372

5-5. Playing an audio CD and MP3/WMA/AAC discs

●

AAC file compatibility

• Compatible standards

MPEG4/AAC-LC

• Compatible sampling frequencies

11.025/12/16/22.05/24/32/44.1/48 (kHz)

• Compatible bit rates

16-320 (kbps)

Compatible channel modes: 1ch and 2ch

●

Compatible media

Media that can be used for MP3, WMA and AAC playback are CD-Rs and
CD-RWs.

Playback in some instances may not be possible if the CD-R or CD-RW is
not finalized. Playback may not be possible or the audio may jump if the
disc is scratched or marked with fingerprints.

●

Compatible disc formats

The following disc formats can be used.

• Disc formats: CD-ROM Mode 1 and Mode 2

CD-ROM XA Mode 2, Form 1 and Form 2

• File formats: ISO9660 Level 1, Level 2, (Romeo, Joliet)

UDF (2.01 or lower)

MP3, WMA and AAC files written in any format other than those listed
above may not play correctly, and their file names and folder names may
not be displayed correctly.

Items related to standards and limitations are as follows.

• Maximum directory hierarchy: 8 levels (including the root)
• Maximum length of folder names/file names: 32 characters
• Maximum number of folders: 192 (including the root)
• Maximum number of files per disc: 255

●

File names

The only files that can be recognized as MP3/WMA/AAC and played are
those with the extension .mp3, .wma or .m4a.

●

Discs containing multi-session recordings

As Entune Audio is compatible with multi session discs, it is possible to play
discs that contain MP3, WMA and AAC files. However, only the first session
can be played.

373

5-5. Playing an audio CD and MP3/WMA/AAC discs

5

Audi

o system

●

ID3, WMA and AAC tags

ID3 tags can be added to MP3 files, making it possible to record the track
title, artist name, etc.

The system is compatible with ID3 Ver. 1.0, 1.1, and Ver. 2.2, 2.3 ID3 tags.
(The number of characters is based on ID3 Ver. 1.0 and 1.1.)

WMA tags can be added to WMA files, making it possible to record the
track title and artist name in the same way as with ID3 tags.

AAC tags can be added to AAC files, making it possible to record the track
title and artist name in the same way as with ID3 tags.

●

MP3, WMA and AAC playback

When a disc containing MP3, WMA or AAC files is inserted, all files on the
disc are first checked. Once the file check is finished, the first MP3, WMA or
AAC file is played. To make the file check finish more quickly, we recom-
mend you do not write any files to the disc other than MP3, WMA or AAC
files or create any unnecessary folders.

Discs that contain a mixture of music data and MP3, WMA or AAC format
data cannot be played.

●

Extensions

If the file extensions .mp3, .wma and .m4a are used for files other than
MP3, WMA and AAC files, they may be mistakenly recognized and played
as MP3, WMA and AAC files. This may result in large amounts of interfer-
ence and damage to the speakers.

●

Playback

• To play MP3 files with steady sound quality, we recommend a fixed bit

rate of at least 128 kbps and a sampling frequency of 44.1 kHz.

• CD-R or CD-RW playback may not be possible in some instances,

depending on the characteristics of the disc.

• There is a wide variety of freeware and other encoding software for MP3,

WMA and AAC files on the market, and depending on the status of the
encoding and the file format, poor sound quality or noise at the start of
playback may result. In some cases, playback may not be possible at all.

• When files other than MP3, WMA or AAC files are recorded on a disc, it

may take more time to recognize the disc and in some cases, playback
may not be possible at all.

• Microsoft, Windows, and Windows Media are the registered trademarks

of Microsoft Corporation in the U.S.A. and other countries.

374

5-5. Playing an audio CD and MP3/WMA/AAC discs

NOTICE

■

Discs and adapters that cannot be used
Do not use the following types of CDs.

Also, do not use 3 in. (8 cm) CD adapters, Dual Discs or printable discs.

Doing so may damage the CD player and/or the CD insert/eject function.

●

Discs that have a diameter that is not 4.7 in. (12 cm).

●

Low-quality or deformed discs.

●

Discs with a transparent or translucent recording area.

●

Discs that have tape, stickers or CD-R labels attached to them, or that
have had the label peeled off.

■

Player precautions
Failure to follow the precautions below may result in damage to the discs or
the player itself.

●

Do not insert anything other than discs into the disc slot.

●

Do not apply oil to the player.

●

Store discs away from direct sunlight.

●

Never try to disassemble any part of the player.

375

5

Audi

o system

5-6. Using an external device

→P. 355

Pressing the “AUDIO” button displays the audio control screen from
any screens of the selected source.

Audio source selection screen
appears

Displays cover art

Selecting the play mode
(

→P. 375)

Shuffle play (

→P. 375)

Repeat play (

→P. 375)

Pause
Select

 to resume playback

Setting the sound (

→P. 366)

Select “Browse” on the screen.

Select the desired play mode. Then select a song to begin using
the selected play mode.

Select

 to change on/off.

Select

 to change on/off.

Listening to an iPod

Connecting an iPod enables you to enjoy music from the vehicle
speakers.

Select “iPod” on the audio source selection screen.

When the iPod connected to the system includes iPod video, the
system can only output the sound by selecting the browse
screen.

Connecting an iPod

Audio control screen

1

2
3

4
5
6

Selecting a play mode

Shuffle play

Repeat play

7

1
2
