Toyota FJ Cruiser (GSJ 10, 15 series). Instruction - part 337
MI–4
MIRROR – POWER MIRROR CONTROL SYSTEM
MI
PROBLEM SYMPTOMS TABLE
HINT:
Use the table below to help determine the causes of the
problem symptom. The potential causes of the symptoms are
listed in order of probability in the "Suspected Area" column
of the table. Check each symptom by checking the suspected
areas in the order they are listed. Replace parts as
necessary.
Power mirror control system
Symptom
Suspected area
See page
Mirror does not operate
ACC fuse
Outer mirror switch assembly
Outer rear view mirror assembly
Wire harness
-
Mirror operates abnormally
Outer mirror switch assembly
Outer rear view mirror assembly
Wire harness
-
