Standard bush length: 41.3 to 41.7 mm (1.63 to 1.64 in.) g. Using SST and a hammer, tap in a new guide bush to the standard protrusion height. SST 09201 -10000 (09201 -01050), 09950-70010 (09951-07100) Standard protrusion height: 14.3 to 14.7 mm (0.563 to 0.579 in.) Fig. 58: Tapping In Guide Bush h. Using a sharp 5.5 mm reamer, ream the guide bush to obtain the standard oil clearance between the guide bush and valve stem. Standard oil clearance: 0.025 to 0.060 mm (0.000984 to 0.00236 in.) Fig. 59: Reaming Guide Bush 2. REPLACE EXHAUST VALVE GUIDE BUSH
2009 Toyota Tundra 2009 ENGINE Engine Mechanical (3UR-FBE) - Tundra
|
