Toyota Tundra. Manual - part 2235





Fig. 248: Removing Spark Plug Tube Gasket
Courtesy of TOYOTA MOTOR SALES, U.S.A., INC.

18. REMOVE WATER PUMP ASSEMBLY (See REMOVAL )

19. REMOVE TIMING CHAIN COVER SUB-ASSEMBLY (See REMOVAL )

20. REMOVE WATER INLET PIPE (See DISASSEMBLY )

21. REMOVE FRONT CRANKSHAFT OIL SEAL

a. Place the timing chain cover on wooden blocks.

b. Place the oil pump on a wooden block.

c. Using a screwdriver and wooden block, pry out the oil seal.

HINT:

Tape the screwdriver tip before use.

Fig. 249: Prying Out Oil Seal
Courtesy of TOYOTA MOTOR SALES, U.S.A., INC.

22. SET NO. 1 CYLINDER TO TDC/COMPRESSION

NOTE:

Be careful not to damage the cylinder head cover.

NOTE:

Do not damage the surface of the oil seal press fit hole.



2009 Toyota Tundra

2009 ENGINE Engine Mechanical (3UR-FBE) - Tundra































a. Temporarily install the pulley set bolt.

b. Rotate the crankshaft clockwise so that the timing marks on the crankshaft timing gear and

camshaft timing gears are as shown in the illustration.

HINT:

If the timing marks do not align, rotate the crankshaft clockwise again and align the timing marks.

Fig. 250: Identifying Timing Marks On Crankshaft Timing Gear And Camshaft Timing Gear
Courtesy of TOYOTA MOTOR SALES, U.S.A., INC.

23. REMOVE NO. 1 CHAIN TENSIONER ASSEMBLY LH

a. Move the stopper plate upward to release the lock, and push the plunger deep into the tensioner.

Fig. 251: Identifying Stopper Plate
Courtesy of TOYOTA MOTOR SALES, U.S.A., INC.

b. Move the stopper plate downward to set the lock, and insert a hexagon wrench into the stopper

plate hole.



2009 Toyota Tundra

2009 ENGINE Engine Mechanical (3UR-FBE) - Tundra































Fig. 252: Identifying Stopper Plate And Plunger
Courtesy of TOYOTA MOTOR SALES, U.S.A., INC.

c. Remove the 2 bolts, chain tensioner and gasket.

Fig. 253: Locating Chain Tensioner Bolts
Courtesy of TOYOTA MOTOR SALES, U.S.A., INC.

24. REMOVE NO. 1 CHAIN TENSIONER SLIPPER LH



2009 Toyota Tundra

2009 ENGINE Engine Mechanical (3UR-FBE) - Tundra































Fig. 254: Identifying No. 1 Chain Tensioner Slipper LH
Courtesy of TOYOTA MOTOR SALES, U.S.A., INC.

25. REMOVE NO. 1 CHAIN VIBRATION DAMPER LH

a. Remove the 2 bolts and chain vibration damper.

Fig. 255: Locating No. 1 Chain Vibration Damper LH Bolts
Courtesy of TOYOTA MOTOR SALES, U.S.A., INC.

26. REMOVE NO. 1 CHAIN SUB-ASSEMBLY LH

a. While pushing down the No. 3 chain tensioner, insert a pin of Ø 1.0 mm (0.0394 in.) into the hole

to fix it in place.



2009 Toyota Tundra

2009 ENGINE Engine Mechanical (3UR-FBE) - Tundra
