Toyota FJ Cruiser (GSJ 10, 15 series). Instruction - part 400

PREPARATION  –  SUPPLEMENTAL RESTRAINT SYSTEM

PP–57

PP

PREPARATION

PREPARATION

SUPPLEMENTAL RESTRAINT SYSTEM

SST

09082-00700

SRS Airbag Deployment Tool

09082-00750

Airbag Deployment Wire
Sub-harness No.3

09082-00760

Airbag Deployment Wire
Sub-harness No.4

09082-00780

Airbag Deployment Wire
Sub-harness No.6

09082-00802

Airbag Deployment Wire
Sub-Harness No. 8

(09082-10801)

Wire A

(09082-30801)

Wire C

09843-18060

SRS Check Wire

PP–58

PREPARATION  –  SUPPLEMENTAL RESTRAINT SYSTEM

PP

RECOMMENDED TOOLS

HINT:
Torx is a registered trademark of Textron Inc.

09042-00010

Torx Socket T30

09082-00040

TOYOTA Electrical Tester

(09083-00150)

Test Lead Set

PREPARATION  –  SUPPLEMENTAL RESTRAINT SYSTEM

PP–59

PP

EQUIPMENT

Torque wrench

Ohmmeter

Bolt
Length: 35.0 mm (1.378 in.)
Diameter: 6.0 mm (0.236 in.)
Pitch: 1.0 mm (0.039 in.)

Airbag disposal

Tire
Width: 185 mm (7.28 in.)
Inner diameter: 360 mm (14.17 in.)

Airbag disposal

Tire with disc wheel
Width: 185 mm (7.28 in.)
Inner diameter: 360 mm (14.17 in.)

Airbag disposal

Plastic bag

Airbag disposal

Battery

Airbag disposal

Knife

Airbag disposal

Service-purpose wire harness

Airbag disposal

Shop rag or pice of cloth

Airbag disposal

Service wire

Airbag disposal

PREPARATION  –  SEAT BELT

PP–59

PP

PREPARATION

PREPARATION

SEAT BELT

SST

09082-00700

SRS Airbag Deployment Tool

09082-00770

Airbag Deployment Wire
Sub-harness No.5
