What to do if... (Troubleshooting)
The shift lever cannot be shifted from P even if you depress
the brake pedal (vehicles with a Multidrive)
● Vehicles without a smart entry & start system:
Is the engine switch in the “ON” position?
If you cannot release the shift lever by depressing the brake pedal with the
engine switch in the “ON” position. (P. 228)
● Vehicles with a smart entry & start system:
Is the engine switch in IGNITION ON mode?
If you cannot release the shift lever by depressing the brake pedal with the
engine switch in IGNITION ON mode. (P. 228)
The steering wheel cannot be turned after the engine is
stopped
● Vehicles without a smart entry & start system:
It is locked to prevent theft of the vehicle if the key is pulled from the engine
switch. (P. 210)
● Vehicles with a smart entry & start system:
It is locked automatically to prevent theft of the vehicle. (P. 219)
The windows do not open or close by operating the power
window switches
● Is the window lock switch pressed?
The power window except for the one at the driver’s seat cannot be oper-
ated if the window lock switch is pressed. (P. 181)
The engine switch is turned off automatically (vehicles with
a smart entry & start system)
● The auto power off function will be operated if the vehicle is left in ACCES-
SORY or IGNITION ON mode (the engine is not running) for a period of
time. (P. 219)
What to do if... (Troubleshooting)
647
A warning buzzer sounds during driving
● The seat belt reminder light is flashing
Are the driver and the front passenger wearing the seat belts? (P. 549)
● The brake system warning light is on
Is the parking brake released? (P. 234)
Depending on the situation, other types of warning buzzer may also sound.
(P. 545, 557)
An alarm is activated and the horn sounds
(vehicles with an alarm)
● Did anyone inside the vehicle open a door during setting the alarm?
The sensor detects it and the alarm sounds. (P. 87)
Vehicles without a smart entry & start system
To stop the alarm, turn the engine switch to the “ON” position or start the
engine.
Vehicles with a smart entry & start system
To stop the alarm, turn the engine switch to IGNITION ON mode or start the
engine.
A warning buzzer sounds when leaving the vehicle
(vehicles with a smart entry & start system)
● Is the electronic key left inside the vehicle?
Vehicles with a 2-ring meter: Check the message on the multi-information
display. (P. 557)
A warning light turns on
(vehicles with a 3-ring meter)
● When a warning light turns on, refer to P. 545.
A warning light turns on or a warning message is displayed
(vehicles with a 2-ring meter)
● When a warning light turns on or a warning message is displayed, refer to
P. 545, 557.
648
What to do if... (Troubleshooting)
When a problem has occurred
If you have a flat tire
● Vehicles with a spare tire:
Stop the vehicle in a safe place and replace the flat tire with the spare tire.
(P. 563)
● Vehicles with an emergency tire puncture repair kit:
Stop the vehicle in a safe place and repair the flat tire temporarily with the
emergency tire puncture repair kit. (P. 576)
The vehicle becomes stuck
● Try the procedure for when the vehicle becomes stuck in mud, dirt, or
snow. (P. 608)
