127

2. Instrument cluster

2

In

st

rum

ent cl

ust
e

r

Eco Driving Indicator Light can be activated or deactivated.
Vehicles without multi-information display:

Press and hold the odometer/trip meter display change button for more than
2 seconds to complete the setting.
Vehicles with multi-information display:

 →P. 649

While the odometer is being displayed,
press and hold the odometer/trip meter
display change button to display the Eco
Driving Indicator Light customization
screen.
Press the odometer/trip meter display
change button to set Eco Driving Indicator
Light to on or off.

WARNING

■

If a safety system warning light does not come on
Should a safety system light such as ABS and the SRS warning light not
come on when you start the engine, this could mean that these systems are
not available to help protect you in an accident, which could result in death
or serious injury. Have the vehicle inspected by any authorized Toyota
dealer or repairer, or another duly qualified and equipped professional
immediately if this occurs.

128

2. Instrument cluster

Gauges and meters

X

Vehicles without multi-information display

X

Vehicles with multi-information display type A

129

2. Instrument cluster

2

In

st

rum

ent cl

ust
e

r

X

Vehicles with multi-information display type B

The units used on the speedometer may differ depending on the target
region, and the positions of the outside temperature and shift position indi-
cators differ depending on vehicles.

Tachometer

Displays the engine speed in revolutions per minute.

Outside temperature

Displays the outside temperature. The temperature range that can be dis-
played is from -40

°C (-40°F) to 50°C (122°F). The low outside temperature

indicator comes on when the ambient temperature is approximately 3

°C

(37

°F) or lower, and goes off when approximately 5°C (41°F) or higher.

(

→P. 125)

Speedometer

Displays the vehicle speed.

Fuel gauge

Displays the quantity of fuel remaining in the tank.

Odometer/trip meter display change button

→P. 130

1

2

3

4

5

130

2. Instrument cluster

Odometer and trip meter

Odometer:
Displays the total distance the vehicle has been driven.
Trip meter:
Displays the distance the vehicle has been driven since the meter was last
reset. Trip meters A and B can be used to record and display different dis-
tances independently.

Multi-information display

Presents the driver with a variety of driving-related data. (

→P. 133, 136)

Shift position and shift range (automatic transmission)

Displays the selected shift position or selected shift range. (

→P. 247)

Engine coolant temperature gauge

Displays the engine coolant temperature.

X

Vehicles without multi-information display

Pressing this button switches between odometer and trip meter dis-
plays.

Odometer
Trip meter A

*

Trip meter B

*

*

: Pressing and holding the button

will reset the trip meter.

Changing the display

6

7

8

9

1
2
3
