DTC

CODE

DETECTION ITEM

MIL

MEMORY

SEE

PAGE

P0024

Camshaft Position "B" - Timing Over-Advanced or System

Performance (Bank 2)

Comes on

DTC

stored

P0025

Camshaft Position "B" - Timing Over-Retarded (Bank 2)

Comes on

DTC

stored

P0031

Oxygen (A/F) Sensor Heater Control Circuit Low (Bank 1 Sensor

1)

Comes on

DTC

stored

P0032

Oxygen (A/F) Sensor Heater Control Circuit High (Bank 1 Sensor

1)

Comes on

DTC

stored

P0037

Oxygen Sensor Heater Control Circuit Low (Bank 1 Sensor 2)

Comes on

DTC

stored

P0038

Oxygen Sensor Heater Control Circuit High (Bank 1 Sensor 2)

Comes on

DTC

stored

P0051

Oxygen (A/F) Sensor Heater Control Circuit Low (Bank 2 Sensor

1)

Comes on

DTC

stored

P0052

Oxygen (A/F) Sensor Heater Control Circuit High (Bank 2 Sensor

1)

Comes on

DTC

stored

P0057

Oxygen Sensor Heater Control Circuit Low (Bank 2 Sensor 2)

Comes on

DTC

stored

P0058

Oxygen Sensor Heater Control Circuit High (Bank 2 Sensor 2)

Comes on

DTC

stored

P006A

MAP - Mass or Volume Air Flow Correlation Bank 1

Comes on

DTC

stored

P0101

Mass Air Flow Circuit Range / Performance Problem

Comes on

DTC

stored

P0102

Mass Air Flow Circuit Low

Comes on

DTC

stored

P0103

Mass Air Flow Circuit High

Comes on

DTC

stored

P0107

Manifold Absolute Pressure / Barometric Pressure Circuit Low

Input

Comes on

DTC

stored

P0108

Manifold Absolute Pressure / Barometric Pressure Circuit High

Input

Comes on

DTC

stored

P0111

Intake Air Temperature Sensor 1 Circuit Range / Performance

Comes on

DTC

stored

P0112

Intake Air Temperature Circuit Low Input

Comes on

DTC

stored

P0113

Intake Air Temperature Circuit High Input

Comes on

DTC

stored

P0115

Engine Coolant Temperature Circuit Malfunction

Comes on

DTC

stored

1UR-FE ENGINE CONTROL SYSTEM: SFI SYSTEM: DIAGNOSTI...

DTC

CODE

DETECTION ITEM

MIL

MEMORY

SEE

PAGE

P0116

Engine Coolant Temperature Circuit Range / Performance

Problem

Comes on

DTC

stored

P0117

Engine Coolant Temperature Circuit Low Input

Comes on

DTC

stored

P0118

Engine Coolant Temperature Circuit High Input

Comes on

DTC

stored

P011B

Engine Coolant Temperature / Intake Air Temperature

Correlation

Comes on

DTC

stored

P0120

Throttle / Pedal Position Sensor / Switch "A" Circuit

Comes on

DTC

stored

P0121

Throttle Pedal Position Sensor / Switch "A" Circuit Range /

Performance

Comes on

DTC

stored

P0122

Throttle / Pedal Position Sensor / Switch "A" Circuit Low Input

Comes on

DTC

stored

P0123

Throttle / Pedal Position Sensor / Switch "A" Circuit High Input

Comes on

DTC

stored

P0125

Insufficient Coolant Temperature for Closed Loop Fuel Control

Comes on

DTC

stored

P0128

Thermostat

Comes on

DTC

stored

P0136

Oxygen Sensor Circuit (Bank 1 Sensor 2)

Comes on

DTC

stored

P0137

Oxygen Sensor Circuit Low Voltage (Bank 1 Sensor 2)

Comes on

DTC

stored

P0138

Oxygen Sensor Circuit High Voltage (Bank 1 Sensor 2)

Comes on

DTC

stored

P0139

Oxygen Sensor Circuit Slow Response (Bank 1 Sensor 2)

Comes on

DTC

stored

P013A

Oxygen Sensor Slow Response - Rich to Lean Bank 1 Sensor 2

Comes on

DTC

stored

P013C

Oxygen Sensor Slow Response - Rich to Lean Bank 2 Sensor 2

Comes on

DTC

stored

P0141

Oxygen Sensor Heater Circuit (Bank 1 Sensor 2)

Comes on

DTC

stored

P014C

A/F Sensor Slow Response - Rich to Lean Bank 1 Sensor 1

Comes on

DTC

stored

P014D

A/F Sensor Slow Response - Lean to Rich Bank 1 Sensor 1

Comes on

DTC

stored

P014E

A/F Sensor Slow Response - Rich to Lean Bank 2 Sensor 1

Comes on

DTC

stored

1UR-FE ENGINE CONTROL SYSTEM: SFI SYSTEM: DIAGNOSTI...

DTC

CODE

DETECTION ITEM

MIL

MEMORY

SEE

PAGE

P014F

A/F Sensor Slow Response - Lean to Rich Bank 2 Sensor 1

Comes on

DTC

stored

P0156

Oxygen Sensor Circuit (Bank 2 Sensor 2)

Comes on

DTC

stored

P0157

Oxygen Sensor Circuit Low Voltage (Bank 2 Sensor 2)

Comes on

DTC

stored

P0158

Oxygen Sensor Circuit High Voltage (Bank 2 Sensor 2)

Comes on

DTC

stored

P0159

Oxygen Sensor Circuit Slow Response (Bank 2 Sensor 2)

Comes on

DTC

stored

P015A

A/F Sensor Delayed Response - Rich to Lean Bank 1 Sensor 1

Comes on

DTC

stored

P015B

A/F Sensor Delayed Response - Lean to Rich Bank 1 Sensor 1

Comes on

DTC

stored

P015C

A/F Sensor Delayed Response - Rich to Lean Bank 2 Sensor 1

Comes on

DTC

stored

P015D

A/F Sensor Delayed Response - Lean to Rich Bank 2 Sensor 1

Comes on

DTC

stored

P0161

Oxygen Sensor Heater Circuit (Bank 2 Sensor 2)

Comes on

DTC

stored

P0171

System Too Lean (Bank 1)

Comes on

DTC

stored

P0172

System Too Rich (Bank 1)

Comes on

DTC

stored

P0174

System Too Lean (Bank 2)

Comes on

DTC

stored

P0175

System Too Rich (Bank 2)

Comes on

DTC

stored

P0220

Throttle / Pedal Position Sensor / Switch "B" Circuit

Comes on

DTC

stored

P0222

Throttle / Pedal Position Sensor / Switch "B" Circuit Low Input

Comes on

DTC

stored

P0223

Throttle / Pedal Position Sensor / Switch "B" Circuit High Input

Comes on

DTC

stored

P0300

Random / Multiple Cylinder Misfire Detected

Comes

on/Blinks *

DTC

stored

P0301

Cylinder 1 Misfire Detected

Comes

on/Blinks *

DTC

stored

P0302

Cylinder 2 Misfire Detected

Comes

on/Blinks *

DTC

stored

1UR-FE ENGINE CONTROL SYSTEM: SFI SYSTEM: DIAGNOSTI...

DTC

CODE

DETECTION ITEM

MIL

MEMORY

SEE

PAGE

P0303

Cylinder 3 Misfire Detected

Comes

on/Blinks *

DTC

stored

P0304

Cylinder 4 Misfire Detected

Comes

on/Blinks *

DTC

stored

P0305

Cylinder 5 Misfire Detected

Comes

on/Blinks *

DTC

stored

P0306

Cylinder 6 Misfire Detected

Comes

on/Blinks *

DTC

stored

P0307

Cylinder 7 Misfire Detected

Comes

on/Blinks *

DTC

stored

P0308

Cylinder 8 Misfire Detected

Comes

on/Blinks *

DTC

stored

P0327

Knock Sensor 1 Circuit Low Input (Bank 1 or Single Sensor)

Comes on

DTC

stored

P0328

Knock Sensor 1 Circuit High Input (Bank 1 or Single Sensor)

Comes on

DTC

stored

P032C

Knock Sensor 3 Circuit Low

Comes on

DTC

stored

P032D

Knock Sensor 3 Circuit High

Comes on

DTC

stored

P0332

Knock Sensor 2 Circuit Low Input (Bank 2)

Comes on

DTC

stored

P0333

Knock Sensor 2 Circuit High Input (Bank 2)

Comes on

DTC

stored

P0335

Crankshaft Position Sensor "A" Circuit

Comes on

DTC

stored

P0337

Crankshaft Position Sensor "A" Circuit Low Input

Comes on

DTC

stored

P0338

Crankshaft Position Sensor "A" Circuit High Input

Comes on

DTC

stored

P0339

Crankshaft Position Sensor "A" Circuit Intermittent

-

DTC

stored

P033C

Knock Sensor 4 Circuit Low Input

Comes on

DTC

stored

P033D

Knock Sensor 4 Circuit High Input

Comes on

DTC

stored

P0340

Camshaft Position Sensor Circuit

Comes on

DTC

stored

P0342

Camshaft Position Sensor "A" Circuit Low Input (Bank 1 or

Single Sensor)

Comes on

DTC

stored
