1GR-FE ENGINE MECHANICAL  –  CYLINDER HEAD

EM–61

EM

EXHAUST PIPE STOPPER BRACKET

FRONT EXHAUST PIPE ASSEMBLY

NO. 2 FRONT EXHAUST PIPE ASSEMBLY

N*m (kgf*cm, ft*lbf)  : Specified torque

Non-reusable part

GASKET

x2

48 (489, 35)

x2

GASKET

GASKET

GASKET

19 (193, 14)

19 (193, 14)

for 4WD:

x2

44 (438, 32)

x2

x2

54 (554, 40)

54 (554, 40)

A126505E01

EM–62

1GR-FE ENGINE MECHANICAL  –  CYLINDER HEAD

EM

26 (265, 19)

x10

GASKET

HEATER HOSE

GASKET

O-RING

GASKET

9.0 (92, 80 in.*lbf)

N*m (kgf*cm, ft*lbf)  : Specified torque

Non-reusable part

N*m (kgf*cm, ft*lbf)  : Specified torque

INTAKE MANIFOLD

WATER BY-PASS
JOINT RR

A126432E01

1GR-FE ENGINE MECHANICAL  –  CYLINDER HEAD

EM–63

EM

GASKET

30 (306, 22)

x6

40 (408, 30)

40 (408, 30)

GASKET

40 (408, 30)

40 (408, 30)

30 (306, 22)

x6

N*m (kgf*cm, ft*lbf)  : Specified torque

Non-reusable part

EXHAUST MANIFOLD
SUB-ASSEMBLY LH

EXHAUST MANIFOLD
SUB-ASSEMBLY RH

MANIFOLD STAY

NO. 2
MANIFOLD
STAY

A126433E01

EM–64

1GR-FE ENGINE MECHANICAL  –  CYLINDER HEAD

EM

9.0 (92, 80 in.*lbf)

x3

24 (245, 18)

NO. 1 CAMSHAFT

NO. 2 CHAIN

CAMSHAFT TIMING
GEAR ASSEMBLY

100 (1,020, 74)

100 (1,020, 74)

CAMSHAFT TIMING GEAR

24 (245, 18)

x3

9.0 (92, 80 in.*lbf)

NO. 2 CAMSHAFT

x8

8.0 (82, 71 in.*lbf)

GROUND CABLE

PLATE WASHER

N*m (kgf*cm, ft*lbf)  : Specified torque

Non-reusable part

19 (194, 14)

CYLINDER HEAD GASKET

CYLINDER HEAD SUB-ASSEMBLY

NO. 2 CAMSHAFT BEARING

NO. 2 CHAIN TENSIONER ASSEMBLY

1st: 36 (367, 27)

2nd: Turn 180°

A126434E01
