419

5

5-6. Using Bluetooth

®

 devices

Au
dio
 sy
stem

Registering a Bluetooth

®

 device

Press the “SETUP ENTER” button.
Select “Bluetooth

*

” using the “TUNE >” or “< SELECT” button, and

press the “SETUP ENTER” button.
Select “Pairing” using the “TUNE >” or “< SELECT” button, and
press the “SETUP ENTER” button.

A passkey will be displayed.

SSP (Secure Simple Pairing) incompatible Bluetooth

®

 devices:

Input the passkey into the device.
SSP (Secure Simple Pairing) compatible Bluetooth

®

 devices:

Select “YES” to register the device. Depending on the type of
device, it may register automatically.

If a Bluetooth

®

 device has both music player and cellular phone func-

tions, both functions will be registered at the same time. When delet-
ing the device, both functions will be deleted at the same time.
If the off-hook switch is pressed and the “TEL” or “PHONE” mode is
entered when no phones have been registered, the registration
screen will be automatically displayed.

*

: The Bluetooth

®

 word mark and logos are registered trademarks owned by

Bluetooth SIG, Inc.

Before using the Bluetooth

®

 audio/phone, it is necessary to reg-

ister a Bluetooth

®

 device in the system. Follow the procedure

below to register (pair) a device:

How to register a Bluetooth

®

 device

1

2

3

4

420

5-7. “SETUP” menu

Using the “SETUP” menu (“Bluetooth*”

menu)

Press the “SETUP ENTER” button.
Select “Bluetooth

*

” using the “TUNE >” or “< SELECT” button, and

press the “SETUP ENTER” button.
Select one of the following functions using the “TUNE >” or
“< SELECT” button.

● Registering a Bluetooth

®

 device

“Pairing”

● Listing the registered cellular phones

“List phone”

● Listing the registered portable players

“List audio”

● Changing the passkey

“Passkey”

● Setting automatic connection of the device on or off

“BT power”

● Displaying the device status

“Bluetooth

*

 info”

● Setting the automatic connection confirmation display to on or off

“Display setting”

● Initialization

“Initialize”

*

: The Bluetooth

®

 word mark and logos are registered trademarks owned by

Bluetooth SIG, Inc.

Registering a Bluetooth

®

 device in the system allows the system

to function. The following functions can be used for registered
devices:

Functions and operation procedures

1

2

3

421

5-7. “SETUP” menu

5

Au
dio
 sy
stem

Select “Pairing” using the “TUNE >” or “< SELECT” button, and press
the “SETUP ENTER” button, and press

 (Add New).

● If a Bluetooth

®

 device is not connected currently

Perform the procedure for registering a Bluetooth

®

 device from step

. (

→P. 419)

● If other Bluetooth

®

 device is connected currently

The Bluetooth

®

 device needs to be disconnected.

After disconnecting, perform the procedure for registering a
Bluetooth

®

 device from step

. (

→P. 419)

● If device list is full

Select the Bluetooth

®

 device to be deleted using the “TUNE >” or

“< SELECT” button, and press the “SETUP ENTER” button.
Press

(YES).

Registering a Bluetooth

®

 device

4

2

1

2

422

5-7. “SETUP” menu

Select “List phone” using the “TUNE >” or “< SELECT” button, and
press the “SETUP ENTER” button. The list of registered cellular
phones will be displayed.
● Connecting the registered cellular phone to the audio system

Select the name of the cellular phone to be connected using the
“TUNE >” or “< SELECT” button, and press the “SETUP ENTER”
button.
Select “Select” using the “TUNE >” or “< SELECT” button, and
press the “SETUP ENTER” button.

● Deleting a registered cellular phone

Select the name of the cellular phone to be deleted using the
“TUNE >” or “< SELECT” button, and press the “SETUP ENTER”
button.
Select “Delete” using the “TUNE >” or “< SELECT” button, and
press the “SETUP ENTER” button.
Press

(YES).

● Disconnecting the registered cellular phone from the audio system

Select the name of the cellular phone to be disconnected using
the “TUNE >” or “< SELECT” button, and press the “SETUP
ENTER” button.
Select “Disconnect” using the “TUNE >” or “< SELECT” button,
and press the “SETUP ENTER” button.
Press

(YES).

Listing the registered cellular phones

1

2

1

2

3

1

2

3
