Toyota Verso S (2014 year). Instruction - part 2
B
Paddle shift switches
P. 188
Telephone
Audio switches ,*2
switch ,*1
P. 320
Cruise control
switch
P. 236
Engine (ignition) switch (vehicles without a
smart entry & start system)
P. 182
C
Headlight leveling dial
P. 214
VSC/TRC off switch
P. 241
Outside rear view mirror switches
P. 96
Power heater switch
P. 279
: If equipped
*1: Refer to “Navigation and multimedia system Owner’s manual”.
*2: For vehicles with a navigation/multimedia system, refer to “Navigation and multimedia system Owner’s manual”.
15
Interior
Pictorial index
(Right-hand drive vehicles)
Tilt and telescopic steering lock release lever
P. 92
SRS driver airbag
P. 122
Head restraints
P. 83
Horn
P. 197
Seat belts
P. 85
Shift lever P. 186, 192
Power window
Auxiliary box P. 327
switches P. 98
SRS front
passenger airbag
P. 122
Glove box
Rear
P. 327
armrest
P. 340
AUX port/USB port ,*1
P. 301, 309, 319
Front seats P. 77
SRS side airbags P. 122
Front armrest
P. 340
Seat heater switch
P. 338
Cup holders
P. 331
Parking brake lever
P. 196
16
A
Anti-glare inside
rear view mirror
P. 94
Vanity mirrors
P. 333
Sun visors*2
P. 332
Panoramic roof shade switch
P. 341
SRS curtain shield airbags
P. 122
Assist grips
P. 344
Personal/interior
lights
P. 324
Interior light
P. 325
Personal lights
P. 324
: If equipped
*1: For vehicles with a navigation/multimedia system, refer to “Navigation and multi-
media system Owner’s manual”.
*2: NEVER use a rearward facing child re-
straint on a seat protected by an
ACTIVE AIRBAG in front of it, DEATH
or SERIOUS INJURY to the CHILD can
occur. (P. 154)
17
Interior
Pictorial index
(Right-hand drive vehicles)
B
Type A
Power window switches
P. 98
Inside lock button
P. 67
Window lock switch
P. 98
Door lock switch
P. 66
Type B
Power window switches
P. 98
Inside lock button
P. 67
Window lock switch
P. 98
Door lock switch
P. 66
18
Instrument panel
Pictorial index
(Right-hand drive vehicles)
Windshield wiper and
washer switch
P. 221, 227
Gauges and meters
P. 198
Emergency flasher switch
P. 436
Audio system
P. 283
Navigation/Multimedia system ,*
Shift lock override
button
P. 495
Power outlet P. 336
Floor mat
P. 345
Fuel filler door
SRS driver knee
opener
airbag
P. 122
P. 101
Headlight switch
P. 213
Cup holders P. 331
Turn signal lever
P. 195
Hood lock release lever
Fog light switch
P. 219
P. 367
: If equipped
*: Refer to “Navigation and multimedia system Owner’s manual”.
19
Instrument panel
Pictorial index
(Right-hand drive vehicles)
A
Vehicles with an automatic air conditioning system
Air conditioning
Rear window defogger
system
P. 272
switch
P. 281
“SPORT” switch P. 187
Vehicles with a manual air conditioning system
Rear window defogger
switch
P. 281
Air conditioning
system
P. 266
“SPORT” switch
P. 187
20
B
Paddle shift switches
P. 188
Audio switches ,*2
Telephone
P. 320
switch ,*1
Cruise control
switch
P. 236
Engine (ignition) switch (vehicles without a
smart entry & start system)
P. 182
C
Engine (ignition) switch
(vehicles with a smart entry & start
system)
P. 173
Headlight leveling dial
P. 214
Outside rear view mirror
switches
P. 96
VSC/TRC off switch
P. 241
: If equipped
*1: Refer to “Navigation and multimedia system Owner’s manual”.
*2: For vehicles with a navigation/multimedia system, refer to “Navigation and multimedia system Owner’s manual”.
21
Pictorial index
Luggage compartment
Child restraint anchor brackets
P. 145
Dual-level deck board
P. 347
Deck board
P. 347
22
A
Rear seatback lock
release lever
P. 80
Power outlet
P. 336
Cargo hook
P. 347
B
Rear seatback lock
release lever
P. 80
Cargo hook
P. 347
: If equipped
23
For your information
Main Owner’s Manual
Please note that this manual applies to all models and all equipment, includ-
ing options. Therefore, you may find some explanations for equipment not
installed on your vehicle.
All specifications provided in this manual are current at the time of printing.
However, because of the Toyota policy of continual product improvement, we
reserve the right to make changes at any time without notice.
Depending on specifications, the vehicle shown in the illustrations may differ
from your vehicle in terms of equipment.
Accessories, spare parts and modification of your Toyota
Both genuine Toyota and a wide variety of other spare parts and accessories
for Toyota vehicles are currently available on the market. Should it be
determined that any of the genuine Toyota parts or accessories supplied with
the vehicle need to be replaced, Toyota recommends that genuine Toyota
parts or accessories, be used to replace them. Other parts or accessories of
matching quality can also be used. Toyota cannot accept any liability or
guarantee spare parts and accessories which are not genuine Toyota
products, nor for replacement or installation involving such parts. In addition,
damage or performance problems resulting from the use of non-genuine
Toyota spare parts or accessories may not be covered under warranty.
24
Installation of an RF-transmitter system
The installation of an RF-transmitter system in your vehicle could affect elec-
tronic systems such as:
Multiport fuel injection system/sequential multiport fuel injection system
Cruise control system
Anti-lock brake system
SRS airbag system
Seat belt pretensioner system
Be sure to check with any authorized Toyota dealer or repairer, or another
duly qualified and equipped professional for precautionary measures or spe-
cial instructions regarding installation of an RF-transmitter system.
Further information regarding frequency bands, power levels, antenna posi-
tions and installation provisions for the installation of RF-transmitters, is
available on request at any authorized Toyota dealer or repairer, or another
duly qualified and equipped professional.
Scrapping of your Toyota
The SRS airbag and seat belt pretensioner devices in your Toyota contain
explosive chemicals. If the vehicle is scrapped with the airbags and seat belt
pretensioners left as they are, this may cause an accident such as fire. Be
sure to have the systems of the SRS airbag and seat belt pretensioner
removed and disposed of by a qualified service shop or by any authorized
Toyota dealer or repairer, or another duly qualified and equipped profes-
sional, before you scrap your vehicle.
Your vehicle contains batteries and/or accumulators. Do not discard them into
the environment but cooperate with separate collection (Directive 2006/66/
EC).
25
CAUTION
General precautions while driving
Driving under the influence: Never drive your vehicle when under the influ-
ence of alcohol or drugs that have impaired your ability to operate your vehi-
cle. Alcohol and certain drugs delay reaction time, impair judgment and
reduce coordination, which could lead to an accident that could result in
death or serious injury.
Defensive driving: Always drive defensively. Anticipate mistakes that other
drivers or pedestrians might make and be ready to avoid accidents.
Driver distraction: Always give your full attention to driving. Anything that dis-
tracts the driver, such as adjusting controls, talking on a cellular phone or
reading can result in a collision with resulting death or serious injury to you,
your occupants or others.
General precaution regarding children’s safety
Never leave children unattended in the vehicle, and never allow children to
have or use the key.
Children may be able to start the vehicle or shift the vehicle into neutral.
There is also a danger that children may injure themselves by playing with
the windows, the panoramic roof shade, or other features of the vehicle. In
addition, heat build-up or extremely cold temperatures inside the vehicle can
be fatal to children.
26
Symbols used throughout this manual
Cautions & Notices
CAUTION
This is a warning against something which, if ignored, may cause death or
serious injury to people. You are informed about what you must or must not do
in order to reduce the risk of death or serious injury to yourself and others.
NOTICE
This is a warning against something which, if ignored, may cause damage to
the vehicle or its equipment. You are informed about what you must or must
not do in order to avoid or reduce the risk of damage to your Toyota and its
equipment.
Symbols used in illustrations
Safety symbol
The symbol of a circle with a slash through it means “Do not”, “Do
not do this”, or “Do not let this happen”.
Arrows indicating operations
Indicates the action
(pushing, turning,
etc.) used to operate switches and other
devices.
Indicates the outcome of an operation
(e.g. a lid opens).
27
28
Before driving
1
1-1.
Key information
1-5.
Refueling
Keys
30
Opening the fuel tank
cap
101
1-2.
Opening, closing and
locking the doors
1-6.
Theft deterrent system
Smart entry & start
Engine immobilizer
system
33
system
105
Wireless remote control
57
Double locking
system
115
Side doors
66
Alarm
117
Back door
72
1-7.
Safety information
1-3.
Adjustable components
(seats, mirrors,
Correct driving posture
120
steering wheel)
SRS airbags
122
Front seats
77
Airbag manual on-off
system
133
Rear seats
78
Child restraint
Head restraints
83
systems
136
Seat belts
85
Installing child
Steering wheel
92
restraints
145
Anti-glare inside rear
view mirror
94
Outside rear view
mirrors
96
1-4.
Opening and closing
the windows
Power windows
98
29
