When storing a bottle, close the cap.

●

The bottle may not be stored depending on its size or shape.

Bottle holders



Front



Rear

WARNING

Do not place anything other than a bottle in the bottle holders.
Other items may be thrown out of the holders in the event of an accident or
sudden braking and cause injury.

NOTICE

Put the cap on before stowing a bottle. Do not place open bottles in the bot-
tle holders, or glass or paper cups containing liquid. The contents may spill
and glass cups may break.

306

Cup holders

The depth of the rear side cup holder can
be changed as shown in the illustration.

WARNING

Do not place anything other than cups or aluminum cans in the cup holders.
Other items may be thrown out of the holders in the event of an accident or
sudden braking, causing injury. If possible, cover hot drinks to prevent
burns.

307

Luggage compartment features

Cargo hooks are provided for
securing loose items.

Cargo hooks

WARNING

To avoid injury, always return the cargo hooks to their positions when they
are not in use.

Grocery bag hooks

NOTICE

Do not hang any object heavier than 4.4 lb. (2 kg) on the grocery bag hook.

308

Lift the deck mat tab and pull it
toward you to remove it.

Auxiliary boxes

Side auxiliary boxes

309



Type A

Unhook the cords and return
the luggage cover to horizontal
position.

Pull it toward you and then lift
the luggage cover to remove it.

Installation position

Confirm that the cover has been
securely installed to the original
position when installing.

Removal position

Luggage cover

310



Type B

■

Removing the luggage cover

Unhook the cords.

Unhook the hook to the hook
brackets.

■

Stowing the luggage cover

Hold the luggage cover with
both hands. Point your
thumbs in opposite direc-
tions.

311

Bend one side of the cover
towards you.

Twist the other side in the
opposite direction, as shown
in the illustration.

Make a small circle, then fold
it inward.

Make sure the three circles
are side by side.

312

Make sure the luggage cover
is properly folded.

WARNING

●

Do not place anything on the luggage cover. In the event of sudden brak-
ing or turning, the item may go flying and strike an occupant. This could
lead to an unexpected accident, resulting in death or serious injury.

●

Do not allow children to climb on the luggage cover. Climbing on the lug-
gage cover could result in damage to the luggage cover, possibly causing
death or serious injury to the child.

●

Type B only: Be sure to properly fold the luggage cover. Other wise it could
unexpectedly unfold, which may lead to serious injuries.

●

Be sure to attach the cord correctly.

NOTICE

Type B only: Do not apply too much force when folding the luggage cover.
Doing so may damage the luggage cover.

313

Other interior features

To set the visor in the forward
position, flip it down.
To set the visor in the side posi-
tion, flip down, unhook, and
swing it to the side.

Slide the cover to open.

The light turns on when the cover
is opened. (if equipped)

Sun visors

Vanity mirrors

314

The clock can be adjusted by pressing and holding the buttons.

Adjusts the hours
Adjusts the minutes

●

Vehicles without a smart key system:
The clock is displayed when the engine switch is in the “ACC” or “ON” posi-
tion.
Vehicles with a smart key system:
The clock is displayed when the engine switch is in ACCESSORY or
IGNITION ON mode.

●

When the battery terminals are disconnected and reconnected, the clock
will automatically be set to 1:00.

Clock

315

Please use as a power supply for electronic goods that use less than
12 VDC/10 A (power consumption of 120 W).
When using electronic goods, make sure that the power consumption
of all the connected power outlets is less than 120 W.

Lift the lid while pulling up the
knob and open the console box.

Open the cover.

Vehicles without a smart key system:
The power outlet can be used when the engine switch is in the “ACC” or “ON”
position.
Vehicles with a smart key system:
The power outlet can be used when the engine switch is in ACCESSORY or
IGNITION ON mode.

Power outlet

NOTICE

●

To avoid damaging the power outlet, close the power outlet cover when
the power outlet is not in use. Foreign objects or liquids that enter the
power outlet may cause a short circuit.

●

To prevent battery discharge, do not use the power outlet longer than nec-
essary when the engine is off.

316

An assist grip installed on the ceil-
ing can be used to support your
body while sitting on the seat.

Assist grips

WARNING

Do not use the assist grip when getting in or out of the vehicle or rising from
your seat.

NOTICE

To prevent damage to the assist grip, do not hang any heavy object or put a
heavy load on the assist grip.

317

Some audio features (audio volume control, radio, CD player, etc.)
can be controlled using the switches on the steering wheel.
For more information, please refer to the “TOYOTA Audio System
Owner’s Manual” or “TOYOTA Navigation System Owner’s Manual”.

Steering wheel audio switches

WARNING

To reduce the risk of an accident, exercise care when operating the audio
switches on the steering wheel.
