Toyota GT86 (2016 year). Instruction - part 13

2-1. Driving procedures

■ When the steering lock cannot be released

The smart entry & start system indicator

light (green) will flash quickly and a mes-

sage will be shown on the multi-informa-

tion display. (→P. 411)

Vehicles with an automatic transmis-

sion

Check that the shift lever is set in P. Press

the “ENGINE START STOP” switch while

turning the steering wheel left and right.

Vehicles with a manual transmission

Press the “ENGINE START STOP” switch

while turning the steering wheel left and

right.

■ Steering lock motor overheating prevention

To prevent the steering lock motor from overheating, the motor may be sus-

pended if the engine is turned on and off repeatedly in a short period of time.

In this case, refrain from operating the engine. After about 10 seconds, the

steering lock motor will resume functioning.

■ If the smart entry & start system indicator flashes in yellow and a mes-

sage is displayed on the multi-information display

The system may be malfunctioning. Have the vehicle inspected by any

authorized Toyota dealer or repairer, or another duly qualified and equipped

professional immediately.

■ If the electronic key battery is depleted

→P. 360

■ If the smart entry & start system has been deactivated in a customized

setting

→P. 456

■ Immediately after reconnecting the battery terminals due to replacing

the battery and so forth

The engine may not start. If this occurs, turn the “ENGINE START STOP”

switch to IGNITION ON mode, and start the engine after waiting at least 10

seconds. Idling may be unstable immediately after the engine starts, how-

ever, this is not a malfunction.

180

86_EE (OM18071E)

2-1. Driving procedures

Engine (ignition) switch (vehicles without a smart entry & start system)

■ Starting the engine

Vehicles with an automatic transmission

STEP

1

Check that the parking brake is set.

STEP

2

Check that the shift lever is set in P.

STEP

3

Firmly depress the brake pedal.

STEP

4

Turn the engine switch to the “START” position to start the

engine.

2

Vehicles with a manual transmission

STEP

1

Check that the parking brake is set.

STEP

2

Check that the shift lever is set in N.

STEP

3

Firmly depress the clutch pedal.

STEP

4

Turn the engine switch to the “START” position to start the

engine.

■ Changing the engine switch positions

“LOCK”

The steering wheel is locked

and the key can be removed.

(Vehicles with an automatic

transmission: The key can be

removed only when the shift

lever is in P.)

“ACC”

Some electrical components

such as the power outlet can

be used.

“ON”

All electrical components can

be used.

“START”

For starting the engine.

183

86_EE (OM18071E)

2-1. Driving procedures

■ Turning the key from “ACC” to “LOCK”

STEP

1

Shift the shift lever to N (manual transmission) or P (automatic

transmission). (→P. 186, 193)

STEP

2

Push in the key and turn to the “LOCK”

position.

■ If the engine does not start

The engine immobilizer system may not have been deactivated. (→P. 93)

Contact any authorized Toyota dealer or repairer, or another duly qualified

and equipped professional.

■ When the steering lock cannot be released

When starting the engine, the engine

switch may seem stuck in the “LOCK”

position. To free it, turn the key while turn-

ing the steering wheel slightly left and

right.

■ Key reminder function

A buzzer sounds if the driver’s door is opened while the engine switch is in

the “LOCK” or “ACC” position to remind you to remove the key.

■ Immediately after reconnecting the battery terminals due to replacing

the battery and so forth

The engine may not start. If this occurs, turn the engine switch to the “ON”

position, and start the engine after waiting at least 10 seconds. Idling may be

unstable immediately after the engine starts, however, this is not a malfunc-

tion.

184

86_EE (OM18071E)

2-1. Driving procedures

WARNING

■ When starting the engine

Always start the engine while sitting in the driver's seat. Do not depress the

accelerator pedal while starting the engine under any circumstances.

Doing so may cause an accident resulting in death or serious injury.

■ Caution when driving

Do not turn the engine switch to the “LOCK” position while driving. If, in an

emergency, you must turn the engine off while the vehicle is moving, turn the

2

engine switch only to the “ACC” position to stop the engine. An accident may

result if the engine is stopped while driving. (→P. 469)

NOTICE

■ To prevent battery discharge

Do not leave the engine switch in the “ACC” or “ON” position for long periods

of time without the engine running.

■ When starting the engine

●Do not crank the engine for more than 10 seconds at a time. This may

overheat the starter and wiring system.

If the engine does not start, turn the engine switch to the “LOCK” position

and try to start the engine again after waiting for 10 seconds or more.

●Do not race a cold engine.

●If the engine becomes difficult to start or stalls frequently, have your vehi-

cle checked by any authorized Toyota dealer or repairer, or another duly

qualified and equipped professional immediately.

185

86_EE (OM18071E)

2-1. Driving procedures

Automatic transmission∗

Select a shift position appropriate for the driving conditions.

■ Shifting the shift lever

Vehicles without a smart entry & start system

While the engine switch is in the “ON” position, move the

shift lever with the brake pedal depressed.

When shifting the shift lever between P and D, make sure that the

vehicle is completely stopped.

Vehicles with a smart entry & start system

While the “ENGINE START STOP” switch is in IGNITION

ON mode, move the shift lever with the brake pedal

depressed.

When shifting the shift lever between P and D, make sure that the

vehicle is completely stopped.

∗: If equipped

186

86_EE (OM18071E)

2-1. Driving procedures

■ Shift position uses

Multi-information display

Shift

Function

Monochrome

position

Color display

display

Parking the vehicle/start-

P

ing the engine

R

Reversing

2

N

Neutral

Normal D position driving*

(gears between “1” and “6”

are automatically

selected)

D

Temporary manual mode

driving (→P. 191)

(paddle shift switches

(paddle shift switches

activated)

activated)

Manual mode driving

M

(→P. 189)

*: Shifting to the D position allows the system to select a gear suitable for

the driving conditions. Setting the shift lever to the D position is recom-

mended for normal driving.

187

86_EE (OM18071E)

2-1. Driving procedures

■ Selecting a driving mode

By pressing the driving pattern selector switch the following

modes can be selected to suit driving and usage conditions:

Normal mode

Sport mode

The “SPORT” indicator comes on.

Use sport mode for sporty driving or when driving in mountainous

regions with lots of curves.

Snow mode

The “SNOW” indicator comes on.

Use snow mode for accelerating and driving on slippery road surfaces

such as snow.

To cancel sport mode or snow mode, press the same side of the

switch again.

188

86_EE (OM18071E)

2-1. Driving procedures

Manual mode driving

To enter manual mode, shift the shift lever to the M position.

When the Gear Shift Indicator is on, gears can be selected by operat-

ing the shift lever or paddle shift switches (if equipped), allowing you

to drive in the gear of your choosing.

The Gear Shift Indicator display is a guide to help the driver achieve

improved fuel economy and reduced exhaust emissions within limits

2

of engine performance.

Even if upshifting operations are performed, if vehicle speed is too low for

the requested gear, the gear will not change.

Upshift indicator

*1

Downshift indicator

Upshifting (+)

*2

Downshifting (-)

Each time the shift lever or pad-

dle shift switches are operated,

the gear changes up or down

one gear and the selected gear,

“1” through “6”, will be set.

The selected gear, from “1” to “6”,

and “M” will be displayed on the

shift position and shift range indi-

cator.

*1: Vehicles with a monochrome multi-information display

*2: Vehicles with a color multi-information display

189

86_EE (OM18071E)

2-1. Driving procedures

When in manual mode, the gear will not change unless the shift lever

or paddle shift switches are operated.

However, even when in manual mode, the gears will be automatically

changed in the following situations:

● When vehicle speed drops (downshift only).

● When engine oil temperature is high and engine speed rises close

to the red zone.

■ When moving the shift lever out of P

If the shift lever is pushed sideways before the brake pedal is depressed,

shift lever operation may not be possible. Depress the brake pedal before

shifting the shift lever out of P.

■ Downshifting restrictions warning buzzer

If downshifting operations are performed at a vehicle speed by which down-

shifting is not possible (when downshifting will cause the engine speed to

enter the red zone), a buzzer will sound to warn the driver that downshifting

cannot be performed.

■ When driving with cruise control activated (if equipped)

Downshifting can be performed even when using cruise control. After down-

shifting, the set speed continues. (→P. 189, 191)

■ Sport mode

● In sport mode, lower gears are used and gears change at a higher

engine speed.

● If sport mode is changed to while the shift lever is in the M position, the

“SPORT” indicator will come on but sport mode controls will not be car-

ried out. Shift the shift lever to the D position.

● Sport mode cannot be changed to when driving with cruise control acti-

vated.

■ Snow mode

To prevent slipping, 1st gear cannot be selected when in snow mode.

190

86_EE (OM18071E)

2-1. Driving procedures

■ Sport mode and snow mode automatic deactivation

In the following situations, the driving mode is automatically deactivated:

● When the engine is turned off after driving in sport mode or snow mode.

●When cruise control (if equipped) is activated while driving in sport mode.

■ If the shift lever cannot be shifted from P

→P. 453

■ Automatic gear selection when the vehicle is stopped

When the vehicle is idling at high rpm in order to warm up, and the vehicle is

2

on a slippery road, the transmission may automatically shift to 2nd gear for

stopping and starting off.

■ Temporary manual mode driving (vehicles with paddle shift switches)

Temporary manual mode driving can be

*1

*2

changed to by operating the paddle shift

switches while the shift lever is in the D

position.

When this occurs, the selected gear and

“D” are displayed on the shift position and

shift range indicator.

(When engine speed rises close to the

red zone, upshifting will be automatically

performed.)

Gear Shift Indicator: →P. 189

*1: Vehicles with a monochrome multi-information display

*2: Vehicles with a color multi-information display

Temporary manual mode driving will be deactivated and normal D position

driving will be returned to in the following situations:

● When driving for longer than the set time (the set time differs according

to driving conditions).

●When the vehicle comes to a stop.

● When the accelerator pedal is continually depressed for longer than the

set time.

● When the accelerator pedal is fully, or near-fully, depressed.

191

86_EE (OM18071E)

2-1. Driving procedures

Manual Transmission∗

■ Shifting the shift lever

2

Fully depress the clutch pedal before operating the shift lever, and

then release it slowly.

■ Shifting the shift lever to R

Shift the shift lever to R while

lifting up the ring section.

∗: If equipped

193

86_EE (OM18071E)

2-1. Driving procedures

Shift position indicator

The selected shift position will be

*1

*2

displayed on the multi-informa-

tion display.

The selected shift position will not

appear in the following situations:

• When the shift lever is in N.

• When the vehicle speed is 10

km/h (6 mph) or less (except

when the shift lever is in R).

• When the clutch pedal is

depressed.

*1: Vehicles with a monochrome multi-information display

*2: Vehicles with a color multi-information display

Gear Shift Indicator

The Gear Shift Indicator display is a guide to help the driver achieve

improved fuel economy and reduced exhaust emissions within limits

of engine performance.

Upshift indicator

*1

*2

Downshift indicator

The Gear Shift Indicator cannot

be deactivated.

*1: Vehicles with a monochrome

multi-information display

*2: Vehicles with a color multi-information display

194

86_EE (OM18071E)

Content   ..  11  12  13  14   ..
