Ease of use and comfort
Torch
Use
F Extract the torch from its location by pulling
it from the front.
F Press the switch, located on the back, to
switch the torch on or off.
F Unfold the leg, located on the back, to set
3
down and raise the torch; for example,
when changing a wheel.
Storing
Portable lighting, located at the rear, which can
be used to illuminate the rear and as a torch.
F Put the torch back in place in its location
starting with the rear.
If you have forgotten to switch off the torch,
this switches it off automatically.
This torch operates with NiMH type
rechargeable batteries.
It has a battery life of approximately 45 minutes
and charges while you are driving.
If the torch is not engaged correctly, it
may not charge and may not come on
when the boot is opened.
Observe the polarities when fitting the
batteries.
Never replace the rechargeable
batteries with single-use batteries.
119
Ease of use and comfort
Skyview®
It is equipped with two manual and independent blinds, which improve thermal and acoustic
comfort.
Blinds
Opening
Closing
F Take one of the blinds by its grip and push
F Take one of the blinds by its grip and pull it
it rearward to the desired position.
forward to the desired position.
120
Ease of use and comfort
Moving forward or backward
Folding and sliding table
Storage
3
F Raise this control (without going beyond
the point of resistance) and slide the
assembly forward or backward.
F Release the control when it is in the
It comprises a central storage space closed
F Slide back the cover for access to 11 litres
desired position.
with a lid. Unfolded, it offers a table with two
of storage space.
F Check that the table is correctly latched on
tops on which objects can be placed. The
the runner. If this is not the case, move the
central area includes two cup holders and can
assembly slightly to the next notch on the
also be used to place small objects (credit card,
runner.
pen, ...).
The assembly is mounted on a runner allowing it
You can move the table folded or
to be positioned equally well in row 2 or row 3.
unfolded. However, for greater safety, it
is recommended that the assembly be
moved in the folded position.
The storage space can accept a
For correct sliding of the table, ensure
maximum weight of 3 kg; do not exceed
that there is no object in the space used
this maximum load in use.
by the runner on the floor.
Before manoeuvring the table, check
that there is nothing on the table.
121
Ease of use and comfort
Unfolding
Folding
Cup holders
F Operate the control on the top and pull the
table assembly up until it clicks into place.
F Raise each table top, going beyond the
Two cups or cans and small objects (such as
point of resistance, to the vertical position.
a credit card, portable ashtray or pen) can be
F Push each table top down into its housing
carried in the middle of the unfolded table.
until it clicks into place.
F Push the control then tip the table
assembly downward until it clicks into
place.
Before stowing the table tops, check
Liquids carried in an open vessel (a cup
that there is no object underneath.
or mug) could be spilt, presenting a risk.
Before tipping the assembly down,
Take care.
check that the two table tops have
Never use the table in this position
F Pull each table top fully up then pivot them
clicked home in the low position and
while the vehicle is being driven.
on each side into the horizontal position.
that there is nothing in the cup holder
area (such as a can or pen).
122
Ease of use and comfort
Removing
Changing the direction
Refitting
F Check that there is no object obstructing
the runner, which could prevent correct
latching.
3
F
Raise the control fully to release the
With the table removed, you can turn it 180°.
anchorages and tip the table assembly
forward.
F
Remove the table assembly through the
F
Check that the control is in the up position
sliding door in row 2.
(latching mechanism armed). If not, raise
this control fully to arm the mechanism.
F
Place the front of the table on the runner.
F
Taking care not to interfere with the control,
Check that there is nothing in the space
Remove a seat to make this easier.
tip the assembly down at the rear until it
around the runner on the floor, so that
clicks into place.
the table disengages cleanly.
F
Check that the assembly is correctly
latched on the runner. if this is not the
case, slide the assembly along the runner
to the next notch.
F
Release the control until the guide latches
in the runner.
123
Ease of use and comfort
Take care of passengers' feet when
manoeuvring the assembly.
Storage off the runner
If removing and storing the table
out of the vehicle, ensure that it is
placed in a clean area, so as to avoid
introducing any foreign bodies into the
mechanisms.
The table assembly must be placed on
Incorrect use of the table could cause
Never place hot objects such as
a flat and level surface when out of the
serious injury.
casseroles or cooking pans on the
vehicle, resting on the guide so as to
Never use the table open or unfolded
table, you risk damaging its surface
avoid damaging the visible parts.
while the vehicle is being driven. An
(risk of fire).
object on the table is turned into a
projectile under heavy braking.
Ensure that the table is correctly stowed
With the table deployed, each top can
in the low position before moving off.
support a maximum of 10 kg. Failure to
Never use the table tops as seats or
observe this maximum load introduces
lean on them.
the risk of damaging all or part of the
A label on the table is a reminder of this.
table module.
Never raise the table when it is between
captain seats; this risks damaging the
table tops.
Caution, when out of the vehicle, the
table leans to the right or left when put
down.
124
Ease of use and comfort
Air intake / Air recirculation
Manual air conditioning
The air conditioning system only operates with the engine running.
The intake of exterior air avoids misting of the
windscreen and side windows.
The recirculation of interior air insulates the
passenger compartment from exterior odours
and fumes.
3
Air flow
Air distribution
This allows hot or cold air to be
F Turn the knob to obtain a
delivered quickly when required.
comfortable air flow.
Windscreen and side windows.
F Press this button to recirculate
the interior air; its indicator lamp
Central and side vents.
comes on.
If you put the air flow control in the
minimum position (system off), the
F Press this button again to allow
Footwells.
temperature is no longer controlled.
exterior air into the passenger
However, a slight flow of air can still be
compartment; its indicator lamp
felt, resulting from the movement of the
goes off.
vehicle.
The air distribution can be adapted by adding
the corresponding buttons.
Return to exterior air intake as soon as
Temperature
possible to avoid deterioration of the air
F Turn the knob from "LO"
quality and the formation of mist.
(cold) to "HI" (hot) to
adjust the temperature to
your requirements.
125
Ease of use and comfort
Air conditioning
Switching off
With the engine running, the air conditioning is
designed to operate effectively in all seasons,
F Press this button again; its
with the windows closed.
indicator lamp goes off.
It enables you to:
-
lower the temperature, in summer,
-
increase the effectiveness of the demisting
Switching off may result in some
in winter, above 3°C.
discomfort (humidity, misting).
Switching on
F Press this button; its indicator
lamp comes on.
The air conditioning does not operate
when the air flow adjustment is set to
off.
To obtain cool air more quickly, you
can use interior air recirculation for
a few moments. Then return to the
intake of exterior air.
126
Ease of use and comfort
Temperature
Dual-zone automatic air conditioning
The driver and front passenger can each set
the temperature to suit their requirements.
The value indicated in the screen corresponds
to a level of comfort and not to a temperature in
degrees Celsius or Fahrenheit.
3
Automatic comfort mode
F Push the button down to
reduce the value or up to
When the engine is cold, the air flow will
increase it.
only reach its optimum level gradually
F Press the "AUTO" button
to prevent too great a distribution of
repeatedly.
cold air.
In cold weather, it favours the
distribution of warm air to the
The active mode appears in the display screen,
A setting around 21 enables you to
windscreen, the side windows and the
as described below:
obtain an optimum level of comfort.
footwells only.
Depending on your requirements, a
Provides strong and effective air flow.
setting between 18 and 24 is usual.
In addition, it is recommended that you
Manual mode
avoid a left/right setting difference of
Offers the best compromise between
more than 3.
a comfortable temperature and quiet
If desired, you can choose settings different
operation.
to those offered by the system, by adjusting a
setting manually. The other functions are still
Provides soft and quiet operation by
managed automatically.
limiting air flow.
The "AUTO" symbol disappears if you modify
a setting.
127
Ease of use and comfort
"Mono" function
Visibility programme
The comfort setting for the passenger side
F Press the "visibility" button for
On entering the vehicle, if the interior
can be indexed to the driver's comfort setting
faster demisting or defrosting
temperature is much colder or warmer
(mono-zone).
of the windscreen and side
than the comfort value, there is no need
windows.
to alter the value displayed in order to
obtain the required level of comfort.
F Press this button to activate /
The system automatically manages the
The system corrects the temperature
deactivate the "Mono" function.
air conditioning, air flow and air intake and
difference automatically and as quickly
The indicator lamp in the button is on
distributes the flow of air to the windscreen and
as possible.
when the function is activated.
side windows to the best effect.
The function is deactivated automatically if a
F Press the "visibility" button
passenger uses the temperature control.
For maximum cooling or heating of
again to stop the programme.
the passenger compartment, you can
exceed the minimum value of 14 or the
Or
maximum value of 28.
F Push the button down
F Press the "AUTO" button to
until "LO" is displayed
return to the automatic comfort
or up until "HI" is
programme.
displayed.
128
Ease of use and comfort
Air conditioning
Air distribution
Air flow
With the engine running, the air conditioning is
F Press this button repeatedly to
F Press this button to increase air
designed to operate effectively in all seasons,
direct the air flow in turn to:
flow.
with the windows closed.
It enables you to:
F Press this button to decrease air
-
lower the temperature, in summer,
-
the windscreen, the side windows and the
flow.
-
increase the effectiveness of the demisting
footwells,
3
in winter, above 3°C.
-
the footwells.
-
the central vents, the side vents and the
The air flow symbol (a fan) appears. It is filled
Switching on
footwells,
in or emptied progressively according to the
F Press this button; its indicator
-
the windscreen, the side windows, the
setting.
lamp comes on.
centre vents and the footwells,
-
the centre and side vents,
The air conditioning does not operate
-
the windscreen and side windows
when the air flow adjustment is set to
(demisting or defrosting),
off.
To obtain cool air more quickly, you
can use interior air recirculation for
a few moments. Then return to the
intake of exterior air.
Switching off
F Press this button again; its
indicator lamp goes off.
Switching off may result in some
discomfort (humidity, misting).
129
Ease of use and comfort
Air intake / Air recirculation
Switching the system off
F Press this button until the fan
The intake of exterior air avoids misting of the
symbol disappears.
windscreen and side windows.
The recirculation of interior air insulates the
passenger compartment from exterior odours
This action switches off all of the functions of
and smoke.
the system.
The temperature is no longer controlled. A
slight flow of air, resulting from the movement
This allows hot or cold air to be
of the vehicle, remains perceptible however.
delivered quickly when required.
Avoid driving for too long with the
system switched off (risk of misting and
F Press this button to recirculate
of deterioration of the air quality).
the interior air; the symbol
appears.
F Press this button to switch the
F Press this button again to allow
system on again.
exterior air into the passenger
compartment; the symbol
disappears.
Return to exterior air intake as soon as
possible to avoid deterioration of the air
quality and the formation of mist.
130
Ease of use and comfort
Front demist - defrost
These markings on the control panel indicate the control positions for rapid demisting or
defrosting of the windscreen and side windows.
Manual air conditioning
Dual-zone digital air
conditioning
3
Heated windscreen and washer jets
For more information on the Wiper
control stalk and in particular the
heated windscreen and washer jets,
refer to the corresponding section.
F Put the air flow, temperature and
F Press this button to demist or
distribution controls to the dedicated
defrost the windscreen and side
marked position.
windows as quickly as possible.
F For air conditioning, press this
The system automatically manages the air
button; its indicator lamp comes
conditioning, air flow and air intake, and
on.
provides optimum distribution towards the
windscreen and side windows.
F To stop, press this button again
or on "AUTO".
With Stop & Start, when demisting has
been activated, the STOP mode is not
The system reverts to the previous settings.
available.
131
Ease of use and comfort
Door mirrors demist - defrost
Switching off
The demisting/defrosting switches off automatically
to prevent an excessive consumption of current.
F It is possible to stop the
demisting/defrosting operation
before it is switched off
automatically by pressing this
button again; its indicator lamp
goes off.
Switch off the heating of the rear screen
and door mirrors as soon as you judge it
possible, as reducing the consumption
of electrical current reduces fuel
Switching on
consumption.
F Press this button to demist/
defrost the door mirrors; its
indicator lamp comes on.
Door mirror demisting and defrosting
only operates with the engine running.
132
Ease of use and comfort
Rear screen demist - defrost
Switching off
The demisting/defrosting switches off automatically
to prevent an excessive consumption of current.
F It is possible to stop the
demisting/defrosting operation
3
before it is switched off
automatically by pressing this
button again; its indicator lamp
goes off.
Switch off the heating of the rear screen
and door mirrors as soon as you judge it
possible, as reducing the consumption
of electrical current reduces fuel
Switching on
consumption.
F Press this button to demist/
defrost the rear screen and the
door mirrors (if your vehicle is
Rear screen demisting and defrosting
so equipped); its indicator lamp
only operates with the engine running.
comes on.
133
Ease of use and comfort
Recommendations for heating, ventilation and air conditioning
In order for these systems to be fully effective, follow the operation and maintenance
If after an extended stop in sunshine,
guidelines below:
the interior temperature is very high, first
F
To obtain an even air distribution, take care not to obstruct the exterior air intake grilles
ventilate the passenger compartment for
located at the base of the windscreen, the nozzles, the vents and the air outlets, as well
a few moments.
as the air extractor located at the rear.
Put the air flow control at a setting high
F
Do not cover the sunshine sensor, located at the top of the windscreen; this is used for
enough to quickly change the air in the
regulation of the air conditioning system.
passenger compartment.
F
Operate the air conditioning system for at least 5 to 10 minutes, once or twice a month
The air conditioning system does not
to keep it in perfect working order.
contain chlorine and does not present
F
Ensure that the passenger compartment filter is in good condition and have the filter
any danger to the ozone layer.
elements replaced regularly.
We recommend the use of a combined passenger compartment filter. Thanks to its
special active additive, it contributes to the purification of the air breathed by the
The condensation created by the air
occupants and the cleanliness of the passenger compartment (reduction of allergic
conditioning results in a discharge
symptoms, bad odours and greasy deposits).
of water under the vehicle which is
F
To ensure correct operation of the air conditioning system, you are also advised to have
perfectly normal.
it checked regularly as recommended in the maintenance and warranty guide.
F
If the system does not produce cold air, switch it off and contact an authorized Toyota
dealer or repairer, or another duly qualified and equipped professional.
Stop & Start
The heating and air conditioning
When towing the maximum load on a steep gradient in high temperatures, switching off the
systems only work when the engine is
air conditioning increases the available engine power and so improves the towing ability.
running.
To maintain a comfortable temperature
in the passenger compartment, you can
Air vents
temporarily deactivate the Stop & Start
To close a vent, move the control
system.
towards the outside of the vehicle. Slight
For more information on Stop & Start,
resistance may be felt.
refer to the corresponding section.
134
Ease of use and comfort
Suggested interior settings
Heating or Manual air conditioning
I require...
Recirculation of interior air /
Air distribution
Air flow
Temperature
Manual AC
Intake of exterior air
3
HOT
COLD
DEMISTING
DEFROSTING
Dual-zone air conditioning: use the automatic mode in preference by pressing the "AUTO" button.
135
