8-2. Steps to take in an emergency

Indicates that the system is temporarily unavail-
able due to a malfunction in a sensor other than
the camera sensor

A buzzer also sounds.

→ Turn the LDA (Lane Departure Alert with

steering control) system off, wait for a little
while, and then turn the LDA (Lane Depar-
ture Alert with steering control) system
back on.

(If equipped)

Indicates that a Blind Spot Monitor sensor or the
surrounding area on the rear bumper is dirty or
covered with snow, ice, etc. or that a sensor is
misaligned

A buzzer also sounds.

→ Clean off the dirt, snow, ice, etc. and drive

the vehicle with the operation conditions of
the BSM function (

→P. 321) satisfied for

approximately 10 minutes. If the warning
message does not disappear, the sensor
may be misaligned. Have the vehicle
inspected by your Toyota dealer.

Indicates a malfunction in the dynamic radar
cruise control system.

• Press the “ON-OFF” button once to deacti-

vate the system, and then press the button
again to reactivate the system.

• A buzzer also sounds.

→ Have the vehicle inspected by your Toyota

dealer.

Indicates a malfunction in the LDA (Lane Depar-
ture Alert with steering control) system

A buzzer also sounds.

→ Have the vehicle inspected by your Toyota

dealer.

Warning message

Details/Actions

(Amber)

(Amber)

597

8-2. Steps to take in an emergency

8

Wh

en tro

uble

 a

ris

es

The operation conditions of the camera sensor
(temperature, etc.) are not met.
→ When the operation conditions of the cam-

era sensor (temperature, etc.) are met, the
following systems will become available.

• PCS (Pre-Collision System)
• LDA (Lane Departure Alert with steering con-

trol) system

• Dynamic radar cruise control
• Automatic High Beam

Dirt, rain, condensation, ice, snow, etc., are pres-
ent on the windshield in front of the camera sen-
sor
The following systems will be temporarily unus-
able.
• PCS (Pre-Collision System)
• LDA (Lane Departure Alert with steering con-

trol) system

• Dynamic radar cruise control
• Automatic High Beam
→ Tum the system off, remove any dirt, rain,

condensation, ice, snow, etc., from the
windshield, and then turn the system back
on.

Indicates a malfunction in the pre-collision sys-
tem

A buzzer also sounds.

→ Have the vehicle inspected by your Toyota

dealer.

(If equipped)

Indicates a malfunction in the BSM (Blind Spot
Monitor) system

A buzzer also sounds.

→ Have the vehicle inspected by your Toyota

dealer.

Warning message

Details/Actions

(Flashes)

(Amber)

(Flashes)

(Amber)

(Flashes)

598

8-2. Steps to take in an emergency

Indicates abnormal engine oil pressure

A buzzer also sounds.

→ Immediately stop the vehicle in a safe place

and contact your Toyota dealer.

Indicates that the automatic transmission fluid
temperature is too high

A buzzer also sounds.

→ Have the vehicle inspected by your Toyota

dealer.

(AWD models)

Indicates a malfunction in the AWD system

A buzzer also sounds.

→ Have the vehicle inspected by your Toyota

dealer.

Indicates that the LDA (Lane Departure Alert with
steering control) system cannot be used as the
vehicle speed is approximately 32 mph (50 km/h)
or less
→ Drive the vehicle at approximately 32 mph

(50 km/h) or more.

Indicates that LDA (Lane Departure Alert with
steering control) system cannot be used due to
the vehicle speed being too high
→ Slow down.

Warning message

Details/Actions

599

8-2. Steps to take in an emergency

8

Wh

en tro

uble

 a

ris

es

Indicates a malfunction in the Stop & Start system

A buzzer also sounds.

→ Have the vehicle inspected by your Toyota

dealer.

Indicates that the engine was stopped while driv-
ing

A buzzer also sounds.

→ Operate the steering wheel with more force

than usual.

Indicates that the engine switch is turned off or
turned to ACCESSORY mode and the driver’s
door is opened while the lights are turned on

A buzzer also sounds.

→ Turn the lights off.

(If equipped)

Indicates that the moon roof or panoramic moon
roof is not fully closed (with the engine switch off,
and the driver’s door open)

A buzzer also sounds.

→ Close the moon roof or panoramic moon

roof.

(AWD models)

Indicates that the AWD system is not currently
functional

A buzzer also sounds.

→ Reduce vehicle speed or stop the vehicle in

a safe place until the warnings clear. In this
case, do not stop the engine.

Warning message

Details/Actions

(Flashes)

(Flashes)

(Flashes)

(Flashes)
