B17614

 Gasket

RH Front Exhaust Pipe

 Gasket

 Non–reusable part

N·m (kgf·cm, ft·lbf) : Specified torque

PS Pump

Oil Dipstick and
Guide for A/T

62 (632, 46)

Ring

 Gasket

17(175, 13)

62 (632, 46)

Heated Oxygen
Sensor

 Gasket

Heated Oxygen
Sensor

 O–Ring

EM–30

–

ENGINE MECHANICAL

CYLINDER HEAD

2609

A23302

RH No.3 Timing Belt Cover

No.2 Timing
Belt Cover

LH No.3 Timing Belt Cover

Drive Belt Idler Pulley

Camshaft Position
Sensor Connector

Cover Plate

Oil Cooler Pipe

Engine Wire

7.5 (76, 66 in.·lbf)

16 (160, 12)

7.5 (76, 66 in.·lbf)

N·m (kgf·cm, ft·lbf) : Specified torque

Wire Grommet

39 (400, 29)

A23373

Timing Belt

RH Camshaft Timing Pulley

LH Camshaft Timing Pulley

Timing Belt Tensioner

Fan Bracket

Dust Boot

16 (160, 12)

32 (330, 24)

26 (270, 19)

N·m (kgf·cm, ft·lbf) : Specified torque

8.1 (83, 72 in.·lbf)

–

ENGINE MECHANICAL

CYLINDER HEAD

EM–31

2610

A23320

Rear Water
Bypass Joint

Engine Wire Protector

 Gasket

Injection Connector

Ignition Coil Connector

Ignition Coil

Throttle Control
Connector

ECT
Sensor Connector

Front Water
Bypass Joint

Water Inlet and Inlet
Housing Assembly

Water Bypass Hose

LH No.1 Timing Belt Rear Plate

 Non–reusable part

Engine Wire

 Gasket

 O–Ring

Engine Wire

Heater Hose

Throttle Body
Cover Bracket

VSV Connector
for EVAP

Fuel Return Hose

Engine Wire

EVAP Hose

Heater Hose

Wire Bracket

Fuel Inlet Hose

 Gasket

RH No.1 Timing Belt Rear Plate

 Gasket

Air Switching Valve No.2

Air Tube No.3

Air Tube No.3

 Gasket

N·m (kgf·cm, ft·lbf) : Specified torque

 Gasket

18 (185, 13)

18 (185, 13)

18 (185, 13)

7.5 (76, 66 in.·lbf)

7.5 (76, 66 in.·lbf)

 Gasket

 Gasket

7.5 (76, 66 in.·lbf)

Air Pump Assembly

16 (163, 12)

10 (102, 7)

10 (102, 7)

16 (163, 12)

EM–32

–

ENGINE MECHANICAL

CYLINDER HEAD

2611

A23321

Fuel Pressure
Pulsation Damper

* 33 (340, 24)





39 (400, 29)

PCV

18 (184, 13)

LH Delivery Pipe

N·m (kgf·cm, ft·lbf) : Specified torque

 Non–reusable part

* For use with SST

 Grommet

Injector

 O–Ring

 Insulator

Fuel Return Pipe

Front Fuel Pipe

 Gasket

 Gasket

Throttle Body Assembly

39 (400, 29)

Fuel Pressure Regulator

Vacuum Hose

RH Delivery Pipe

VSV for EVAP

VSV for Secondary Air Injection System

VSV Wire Connector
for ACIS

VSV for ACIS

7.5 (76, 66 in.·lbf)

Union

39 (400, 29)

Union

 Upper Gasket

7.5 (76, 66 in.·lbf)

7.5 (76, 66 in.·lbf)

21 (214, 15)

21 (214, 15)

Ventilation
Hose

7.5 (76, 66 in.·lbf)

7.5 (76, 66 in.·lbf)

 O–Ring

 Lower Gasket

7.5 (76, 66 in.·lbf)

18 (185, 13)

–

ENGINE MECHANICAL

CYLINDER HEAD

EM–33
