480

6-4. Using the other interior features



Type A

Fold down the armrest for use.



Type B

Lower the armrest from the
highest position to the lowest
position.

Raise the armrest to the
desired angle.

To unlock the armrest, lift the arm-
rest to raise it to the highest posi-
tion.

Armrest

1

2

NOTICE

To prevent damage to the armrest, do not apply too much load on the arm-
rest.

481

6-4. Using the other interior features

6

In

te

rior fe

atures

Coat hooks are provided on the
rear assist grips.

An assist grip installed on the ceil-
ing can be used to support your
body while sitting on the seat.

Coat hooks

WARNING

Do not hang coat hangers or other hard or sharp objects on the hook. If the
SRS curtain shield airbags deploy, these items may become projectiles,
causing death or serious injury.

Assist grips

WARNING

Do not use the assist grip when getting in or out of the vehicle or rising from
your seat.

NOTICE

To prevent damage to the assist grip, do not hang any heavy object or put a
heavy load on the assist grip.

482

6-4. Using the other interior features

Fold the side table up for use.

Side table (if equipped)

■

To stowing the side table
To fold down the side table, pull up the
lever to release the lock. Hold the table to
let it lower slowly until you hear a click.

WARNING

When not in use, store the side table at the fully lowered position.

NOTICE

To prevent damage to the side table, do not place very heavy objects on it.

483

6-4. Using the other interior features

6

In

te

rior fe

atures

The garage door opener (HomeLink



 Universal Transceiver) is manu-

factured under license from HomeLink



.

The HomeLink

®

 compatible transceiver in your vehicle has 3 buttons

which can be programmed to operate 3 different devices. Refer to the
programming method below appropriate for the device.

Buttons

HomeLink

®

 indicator light

Garage door operation indica-
tors

■

Before programming HomeLink

®

● During programming, it is possible that garage doors, gates, or

other devices may operate. For this reason, make sure that peo-
ple and objects are clear of the garage door or other devices to
prevent injury or other potential harm.

● It is recommended that a new battery be placed in the remote

control transmitter for more accurate programming.

● Garage door openers manufactured after 1995 may be equipped

with rolling code protection. If this is the case, you will need a
stepladder or other sturdy, safe device to reach the “learn” or
“smart” button on the garage door opener motor.

Garage door opener

∗

∗

: If equipped

The garage door opener can be programmed to operate garage
doors, gates, entry doors, door locks, home lighting systems,
security systems, and other devices.

Programming the HomeLink

®

1
2
3
