RS0BP–11

H23878

N·m (kgf·cm, ft·lbf) : Specified torque

Front Airbag Sensor (LH)

Front Airbag Sensor (RH)

17.5 (179, 13)

17.5 (179, 13)

RS–86

–

SUPPLEMENTAL RESTRAINT SYSTEM

FRONT AIRBAG SENSOR

3369

FRONT AIRBAG SENSOR

COMPONENTS

RS0TI–03

H23879

–

SUPPLEMENTAL RESTRAINT SYSTEM

FRONT AIRBAG SENSOR

RS–87

3370

REMOVAL

HINT:

Use the same procedures for the RH side and LH side.

The procedures listed below are for the LH side.

NOTICE:

If the wiring connector of the SRS is disconnected
with the ignition switch in the ON position, DTCs will
be recorded.

Never use airbag parts from another vehicle. When
replacing parts, replace them with new ones.

Never reuse a front airbag sensor if the airbag has
previously deployed in a collision.

1.

PRECAUTION (SEE PAGE

RS–1

 and

RS–3

)

2.

DISCONNECT CABLE FROM NEGATIVE BATTERY
TERMINAL

Wait for 90 seconds after disconnecting the cable to prevent the
airbag working.

3.

REMOVE FRONT AIRBAG SENSOR LH

(a)

Disconnect the front airbag sensor LH connector.

NOTICE:
Disconnect the connector  with the  sensor assembly
installed.
(b)

Remove the 2 nuts and front airbag sensor LH.

RS11H–01

RS–88

–

SUPPLEMENTAL RESTRAINT SYSTEM

FRONT AIRBAG SENSOR

3371

INSPECTION

1.

VEHICLE NOT INVOLVED IN COLLISION

Perform a diagnostic system check (see page

DI–1147

).

2.

VEHICLE INVOLVED IN COLLISION AND AIRBAG IS NOT DEPLOYED

Perform a diagnostic system check (see page

DI–1147

).

3.

VEHICLE INVOLVED IN COLLISION AND AIRBAG IS DEPLOYED

Replace the front airbag sensor LH and RH (see page

DI–1147

).

RS0BS–07

–

SUPPLEMENTAL RESTRAINT SYSTEM

FRONT AIRBAG SENSOR

RS–89

3372

REPLACEMENT

REPLACEMENT REQUIREMENTS
In the following cases, replace the front airbag sensor with a new one.

The SRS has been deployed in a collision. (replace both the left and right airbag sensors.)

The front airbag sensor has been found to be faulty in troubleshooting.

The front airbag sensor has been found to be faulty while checking items (see page

RS–88

).

The front airbag sensor has been dropped.

CAUTION:
For removal and installation of the front airbag sensor, see page

RS–87

 and

RS–90

. Be sure to follow

the correct procedure.
