83

1-2. Child safety

1

Fo
r s

afe
ty a
nd

 se
cu

rity

X

Single-cab models

Key of letters inserted in the above table:
X: Not suitable seat position for children in this mass group.
U: Suitable for “universal” category child restraint systems approved

for use in this mass group.

UF: Suitable for forward-facing “universal” category child restraint sys-

tems approved for use in this mass group.

*

1

: Adjust the seatback angle to the most upright position. Move the front

seat fully rearward. If the passenger seat height can be adjusted, move it
to the upper most position.

*

2

: If the head restraint interferes with your child restraint system, and the

head restraint can be removed, remove the head restraint. Otherwise, put
the head restraint in the upper most position.

Mass groups

Seating position

Front passenger seat

0
Up to 10 kg
(22 lb.)

X

0+
Up to 13 kg
(28 lb.)

X

I
9 to 18 kg
(20 to 39 lb.)

Rearward-facing



X

Forward-facing



UF

*

1, 2

II, III
15 to 36 kg
(34 to 79 lb.)

UF

*

1, 2

84

1-2. Child safety

X

Smart-cab models

Key of letters inserted in the above table:
X: Not suitable seat position for children in this mass group.
U: Suitable for “universal” category child restraint systems approved

for use in this mass group.

UF: Suitable for forward-facing “universal” category child restraint sys-

tems approved for use in this mass group.

*

1

: Adjust the seatback angle to the most upright position. Move the front

seat fully rearward. If the passenger seat height can be adjusted, move it
to the upper most position.

*

2

: If the head restraint interferes with your child restraint system, and the

head restraint can be removed, remove the head restraint. Otherwise, put
the head restraint in the upper most position.

Mass groups

Seating position

Front passenger seat

Rear seat

0
Up to 10 kg
(22 lb.)

X

X

0+
Up to 13 kg
(28 lb.)

X

X

I
9 to 18 kg
(20 to 39 lb.)

Rearward-facing



X

X

Forward-facing



UF

*

1, 2

II, III
15 to 36 kg
(34 to 79 lb.)

UF

*

1, 2

X

85

1-2. Child safety

1

Fo
r s

afe
ty a
nd

 se
cu

rity

X

Double-cab models

Key of letters inserted in the above table:
X: Not suitable seat position for children in this mass group.
U: Suitable for “universal” category child restraint systems approved

for use in this mass group.

UF: Suitable for forward-facing “universal” category child restraint sys-

tems approved for use in this mass group.

*

1

: Adjust the seatback angle to the most upright position. Move the front

seat fully rearward. If the passenger seat height can be adjusted, move it
to the upper most position.

*

2

: If the head restraint interferes with your child restraint system, and the

head restraint can be removed, remove the head restraint. Otherwise, put
the head restraint in the upper most position.

Mass groups

Seating position

Front

passenger seat

Rear seat

Outboard

Center

0
Up to 10 kg
(22 lb.)

X

U

X

0+
Up to 13 kg
(28 lb.)

X

U

X

I
9 to 18 kg
(20 to 39 lb.)

Rearward-

facing



X

U

*

2

X

Forward-
facing



UF

*

1, 2

II, III
15 to 36 kg
(34 to 79 lb.)

UF

*

1, 2

U

*

2

X

86

1-2. Child safety

Double-cab models: When securing some types of child restraint sys-
tems in rear seat, it may not be possible to properly use the seat belts
in positions next to the child restraint without interfering with it or
affecting seat belt effectiveness. Be sure your seat belt fits snugly
across your shoulder and low on your hips. If it does not, or if it inter-
feres with the child restraint, move to a different position. Failure to do
so may result in death or serious injury.

◆

Installing child restraint system using a seat belt

Install the child restraint system in accordance to the operation
manual enclosed with the child restraint system.

Front seat:
Adjust the seatback angle to the most upright position. Move the
front seat fully rearward. (

→P. 186)

If the head restraint interferes with your child restraint system,
and the head restraint can be removed, remove the head
restraint. Otherwise, put the head restraint in the upper most
position. (

→P. 191)

Rear seat:
If the head restraint interferes with your child restraint system,
and the head restraint can be removed, remove the head
restraint. Otherwise, put the head restraint in the upper most
position. (

→P. 191)

Run the seat belt through the
child restraint system and
insert the plate into the
buckle. Make sure that the
belt is not twisted. Securely
fix the seat belt to the child
restraint system in accor-
dance to the directions
enclosed with the child
restraint system.

1

2
