PP–2

PREPARATION  –  1GR-FE ENGINE MECHANICAL

PP

PREPARATION

PREPARATION

1GR-FE ENGINE MECHANICAL

RECOMMENDED TOOLS

09040-00011

Hexagon Wrench Set

(09043-20080)

Socket Hexagon Wrench 8

(09043-20100)

Socket Hexagon Wrench 10

(09043-20120)

Socket Hexagon Wrench 12

(09043-30140)

Straight  Hexagon Wrench 14

09043-50100

Bi-hexagon Wrench 10 mm

PREPARATION  –  1GR-FE ENGINE MECHANICAL

PP–3

PP

EQUIPMENT

Abrasive compound

Brush

Caliper gauge

Carbide cutter

V-block

Pin hole grinder

Piston ring compressor

Piston ring expander

CO/HC meter

Compression gauge

Connecting rod aligner

Cylinder gauge

Dial indicator

Dye penetrant

Pin punch

Spring scale

Feeler gauge

Micrometer

Precision straight edge

Press

Reamer

Ridge reamer

Soft brush

Solvent

Radiator cap tester

Steel square

Grinder

Torque wrench

"Torx" socket wrench

Plastic hammer

Valve guide bushing brush

Vernier caliper

Wire brush

Dial indicator with magnetic base

Deep socket wrench

Magnetic finger

Scraper

Wooden block

Chain block

Spring tester

Plastigage

Heater

Timing light

Bar

Pin hole grinder

Seal Packing Black

Seal Packing 1282B

Adhesive 1324

PP–4

PREPARATION  –  1GR-FE FUEL

PP

PREPARATION

PREPARATION

1GR-FE FUEL

RECOMMENDED TOOLS

09040-00011

Hexagon Wrench Set

(09043-20080)

Socket Hexagon Wrench 8

09082-00040

TOYOTA Electrical Tester

(09083-00150)

Test Lead Set

PREPARATION  –  1GR-FE FUEL

PP–5

PP

EQUIPMENT

Stopwatch

Measuring flask

Radiator cap tester

Torque wrench

Clip
