Toyota Tundra (2015 year). Manual - part 2395
32. INSTALL FRONT DOOR SCUFF PLATE LH
(a) Attach the 6 claws and 3 clips to install the front door scuff plate LH.
33. INSTALL FRONT DOOR SCUFF PLATE RH
HINT:
Use the same procedure described for the LH side.
34. INSTALL REAR SEAT ASSEMBLY (for LH Side)
35. INSTALL REAR SEAT ASSEMBLY (for RH Side)
36. INSTALL FRONT SEAT ASSEMBLY (for Center Seat)
37. INSTALL FRONT SEAT ASSEMBLY (for Manual Seat)
38. INSTALL FRONT SEAT ASSEMBLY (for Power Seat)
39. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
NOTICE:
When disconnecting the cable, some systems need to be initialized after the cable is reconnected
.
40. CHECK SRS WARNING LIGHT
INTERIOR: ROOF HEADLINING (for CrewMax): INSTALLATION; 20...
