Toyota Highlander (2018 year). Manual - part 96

396

5-8. Bluetooth

®

 Audio

You can check such indicators as signal strength and battery charge
on the screen.

Connection status

Battery charge

Select

 or

 to Play/Pause.

For details on “Bluetooth

*

 Audio” screen operation methods, refer to

Basic Audio Operations. (

→P. 356)

For details on how to select a track or album, refer to selecting, fast-
forwarding and reversing tracks/files/songs. (

→P. 365)

*

: Bluetooth is a registered trademark of Bluetooth SIG, Inc.

Listening to Bluetooth

®

 Audio

The Bluetooth

®

 audio system enables the user to enjoy music

played on a portable player from the vehicle speakers via wire-
less communication.

When a Bluetooth

®

 device cannot be connected, check the connec-

tion status on the “Bluetooth

*

 Audio” screen. If the device is not con-

nected, either register or reconnect the device. (

→P. 392)

*

: Bluetooth is a registered trademark of Bluetooth SIG, Inc.

Status display

1
2

Indicators

Conditions

Connection status

Good

Not connected

Battery charge

Full

Empty

Playing Bluetooth

®

 audio

397

5

Audi

o system

5-9. Bluetooth

®

 phone

To display the screen shown below, press the off-hook switch on the
steering wheel or the

 button.

Several functions are available to operate on each screen that is dis-
played by selecting the 4 tabs.

Device name

Bluetooth

®

 connection status

Using a Bluetooth

®

 Phone

The hands-free system is a function that allows you to use your
cellular phone without touching it.

This system supports Bluetooth

®

. Bluetooth

®

 is a wireless data

system that allows the cellular phone to wirelessly connect to
the hands-free system and make/receive calls.

Before making a phone call, check the connection status, battery
charge, call area and signal strength. (

→P. 398)

If a Bluetooth

®

 device cannot be connected, check the connection

status on the phone screen. If the device is not connected, either
register or reconnect it. (

→P. 392)

Phone screen

1
2

398

5-9. Bluetooth

®

 phone

■

Telephone switch (

→P. 410)

■

Microphone

The vehicle’s built in micro-
phone is used when talking on
the phone.

The person you are speaking to
can be heard from the front
speakers.

To use the hands-free system,
you must register your
Bluetooth

®

 phone in the sys-

tem. (

→P. 390)

You can check indicators such as signal strength and battery charge
on the phone screen.

Connection status

Signal strength

Battery charge

Status display

1
2
3

Indicators

Conditions

Connection status

Good

Poor

Not connected

Battery charge

Full

Empty

Call area

“Rm”: Roaming area

Signal strength

Excellent

Poor

399

5-9. Bluetooth

®

 phone

5

Audi

o system

Display the phone screen. (

→P. 397)

Select the “Dial Pad” tab and enter a phone number.

To delete the input phone number, select

.

For the first digit, you can enter “+” by selecting “

∗” for a while.

Press the off-hook switch on the steering wheel or select

.

You can dial a number from the contact data imported from your cellu-
lar phone. The system has one contact for each registered phone. Up
to 2500 contacts may be stored in each contact. (

→P. 399)

Display the phone screen. (

→P. 397)

Select “Contacts” tab.

Choose the desired contact to call from the list.

Choose the number and then press the off-hook switch on the
steering wheel or select

.

You can transfer the phone numbers in a Bluetooth

®

 phone to the sys-

tem.
Operation methods differ between PBAP (Phone Book Access Profile)
compatible and PBAP incompatible Bluetooth

®

 phones. If the cellular

phone does not support either PBAP or OPP (Object Push Profile)
service, you cannot transfer contacts.

Making a call

Once a Bluetooth

®

 phone is registered, you can make a call

using the following procedure:

Dialing

Dialing from the contacts list

When the contact is empty

1
2

3

1
2
3
4
