26. REMOVE PROPELLER SHAFT ASSEMBLY

a. Remove the propeller shaft (See REMOVAL ).

27. REMOVE FRONT PROPELLER SHAFT ASSEMBLY

a. Remove the front propeller shaft (See REMOVAL ).

28. REMOVE FRONT FENDER APRON SEAL RH (See REMOVAL )

29. REMOVE FRONT FENDER APRON SEAL REAR RH (See REMOVAL )

30. REMOVE ENGINE OIL LEVEL DIPSTICK GUIDE (See REMOVAL )

31. REMOVE NO. 1 EXHAUST MANIFOLD HEAT INSULATOR (See REMOVAL )

32. REMOVE EXHAUST MANIFOLD SUB-ASSEMBLY RH (See REMOVAL )

33. REMOVE STARTER COVER (See REMOVAL )

34. REMOVE STARTER ASSEMBLY (See REMOVAL )

35. REMOVE AUTOMATIC TRANSMISSION ASSEMBLY

a. Remove the automatic transmission (See REMOVAL ).

36. REMOVE DRIVE PLATE AND RING GEAR SUB-ASSEMBLY

a. Using SST, hold the crankshaft.

SST 09213-70011, 09330-00021

Fig. 193: Removing Drive Plate And Ring Gear
Courtesy of TOYOTA MOTOR SALES, U.S.A., INC.

b. Remove the 10 bolts, rear drive plate spacer, drive plate and crankshaft position sensor rotor.



2009 Toyota Tundra

2009 ENGINE Engine Mechanical (3UR-FBE) - Tundra































Fig. 194: Locating Rear Drive Plate Bolts
Courtesy of TOYOTA MOTOR SALES, U.S.A., INC.

37. REMOVE NO. 1 WATER BY-PASS PIPE

a. Remove the 2 bolts and disconnect the hose. Then remove the water by-pass pipe.

Fig. 195: Locating No. 1 Water By-Pass Pipe Bolts
Courtesy of TOYOTA MOTOR SALES, U.S.A., INC.

38. REMOVE ENGINE ASSEMBLY

a. Install the 2 engine hangers with the 2 bolts as shown in the illustration.



2009 Toyota Tundra

2009 ENGINE Engine Mechanical (3UR-FBE) - Tundra































Engine hanger

ENGINE HANGER PART NUMBER REFERENCE CHART

Fig. 196: Locating Engine Hangers Bolts
Courtesy of TOYOTA MOTOR SALES, U.S.A., INC.

Torque: 43 N*m (438 kgf*cm, 32 ft.*lbf)

b. Attach an engine sling device and hang the engine with a chain block.

c. Remove the 4 engine mounting insulator bolts.

Fig. 197: Locating Engine Mounting Insulator Bolts
Courtesy of TOYOTA MOTOR SALES, U.S.A., INC.

Item

Part No.

Engine hanger 12281-38060,12281-38070

Bolt

90119-A0166



2009 Toyota Tundra

2009 ENGINE Engine Mechanical (3UR-FBE) - Tundra































d. Lift the engine out from the vehicle slowly and carefully.

39. REMOVE NO. 2 EXHAUST MANIFOLD HEAT INSULATOR (See REMOVAL )

40. REMOVE EXHAUST MANIFOLD SUB-ASSEMBLY LH (See REMOVAL )

41. INSTALL ENGINE ON ENGINE STAND

a. Install the engine onto an engine stand with the bolts.

b. Remove the 2 bolts and 2 engine hangers.

Fig. 198: Locating Engine Hangers With Bolts
Courtesy of TOYOTA MOTOR SALES, U.S.A., INC.

INSTALLATION

1. REMOVE ENGINE STAND

a. Install the 2 engine hangers with the 2 bolts as shown in the illustration.

Engine hanger

ENGINE HANGER PART NUMBER REFERENCE CHART

Torque: 43 N*m (438 kgf*cm, 32 ft.*lbf)

b. Attach an engine sling device and hang the engine with a chain block.

c. Remove the bolts and engine assembly from the engine stand.

NOTE:

Make sure the engine is clear of all wiring, hoses and cables.

Item

Part No.

Engine hanger 12281-38060, 12281-38070

Bolt

90119-A0166



2009 Toyota Tundra

2009 ENGINE Engine Mechanical (3UR-FBE) - Tundra
