Toyota Hilux (2017 year). Manual - part 86

351

4-5. Using the driving support systems

4

D

riv

in

g

●

When the engine automatically restarts while stopped by the Stop & Start
system

■

If “Stop & Start system malfunction Visit your dealer” is shown on the
multi-information display (if equipped)
The system may be malfunctioning. Have the vehicle inspected by any autho-
rized Toyota dealer or repairer, or another duly qualified and equipped profes-
sional.

■

If the Stop & Start cancel indicator continues to flash
The system may be malfunctioning. Have the vehicle inspected by any autho-
rized Toyota dealer or repairer, or another duly qualified and equipped profes-
sional.

Message

Details/Actions

“For climate
control”

Vehicles with automatic air conditioning sys-
tem:
• The air conditioning system is turned on or

the air conditioning is being used.

•

 is turned on.

“For brake
system”

The brake pedal is strongly depressed fur-
ther or pumped.

→ When a predetermined load is gener-

ated from the brake booster by driving
the vehicle, the system recovers.

“Battery charging”

The battery charge amount may be low.

→ The engine is restarted to prioritize

battery charging. Operating the engine
for a short while allows the system to
recover.

“Steering wheel
turned”

The steering wheel is turned.

“Driver seat belt
unbuckled”

The driver seat belt is not fastened.

352

4-5. Using the driving support systems

WARNING

■

When the Stop & Start system is operating

●

Keep the shift lever in N (manual transmission), depress the brake pedal
or apply the parking brake when necessary while the engine is stopped
due to the Stop & Start system (while the Stop & Start indicator is on).
Unexpected accidents may occur due to the automatic engine start func-
tion.

●

Do not allow anyone to leave the vehicle while the engine is stopped due
to the Stop & Start system (while the Stop & Start indicator is on).
Unexpected accidents may occur due to the automatic engine start func-
tion.

●

Ensure that the engine is not stopped by the Stop & Start system while the
vehicle is in a poorly ventilated area. The engine may restart due to the
automatic engine start function, causing exhaust gases to collect and
enter the vehicle and resulting in death or a serious health hazard.

■

Off-road driving precaution
When driving off-road, such as driving through water, press the Stop & Start
cancel switch to disable the Stop & Start system. Failure to do so may
cause the engine to be unable to restart.

NOTICE

■

To ensure the system operates correctly
If any one of the following situations occurs, the Stop & Start system may
not operate correctly. Have the vehicle inspected by any authorized Toyota
dealer or repairer, or another duly qualified and equipped professional.

●

While the driver’s seat belt is fastened, the driver’s and front passenger’s
seat belt reminder light flashes.

●

Even when the driver’s seat belt is not fastened, the driver’s and front pas-
senger’s seat belt reminder light remains off.

●

Even when the driver’s door is closed, the symbol indicating the driver’s
door is open is shown on the multi-information display, or the personal/
interior lights come on when the personal/interior light main switch or inte-
rior light switch (if equipped) is in the door position.

●

Even when the driver’s door is opened, the symbol indicating the driver’s
door is open is not shown on the multi-information display, or the personal/
interior lights do not come on when the personal/interior light main switch
or interior light switch (if equipped) is in the door position.

353

4

4-5. Using the driving support systems

D

riv

in

g

Driving assist systems

◆

ABS (Anti-lock Brake System)

Helps to prevent wheel lock when the brakes are applied suddenly, or if the
brakes are applied while driving on a slippery road surface

◆

Brake assist (if equipped)

Generates an increased level of braking force after the brake pedal is
depressed when the system detects a panic stop situation

◆

VSC (Vehicle Stability Control) (if equipped)

Helps the driver to control skidding when swerving suddenly or turning on
slippery road surfaces

◆

TRC (Traction Control) for Pre Runner and H2 position on 4WD
models (if equipped)

Helps to maintain drive power and prevent the drive wheels from spinning
when starting the vehicle or accelerating on slippery roads

◆

A-TRC (Active Traction Control) for H4 and L4 position on 4WD
models (if equipped)

Helps to maintain drive power and prevent the four wheels from spinning
when starting the vehicle or accelerating on slippery roads

◆

Hill-start assist control (if equipped)

Helps to prevent the vehicle from rolling backward when starting on an
incline or slippery slope

To help enhance driving safety and performance, the following
systems operate automatically in response to various driving
situations. Be aware, however, that these systems are supple-
mentary and should not be relied upon too heavily when operat-
ing the vehicle.

354

4-5. Using the driving support systems

◆

PCS (Pre-Crash Safety system) (if equipped)

→P. 287

◆

Emergency brake signal (if equipped)

When the brakes are applied suddenly, the emergency flashers automati-
cally flash to alert the vehicle behind.

◆

Trailer Sway Control (if equipped)

Helps the driver to control trailer sway by selectively applying brake pres-
sure for individual wheels and reducing engine torque when trailer sway is
detected.
Trailer Sway Control is part of the VSC system and will not operate if VSC
turned off or experiences a malfunction.

The slip indicator will flash while
the TRC/A-TRC/VSC/Trailer
Sway Control systems are operat-
ing.

When the TRC/A-TRC/VSC/Trailer Sway Control systems are
operating
