RECOMMENDED TOOLS

A750F AUTOMATIC TRANSMISSION - RECOMMENDED TOOLS

(09351-32020) Stator Stopper

09351-40010

Tool Set, TOYOTA Automatic Transmission

09387-00070

First & Reverse Brake Wrench

09843-18040

Diagnosis Check Wire No. 2

09992-00095

Automatic Transmission Oil Pressure Gauge Set

(09992-00231) Adaptor C

(09992-00271) Gauge Assembly

09031-00030

Pin Punch

2009 Toyota Tundra

2009 GENERAL INFORMATION Preparation - Tundra

EQUIPMENT

A750F AUTOMATIC TRANSMISSION - EQUIPMENT

LUBRICANT

A750F AUTOMATIC TRANSMISSION - LUBRICANT

SSM

A750F AUTOMATIC TRANSMISSION - SSM

AB60E AUTOMATIC TRANSMISSION

SST

09082-00040

TOYOTA Electrical Tester

Angle gauge

Calipers

Cylinder gauge

Dial indicator

Feeler gauge

Micrometer

OBD II scan tool

Straight edge

Torque wrench

V block

Vernier calipers

Automatic transmission fluid: Dry fill

10.4 liters (11.0 US qts, 9.2 lmp.

qts)

Toyota Genuine ATF
WS

Automatic transmission fluid: Drain and
refill

3.0 liters (3.2 US qts, 2.6 lmp. qts)

Toyota Genuine Seal Packing 1281, Three Bond 1281 or equivalent

Toyota Genuine Adhesive 1344, Three Bond 1344 or equivalent

2009 Toyota Tundra

2009 GENERAL INFORMATION Preparation - Tundra

AB60E AUTOMATIC TRANSMISSION - SST

09308-00010 Oil Seal Puller

09308-60010 Oil Seal Replacer

09350-30020 TOYOTA Automatic Transmission Tool Set

(09350-07040) No. 2 Piston Spring Compressor

(09350-07060) No. 1 Snap Ring Expander

(09350-07070) No. 2 Snap Ring Expander

(09350-07110) Oil Seal Replacer

2009 Toyota Tundra

2009 GENERAL INFORMATION Preparation - Tundra

09380-60010 Automatic Transmission Set Brake Spring Compressor

(09381-05040) Nut

(09381-05050) Washer

(09381-06010) Hanger A

(09381-06020) Hanger B

(09381-06030) Hanger C

(09381-06040) Arm A

(09381-06050) Arm B

2009 Toyota Tundra

2009 GENERAL INFORMATION Preparation - Tundra
