Toyota Hilux (2017 year). Manual - part 119

483

6-4. Using the other interior features

6

In

teri
or f
eatu

res

ERA-GLONASS

∗

Microphone
“SOS” button
Indicator lights

■

Automatic Collision Notification
If any airbag deploys, the system is designed to automatically call
the Public Safety Answering Point (PSAP). The responding agent
receives the vehicle’s location and attempts to speak with the vehi-
cle occupants to assess the level of emergency. If the occupants
are unable to communicate, the agent automatically treats the call
as an emergency, contacts the nearest emergency services pro-
vider to describe the situation, and requests that assistance be sent
to the location.

∗

: If equipped

ERA-GLONASS is a telematics service that uses Global Naviga-
tion Satellite System (GLONASS) data and embedded cellular
technology to enable the following emergency calls to be made:
Automatic emergency calls (Automatic Collision Notification)
and manual emergency calls (by pressing the “SOS” button).
This service is required by Eurasian Customs Union Regula-
tions.

System components

1
2
3

Emergency Notification Services

484

6-4. Using the other interior features

■

Emergency Assistance Button (“SOS”)
In the event of an emergency, push the “SOS” button to reach the
Public Safety Answering Point (PSAP). The answering agent will
determine your vehicle’s location, assess the emergency, and dis-
patch the necessary assistance required.

If you accidentally press the “SOS” button, tell the agent that you are not
experiencing an emergency.

When the engine switch is turned to the “ON” position (vehicles with-
out smart entry & start system) or IGNITION ON mode (vehicles with
smart entry & start system), the red indicator light will illuminate for 10
seconds and then the green indicator light will illuminate for 2 sec-
onds, indicating that the system is enabled. The indicator lights indi-
cate the following:
● If the green indicator light illuminates and stays on, the system is

enabled.

● If the green indicator light flashes, an emergency call is being made

(either automatically or manually).

● If no indicator lights illuminate, the system is not enabled.
● If the red indicator light illuminates any time other than immediately

after the engine switch is turned to the “ON” position (vehicles with-
out smart entry & start system) or IGNITION ON mode (vehicles
with smart entry & start system), the system may be malfunctioning
or the backup battery may be depleted. Contact any authorized
Toyota dealer or repairer, or another duly qualified and equipped
professional.

The service life of the backup battery is 3 years or more.

Indicator lights

485

7

Maintenance and care

7-1. Maintenance and care

Cleaning and protecting

the vehicle exterior ..........486

Cleaning and protecting

the vehicle interior ...........489

7-2. Maintenance

Maintenance

requirements....................492

7-3. Do-it-yourself maintenance

Do-it-yourself service

precautions ......................495

Hood ..................................497
Engine compartment..........499
Tires...................................518
Tire inflation pressure ........526
Wheels...............................528
Air conditioning filter ..........530
Wireless remote control/

electronic key battery.......532

Checking and

replacing fuses ................535

Light bulbs .........................540

486

7-1. Maintenance and care

Cleaning and protecting the vehicle

exterior

● Working from top to bottom, liberally apply water to the vehicle

body, wheel wells and underside of the vehicle to remove any dirt
and dust.

● Wash the vehicle body using a sponge or soft cloth, such as a

chamois.

● For hard-to-remove marks, use car wash soap and rinse thoroughly

with water.

● Wipe away any water.
● Wax the vehicle when the waterproof coating deteriorates.

If water does not bead on a clean surface, apply wax when the vehicle
body is cool.

■

Automatic car washes

●

Fold the mirrors and remove the antenna before washing the vehicle. Start
washing from the front of the vehicle. Make sure to re-install the antenna
and extend the mirrors before driving.

●

Brushes used in automatic car washes may scratch the vehicle surface and
harm your vehicle’s paint.

■

High pressure car washes

●

Do not allow the nozzles of the car wash to come within close proximity of
the windows.

●

Vehicles with fuel filler door: Before using the car wash, check that the fuel
filler door on your vehicle is closed properly.

Perform the following to protect the vehicle and maintain it in
prime condition:
