Toyota Highlander (2018 year). Manual - part 14

68

1-1. For safe use



Type B

Latch the buckles onto the
LATCH anchors.

If the child restraint has a top
tether strap, the top tether strap
should be latched onto the top
tether strap anchor.

For owners in Canada:
The symbol on a child restraint
system indicates the presence
of a lower connector system.

Canada only

3

69

1-1. For safe use

1

Fo
r

safety and securi

ty

■

Rear-facing

⎯ Infant seat/convertible seat

Adjusting the seat



Second seats

Fold the seatback while pulling
the lever. Return the seatback
and secure it at the 1st lock
position (most upright position).

Move the seat as far back as
possible.



Third seats

Fold the seatback while pulling
the strap. Return the seatback
and secure it at the 1st lock
position (most upright position).

Place the child restraint sys-
tem on the rear seat facing
the rear of the vehicle.

Installing child restraints using a seat belt (child restraint lock
function belt)

1

2

70

1-1. For safe use

Run the seat belt through the
child restraint system and
insert the plate into the
buckle. Make sure that the
belt is not twisted.

Fully extend the shoulder belt
and allow it to retract to put it
in lock mode. In lock mode,
the belt cannot be extended.

While pushing the child
restraint system down into
the rear seat, allow the
shoulder belt to retract until
the child restraint system is
securely in place.

After the shoulder belt has
retracted to a point where there
is no slack in the belt, pull the
belt to check that it cannot be
extended.

3

4

5

71

1-1. For safe use

1

Fo
r

safety and securi

ty

■

Forward-facing

⎯ Convertible seat

Adjusting the seat



Second seats

Fold the seatback while pulling
the lever. Return the seatback
and secure it at the 1st lock
position (most upright position).

Move the seat as far back as
possible.



Third seats

Fold the seatback while pulling
the strap. Return the seatback
and secure it at the 1st lock
position (most upright position).

Place the child restraint sys-
tem on the seat facing the
front of the vehicle.

If your child restraint system
interferes with a head restraint
and cannot be installed properly,
install the child restraint system
after removing the head
restraint. (

→P. 163)

1

2
