B12629

Example:

Correct

Wrong

Z13951

Example:

–

INTRODUCTION

FOR ALL OF VEHICLES

IN–13

13

(e)

FRONT PASSENGER AIRBAG ASSEMBLY
(1)

Always store a removed or new front passenger air-
bag assembly with the airbag deployment side fac-
ing up.
Storing the airbag assembly with the airbag deploy-
ment side facing down could cause a serious acci-
dent if the airbag deploys.

(2)

Never measure the resistance of the airbag squib
(This may cause the airbag to deploy, which is very
dangerous.).

(3)

Grease should not be applied to the front passen-
ger airbag assembly and the airbag door should not
be cleaned with any kind of detergents.

(4)

Store the airbag assembly where the ambient tem-
perature remains below 93

°

C (200

°

F), without high

humidity and away from electrical noise.

(5)

When using electric welding, first disconnect the air-
bag connector (yellow color and 2 pins) installed on
assembly before starting work.

(6)

When disposing of a vehicle or the airbag assembly
alone, the airbag should be deployed using an SST
before disposal (See page

RS–36

).

Perform the operation in a safe place away from
electrical noise.

B02129

Example:

Correct

Wrong

B01546

Example:

IN–14

–

INTRODUCTION

FOR ALL OF VEHICLES

14

(f)

SIDE AIRBAG ASSEMBLY
(1)

Always store a removed or new side airbag assem-
bly with the airbag deployment side facing up.
Storing the airbag assembly with the airbag deploy-
ment side facing down could cause a serious acci-
dent if the airbag inflates.

(2)

Never measure the resistance of the airbag squib
(This may cause the airbag to deploy, which is very
dangerous.).

(3)

Grease should not be attached to the side airbag
assembly and the surface should not be cleaned
with any kind of detergents.

(4)

Store the airbag assembly where the ambient tem-
perature remains below 93

°

C (200

°

F), without high

humidity and away from electrical noise.

(5)

When using electric welding, first disconnect the air-
bag connector (yellow color and 2 pins) under the
seat before starting work.

(6)

When disposing of a vehicle or the side airbag as-
sembly alone, the airbag should be deployed using
an SST before disposal (See page

RS–50

 or

RS–65

).

Perform the operation in a safe place away from
electrical noise.

H11622 H12060

B08604

Example:

Correct

Wrong

Clear Plastic Bag

R06952

H12059

B08605

Example:

–

INTRODUCTION

FOR ALL OF VEHICLES

IN–15

15

(g)

CURTAIN SHIELD AIRBAG ASSEMBLY
(1)

Always store a removed or new curtain shield air-
bag assembly in a clear plastic bag, and keep it in
a safe place.

NOTICE:
Protection bag is not reused.
CAUTION:
Never disassemble the curtain shield airbag assembly

(2)

Never measure the resistance of the airbag squib
(This may cause the airbag to deploy, which is very
dangerous.).

(3)

Grease should not be attached to the curtain shield
airbag assembly and the surface should not be
cleaned with any kind of detergents.

(4)

Store the airbag assembly where the ambient tem-
perature remains below 93

°

C (200

°

F), without high

humidity and away from electrical noise.

(5)

When using electric welding, first disconnect the air-
bag connector (yellow color and 2 pins) into the
instrument panel before starting work.

(6)

When disposing of a vehicle or the curtain shield air-
bag assembly alone, the airbag should be deployed
using an SST before disposal (See page

RS–73

).

Perform the operation in a safe place away from
electrical noise.

B02121

Example:

IN–16

–

INTRODUCTION

FOR ALL OF VEHICLES

16

(h)

SEAT BELT PRETENSIONER
(1)

Never measure the resistance of the seat belt pre-
tensioner (This may cause the seat belt pretension-
er activation which is very dangerous.).

(2)

Never disassemble the seat belt pretensioner.

(3)

Never install the seat belt pretensioner in another
vehicle.

(4)

Store the seat belt pretensioner where the ambient
temperature remains below 80

°

C (176

°

F) and

away from electrical noise without high humidity.

(5)

When using electric welding, first disconnect the
connector (yellow color and 2 pins) before starting
work.

(6)

When disposing of a vehicle or the seat belt preten-
sioner alone, the seat belt pretensioner should be
activated before disposal (See page

BO–166

). Per-

form the operation in a safe place away from electri-
cal noise.

(7)

The seat belt pretensioner is hot after activation, so
let it cool down sufficiently before the disposal.
However never apply water to the seat belt preten-
sioner.
