652

9-1. Specifications

■

Engine number

The engine number is stamped on the engine block as shown.



2.7 L 4-cylinder (1AR-FE)
engine



3.5 L V6 (2GR-FKS) engine

653

9-1. Specifications

9

Vehi

cl

e specificatio

ns

Engine

Model

1AR-FE

2GR-FKS

Type

4-cylinder in line,
4-cycle, gasoline

6-cylinder V type,
4-cycle, gasoline

Bore and stroke

3.54

× 4.13 in.

(90.0

× 105.0 mm)

3.70

× 3.27 in.

(94.0

× 83.0 mm)

Displacement

163.1 cu. in.



(2672 cm

3

)

210.9 cu. in.



(3456 cm

3

)

Valve clearance

Automatic adjustment

Drive belt tension

Fuel

Fuel type

Unleaded gasoline only

Octane rating

87 (Research Octane Number 91) or higher

Fuel tank capacity
(Reference)

19.2 gal. (72.5 L, 15.9 Imp. gal.)

654

9-1. Specifications

*

: The engine oil capacity is a reference quantity to be used when changing

the engine oil. Warm up and turn off the engine, wait more than 5 minutes,
and check the oil level on the dipstick.

■

Engine oil selection

“Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use
Toyota approved “Toyota Genuine Motor Oil” or equivalent to satisfy
the following grade and viscosity.

Oil grade: ILSAC GF-5 multigrade engine oil

Recommended viscosity: SAE 0W-20

SAE 0W-20 is the best choice
for good fuel economy and
good starting in cold weather.
If SAE 0W-20 is not available,
SAE 5W-20 oil may be used.
However, it must be replaced
with SAE 0W-20 at the next oil
change.

Lubrication system

Oil capacity
(Drain and refill

⎯ reference

*

)

With filter



2.7 L 4-cylinder (1AR-FE) engine

4.6 qt. (4.4 L, 3.9 Imp. qt.)



3.5 L V6 (2GR-FKS) engine

5.8 qt. (5.5 L, 4.8 Imp. qt.)

Without filter



2.7 L 4-cylinder (1AR-FE) engine

4.2 qt. (4.0 L, 3.5 Imp. qt.)



3.5 L V6 (2GR-FKS) engine

5.6 qt. (5.3 L, 4.7 Imp. qt.)

Outside temperature

655

9-1. Specifications

9

Vehi

cl

e specificatio

ns

Oil viscosity (0W-20 is explained here as an example):

• The 0W in 0W-20 indicates the characteristic of the oil which

allows cold startability. Oils with a lower value before the W allow
for easier starting of the engine in cold weather.

• The 20 in 0W-20 indicates the viscosity characteristic of the oil

when the oil is at high temperature. An oil with a higher viscosity
(one with a higher value) may be better suited if the vehicle is
operated at high speeds, or under extreme load conditions.

How to read oil container label:
The International Lubricant Specification Advisory  Committee
(ILSAC) Certification Mark is added to some oil containers to help
you select the oil you should use.
