Toyota Tundra (2015 year). Manual - part 1775
Last Modified: 9-16-2014
6.6 A
Doc ID: RM000002I2W03DX
Model Year: 2015
Model: Tundra
Prod Date Range: [08/2014 - ]
Title: 3UR-FBE IGNITION: IGNITION COIL AND SPARK PLUG: INSTALLATION; 2015 MY Tundra [08/2014 -
]
INSTALLATION
1. INSTALL SPARK PLUG
(a) Using a 16 mm plug wrench, install the 8 spark plugs.
Torque:
21 N·m {214 kgf·cm, 15ft·lbf}
2. INSTALL IGNITION COIL ASSEMBLY
(a) Install the 8 ignition coils with the 8 bolts.
Torque:
10 N·m {102 kgf·cm, 7ft·lbf}
(b) Connect the 8 ignition coil connectors.
3. INSTALL AIR CLEANER ASSEMBLY
4. INSTALL AIR CLEANER HOSE ASSEMBLY
5. INSTALL V-BANK COVER SUB-ASSEMBLY
