311

4-5. Using the driving support systems

4

D

riv

in

g

The following types of road signs, including electronic signs and blink-
ing signs, are recognized.

A non-official (not meeting the Vienna Convention) or a recently introduced
traffic sign may not be recognized.

Types of recognized road signs

Type

Multi-information display

Speed limit begins/ends

*

1

Highway entrance/exit

Speed limit with

supplemental

mark

(Displayed simul-

taneously with

speed limit)

(Display example)

Wet

Rain

Ice

On/off ramp

*

2

Supplemental

mark exists

(Contents not rec-

ognized)

No overtaking begins/ends

312

4-5. Using the driving support systems

*

1

: A speed limit sign with a value greater than 130 may not be recognized

and a wrong speed limit may be displayed.

*

2

: If the turn signal indicator is not operated when changing lanes, the mark

does not display.

In the following situations, the RSA system alerts the driver using a
warning display.
● When the vehicle speed exceeds the speed warning threshold

applied to the speed limit of the sign displayed on the multi-informa-
tion display, the sign color becomes inverted.

● If it is detected that your vehicle is overtaking when a no overtaking

sign is displayed on the multi-information display, the sign flashes.

Depending on the situation, traffic environment (traffic direction,
speed, unit) may be detected incorrectly and a warning display may
not operate properly.

■

Automatic turn-off of RSA sign display
One or more signs automatically turn off in the following situations.

●

A new sign is not recognized for a certain distance.

●

The road changes due to a left or right turn, etc.

■

Conditions in which the function may not operate or detect correctly
In the following situations, RSA does not operate normally and may not rec-
ognize signs, display the incorrect sign, etc. However, this does not indicate a
malfunction.

●

The camera sensor is misaligned due to a strong impact being applied to
the sensor, etc.

●

Dirt, snow, stickers, etc., are on the windshield near the camera sensor.

●

In inclement weather such as heavy rain, fog, snow or sand storms

●

Light from an oncoming vehicle, the sun, etc., enters the camera sensor.

●

The sign is dirty, faded, tilted or bent, and if an electronic sign, the contrast
is poor.

●

All or part of the sign is hidden by the leaves of a tree, a pole, etc.

All canceled

(All restrictions canceled. Returns to

default road regulation.)

Warning display

Type

Multi-information display

313

4-5. Using the driving support systems

4

D

riv

in

g

●

The sign is only visible to the camera sensor for a short amount of time.

●

The driving scene (turning, lane change, etc.) is judged incorrectly.

●

Even if it is a sign not appropriate for the currently traveled lane, such a sign
exists directly after a freeway branches, or in an adjacent lane just before
merging.

●

Stickers are attached to the rear of the preceding vehicle.

●

A sign resembling a system compatible sign is recognized.

●

The vehicle is driven in a country with a different direction of traffic.

●

Side road speed signs may be detected and displayed (if positioned in sight
of the camera sensor) while the vehicle is traveling on the main road.

●

Roundabout exit road speed signs may be detected and displayed (if posi-
tioned in sight of the camera sensor) while traveling on a roundabout.

●

The speed information displayed on the meter and that displayed on the
Navigation system (if equipped) may be different due to the Navigation sys-
tem or Multimedia system using map data.

■

When driving vehicle in country with different speed unit
Since RSA recognizes signs based on the set unit of the meter, it is neces-
sary to change the set unit of the meter. Adjust the set unit of the meter to the
speed unit of signs in the current location. (

→P. 649)

■

Turning the system on/off

Use the meter control switches to select

 while the vehicle is stopped and

press

, and select

 and press

.

■

Speed limit sign display
If the engine switch was last turned to the “LOCK” position (vehicles without
smart entry & start system) or off (vehicles with smart entry & start system)
while a speed limit sign was displayed on the multi-information display, the
same sign displays again when the engine switch is turned to the “ON” posi-
tion (vehicles without smart entry & start system) or IGNITION ON mode
(vehicles with smart entry & start system).

■

Customization
Setting (e.g. speeding warning threshold) can be changed.
(Customizable feature:

→P. 648)

314

4-5. Using the driving support systems

Cruise control

∗

Use the cruise control to maintain a set speed without depressing the
accelerator pedal.

Indicators
Cruise control switch

Press the “ON-OFF” button to
activate the cruise control.

Cruise control indicator will come
on.
Press the button again to deacti-
vate the cruise control.

Accelerate or decelerate the
vehicle to the desired speed,
and push the lever down to set
the speed.

“SET” indicator will come on.
The vehicle speed at the moment
the lever is released becomes the
set speed.

∗

: If equipped

Summary of functions

1
2

Setting the vehicle speed

1

2
