PP42N–01

–

PREPARATION

AUTOMATIC TRANSMISSION (A750E, A750F)

PP–35

93

LUBRICANT

Item

Capacity

Classification

Automatic transmission fluid

    Dry fill

    Drain and refill

10.4 liters (11.0 US qts, 9.2 lmp qts)

3.0 liters (3.2 US qts, 2.6 lmp qts)

Toyota Genuine ATF WS

PP42S–01

PP–36

–

PREPARATION

TRANSFER

94

TRANSFER

SST (Special Service Tools)

09223–15020

Oil Seal & Bearing Replacer

PLANETARY GEAR

09223–46011

Crankshaft Front Oil Seal

Replacer

TRANSFER ASSEMBLY

09316–60011

Transmission & Transfer Bearing

Replacer

REAR OUTPUT SHAFT

DRIVEN SPROCKET

TRANSFER ASSEMBLY

(09316–00011)

Replacer Pipe

REAR OUTPUT SHAFT

TRANSFER ASSEMBLY

(09316–00031)

Replacer ”B”

DRIVEN SPROCKET

(09316–00071)

Replacer ”F”

REAR OUTPUT SHAFT

09330–00021

Companion Flange Holding Tool

TRANSFER ASSEMBLY

09515–30010

Rear Wheel Bearing Replacer

PLANETARY GEAR

09554–30011

Differential Oil Seal Replacer

PLANETARY GEAR

09555–55010

Differential Drive Pinion

Bearing Replacer

PLANETARY GEAR

REAR OUTPUT SHAFT

DRIVEN SPROCKET

09612–65014

Steering Worm Bearing Puller

PLANETARY GEAR

(09612–01030)

Claw ”C”

PLANETARY GEAR

–

PREPARATION

TRANSFER

PP–37

95

(09612–01050)

Hanger Pin with Nut

PLANETARY GEAR

09631–32020

Seal Ring Tool

TRANSFER ASSEMBLY

09950–40011

Puller B Set

TRANSFER ASSEMBLY

(09951–04020)

Hanger 200

TRANSFER ASSEMBLY

(09952–04010)

Slide Arm

TRANSFER ASSEMBLY

(09953–04030)

Center Bolt 200

TRANSFER ASSEMBLY

(09954–04010)

Arm 25

TRANSFER ASSEMBLY

(09955–04051)

Claw No.5

TRANSFER ASSEMBLY

(09957–04010)

Attachment

TRANSFER ASSEMBLY

(09958–04011)

Holder

TRANSFER ASSEMBLY

09950–60010

Replacer Set

PLANETARY GEAR

TRANSFER ASSEMBLY

(09951–00320)

Replacer 32

TRANSFER ASSEMBLY

(09951–00570)

Replacer 57

PLANETARY GEAR

PP–38

–

PREPARATION

TRANSFER

96

(09951–00590)

Replacer 59

TRANSFER ASSEMBLY

09950–70010

Handle Set

PLANETARY GEAR

TRANSFER ASSEMBLY

(09951–07100)

Handle 100

PLANETARY GEAR

TRANSFER ASSEMBLY
