Toyota Hilux (2017 year). Manual - part 7

35

1

For safety and security

1-1. For safe use

Before driving.......................36
For safety drive ....................38
Seat belts.............................40
SRS airbags.........................45
Exhaust gas precautions .....56

1-2. Child safety

Front passenger occupant

classification system..........57

Airbag manual on-off

system ...............................62

Riding with children..............64
Child restraint systems ........65

1-3. Theft deterrent system

Engine immobilizer

system .............................107

Alarm .................................116

36

1-1. For safe use

Before driving

Use only floor mats designed specifically for vehicles of the same
model and model year as your vehicle. Fix them securely in place
onto the carpet.

Insert the retaining hooks (clips)
into the floor mat eyelets.

Turn the upper knob of each
retaining hook (clip) to secure
the floor mats in place.

*

: Always align the

 marks.

The shape of the retaining hooks (clips) may differ from that shown in the
illustration.

Floor mat

1

*

2

37

1-1. For safe use

1

Fo
r s

afe
ty a
nd

 se
cu

rity

WARNING

Observe the following precautions.
Failure to do so may cause the driver’s floor mat to slip, possibly interfering
with the pedals while driving. An unexpectedly high speed may result or it may
become difficult to stop the vehicle. This could lead to an accident, resulting in
death or serious injury.

■

When installing the driver’s floor mat

●

Do not use floor mats designed for other models or different model year
vehicles, even if they are Toyota Genuine floor mats.

●

Only use floor mats designed for the driver’s seat.

●

Always install the floor mat securely using the retaining hooks (clips) pro-
vided.

●

Do not use two or more floor mats on top of each other.

●

Do not place the floor mat bottom-side up or upside-down.

■

Before driving

●

Check that the floor mat is securely
fixed in the correct place with all the
provided retaining hooks (clips). Be
especially careful to perform this check
after cleaning the floor.

●

With the engine stopped and the shift
lever in P (automatic transmission) or N
(manual transmission), fully depress
each pedal to the floor to make sure it
does not interfere with the floor mat.

38

1-1. For safe use

For safety drive

Adjust the angle of the seat-
back so that you are sitting
straight up and so that you do
not have to lean forward to
steer. (

→P. 186)

Adjust the seat so that you can
depress the pedals fully and so
that your arms bend slightly at
the elbow when gripping the
steering wheel. (

→P. 186)

Vehicles with adjustable type head restraint: Lock the head restraint
in place with the center of the head restraint closest to the top of
your ears. (

→P. 191)

Wear the seat belt correctly. (

→P. 40)

Make sure that all occupants are wearing their seat belts before driv-
ing the vehicle. (

→P. 40)

Use a child restraint system appropriate for the child until the child
becomes large enough to properly wear the vehicle’s seat belt.
(

→P. 65)

For safe driving, adjust the seat and mirror to an appropriate
position before driving.

Correct driving posture

1

2

Correct use of the seat belts

3

4
