DOOR LOCK – WIRELESS DOOR LOCK BUZZER
DL–121
DL
(b) Disconnect the connector and remove the wireless
door lock buzzer.
INSPECTION
1.
INSPECT WIRELESS DOOR LOCK BUZZER
(a) Check the resistance.
(1) Using an ohmmeter, measure the resistance
between the terminals.
Standard Resistance
If the result is not as specified, replace the
wireless door lock buzzer.
INSTALLATION
1.
INSTALL WIRELESS DOOR LOCK BUZZER
(a) Connect the connector.
(b) Engage the clamp and install the wireless door lock
buzzer.
2.
INSTALL NO. 1 WIRING HARNESS PROTECTOR
(a) Engage the 4 claws and install the No. 1 wiring
harness protector.
B138139
1
2
B107863
Tester Connection
Specified Condition
1 (B) - 2 (B2)
Approximately 1 k
Ω
B138139
B138138
B138137
