or other remote control device

The garage door may operate, so ensure people and objects are out of dan-

ger to prevent potential harm.

■ Conforming to federal safety standards

Do not use the HomeLink Compatible Transceiver with any garage door

opener or device that lacks safety stop and reverse features as required by

federal safety standards.

This includes any garage door that cannot detect an obstruction object. A

door or device without these features increases the risk of death or serious

injury.

■When operating or programming HomeLink®

Never allow a child to operate or play with the HomeLink® buttons.

HIGHLANDER_HV_U (OM0E032U)

6-4. Using the other interior features

479

Safety Connect∗

Safety Connect is a subscription-based telematics service that

uses Global Positioning System (GPS) data and embedded cel-

lular technology to provide safety and security features to sub-

scribers. Safety Connect is supported by Toyota’s designated

response center, which operates 24 hours per day, 7 days per

week.

Safety Connect service is available by subscription on select,

telematics hardware-equipped vehicles.

By using the Safety Connect service, you are agreeing to be

bound by the Telematics Subscription Service Agreement and

its Terms and Conditions, as in effect and amended from time to

time, a current

copy of which is available at Toyota.com. All use

of the Safety Connect service is subject to such then-applicable

Terms and Conditions.

■ System components

1

Microphone

6

2

LED light indicators

3

“SOS” button

∗: If equipped

HIGHLANDER_HV_U (OM0E032U)

6-4. Using the other interior features

481

■Safety Connect Services Information

● Phone calls using the vehicle’s Bluetooth® technology will not be possible

during Safety Connect.

● Safety Connect is available beginning Fall 2009 on select Toyota models.

Contact with the Safety Connect response center is dependent upon the

telematics device being in operative condition, cellular connection availabil-

ity, and GPS satellite signal reception, which can limit the ability to reach the

response center or receive emergency service support. Enrollment and

Telematics Subscription Service Agreement are required. A variety of sub-

scription terms are available; charges vary by subscription term selected.

● Automatic Collision Notification, Emergency Assistance, Stolen Vehicle

Location, and Enhanced Roadside Assistance will function in the United

States, including Hawaii and Alaska, and in Canada. No Safety Connect

services will function outside of the United States in countries other than

Canada.

● Safety Connect services are not subject to section 255 of the Telecommuni-

cations Act and the device is not TTY compatible.

■Languages

The Safety Connect response center will offer support in multiple languages.

The Safety Connect system will offer voice prompts in English and Spanish.

Please indicate your language of choice when enrolling.

■ When contacting the response center

You may be unable to contact the response center if the network is busy.

6

HIGHLANDER_HV_U (OM0E032U)

482

6-4. Using the other interior features

Safety Connect LED light Indicators

When the power switch is turned to ON mode, the red indicator light

comes on for 2 seconds then turns off. Afterward, the green indicator

light comes on, indicating that the service is active.

The following indicator light patterns indicate specific system usage

conditions:

● Green indicator light on = Active service

● Green indicator light flashing = Safety Connect call in process

● Red indicator light (except at vehicle start-up) = System malfunction

(contact your Toyota dealer)

● No indicator light (off) = Safety Connect service not active

Safety Connect services

■ Automatic Collision Notification

In case of either airbag deployment or severe rear-end collision, the

system is designed to automatically call the response center. The

responding agent receives the vehicle’s location and attempts to

speak with the vehicle occupants to assess the level of emergency.

If the occupants are unable to communicate, the agent automati-

cally treats the call as an emergency, contacts the nearest emer-

gency services provider to describe the situation, and requests that

assistance be sent to the location.

HIGHLANDER_HV_U (OM0E032U)

484

6-4. Using the other interior features

Safety information for Safety Connect

Important! Read this information before using Safety Connect.

■ Exposure to radio frequency signals

The Safety Connect system installed in your vehicle is a low-power

radio transmitter and receiver. It receives and also sends out radio

frequency (RF) signals.

In August 1996, the Federal Communications Commission (FCC)

adopted RF exposure guidelines with safety levels for mobile wire-

less phones. Those guidelines are consistent with the safety stan-

dards previously set by the following U.S. and international

standards bodies.

● ANSI (American National Standards Institute) C95.1 [1992]

● NCRP (National Council on Radiation Protection and Measure-

ment) Report 86 [1986]

● ICNIRP (International Commission on Non-Ionizing Radiation

Protection) [1996]

Those standards were based on comprehensive and periodic eval-

uations of the relevant scientific literature. Over 120 scientists, engi-

neers, and physicians from universities, and government health

agencies and industries reviewed the available body of research to

develop the ANSI Standard (C95.1).

The design of Safety Connect complies with the FCC guidelines in

addition to those standards.

■Certification for Safety Connect

FCC ID: O6Y-CDMRF101

FCC ID: XOECDMRF101B

FCC ID: N7NGTM2

NOTE:

This device complies with Part 15 of the FCC Rules. Operation is subject to

the following two conditions: (1) This device may not cause harmful interfer-

ence, and (2) this device must accept any interference received, including

interference that may cause undesired operation.

FCC WARNING:

Changes or modifications not expressly approved by the party responsible for

compliance could void the user's authority to operate the equipment.

HIGHLANDER_HV_U (OM0E032U)

6-4. Using the other interior features

485

Compass∗

The compass on the inside rear view mirror indicates the direc-

tion in which the vehicle is heading.

Operation

To turn the compass on or off,

press the button for more than 3

seconds.

Displays and directions

Display

Direction

N

North

NE

Northeast

6

E

East

SE

Southeast

S

South

SW

Southwest

W

West

NW

Northwest

∗: If equipped

HIGHLANDER_HV_U (OM0E032U)

486

6-4. Using the other interior features

Calibrating the compass

The direction display deviates from the true direction determined by

the earth’s magnetic field. The amount of deviation varies according to

the geographic position of the vehicle.

If you cross over a map boundary shown in illustration, the compass will

deviate.

To obtain higher precision or perfect calibration, refer to the following.

■ Deviation calibration

1

Stop the vehicle.

2

Press and hold the button for

6 seconds.

A number (1 to 15) appears on

the compass display.

3

Press the switch and referring to the map above, select the num-

ber of the zone where you are.

If the direction is displayed several seconds after adjustment, the cali-

bration is complete.

HIGHLANDER_HV_U (OM0E032U)

6-4. Using the other interior features

487

■ Circling calibration

1

Stop the vehicle in a place where it is safe to drive in a circle.

2

Press and hold the button for

9 seconds.

“C” appears on the compass

display.

Drive the vehicle at 5 mph (8

3

km/h) or less in a circle until

a direction is displayed.

If there is not enough space to

drive in a circle, drive around the

block until the direction is dis-

played.

6

HIGHLANDER_HV_U (OM0E032U)

490

7-1. Maintenance and care

Cleaning and protecting the vehicle

exterior

Perform the following to protect the vehicle and maintain it in

prime condition:

● Working from top to bottom, liberally apply water to the vehicle

body, wheel wells and underside of the vehicle to remove any dirt

and dust.

● Wash the vehicle body using a sponge or soft cloth, such as a

chamois.

● For hard-to-remove marks, use car wash soap and rinse thoroughly

with water.

● Wipe away any water.

● Wax the vehicle when the waterproof coating deteriorates.

If water does not bead on a clean surface, apply wax when the vehicle

body is cool.

■Automatic car washes

● Before washing the vehicle:

• Fold the mirrors.

• Turn off the power back door (if equipped).

Start washing from the front of the vehicle. Make sure to extend the mirrors

before driving.

● Brushes used in automatic car washes may scratch the vehicle surface and

harm your vehicle’s paint.

■ High pressure car washes

● Do not allow the nozzles of the car wash to come within close proximity of

the windows.

● Before using the car wash, check that the fuel filler door on your vehicle is

closed properly.

HIGHLANDER_HV_U (OM0E032U)

7-1. Maintenance and care

491

■When using a car wash

If the door handle becomes wet while the electronic key is within the effective

range, the door may lock and unlock repeatedly. In that case, follow the fol-

lowing correction procedures to wash the vehicle:

● Place the key in a position 6 ft. (2 m) or more separate from the vehicle

while the vehicle is being washed. (Take care to ensure that the key is not

stolen.)

● Set the electronic key to battery-saving mode to disable the smart key sys-

tem. (→P. 148)

■Aluminum wheels

● Remove any dirt immediately by using a neutral detergent.

● Wash detergent off with water immediately after use.

● To protect the paint from damage, make sure to observe the following pre-

cautions.

• Do not use acidic, alkaline or abrasive detergent

• Do not use hard brushes

• Do not use detergent on the wheels when they are hot, such as after driv-

ing or parking in hot weather

■Bumpers

Do not scrub with abrasive cleaners.

7

HIGHLANDER_HV_U (OM0E032U)

492

7-1. Maintenance and care

WARNING

■ When washing the vehicle

Do not apply water to the inside of the engine compartment. Doing so may

cause the electrical components, etc. to catch fire.

■ When cleaning the windshield (vehicles with rain-sensing windshield

wipers)

Set the wiper switch to off.

If the wiper switch is in “AUTO”, the wip-

ers may operate unexpectedly in the fol-

Off

lowing situations, and may result in

hands being caught or other serious inju-

ries and cause damage to the wiper

blades.

● When the upper part of the windshield where the raindrop sensor is

located is touched by hand

● When a wet rag or similar is held close to the raindrop sensor

● If something bumps against the windshield

● If you directly touch the raindrop sensor body or if something bumps into

the raindrop sensor

■ Precautions regarding the exhaust pipe

Exhaust gasses cause the exhaust pipe to become quite hot.

When washing the vehicle, be careful not to touch the pipe until it has

cooled sufficiently, as touching a hot exhaust pipe can cause burns.

■ Precaution regarding the rear bumper with Blind Spot Monitor (if

equipped)

If the paint of the rear bumper is chipped or scratched, the system may mal-

function. If this occurs, consult your Toyota dealer.

HIGHLANDER_HV_U (OM0E032U)

Content   ..  27  28  29  30   ..
