Toyota Highlander (2018 year). Manual - part 137

560

7-3. Do-it-yourself maintenance

■

Headlight high beams/daytime running lights (if equipped)

Turn the bulb base counter-
clockwise.

Unplug the connector while
pressing the lock release.

Replace the light bulb, and
install the bulb base.

Align the 3 tabs on the light bulb
with the mounting, and insert.

Turn and secure the bulb
base.

Shake the bulb base gently to
check that it is not loose, turn
the headlights on once and visu-
ally confirm that no light is leak-
ing through the mounting.

1

2

3

4

561

7-3. Do-it-yourself maintenance

7

Mainten

ance an

d ca

re

■

Front turn signal lights/parking lights (if equipped)

Remove the 2 clips and
remove the side cover.

Turn the bulb base counter-
clockwise.

Remove the light bulb.

Install by conducting

 and

 with the directions reversed.

Install the side cover and
then install the 2 clips.

1

2

3

4

3

2

5

562

7-3. Do-it-yourself maintenance

■

Front side marker lights

Remove the 2 clips and
remove the side cover.

Turn the bulb base counter-
clockwise.

Remove the light bulb.

Install by conducting

 and

 with the directions reversed.

Install the side cover and
then install the 2 clips.

1

2

3

4

2

3

5

563

7-3. Do-it-yourself maintenance

7

Mainten

ance an

d ca

re

■

Front fog lights (if equipped)

Remove the 3 screws and
partly remove the fender
liner.

Unplug the connector while
pressing the lock release.

Turn the bulb base counter-
clockwise.

Install a new light bulb.

Align the 3 tabs on the light bulb
with the mounting and insert.

1

2

3

4
