172

3-5. Opening and closing the windows

The power windows can be opened and closed using the switches.
Operating the switch moves the windows as follows:



Models available with one touch opening/closing on the front side
windows

Closing

One-touch closing (front side
windows only)

*

Opening

One-touch opening (front side
windows only)

*

*

: To stop the window partway, oper-

ate the switch in the opposite direc-
tion.



Models available with one touch opening/closing on all side win-
dows

Closing

One-touch closing

*

Opening

One-touch opening

*

*

: To stop the window partway, oper-

ate the switch in the opposite direc-
tion.

Power windows

Opening and closing procedures

1
2

3
4

1
2
3
4

173

3-5. Opening and closing the windows

3

Op
eration

 o

f each

 compo

nen

t

Press the switch to lock the pas-
senger window switches.

Use this switch to prevent children
from accidentally opening or clos-
ing a passenger window.

Models available with one touch
opening/closing on the front side
windows: If the lock switch is on,
the passenger window switches on
the driver’s side are also locked.

Models available with one touch opening/closing on all side windows: If the
lock switch is on, the passenger windows can still be opened and closed
using the power window switches on the driver’s side.

■

The power windows can be operated when



Vehicles without a smart key system

The engine switch is in the “ON” position.



Vehicles with a smart key system

The engine switch is in IGNITION ON mode.

■

Operating the power windows after turning the engine off



Vehicles without a smart key system

The power windows can be operated for approximately 45 seconds even
after the engine switch is turned to the “ACC” or “LOCK” position. They can-
not, however, be operated once either front door is opened.



Vehicles with a smart key system

The power windows can be operated for approximately 45 seconds even
after the engine switch is turned to ACCESSORY mode or turned off. They
cannot, however, be operated once either front door is opened.

■

Jam protection function (windows with one-touch closing function only)
If an object becomes caught between the window and the window frame, win-
dow travel is stopped and the window is opened slightly.

Window lock switch

174

3-5. Opening and closing the windows

■

When the power window does not close normally (windows with one-
touch closing function only)
If the jam protection function is operating abnormally and a window cannot be
closed, perform the following operations using the power window switch on
the relevant door.

●

Vehicles without a smart key system: After stopping the vehicle, the window
can be closed by holding the power window switch in the one-touch closing
position while the engine switch is turned to the “ON” position.

Vehicles with a smart key system: After stopping the vehicle, the window
can be closed by holding the power window switch in the one-touch closing
position while the engine switch is turned to IGNITION ON mode.

●

If the window still cannot be closed even by carrying out the operation
explained above, initialize the function by performing the following proce-
dure.

Hold the power window switch in the one-touch closing position. Continue
holding the switch for a further 6 seconds after the window has closed.

Hold the power window switch in the one-touch opening position. Con-
tinue holding the switch for a further 2 seconds after the window has
opened completely.

Hold the power window switch in the one-touch closing position once
again. Continue holding the switch for a further 2 seconds after the win-
dow has closed.

If you release the switch while the window is moving, start again from the
beginning.
If the window continues to close but then re-open slightly even after perform-
ing the above procedure correctly, have the vehicle inspected by your Toyota
dealer.

■

Door lock linked window operation (windows with one-touch closing
function only)

●

The power windows can be opened and closed using the key or mechanical

key.

*

(

→P. 117, 635)

●

The power windows can be opened using the wireless remote control.

*

(

→P. 116)

*

: These settings must be customized at your Toyota dealer.

■

Customization
Settings (e.g. linked door lock operation) can be changed.
(Customizable features:

→P. 680)

1

2

3

175

3-5. Opening and closing the windows

3

Op
eration

 o

f each

 compo

nen

t

WARNING

Observe the following precautions.
Failure to do so may result in death or serious injury.

■

Closing the windows

●

The driver is responsible for all the power window operations, including the
operation for the passengers. In order to prevent accidental operation,
especially by a child, do not let a child operate the power windows. It is
possible for children and other passengers to have body parts caught in
the power window. Also, when riding with a child, it is recommended to use
the window lock switch. (

→P. 173)

●

Check to make sure that all passengers do not have any part of their body
in a position where it could be caught when a window is being operated.

●

When using the wireless remote control, key or mechanical key and oper-
ating the power windows, operate the power window after checking to
make sure that there is no possibility of any passenger having any of their
body parts caught in the window. Also do not let a child operate window by
the wireless remote control, key or mechanical key. It is possible for chil-
dren and other passengers to get caught in the power window.

●

When exiting the vehicle, turn the engine switch off, carry the key and exit
the vehicle along with the child. There may be accidental operation, due to
mischief, etc., that may possibly lead to an accident.

■

Jam protection function (windows with one-touch closing function
only)

●

Never use any part of your body to intentionally activate the jam protection
function.

●

The jam protection function may not work if something gets caught just
before the window fully closes.
