Toyota Prius Prime (2020 year). Owner's manual - part 34

Luggage compartment features

■

When installing the deck board

Auxiliary boxes



Center



Right side

Pull the strap upwards to lift up
the deck board.

The luggage cover, charging cable,
tool bag, etc. can be stowed.

Pull the strap upwards to lift up
the deck board.

Insert the claw in to the hole, and return
the deck board.

WARNING

If the deck board is removed, return it to its original positions before driving.
In the event of sudden braking, an accident may occur due to an occupant
being struck by the deck board or the items stored in the auxiliary box.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

537

When using the hooks, press the
bottom side to lift it up.

There also is a hook on the other
side.

The warning reflector can be
stowed.
(The warning reflector itself is not
included as an original equipment)

Depending on the size and shape of the warning reflector case, etc., you may
not be able to store it.

NOTICE

To prevent damage to the deck board, do not apply too much load on the
deck board.

Grocery bag hooks

NOTICE

In order to prevent damage to the grocery bag hooks, do not place large
objects or objects that weight more than 8.8 lb. (4 kg) onto the hooks.

Warning reflector storage space

WARNING

When storing the warning reflector, etc., make sure that it is properly stored.
If the warning reflector is not properly stored, it may fly out during emer-
gency braking and lead to an accident.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

538

■

Installing the luggage cover
Install one side of the luggage
cover to the holder. While push-
ing that side in, install the other
side to the opposite holder.

■

Using the luggage cover
Pull out the luggage cover and
secure it to the hook brackets.

■

Removing the luggage cover
Push one end of the luggage
cover inward and remove it
from the holder.

Luggage cover

-------------------------------------------------------------------------------------------------------------------------------------------------------------

539

■

Stowing the luggage cover

Remove the deck boards.

Store cover in the center aux-
iliary box.

Return the deck boards to its original position and close it.

WARNING

●

Do not place anything on the luggage cover. In the event of sudden brak-
ing or turning, the item may go flying and strike an occupant. This could
lead to an unexpected accident, resulting in death or serious injury.

●

Do not allow children to climb on the luggage cover. Climbing on the lug-
gage cover could result in damage to the luggage cover, possibly causing
death or serious injury to the child.

●

Make sure that the rear edge of the cover is laying flat. If the cover is
installed with the rear edge raised, the view from the rear window may be
obstructed, which could cause an accident.

●

Make sure that seat belts are not caught up in the luggage cover. If a seat
belt is caught up in the cover, it may not be able to restrain passengers
properly.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

540

Other interior features

To  set  the  visor  in  the  forward
position, flip it down.
To set the visor in the side posi-
tion,  flip  down,  unhook,  and
swing it to the side.
To use the side extender, place
the  visor  in  the  side  position,
then slide it backward.

Slide the cover to open.

The light turns on when the cover
is opened.

If the vanity light remain on when the power switch is turned off, the light will
go off automatically after 20 minutes.

Sun visors

Vanity mirrors

NOTICE

To prevent 12-volt battery discharge, do not leave the vanity lights on for
extended periods while the hybrid system is off.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

541

Please use as a power supply for electronic goods that use less than
12 V DC/10 A (power consumption of 120 W).
Open the lid.

■

The power outlet can be used when
The power switch is in ACCESSORY or ON mode.

■

When stopping the hybrid system
Disconnect electrical devices with charging functions, such as mobile battery
packs.
If such devices are left connected, the hybrid system may not stop normally.

Power outlets

NOTICE

●

To avoid damaging the power outlets, close the lid when the power outlet
is not in use.
Foreign objects or liquids that enter the power outlets may cause a short
circuit.

●

To prevent 12-volt battery discharge, do not use the power outlet longer
than necessary when the hybrid system is off.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

543

■

The USB charging ports can be used when
The power switch is in ACCESSORY or ON mode.

■

Situations in which the USB charging ports may not operate correctly

●

If a device which consumes more than 2.1 A at 5 V is connected

●

If a device designed to communicate with a personal computer, such as a
USB memory device, is connected

●

If the connected external device is turned off (depending on device)

●

If the temperature inside the vehicle is high, such as after the vehicle has
been parked in the sun

■

About connected external devices
Depending on the connected external device, charging may occasionally be
suspended and then start again. This is not a malfunction.

NOTICE

■

To prevent damage to the USB charging ports

●

Do not insert foreign objects into the ports.

●

Do not spill water or other liquids into the ports.

●

When the USB charging ports are not in use, close the lids. If a foreign
object or liquid enters a port may cause a short circuit.

●

Do not apply excessive force to or impact the USB charging ports.

●

Do not disassemble or modify the USB charging ports.

■

To prevent damage to external devices

●

Do not leave external devices in the vehicle. The temperature inside the
vehicle may become high, resulting in damage to an external device.

●

Do not push down on or apply unnecessary force to an external device or
the cable of an external device while it is connected.

■

To prevent 12-volt battery discharge
Do not use the USB charging ports for a long period of time with the hybrid
system stopped.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

544

A portable device can be charged by just placing Qi standard wireless
charge compatible portable devices according to the Wireless Power
Consortium, such as smart phones and mobile batteries, etc., on the
charge area.
This function cannot be used with portable devices that are larger
than the charging area. Also, depending on the portable device, it may
not operate as normal. Please read the operation manual for portable
devices to be used.

■

The “Qi” symbol
The “Qi” symbol is a trademark of the Wireless Power Consortium.

■

Name for all parts

Power supply switch
Operation indicator light
Charge area

Wireless charger (if equipped)

1
2
3

-------------------------------------------------------------------------------------------------------------------------------------------------------------

545

■

Using the wireless charger

Press the power supply
switch of the wireless char-
ger.

Switches  on  and  off  with  each
press  of  the  power  supply
switch.
When  turned  on,  the  operation
indicator light (green) comes on.
Even with the hybrid system off,
the  on/off  state  of  the  power
supply switch is memorized.

Place the charging side of
the portable device down.

When  charging,  the  operation
indicator  light  (orange)  comes
on.
If  charging  is  not  occurring,  try
placing  the  portable  device  as
close  to  the  center  of  the
charging area as possible.
When charging is complete, the operation indicator light (green) comes
on.

● Recharging function

• When charging is complete and after a fixed time in the charge

suspension state, charging restarts.

• When the portable device is moved, charging is stopped for a

moment and then it restarts.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

546

■

Lighting conditions of operation indicator light

: Depending on the portable device, there are cases where the operation

indicator light will continue being lit up orange even after the charging is
complete.

● When the operation indicator light flashes

When an error occurs, the operation indicator light flashes an
orange color. Handle the error based on the following table.

Operation indicator light

Conditions

Turning off

When the Wireless charger power supply is
off

Green (comes on)

On Standby (charging possible state)

When charging is complete

Orange (comes on)

When placing the portable device on the
charging area (detecting the portable device)

Charging

Operation indicator

light

Suspected causes

Handling method

Flashing

repeatedly

once every second
(Orange)

Vehicle to charger com-
munication failure.

Contact your Toyota
dealer.

Repeatedly

flashes

3 times continuously
(Orange)

A foreign substance is
between the portable
device and charge area.

Remove the foreign
substance

from

between

portable

device and the charge
area.

The portable device is
out of sync due to the
device being shifted from
its position.

Place

the

portable

device near the center
of the charge area.

Repeatedly

flashes

4 times continuously
(Orange)

Temperature

rising

within the wireless char-
ger.

Stop charging at once
and

start

charging

again after for a while.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

547

■

The wireless charger can be operated when
The power switch is in ACCESSORY or ON mode.

■

Usable portable devices
Qi standard wireless charge standard can be used on compatible devices.
However, not all Qi standard devices and compatibility are guaranteed.
Starting with mobile phones and smart phones, it is aimed for low power elec-
trically supplied portable devices of no more than 5W.

■

When covers and accessories are attached to portable devices
Do not charge in situations where cover and accessories not able to handle
Qi are attached to the portable device. Depending on the type of cover and
accessory, it may not be possible to charge. When charging is not performed
even with the portable device placed on the charge area, remove the cover
and accessories.

■

While charging, noise enters the AM radio
Turn off the wireless charger and confirm that the noise has decreased. If the
noise decreases, continuously pushing the power supply switch of the wire-
less charger for 2 seconds, the frequency of the charger can be changed and
the noise can be reduced.
Also, on that occasion, the operation indicator light will flash orange 2 times.

■

Important points of the wireless charger

●

If the electronic key cannot be detected within the vehicle interior, charging
cannot be done. When the door is opened and closed, charging may be
temporarily suspended.

●

When charging, the wireless charging device and portable device will get
warmer, however this is not a malfunction.
When a portable device gets warm while charging, charging may stop due
to the protection function on the portable device side. In this case, when the
temperature of the portable device drops significantly, charge again.

■

Operation sounds
When the power supply is turned on, while searching for the portable device a
sound will be produced, however this is not a malfunction.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

551
