Toyota Hilux (2017 year). Manual - part 139

563

8-2. Steps to take in an emergency

8

W

hen
 trou

bl

e ari

se

s

NOTICE

■

To prevent damage to the vehicle when towing using a wheel-lift type
truck

●

Do not tow the vehicle from the rear when the engine switch is in the
“LOCK” position or the key is removed (vehicles without smart entry & start
system) or the engine switch is turned to off (vehicles with smart entry &
start system). The steering lock mechanism is not strong enough to hold
the front wheels straight.

●

When raising the vehicle, ensure adequate ground clearance for towing at
the opposite end of the raised vehicle. Without adequate clearance, the
vehicle could be damaged while being towed.

■

To prevent damage to the vehicle when towing with a sling-type truck
Do not tow with a sling-type truck, either from the front or rear.

■

To prevent damage to the vehicle during emergency towing
Do not secure cables or chains to the suspension components.

■

When towing a vehicle equipped with the Stop & Start system (if
equipped)
When it is necessary to tow the vehicle with all four wheels contacting the
ground, perform the following procedure before towing the vehicle to protect
the system.
Turn the engine switch to the “LOCK” position (vehicles without smart entry
& start system) or off (vehicles with smart entry & start system) once, and
then start the engine. If the engine does not start, turn the engine switch to
the “ON” position (vehicles without smart entry & start system) or IGNITION
ON mode (vehicles with smart entry & start system).

564

8-2. Steps to take in an emergency

If you think something is wrong

● Fluid leaks under the vehicle.

(Water dripping from the air conditioning after use is normal.)

● Flat-looking tires or uneven tire wear
● Engine coolant temperature gauge needle continually points higher

than normal.

● Changes in exhaust sound
● Excessive tire squeal when cornering
● Strange noises related to the suspension system
● Pinging or other noises related to the engine

● Engine missing, stumbling or running roughly
● Appreciable loss of power
● Vehicle pulls heavily to one side when braking
● Vehicle pulls heavily to one side when driving on a level road
● Loss of brake effectiveness, spongy feeling, pedal almost touches

the floor

If you notice any of the following symptoms, your vehicle proba-
bly needs adjustment or repair. Contact any authorized Toyota
dealer or repairer, or another duly qualified and equipped pro-
fessional as soon as possible.

Visible symptoms

Audible symptoms

Operational symptoms

565

8-2. Steps to take in an emergency

8

W

hen
 trou

bl

e ari

se

s

Fuel pump shut off system (gasoline engine only)

Follow the procedure below to restart the engine after the system is
activated.

Turn the engine switch to the “ACC” or “LOCK” position (vehicles
without smart entry & start system) or ACCESSORY mode or off
(vehicles with smart entry & start system).
Restart the engine.

To minimize the risk of fuel leakage when the engine stalls or
when an airbag inflates upon collision, the fuel pump shut off
system stops the supply of fuel to the engine.

NOTICE

■

Before starting the engine
Inspect the ground under the vehicle.
If you find that fuel has leaked onto the ground, the fuel system has been
damaged and is in need of repair. Do not restart the engine.

1

2

566

8-2. Steps to take in an emergency

Fire extinguisher

∗

Unhook the tightening strap and
take out the fire extinguisher.

The shape of the fire extinguisher and tightening strap, and the taking out
procedure may differ from those shown in the illustration.

■

After using the fire extinguisher
Store it securely in place. Replace it with a new one as soon as possible.

∗

: If equipped

A fire extinguisher is located under the front passenger’s seat. It
is for use in emergencies, such as in the event of a fire.
For information about using, refer to the label on the fire extin-
guisher.

Taking out the fire extinguisher

WARNING

■

When the fire extinguisher is not in use
Keep the fire extinguisher securely in place. Otherwise, it may be thrown
about in the event of sudden braking or a collision.

NOTICE

■

Fire extinguisher

●

Do not reuse the fire extinguisher.
Replace it with a new one as soon as possible after using it.

●

Use a genuine Toyota fire extinguisher when replacing.
If a non-genuine Toyota fire extinguisher is used, it may not be possible to
secure the fire extinguisher properly and it may come loose.
